Danfoss ERC 213 Manuel utilisateur

Quick Start Guide

ERC 213

DKRCE.PD.RL0.A3.02 | 1

Overview

The ERC 213 is designed to be an easy, universal replacement control. We encourage users to employ one of ﬁve predeﬁned applications that meet the

needs of most systems. If users need to modify speciﬁc parameters, it should be done after installing the predeﬁned application that most closely meets

system needs.

For more information, including detailed instructions, error codes, parameters, and more,

visit www.danfoss.com/erc or download the Koolcode app from iTunes or Google Play.

For a video guide of the quick set-up, visit http://bit.ly/ERC213 or use the QR code located to the right.

STEP Action Screen Display

STEP 1 Wire control, to include power and sensors

STEP 2

Power up control

Energize control

Control turns on, goes through start up,

then shows the current temperature reading

STEP 3

Enter Quick Conﬁguration Menu and Select app

Press ”<”for more than three seconds within one minute of power up to enter Quick Conﬁguration Menu. o61 appears on screen

Press“set” while o61 is on screen AP0 ﬂashes on screen

Select appropriate app using App Selection section below by pressing “ ” or “ ”, then press “set”. o06 appears on screen

STEP 4

Select Sensor

Press“set” while o06 is on screen n10 ﬂashes on screen

If using included sensor, leave default value “n10”. If using another sensor, select using Sensor Resistance

section on opposing page or cycle through steps 2 – 4 changing the sensor type until the temperature reading

on the main screen is accurate. As above, cycle between options by pressing “ ” or “ ” and press “set” to save.

o06 appears on screen, then control resets

STEP 5

Set Temperature

From main screen, quickly press “set” (1 second). Current temp. setting appears on screen

Cycle to intended temperature by pressing“ ” or “ ” and press “set” to save. Screen returns to main screen

Quick Set-up

Control

Application

Code

Application Defrost

Type*

Defrost

Termination

Sensors

Default

Temp. [°F]

[r00]

Temp. Range

min./max.

[°F]

[r02/r03]

Default Dif.

[°F] [r01]

Defrost

Interval

[hrs]

[d03]

Max.

Defrost

Time [mins]

[d04]

Defrost

Termination

Temp. [°F]

[d02]

AP0 (Default) No preset application - full menu 2 36 -31/22 4 6 30 43

AP1 Refrigeration Natural Time 1 39 36/43 4 4 30 –

AP2 Refrigeration Electric Time 1 36 32/39 4 6 15 –

AP3 Freezing Electric Time 1 -11 -15/-4 4 6 15 –

AP4 Refrigeration Electric Temp. 2 36 32/39 4 6 30 43

AP5 Freezing Electric Temp. 2 -11 -15/-4 4 6 30 43

AP6 No preset application - simpliﬁed menu 2 36 -31 – 122 4 6 30 43

* Hot gas defrost is an option available in full menu (d01).

Key Functions

Press and hold at power up:

FACTORY RESET (“FAC” is

displayed)

Press for one second: UP

Press and hold: ON/OFF

Press for one second: DOWN

Press and hold: DEFROST

Press for one second: BACK

Press and hold: PULL-DOWN

Press for one second: TEMP. SETPOINT/OK

Press and hold: MENU

SET

Display Icons

Night mode (Energy saving) Fan running

Compressor running (Flashes

in pull-down mode) Active alarm

Defrost °C Unit (°C or °F)

Key Functions and Display Icons

– Sair Control sensor

– S5 Defrost (evaporator) sensor

– SC Condenser sensor

– DI1 Digital input – conﬁgurable to the functions listed under

menu code o02

– DI2 Digital input – conﬁgurable to the functions listed under

menu code o37

Connection Diagram

DO1

SairS5Sc/DI1 DI2

DO2 DO3

GND GND

ogramming key – EKA 183B (080G9741)

3L 4N 5678

910

15 16 17 18

11 12 13 14

~~~~

Power supply

(according to the product code number)

GND TX RX +5V

App Selection

Select application based on application and wiring conﬁguration (i.e., refrigeration vs. freezing, and number of temperature sensors). The Typical Wiring

Conﬁgurations diagram on the reverse side of this document may be used to assist with selection. All parameters can be modiﬁed using the full menu.

Some parameters have min and max set points which may need to be changed for less common conﬁgurations.

Quick Start Guide, ERC 213

2 | DKRCE.PD.RL0.A3.02

Sensor Resistance: Using an ohmmeter, you can measure resistance of a sensor to identify sensor type or to troubleshoot a potentially faulty sensor.

Sensor Type Code Resistance [ohm] at Temperature [°F]

0 20 32 75

PTC Ptc 690 761 807 980

PTC 1000 Pt1 931 974 1000 1093

NTC 10000 * n10 70317 40411 29481 10459

NTC 5000 n5 42664 23110 16325 5251

* Included in kit

Common Functions

Adjust Temperature Set Point

From main screen, quickly press “set” (one second). The current temperature setting will appear on screen. Cycle to intended temperature by pressing

“^” or “^” and press“set” to save. The display will return to the main screen.

Adjust Diﬀerential

From main screen, press“set” for more than three seconds. Cycle to“r--”submenu by pressing “ ” or “ ” and press “set.” Cycle to “r01” and press “set.” Cycle to

preferred diﬀerential setting, and press “set” to save.“r01”will appear on screen. Press“<” twice to return to main screen.

Manual Defrost

From main screen, press defrost for more than three seconds to initiate defrost. The DEFROST icon is shown during defrost. Press defrost key for at least

three seconds to stop manual defrost.

Factory Reset

Press and hold“ ” and “ ” simultaneously at power up.

Unlock Keypad

After 5 minutes of no activity, the keypad will lock if P76 = yes (by default it is set to no). When the keypad is locked any key press shows“LoC”

in the display. Press“ ” and “ ” simultaneously for three seconds to unlock the keyboard.“unl” is displayed for three seconds.

Typical Wiring Conﬁgurations

Sair

(Control Sensor)

DI1DI2

Sair

(Control Sensor)

DI1DI2

Sair

(Control

Sensor)

DI1DI2

(Defrost)

DO1

115 V AC

230 V AC

115 V AC

230 V AC

115 V AC

230 V AC

DO2 DO3 DO1 DO3DO2 DO1DO3DO2

ERC 213 - APP 1 ERC 213 - APP 2-3 ERC 213 - APP 4-5

Troubleshooting

Power Supply Code Description Remedy (applicable parameter code in parenthesis)

Common Alarm

Error Codes

A01 High temperature alarm Bring down temperature or increase high limit alarm limit (A13)

A02 Low temperature alarm Increase temperature or low temperature alarm limit (A14)

E27 Defrost sensor error Verify that defrost sensor is wired into terminals 10 and 11

Verify that correct sensor type is selected (o06)

E29 Air temperature sensor error Verify that control sensor is wired into terminals 9 and 10 – 8 is not used

Verify that correct sensor type is selected

Common

Problems/

Resolution

Problem Likely Cause Remedy (applicable parameter number in parenthesis)

Compressor does

not start

Waiting for compressor delay timer

Check compressor minimum oﬀ time (

CO2

)

Defrost in progress Check defrost interval (d03)

Check defrost on demand (temp. initiated defrost) (d19)

Defrost does not start

Controller in pull down mode Check pull-down duration (r96)

Wrong temperature

is displayed

Wrong type of sensor selected Verify that correct sensor type is selected (o06)

Sensor installed into incorrect terminals Verify that control sensor is wired into terminals 9 and 10 – 8 is not used

Evaporator icing Defrost interval too long Reduce defrost interval (d03)

Defrost time too short Increase max. defrost time (d04)

Need additional help with programming, parameters, or error codes? Download Danfoss’ Koolcode app.

Technical Speciﬁcations

Power Supply 080G3411 115V AC 50/60 HZ;

080G3412 230V AC 50/60 Hz

Inputs 4 total; 2 analog, 1 analog/digital, 1 digital

Sensor Included in Kit NTC 10000

Output

D01 Compressor Relay

115 V (080G3268): 16 FLA/72 LRA

230 V (080G3269): 10 FLA/60 LRA

D02 Defrost Relay and/D03 Fan Relay

8A, 2 FLA, 12 LRA

Operating Conditions 14 – 131 °F

Storage Conditions -40 – 158 °F

Approvals UL Recognized/NSF

DKRCE.PD.RL0.A3.02 | 3

Quick Start Guide, ERC 213

Parameter Name Menu Code Unit Min. Value Max. Value Default Value Value

Predeﬁned applications o61 – – – App0 App0

Sensor type o06 – – – n10 n10

Temperature Setpoint r00 °C -100 200 2 2

Diﬀerential r01 K 0.1 20 2 2.7

Min. set point limit r02 °C -100 200 -35 -35

Max. set point limit r03 °C -100 200 50 50

Display oﬀset r04 K -10 10 0 0

Display Unit r05 – – – °C °F

Calibration of Sair r09 K -20 20 0 0

Night Set back r13 K -50 50 0 0

Oﬀset reference displacement r40 °C -50 20 0 0

Pull down duration r96 min.. 0 960 0 0

Pull down temp limit r97 °C -100 200 0 0

Alarm delay - Normal conditions A03 min. 0 240 30 30

Alarm delay - pulldown / startup / def

A12 min. 0 240 60 60

High temp alarm A13 °C -100 200 8 8

Low temp alarm A14 °C -100 200 -30 -30

DI1 delay A27 min. 0 240 30 30

DI2 delay A28 min. 0 240 30 30

Condenser High temp alarm A37 °C 0 200 80 80

Condenser High block limit A54 °C 0 200 85 85

Voltage protection A72 – – – No No

Min. cut-in voltage A73 V 0 270 0 0

Min. cut-out voltage A74 V 0 270 0 0

Max. voltage A75 V 0 270 270 270

Defrost Method d01 – – – Electric Electric

Defrost stop temperature d02 °C 0 50 6 6.5

Defrost Interval d03 hour 0 240 8 6

Max. defrost Time d04 min. 0 480 30 30

Defrost delay at power up d05 min. 0 240 0 0

Drip delay d06 min. 0 60 0 0

Fan delay after defrost d07 min. 0 60 0 0

Fan start temp after defrost d08 °C -50 0 -5 -5

Fan ON during defrost d09 – – – On On

Defrost stop sensor d10 – – – None None

Comp accumulated runtime d18 hour 0 96 0 0

Defrost on demand d19 K 0 20 20 20

Defrost delay after pulldown d30 min. 0 960 0 0

Fan at compressor cutout F01 – – – FFC FAo

Fan stop evaporator temp F04 °C -50 50 50 50

Fan ON time F07 min. 0 15 2 2

Fan OFF time F08 min. 0 15 2 2

Parameter sheet

Quick Start Guide, ERC 213

4 | DKRCE.PD.RL0.A3.02

Parameter Name Menu Code Unit Min. Value Max. Value Default Value Value

Compressor min. ON time C01 min. 0 30 0 0

Compressor min. OFF time C02 min. 0 30 2 2

Comp OFF delay at open door C04 min. 0 15 0 0

Zero crossing C70 – – – yes yes

Delay of outputs at startup o01 sec 0 600 5 5

DI1 conﬁguration o02 – – – Oﬀ Oﬀ

Serial address o03 – 0 247 0 0

Password o05 – 0 999 0 0

Display Resolution o15 – – – 0.1 1

Relay 1 counter o23 – – – – 0

Relay 2 counter o24 – – – – 0

Relay 3 counter o25 – – – – 0

DI2 conﬁguration o37 – – – Oﬀ Oﬀ

Display during defrost o91 – – – -d- -d-

DO2 Conﬁg o71 – – – def def

DI1 polarity P73 – – – no no

DI2 polarity P74 – – – no no

Invert alarm relay P75 – – – Normal Normal

Keyboard lock P76 – – – No No

Main switch r12 – – – Oﬀ On

Controller status u00 – – – S25 S20

Air temperature (Sair) u01 °C – – – 321

Present regulation reference u02 – – – 0

Evaporator temperature (S5) u09 °C – – – 0

DI1 status u10 – – – Oﬀ Oﬀ

Night mode u13 – – – Oﬀ Oﬀ

DI2 status u37 – – – Oﬀ Oﬀ

Condenser temperature (Sc) U09 – – – 0

Compressor relay status u58 – – – Oﬀ Oﬀ

Fan relay status u59 – – – Oﬀ On

Defrost relay status u60 – – – Oﬀ Oﬀ

Firmware version u80 – – – – 4.16

Database version – – – – – 4.02

Order No Low – – – – – 3502

Air temperature sensor(Sair) error E29 – – – Oﬀ On

Defrost sensor (S5) error E27 – – – Oﬀ Oﬀ

Condensor sensor(Sc) error E30 – – – Oﬀ Oﬀ

High temperature alarm A01 – – – Oﬀ Oﬀ

Low temperature alarm A02 – – – Oﬀ Oﬀ

High voltage alarm A99 – – – Oﬀ Oﬀ

Low voltage alarm AA1 – – – Oﬀ Oﬀ

High condenser temperature alarm A61 0 – – Oﬀ Oﬀ

Door alarm A04 0 – – Oﬀ Oﬀ

DI external alarm A15 0 – – Oﬀ Oﬀ

Autres manuels pour ERC 213

Autres manuels Danfoss Contrôleurs

Danfoss

Danfoss VLT PROFIBUS DP MCA 101 Mode d'emploi

Danfoss

Danfoss PLUS+1 Series Manuel

Danfoss

Danfoss VLT AQUA Drive FC 200 Manuel utilisateur

Danfoss

Danfoss Icon Master Controller 24 V Manuel utilisateur

Danfoss

Danfoss MCO 305 Mode d’emploi

Danfoss

Danfoss ECL Comfort 210 Manuel d'instructions d'installation

Danfoss

Danfoss AMV 130 Manuel utilisateur

Danfoss

Danfoss ECL Comfort 310 Manuel utilisateur

Danfoss

Danfoss AK-CS Manuel utilisateur

Danfoss

Danfoss ECL Comfort 301 Manuel utilisateur

Danfoss

Danfoss ICAD 600B Manuel utilisateur

Danfoss

Danfoss 088U0200 Manuel utilisateur

Danfoss

Danfoss EKC 414A Manuel utilisateur

Danfoss

Danfoss AK-CC 550 Manuel utilisateur

Danfoss

Danfoss AME 23 SU Manuel utilisateur

Danfoss

Danfoss ECL Comfort 296 Manuel utilisateur

Danfoss

Danfoss ECL Comfort 210 Manuel utilisateur

Danfoss

Danfoss DEVIreg Multi Manuel utilisateur

Danfoss

Danfoss PLUS+1 Series Manuel

Danfoss

Danfoss Danfoss Link Manuel utilisateur

Danfoss

Danfoss PVED-CLS Manuel utilisateur

Danfoss

Danfoss VLT HVAC Basic Drive FC 101 Manuel utilisateur

Danfoss

Danfoss ERC 211 Manuel utilisateur

Danfoss

Danfoss PN 25 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
