Danfoss TP4000 Range Manuel utilisateur

Fig.1

TP4000

User Instructions

Fig.2

Before programming the thermostat press and release the RESET button to restart

the unit. (Fig. 1)

Setting the Clock and Day

The time is set in the factory and therefore it will not normally be necessary to do this

on site.

Accepting the Factory Pre-settings

The TP4000 has pre-set times already programmed in, which often suit most people

(see table below).

To adjust the factory pre-settings & set your own time and temperature

programmes

a) Press PROG (Fig. 2) Until 1st pre-set time and temperature appears in display(Fig.

3).

b) Use + or – buttons (Fig. 4) to adjust the TIME (press and hold to change in 10 min

increments).

c) Use Λ or V buttons (Fig. 5) to adjust the TEMPERATURE.

d) Press PROG (Fig. 2) to move to next preset time & temp (Event 2) (Fig. 6).

e) Repeat steps b, c & d for programming Events 3, 4, 5 & 6.

Returning to RUN mode

Press PROG (Fig. 2) – the colon in the LCD display will start to ash (Fig. 7).

Temporary User Overrides

Fig.5

Fig.4

Fig.6

Fig.7

Event Time Temp. °C

1 06:30 20

2 08:30 15

3 11:30 20

4 13:30 15

5 16:30 21

6 22:30 15

RESET

Fig.3

Fig.9

Fig.10

Selection of time

or actual room

temperature in main

LCD display

Temporary

override of

programmed

temperature

press

together

Frost

Protection

Fig.8

The TP4000 has several useful overrides which can be selected without aecting the

thermostat programming.

• Selection of time or actual room temperature in main LCD display – press +

and – together to change between settings (Fig. 8).

• Temporary override of programmed temperature – press Λ or V until required

temperature is displayed (override will automatically cancel at beginning of next

programmed event) (Fig. 9).

• Frost Protection – a constant low temperature can be selected whilst away from

home - press Λ and V together (Fig.10). Then use Λ or V to select the required

temperature. To return to automatic programming press Λ and V together

again.

The TP4000 is both a programmer and a room thermostat. It allows you to programme

up to 6 times and temperatures at which your heating will come on and go o each

day.

Danfoss Ltd

Ampthill Road

Bedford, MK42 9ER

Tel: 0845 1217 400

Fax: 0845 1217 515

Email: [email protected]

Website: www.heating.danfoss.co.uk

Fig.11

• A low battery symbol will ash in the LCD display (Fig. 11)

• You have 15 days to replace the battery before the unit will switch o.

• Remove old batteries and insert new ones. All settings including time are

maintained.

• Press and release the RESET button to restart the unit. (Fig. 1)

NB. If the display ever goes blank during normal operation, the batteries will need

to be renewed with high quality alkaline cells.The reset button should be pressed

to restart the unit. All times, dates and events will be retained and need not be

re-programmed.

Battery Replacement
