QuickScan™ Mobile

General Purpose Handheld

Linear Imager Bar Code Reader with

Datalogic’s STAR Cordless System™

Quick Reference Guide

Datalogic ADC, Inc.

959 Terry Street

Eugene, OR 97402

USA

Telephone: (541) 683-5700

Fax: (541) 345-7140

mentation or the procedures described therein may be reproduced or transmitted

in any form or by any means without prior written permission of Datalogic ADC,

Inc. or its subsidiaries or affiliates ("Datalogic" or "Datalogic ADC"). Owners of Data-

logic products are hereby granted a non-exclusive, revocable license to reproduce

and transmit this documentation for the purchaser's own internal business pur-

poses. Purchaser shall not remove or alter any proprietary notices, including copy-

right notices, contained in this documentation and shall ensure that all notices

appear on any reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed ver-

sions by contacting your Datalogic representative. Electronic versions may either

be downloadable from the Datalogic website (www.datalogic.com) or provided on

appropriate media. If you visit our website and would like to make comments or

suggestions about this or other Datalogic publications, please let us know via the

"Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual

that is complete and accurate, however, Datalogic reserves the right to change any

specification at any time without prior notice.

Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in

many countries, including the U.S.A. and the E.U. All other brand and product

names may be trademarks of their respective owners.

Patents

This product may be covered by one or more of the following patents:

Utility patents: EP0789315B1; EP0851378B1; EP0895175B1; EP1128314B1;

EP1164536B1; EP1205871B1; EP1205873B1;

EP1942442B1; US5992740; US6305606; US6517003; US6712271; US6834806;

US6871785; USRE41349

Additional patents pending.

Table of Contents

Using Quickscan™ Mobile Reader and Cradle ............................................... 1

Reading Angle ......................................................................................... 2

Hands-Free Use ...................................................................................... 2

Using Your QuickScanTM Mobile Reading System ............................. 3

Installing the Battery ...................................................................................... 3

Changing the Batteries .......................................................................... 5

Connecting the QuickScan Mobile ................................................................. 7

System Connections ............................................................................... 7

QuickScan Mobile Cradle Configuration ..................................................... 10

Serial/USB-COM Configuration ........................................................... 10

QuickScan Mobile Reader Configuration .................................................... 10

Interface Selection ........................................................................................ 12

USB Interface Configuration ................................................................ 12

START-UP ...................................................................................... 12

USB Interface Selection ................................................................................ 13

RS-232 Interface Selection .......................................................................... 14

Wedge Interface Selection ........................................................................... 15

USB / Wedge Keyboard Nationality .................................................... 18

IBM46xx Interface Selection ....................................................................... 19

Pen Interface Selection ........................................................................ 20

Operating Test ............................................................................................... 21

Reader Default Configuration ...................................................................... 22

Cradle Default Configuration ....................................................................... 23

Technical Features ........................................................................................ 24

Compliance .................................................................................................... 26

Power Supply ......................................................................................... 26

FCC Compliance ..................................................................................... 26

LED Class ............................................................................................... 27

Radio Compliance ................................................................................. 27

WEEE Statement .................................................................................. 30

Datalogic ADC Limited Factory Warranty ................................................... 31

Ergonomic Recommendations .................................................................... 32

Services and Support .................................................................................... 33

Products......................................................................................... 33

Service & Support ......................................................................... 33

NOTES

Quick Reference Guide

Using Quickscan™ Mobile Reader and Cradle

The QuickScan Mobile reader and cradle build a Cordless Reading System for

the collection, decoding and transmission of barcode data.

Standard models can be connected to a Host PC through a USB, RS-232,

Wedge or Pen emulation cable. All models are suited for single-cradle

layouts.

The LEDs signal the QuickScan Mobile cradle status, as described in the

following table:

LED BEEPER STATUS

Power on /

Data -

Yellow On = QuickScan

Mobile cradle is powered.

Yellow Blinking = the cradle receives data and com-

mands from the Host or the reader.

Charging - Red On = the battery charge is in progress.

Charge com-

pleted - Green On = the battery is completely charged.

Alternating

red/green

Repetitive

beep

Charging out of temperature range, over-current or

over-voltage conditions

Charge completed

(green LED)

Charging (red LED)

Power on / Data

(yellow LED)

2QuickScan™ Mobile

Reading Angle

QuickScanTM Mobile readers automatically scan barcodes at a distance.

Simply aim and pull the trigger. Code scanning is performed along the center

of the light bar emitted from the reading window. This bar must cover the

entire code.

Successful scanning is obtained by tilting the reader with respect to the

barcode to avoid direct reflections, which could impair the reading

performance. See the figures below.

Successful reading is indicated by an audible tone.

OK Not Recommended

Hands-Free Use

When using the QuickScan Mobile on the cradle, remember to lock the reader

by pushing up the locking system as indicated in the following figure.

Good read LED

Installing the Battery

Quick Reference Guide 3

Using Your QuickScanTM Mobile Reading System

Follow the procedure below to start using your QuickScan Mobile reading

system:

1. Connect a QuickScan Mobile cradle to the Host. For installation and

connection information see "System Connections" on page 7.

2. Insert the QuickScan Mobile reader into the cradle to start the battery

charging.

A full charge of the Lithium battery takes 3.5 – 6 hours.

For hands-free use, you can immediately begin using the reader, since

it is powered by the cradle.

3. Configure the QuickScan Mobile reader.

4. Configure the QuickScan Mobile cradle. Reference "QuickScan Mobile

Cradle Configuration" on page 10.

Installing the Battery

To install, charge and/or do any other action on the battery, follow the

instructions in this manual.

Battery Safety

To achieve the best battery life, it is recommended to perform a

full battery charge before using the reader in handheld mode.

Datalogic recommends annual replacement of rechargeable bat-

tery packs to ensure maximum performance.

WARNING

Do not discharge the battery using any device except the scanner.

When the battery is used in devices other than the designated

product, it may damage the battery or reduce its life expectancy. If

the device causes an abnormal current to flow, it may cause the

battery to become hot, explode or ignite and cause serious injury.

Lithium-ion battery packs may get hot, explode or ignite and

cause serious injury if exposed to abusive conditions. Be sure to

follow the safety warnings that follow:

• Do not place the battery pack in fire or heat.

• Do not connect the positive terminal and negative terminal of the

battery pack to each other with any metal object (such as wire).

• Do not carry or store the battery pack together with metal objects.

Installing the Battery

4QuickScan™ Mobile

As with other types of batteries, Lithium-Ion (LI) batteries will lose capacity

over time. Capacity deterioration is noticeable after one year of service

whether the battery is in use or not. It is difficult to precisely predict the finite

life of a LI battery, but cell manufacturers rate them at 500 charge cycles. In

other words, the batteries should be expected to take 500 full discharge /

charge cycles before needing replacement. This number is higher if partial

discharging / recharging is adhered to rather than full / deep discharging.

WARNING

• Do not pierce the battery pack with nails, strike it with a hammer,

step on it or otherwise subject it to strong impacts or shocks.

• Do not solder directly onto the battery pack.

• Do not expose the battery pack to liquids, or allow the battery to get

wet.

• Do not apply voltages to the battery pack contacts.

In the event the battery pack leaks and the fluid gets into your

eye, do not rub the eye. Rinse well with water and immediately

seek medical care. If left untreated, the battery fluid could cause

damage to the eye.

CAUTION

Always charge the battery at 32° – 113°F (0° - 45°C) temperature

range.

Use only the authorized power supplies, battery pack, chargers,

and docks supplied by your Datalogic reseller. The use of any

other power supplies can damage the device and void your war-

ranty.

Do not disassemble or modify the battery. The battery contains

safety and protection devices, which, if damaged, may cause the

battery to generate heat, explode or ignite.

Do not place the battery in or near fire, on stoves or other high

temperature locations.

Do not place the battery in direct sunlight, or use or store the bat-

tery inside cars in hot weather. Doing so may cause the battery to

generate heat, explode or ignite. Using the battery in this manner

may also result in a loss of performance and a shortened life

expectancy.

Do not place the battery in microwave ovens, high-pressure con-

tainers or on induction cookware.

Immediately discontinue use of the battery if, while using,

charging or storing the battery, the battery emits an unusual

smell, feels hot, changes color or shape, or appears abnormal in

any other way.

CAUTION

Do not replace the battery pack when the device is turned on.

Do not remove or damage the battery pack’s label.

Do not use the battery pack if it is damaged in any part. Battery

pack usage by children should be supervised.

Installing the Battery

Quick Reference Guide 5

The typical manufacturer advertised useful life of LI batteries is one to three

years, depending on usage and number of charges, etc., after which they

should be removed from service, especially in mission critical applications. Do

not continue to use a battery that is showing excessive loss of capacity, it

should be properly recycled / disposed of and replaced. For most applications,

batteries should be replaced after one year of service to maintain customer

satisfaction and minimize safety concerns.

Collect and recycle waste batteries separately from the device in comply with

European Directive 2006/66/EC, 2011/65/EU, 2002/96/EC and 2012/19/EU

andsubsequent modifications, US and China regulatory and others laws and

regulations about the environment.

Changing the Batteries

To change the battery of your reader, you must:

1. Unscrew the battery cover screw (Figure 1-A)

2. Unplug the white connector and remove the old battery (Figure 1-B)

3. Insert the new battery and plug in the white connector (Figure 1-C)

Figure 1. Changing the Battery

When inserting the new battery into the handle be sure to posi-

tion the battery and the connector as shown below.

ABC

Installing the Battery

6QuickScan™ Mobile

4. Re-insert the cover in the handle, and replace the screw to secure it.

Do not incinerate, disassemble, short terminals or expose to

high temperature. Risk of fire, explosion. Use specified charger

only. Risk of explosion if the battery is replaced by an incorrect

type. Dispose of the batteries as required by the relevant laws

in force.

WARNING

Autres manuels pour QuickScan Mobile

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Datalogic Lecteur de codes-barres

Datalogic

Datalogic BC-80X0 Cradle Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Datalogic

Datalogic Quickscan QD2200 Manuel d'installation et d'exploitation

Datalogic

Datalogic QuickScan QM21 1 Series Manuel utilisateur

Datalogic

Datalogic JOYA X2 Manuel utilisateur

Datalogic

Datalogic QuickScan QD2590 Manuel d'installation et d'exploitation

Datalogic

Datalogic PowerScan PD7130 Manuel d'installation et d'exploitation

Datalogic

Datalogic Magellan 1100i Manuel utilisateur

Datalogic

Datalogic PowerScan RF SR Manuel utilisateur

Datalogic

Datalogic Gryphon I GM410X Manuel utilisateur

Datalogic

Datalogic HandScanner SR Manuel utilisateur

Datalogic

Datalogic Gryphon GFS4100 Manuel utilisateur

Datalogic

Datalogic QuickScan I QD24 Series Manuel d'installation et d'exploitation

Datalogic

Datalogic Compact 2D Reader Matrix-2000 Manuel utilisateur

Datalogic

Datalogic Gryphon I GD4100 Manuel d'installation et d'exploitation

Datalogic

Datalogic Touch TD1100 Family Manuel utilisateur

Datalogic

Datalogic QuickScan QM24 series Manuel d'installation et d'exploitation

Datalogic

Datalogic MAGELLAN 8200 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GBT4400 Manuel utilisateur

Datalogic

Datalogic DSM0400 Manuel utilisateur

Datalogic

Datalogic QuickScan QBT24 series Manuel d'installation et d'exploitation

Datalogic

Datalogic Dragon D131 Manuel utilisateur

Datalogic

Datalogic Magellan 2300HS Manuel utilisateur

Datalogic

Datalogic PowerScan RF Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur

Atid

Atid AT188N Plus Manuel utilisateur
