Latitude Rugged DisplayPort

Desk Dock

User’s Guide

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data

and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury,

or death.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly

forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc. Other

trademarks and trade names may be used in this document to refer to either the entities

claiming the marks and names of their products. Dell Inc. disclaims any proprietary interest

in trademarks and trade names other than its own.

2016 - 03 Rev. A02

Regulatory model K13A

Regulatory type K13A002

Contents

1. About Your Latitude Rugged DisplayPort Desk Dock...........................................................5

2. Adjusting the Latitude Rugged DisplayPort Desk Dock........................................................7

Adjusting your Latitude Rugged DisplayPort Desk Dock for your laptop....................... 7

3. Using the Latitude Rugged DisplayPort Desk Dock ..............................................................9

Setting up your Latitude Rugged DisplayPort Desk Dock ................................................. 9

Docking Your Laptop ............................................................................................................... 10

Securing the Latitude Rugged DisplayPort Desk Dock..................................................... 12

Latitude Rugged DisplayPort Desk Dock Laptop Power and Docking Status ............. 13

Using the Latitude Rugged DisplayPort Desk Dock With Three Monitors.................... 14

Undocking Your Laptop........................................................................................................... 15

4. Speciﬁcations..............................................................................................................................16

5. Finding Information...................................................................................................................17

6. Glossary........................................................................................................................................18

About your Latitude Rugged

DisplayPort Desk Dock

The Latitude Rugged DisplayPort Desk Dock docking device supports the Dell Rugged Family

of laptop computers, but is not compatible with any previous series laptop computers.

The Latitude Rugged DisplayPort Desk Dock enables you to connect your laptop computer to

the following external devices:

Connector Description

RJ-45 NETWORK CONNECTOR - Connects a network

interface cable.

AUDIO CONNECTORS (2) - Connects audio headset or

speakers and a microphone.

USB 2.0 CONNECTOR - Connect a USB 2.0 compliant

device, such as a USB mouse. The USB 2.0 connector is

located on the right side of the Rugged Desk Dock.

USB 3.0 CONNECTORS (3)

(2 USB 3.0 connectors, 1 USB 3.0 with PowerShare) -

Connect up to three USB 3.0 compliant devices. All three

USB 3.0 connectors are located on the back side of the

Rugged Desk Dock.

AC ADAPTER CONNECTOR - Connects the AC adapter.

VGA CONNECTOR - Connects an external monitor.

SERIAL CONNECTOR - Connects serial devices,

such as a mouse or handheld device.

DISPLAYPORT CONNECTORS (2) - Connects an external

monitor.

1. Eject button

2. Power button

3. Audio connector

4. Microphone connector

5. USB 2.0 connector

6. Position setting indicator

7. Front hook

8. Front hook

9. Front hook tray

10. Position setting indicator

11. Docking connector

12. Serial connector

13. VGA connector

14. DisplayPort connectors (2)

15. Security cable slot

16. USB 3.0 connector with PowerShare

17. USB 3.0 connectors (2)

18. Network connector

19. Security cable slot

20. AC adapter connector

Adjusting the Latitude Rugged

DisplayPort Desk Dock

CAUTION: If the Latitude Rugged DisplayPort Desk Dock is not adjusted to the correct

position for your speciﬁc laptop, damage to laptop or Latitude Rugged DisplayPort

Desk Dock may occur.

Adjusting your Latitude Rugged DisplayPort Desk Dock for

your laptop

1 Determine the correct adjustment letter (A, B, C, D, E) for your speciﬁc laptop:

A: Latitude 12 Rugged Extreme

B: Future Model

C: Latitude 14 Rugged

D: Future Model

E: Latitude 14 Rugged Extreme

2 Hold Latitude Rugged DisplayPort Desk Dock against desktop and slide front hook tray

out by pulling from center opening until the correct letter designation is visible in both

position setting indicator windows.

NOTE: You must exert enough force to overcome the resistance between

position settings. If you adjust past your desired position setting, simply slide the

Front Hook Tray in the opposite direction.

Using the Latitude Rugged

DisplayPort Desk Dock

WARNING: Before you begin any of the procedures in this section, follow the safety

instructions that shipped with your computer.

Setting up your Latitude Rugged DisplayPort Desk Dock

NOTE: If the cable connector of the external device has thumbscrews, tighten

the screws to ensure a proper connection.

1 Connect the peripheral device’s cable to the appropriate connector on the Latitude

Rugged DisplayPort Desk Dock.

2 Connect any external devices, like external displays, to electrical outlets.

If you attach an external monitor to the Latitude Rugged DisplayPort Desk Dock, you may need

to press <Fn><F8> one or more times to switch the screen image to the desired location. If the

laptop cover is closed, press <Scroll Lck><F8> on an attached external keyboard to switch the

image.

Before you dock for the ﬁrst time

Before connecting your laptop to the Latitude Rugged DisplayPort Desk Dock, please ensure

the following:

1 Ensure that the Rugged Desk Dock has been adjusted for your speciﬁc laptop (see

“Adjusting the Latitude Rugged DisplayPort Desk Dock” on page 7).

2 Ensure that the laptop is not connected to the Latitude Rugged DisplayPort Desk Dock

(docked).

3 Turn on the laptop.

4 Verify that your laptop operating system has completed the setup process.

5 Verify that your laptop battery is installed before docking your laptop.

Docking your laptop

CAUTION: Always use the Dell AC adapter that came with the Latitude Rugged

DisplayPort Desk Dock. If you use any other commercially available AC adapter, you

may damage the Latitude Rugged DisplayPort Desk Dock or the laptop.

1 Follow the instructions in “Before you dock for the ﬁrst time” on page 9.

2 Place the Latitude Rugged DisplayPort Desk Dock with enough ﬂat space in front of it to

completely support the laptop when docked to the Latitude Rugged DisplayPort Desk

Dock.

1. AC adapter cable 2. AC adapter connector
