Danfoss Vacon NXP Series Manuel utilisateur

Operating guide

VACON® NXS/NXP Air-cooled

Wall-mounted and Standalone

Contents

1 Introduction 8

1.1 Purpose of this Operating Guide 8

1.2 Additional Resources 8

1.3 Disposal 8

1.4 Type Approvals and Certifications 8

1.5 Start-up Quick Guide 9

2 Safety 11

2.1 Safety Symbols 11

2.2 Danger and Warnings 11

2.3 Cautions and Notices 13

3 Product Overview 15

3.1 Intended Use 15

3.2 Manual Version 15

3.3 Package Label 15

3.4 Description of the Type Code 16

3.5 Enclosure Sizes 19

3.6 Available Protection Ratings 21

3.7 Available EMC Classes 22

3.8 Control Panel 23

3.8.1 Introduction to Control Panel 23

3.8.2 Keypad 23

3.8.3 Display 25

3.8.4 Basic Menu Structure 26

4 Receiving the Delivery 28

4.1 Checking the Delivery 28

4.2 Storing the Product 30

4.3 Lifting the Product 30

4.4 Using the Product Modified Label 30

5 Mounting the Unit 32

5.1 Environmental Requirements 32

5.1.1 General Environmental Requirements 32

5.1.2 High Altitude Installation 32

5.2 Cooling Requirements 33

5.2.1 General Cooling Requirements 33

5.2.2 Cooling of FR4 to FR9 33

5.2.3 Cooling of Standalone AC drives (FR10 to FR11) 36

Contents

Operating guide | VACON® NXS/NXP Air-cooled

5.3 Installation Sequence 37

5.3.1 Installation Sequence for Wall-mounted AC Drives 37

5.3.2 Installation Sequence for Standalone AC drives 37

6 Electrical Installation 38

6.1 Cable Connections 38

6.1.1 General Cable Requirements 38

6.1.2 UL Standards on Cabling 39

6.1.3 Cable Selection and Dimensioning 39

6.1.4 Cable Selection and Dimensioning, North America 39

6.1.5 Fuse Selection 40

6.1.6 Principle of the Power Unit Topology 40

6.1.7 Brake Resistor Cables 40

6.2 EMC-compliant Installation 41

6.2.1 Installation in a Corner-grounded Network 42

6.3 Grounding 42

6.4 Get Access and Locate the Terminals 44

6.4.1 Get Access and Locate the Terminals for FR4 44

6.4.2 Get Access and Locate the Terminals for FR5 46

6.4.3 Get Access and Locate the Terminals for FR6 48

6.4.4 Get Access and Locate the Terminals for FR7 50

6.4.5 Get Access and Locate the Terminals for FR8 52

6.4.6 Get Access and Locate the Terminals for FR9 54

6.5 Installing the Cables 56

6.5.1 Additional Instructions for Cable Installation 57

6.5.2 Installing the Cables, FR4-FR6 57

6.5.3 Installing the Cables, FR7 60

6.5.4 Installing the Cables, FR8 63

6.5.5 Installing the Cables, FR9 66

6.5.6 Installing the Cables, FR10-FR11 68

6.6 Installation in an IT System 68

6.6.1 Installing the AC drive in an IT System, FR4-FR6 69

6.6.2 Installing the AC Drive in an IT System, FR7 72

6.6.3 Installing the AC Drive in an IT System, FR8-FR11 75

7 Control Unit 76

7.1 Control Unit Components 76

7.2 Control Voltage (+24V/EXT +24V) 76

7.3 Control Unit Cabling 77

7.3.1 Selection of the Control Cables 77

7.3.2 Control Terminals on OPTA1 78

7.3.3 Control Terminals on OPTA2 and OPTA3 81

Contents

Operating guide | VACON® NXS/NXP Air-cooled

7.4 Installation of Option Boards 83

7.5 Galvanic Isolation Barriers 83

8 Using the Control Panel 85

8.1 Navigating on the Control Panel 85

8.2 Using the Monitoring Menu (M1) 85

8.2.1 Monitored Values 86

8.3 Using the Parameter Menu (M2) 87

8.3.1 Finding the Parameter 87

8.3.2 Selecting Values 88

8.3.3 Editing the Values Digit by Digit 89

8.4 Using the Keypad Control Menu 90

8.4.1 Finding the Keypad Control Menu 90

8.4.2 Keypad Control Parameters M3 91

8.4.3 Changing the Control Mode 91

8.4.4 Keypad Reference 92

8.4.5 Changing the Rotation Direction 92

8.4.6 Disabling the Stop Motor Function 93

8.4.7 Special Functions in Keypad Control Menu 93

8.5 Using the Active Faults Menu (M4) 94

8.5.1 Finding the Active Faults Menu 94

8.5.2 Examining the Fault Time Data Record 95

8.5.3 Fault Time Data Record 95

8.6 Using the Fault History Menu (M5) 96

8.6.1 Fault History Menu (M5) 96

8.6.2 Resetting the Fault History 97

8.7 Using the System Menu (M6) 97

8.7.1 Finding the System Menu 97

8.7.2 System Menu Functions 97

8.7.3 Changing the Language 100

8.7.4 Changing the Application 100

8.7.5 Copy Parameters (S6.3) 101

8.7.6 Security 104

8.7.7 Keypad Settings 107

8.7.8 Hardware Settings 108

8.7.9 System Info 111

8.8 Using the Expander Board Menu 114

8.8.1 Expander Board Menu 114

8.8.2 Examining the Connected Option Boards 114

8.8.3 Finding the Option Board Parameters 115

8.9 Further Control Panel Functions 115

Contents

Operating guide | VACON® NXS/NXP Air-cooled

9 Commissioning 116

9.1 Safety Checks before Starting the Commissioning 116

9.2 Commissioning the AC Drive 117

9.3 Measuring the Cable and Motor Insulation 118

9.3.1 Insulation Checks of the Motor Cable 118

9.3.2 Insulation Checks of the Mains Cable 119

9.3.3 Insulation Checks of the Motor 119

9.4 Checks after Commissioning 120

9.4.1 Testing the AC Drive after Commissioning 120

9.4.2 RUN Test without Load 120

9.4.3 Start-up Test 121

9.4.4 Identification Run 121

10 Maintenance 122

10.1 Maintenance Schedule 122

10.2 Reforming the Capacitors 122

11 Fault Tracing 123

11.1 General Information on Fault Tracing 123

11.2 Resetting a Fault 123

11.3 Creating Service Info File 124

12 Specifications 125

12.1 Weights of the AC Drive 125

12.2 Dimensions 125

12.2.1 List of Dimension Information 125

12.2.2 Wall-mounted 126

12.2.3 Flange mounting 130

12.2.4 Standalone 136

12.3 Cable and Fuse Sizes 137

12.3.1 List of Cable and Fuse Size Information 137

12.3.2 Cable and Fuse Sizes for 208–240 V and 380–500 V, FR4 to FR9 137

12.3.3 Cable and Fuse Sizes for 208–240 V and 380–500 V, FR4 to FR9, North America 138

12.3.4 Cable and Fuse Sizes for 525–690 V, FR6 to FR9 140

12.3.5 Cable and Fuse Sizes for 525–690 V (UL Rating 600 V), FR6 to FR9, North America 141

12.3.6 Cable and Fuse Sizes for 380–500 V, FR10 to FR11 142

12.3.7 Cable and Fuse Sizes for 380–500 V, FR10 to FR11, North America 142

12.3.8 Cable and Fuse Sizes for 525–690 V, FR10 to FR11 143

12.3.9 Cable and Fuse Sizes for 525–690 V (UL Rating 600 V), FR10 to FR11, North America 144

12.4 Cable Stripping Lengths 144

12.5 Tightening Torques for Cover Screws 146

12.6 Tightening Torques of the Terminals 146

Contents

Operating guide | VACON® NXS/NXP Air-cooled

12.7 Power ratings 147

12.7.1 Overload Capability 147

12.7.2 Power Ratings for Mains Voltage 208–240 V 148

12.7.3 Power Ratings for Mains Voltage 208–240 V, North America 149

12.7.4 Power Ratings for Mains Voltage 380–500 V 150

12.7.5 Power Ratings for Mains Voltage 380–500 V, North America 151

12.7.6 Power Ratings for Mains Voltage 525–690 V (UL Rating 600 V) 152

12.7.7 Power Ratings for Mains Voltage 525–690 V (UL Rating 600 V), North America 153

12.8 VACON NXP Technical Data 154

12.9 Brake Resistor Ratings 159

12.9.1 Brake Resistor Ratings 159

12.9.2 Brake Resistor Ratings for Mains Voltage 208–240 V 159

12.9.3 Brake Resistor Ratings for Mains Voltage 380–500 V 160

12.9.4 Brake Resistor Ratings for Mains Voltage 525–690 V 161

12.10 Fault Codes 162

12.11 EU Declaration of Conformity 169

Contents

Operating guide | VACON® NXS/NXP Air-cooled

1 Introduction

1.1 Purpose of this Operating Guide

This operating guide provides information for safe installation and commissioning of the AC drive. It is intended for use by qualified

personnel. Read and follow the instructions to use the drive safely and professionally. Pay particular attention to the safety instructions

and general warnings. Always keep this operating guide available with the drive.

1.2 Additional Resources

Other resources are available to understand advanced AC drive functions and programming.

• The VACON®NX All-in-One Application Manual provides greater detail on working with parameters and shows many application

examples.

• The VACON®NX I/O Boards User Manual gives more information on the I/O boards and their installation.

• Instructions for operation with option boards and other optional equipment.

Supplementary publications and manuals are available from Danfoss.

NOTE! Download the English and French product manuals with applicable safety, warning and caution information from https://

www.danfoss.com/en/service-and-support/.

REMARQUE Vous pouvez télécharger les versions anglaise et française des manuels produit contenant l'ensemble des informations

de sécurité, avertissements et mises en garde applicables sur le site https://www.danfoss.com/en/service-and-support/.

1.3 Disposal

Context:

Do not dispose of equipment containing electrical components together with domestic waste. Collect it separately in accordance with

local and currently valid legislation.

1.4 Type Approvals and Certifications

The following list is a selection of possible type approvals and certifications for Danfoss drives:

Introduction

Operating guide | VACON® NXS/NXP Air-cooled

DPD00910G

089

NOTICE

The specific approvals and certification for the drive are on the nameplate of the drive. For more information, contact the local

Danfoss office or partner.

1.5 Start-up Quick Guide

Context:

Do at minimum these procedures during the installation and commissioning.

If there are problems, speak to the local distributor.

Vacon Ltd is not responsible for the use of the AC drives against the instructions.

Introduction

Operating guide | VACON® NXS/NXP Air-cooled

DPD00910G | 9

Procedure

1. Check that the delivery agrees to the order, see 4.1 Checking the Delivery.

2. Before starting the commissioning, read carefully the safety instructions in 2.2 Danger and Warnings and 2.3 Cautions and Notices.

3. Before the mechanical installation, check the minimum clearances around the AC drive ( 5.2.2 Cooling of FR4 to FR9 and 5.2.3

Cooling of Standalone AC drives (FR10 to FR11)) and check the ambient conditions in 12.8 VACON NXP Technical Data.

4. Check the dimensions of the motor cable, mains cable, mains fuses and check the cable connections. Read 6.1 Cable Connections,

6.2 EMC-compliant Installation and 6.3 Grounding.

5. Obey the installation instructions, see 6.5 Installing the Cables.

6. Find information on the control connections in 7.3.2 Control Terminals on OPTA1.

7. If the start-up wizard is active, select the language of the control panel and the application. Accept the selections with the Enter

button. If the start-up wizard is not active, obey the instructions a and b.

ASelect the language of the control panel from the Menu M6, page 6.1. For instructions, see 8.7.3 Changing the Language.

BSelect the application from the Menu M6, page 6.2. For instructions, see 8.7.4 Changing the Application.

8. All parameters have factory default values. To make sure that the AC drive operates correctly, make sure that these group G2.1

parameters have the same data as the nameplate. For more information on the parameters in the list, see the VACON®All in One

Application Manual.

• Nominal voltage of the motor

• Nominal frequency of the motor

•Nominal speed of the motor

• Nominal current of the motor

• Motor cos phi

9. Obey the commissioning instructions, see 9.2 Commissioning the AC Drive.

The VACON®NXS/NXP AC drive is ready for operation.

Introduction

Operating guide | VACON® NXS/NXP Air-cooled

DPD00910G

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Danfoss Contrôleurs

Danfoss

Danfoss ECL Comfort 296 Manuel utilisateur

Danfoss

Danfoss AK-PC 420 Manuel utilisateur

Danfoss

Danfoss VLT PROFIBUS DP MCA 101 Mode d'emploi

Danfoss

Danfoss EKC 202D Manuel utilisateur

Danfoss

Danfoss VACON 100 industrial Manuel utilisateur

Danfoss

Danfoss VLT AutomationDrive FC 301 Manuel utilisateur

Danfoss

Danfoss VLT 6000 series Manuel utilisateur

Danfoss

Danfoss vlt soft starter mcd 500 Manuel utilisateur

Danfoss

Danfoss ECL Comfort 300 Manuel utilisateur

Danfoss

Danfoss EKC 414A Manuel utilisateur

Danfoss

Danfoss 51 Series Manuel utilisateur

Danfoss

Danfoss Icon Series Manuel utilisateur

Danfoss

Danfoss EKC 331T Manuel utilisateur

Danfoss

Danfoss Icon Master Controller 24 V Manuel utilisateur

Danfoss

Danfoss ECL Comfort 210 Manuel utilisateur

Danfoss

Danfoss VLT Center Winder MCO 352 Manuel utilisateur

Danfoss

Danfoss VLT FC 103 Manuel utilisateur

Danfoss

Danfoss VLT DMS 300 Manuel utilisateur

Danfoss

Danfoss RAE-K Manuel utilisateur

Danfoss

Danfoss EKC 102C Manuel utilisateur

Danfoss

Danfoss AMI 140 Series Manuel utilisateur

Danfoss

Danfoss VLT Decentral FCD 300 Manuel utilisateur

Danfoss

Danfoss VLT AQUA Drive FC 202 Manuel utilisateur

Danfoss

Danfoss 101N0715 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
