Daewoo FR-521KT/KB Manuel utilisateur

Service Manual

Refrigerator

Model: FR-521/551 KT/KB

FR-630/662/700 KT/KB

http : //svc.dwe.co.kr Mar. 2000

DAEWOO ELECTRONICS CO., LTD.

S/M No. :FR521KTB10

✔

Caution

: In this Manual, some parts can be changed for improving, their

performance without notice in the parts list. So, if you need the

latest parts information,please refer to PPL(Parts Price List) in

Service Information Center (http://svc.dwe.co.kr).

TABLE OF CONTENTS

1. External Views ............................................................................................................................... 2

1. External Size ................................................................................................................................ 2

2. Name of Parts ............................................................................................................................... 3

2. Specifications ................................................................................................................................ 4

1. Outline .......................................................................................................................................... 4

2. Electric Parts ................................................................................................................................ 4

3. Power Cord ................................................................................................................................... 9

4. Door Color .................................................................................................................................... 10

3. Diagram 11

2. Air Flow Diagram .......................................................................................................................... 11

3. Refrigent Cycle Diagram .............................................................................................................. 13

4. Exploded View And Parts List....................................................................................................... 14

1. FR-521,551 KT/KB ....................................................................................................................... 14

2. FR-630,662,700 KT/KB................................................................................................................. 19

3. Machine Room Exploded View And Parts List ............................................................................. 24

1) For starters, be sure to check any chances of the leakage of electricity.

2) You could handle a part in the vicinity of electricity after unplugging.

3) You should put on rubber glovers to prevent an electric shock on operation test.

4) Make sure the rated current, voltage, capacity before using an instrument.

5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten.

6) Be careful not to let water to permeate the electric part in the machine room.

7) With the door open during your working, you might be damaged by that door.

8) You should give a title to the refrigerator for your safe after removing the breakable goods inside the refrigerator.

9) You'd better use cotton gloves if you fix it up around the evaporator.

SAFETY AND PRECAUTIONS

"*A"

1. EXTRNAN VIEWS

2) FR 551 KT/KB

3) FR 630,662,700 KT/KB

“ *A ”

630KT/KB 662KT/KB 700KT/KB

590mm 620mm 650mm

1) FR521 KT/KB

2. NAME OF PARTS

1. FR-521,551KT/KB

2. FR-630,662,700KT/KB

1 Freezer Compartment Lamp

2 Shell Freezer & Icr Tray

3 Case Icing

4 Temperature Controller

(Freezer Compartment)

5 Refrigerator Compartment Lamp

6 Temperature Controller

(Refrigerator Compantment)

7 Fresh Case

8 Shell Refrigerator

9 Cover Vegetable

10 Case Vegetable

11 Front Grille

12 Adjustable Foot

13 Freezer Pocket

14 Egg Pocket

15 Egg Tray

16 Bottle Pocket

17 Multi Pocket

18 Multi Pocket

1 Freezer Compartment Lamp

1-1 Temperature contraller

(Freezer Compartment)

Shelf Freezer

¨3

Case Icing

Guide Icing

5 Ice Box

5-1

Temperature contraller

(Refrigerator Compartment)

6 Refrigerator Compartment Lamp

7 Cover Cubic Duct

8 Fresh Case

9 Shelf Refrigerator

10 Deodorant

11 Cover Vegetable

12 Case Vegetable(B)

13 Case Vegetable(A)

14 Guide Vegetable

15 Front Grille

16 Adjustable Foot

17 Freezer Pocket Top

18 Freezer Pocket Under

19 Egg Pocket

20 Egg Tray

21 Guide Bottle

22 Bottle Pocket

23 Multi Pocket

24 Multi Pocket

EXTENAN VIEWS

5-1

1-1

2. SPECIFICATION

1. OUTLINE

2. ELECTRIC PARTS

1) COMPRESSOR

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

DIVISION CONTENTS

MODEL NAME FR-521KT/KB FR-551KT/KB FR-630KT/KB FR-662KT/KB FR-700KT/KB

USABLE CAPACITY FREEZER 125

§¤

125

§¤

138

§¤

147

§¤

156

§¤

REFRIGERATOR 319

§¤

355

§¤

366

§¤

377 398

TOTAL 444

§¤

480

§¤

504

§¤

524 554

EXTERNAL DIMENSION WIDTH 757mm 757mm 818mm 818mm 818mm

DEPTH 750mm 750mm 752mm 782mm 812mm

HEIGHT 1749mm 1809mm 1818mm 1818mm 1818mm

REFRIGENT R12 160g 160g 170g

R134a 130g 130g 140g

COOLING & CONTROL

SYSTEM COOLING SYSTEM Fan Cooling System

DEFROST SYSTEM Fin Evaporator Forced

DEFORST CONTROL Automatic Start & Stop

NET WEIGHT 71kg 72kg 84kg 91kg 94kg

REFRIGERANT R12

VOLTAGE(V/HZ) 100/50, 60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

COMP MODEL XXXXSL28YE-5 PL23YH-4 SL28YE-5 SL28YE-5

PART CODE XXXX3954128A50 3956123P40 3954128A50 3954128A50

STARING TYPE XXXXRSIR RSCR RSIR RSIR

REFRIGERANT R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

COMP MODEL XHBL25YG-3 X X HPL26YH-5 XHPL26YH-5 HPL26YH-5

PART CODE X3952125R30 X X 3956126S50 X3956126S50 3956126S50

STARING TYPE XCSR X X RSCR XRSCR RSCR

REFRIGERANT R12

VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 50 240 / 50

COMP MODEL X X X X SL28YE-5 PL23YH-4 SL28YE-5 SL28YE-5

PART CODE X X X X 3954128A50 3956125G40 3954128A50 3954128A50

STARTING TYPE X X X X RSIR RSCR RSIR RSIR

REFRIGERANT R134a

VOLTAGE ( V/HZ) 100 /50,60 110 / 60 115,120/60 127/60 220/50 220 / 60 230 / 50 240 / 50

COMP MODEL XHBL25YG-3 X X HPL26YH-5 XHPL26YH-5 HPL26YH-5

PART CODE X3952125R30 X X 3956126S50 X3956126S50 3956126S50

STARTING TYPE XCSR X X RSCR XRSCR RSCR

SPECIFICATIONS

2)RELAY

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

3) STARTING CAPACITOR

(

1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

REFRIGERANT R12

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

ASSY TYPE NAME X

X X

276THBYY-52 181SHBYY-52 276THBYY-52 276THBYY-52

PART CODE

X X

X3018119940 3018116610 3018119940 3018449940

PTC RESISTANCE X X X X S220 S330 S220 S220

OVER LOAD TYPE NAME X X X X 276THB 181SHB 276THB 276THB

REFRIGERANT R134a

VOLTAGE(V/HZ)100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

ASSY TYPE NAME X

783NHBZZ-52

X X

197NHBYY-52 X197NHBYY-52 197NHBYY-52

PART CODE

X3018119390

X3018119920 X3018119920 3018449920

PTC RESISTANCE XS220 X X S330 XS220 S330

OVER LOAD TYPE NAME X783NHB X X 197NHB X197NHB 197NHB

REFRIGERANT R12

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

ASSY TYPE NAME X

X X

276THBYY-52 181SHBYY-52 276THBYY-52 276THBYY-52

PART CODE

X X

X3018119940 3018116610 3018119940 3018449940

PTC RESISTANCE X X X X S220 S330 S220 S220

OVER LOAD TYPE NAME X X X X 276THB 181SHB 276THB 276THB

REFRIGERANT R134a

VOLTAGE(V/HZ)100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

ASSY TYPE NAME X

783NHBZZ-52

X X

197NHBYY-52 X197NHBYY-52 197NHBYY-52

PART CODE

X3018119390

X3018119920 X3018119920 3018449920

PTC RESISTANCE XS220 X X S330 XS330 S330

OVER LOAD TYPE NAME X783NHB X X 197NHB X197NHB 197NHB

REFRIGERANT R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

PART CODE X3016400100 X X X X X X

RATED VOLTAE X200V X X X X X X

RATED CAPACITANCE X X X X X X X

REFRIGERANT R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

PART CODE X3016400100 X X X X X X

RATED VOLTAE X200V X X X X X X

RATED CAPACITANCE X100uF X X X X X X

100uF

SPECIFICATIONS

4) RUNNING CAPACITOR

(1) FR-521,551,630,662,700 KT/KB

5) C-FAN MOTER

(1) FR-521/551 KT/KB

(2) FR-630,662,700 KT/KB

6) F-FAN MOTER

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

REFRIGERANT R12

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

PART CODE X X X X X

400EL15110

X X

RATED VOLTAE X X X X X 350V X X

RATED CAPACITANCE X X X X X X X

REFRIGERANT R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

PART CODE X

3816800400

X X

3016401900

X3016401900 3016401900

RATED VOLTAE X300V X X 400 X400V 400

RATED CAPACITANCE X X X X

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

TYPE NAME

DL-2213DWCB

PART CODE 3015907300

REVOLUTION 2200RPM

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

TYPE NAME

DL-2213DWCB

PART CODE 3015906800

REVOLUTION 2200RPM

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

TYPE NAME

DL-2213DWCB

PART CODE 3015907200

REVOLUTION 2200RPM

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

TYPE NAME

DL-2213DWCB

PART CODE 3015905300

REVOLUTION 2200RPM

5uF

7uF 4uF 4uF 4uF

7) R-FAN MOTER

(1) FR-630

,662,700

KT/KB

8) DEFROST HEATER

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

9) LAMP ASSEMBLY

(1) FR-521,551,630.662.700 KT/KB

10) PCB TRANSFORMER

(1) FR-521,551,630,662,700 KT/KB

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

TYPE NAME

XORM-1027W X

ORM-1018C2

1S-23211DWBFC

ORM-108C2 ORM-108C2

PART CODE X3015902831 X3015902691 3015912672 3015902691

REVOLUTION X2200rpm X2200rpm

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

X148W

PART CODE X3012803210 3012805500

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

X180W

PART CODE X3012803210 3012805500

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

X15W

PART CODE X3013600050 3013600020

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

XFRB-5070KT

PART CODE X5EPK648110 5EPK048007 5EPK0548041

SPECIFICATIONS

11) MAIN PCB ASSEMBLY

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

12) DEFROST TIMER

13) DOOR S/W

(1) FR-521,551,630,662,700 KT/KB

14) DRYER

(1) FR-521/551 KT/KB

(2) FR-630/662/700 KT/KB

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

XRT

PART CODE X3014387020 3015387010

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

XRT

PART CODE X3014386020 3014386010

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

SPEC(W)

XTMDEX09UD1

TMDE807F1

TMDEX09UR1

TMDE807UF1

PART CODE X3018120030 3018120020 30181200100 30181200200

REFRIGERANT R12,R134a

VOLTAGE(V/HZ) 100/50,60 110/60 115,120/60 127/60 220/50 220/60 230/50 240/50

PART CODE 3018100010

REFRIGERANT R12 R134a

VOLTAGE(V/HZ) 10g 15g

SPEC(W)

3016801000 3016801010

REFRIGERANT R12 R135a

VOLTAGE(V/HZ) 10g 15g

SPEC(W)

3016805300 3016801020

3. POWER CORD

Upper power cord’s part code is only for lead wire, without any kinds of terminal or housing

NO SHAPE OF CODE PART CODE DESCRIPTION REMARK

13011315000 CP-2PIN FOR EUROPEAN COUNTRY

2401RA17200 CP-2PIN FOR OTHER COUNTRY

34006D17101 KP-30 FOR AMERICA & ELSALVADOR

4401PD17101 KP-211 FOR JAPAN & TAIWAN

53011300801 BP-3PIN

63011303010 #267 FOR CHILE

73011315310 FOR ISRAEL

3011303050 BS-1363A FOR U.K, MIDDLE ASIA

SINGAPORE & MALAYSIA

93011301200 KP551/550 FOR CHINA & AUSTRALIA

SPECIFICATIONS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Daewoo Réfrigérateur

Daewoo

Daewoo NO-FROST Manuel utilisateur

Daewoo

Daewoo FRX-623B Series Manuel utilisateur

Daewoo

Daewoo FR-093 Manuel utilisateur

Daewoo

Daewoo FRS-U20 Series Manuel utilisateur

Daewoo

Daewoo FRS-T20BA Series Manuel utilisateur

Daewoo

Daewoo FR-171 Manuel utilisateur

Daewoo

Daewoo FR-460DLX Manuel utilisateur

Daewoo

Daewoo FRS-U20IA Series Manuel utilisateur

Daewoo

Daewoo RF-405N Manuel utilisateur

Daewoo

Daewoo FR-063(SLK) Manuel utilisateur

Daewoo

Daewoo FRS-263 Series Manuel utilisateur

Daewoo

Daewoo FR-2702 Manuel utilisateur

Daewoo

Daewoo RN408N Serie Manuel utilisateur

Daewoo

Daewoo FR-490M Manuel utilisateur

Daewoo

Daewoo FR120RC Manuel utilisateur

Daewoo

Daewoo FRS-2221EAL Manuel utilisateur

Daewoo

Daewoo FRN-U20DD Series Manuel utilisateur

Daewoo

Daewoo KUS-T24HBR Manuel utilisateur

Daewoo

Daewoo FRM-405 SERIES Manuel utilisateur

Daewoo

Daewoo FRAH52WDS3 Instructions d'installation

Daewoo

Daewoo FRS-250BAL Manuel utilisateur

Daewoo

Daewoo ERF-368MBW Manuel utilisateur

Daewoo

Daewoo FRS-T24DA Series Manuel utilisateur

Daewoo

Daewoo FN15AW Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
