D-Link DIS-2650AP Manuel utilisateur

Quick Installation Guide

Wireless AC1200 Wave 2 Industrial Indoor Access Point

DIS-2650AP

5G 2.4G ALARM POE PWR2 PWR1 STATUS SIGNAL

CONSOLE RESET LAN 2 LAN1/ POE

Additional documentation is also available on the D-Link website

Contents

English 1

Before You Begin Hardware Overview

This Quick Installation Guide gives you step-by-

step instructions for setting up your DIS-

2650AP Wireless Access Point. The model you

have purchased may appear slightly different

from the one shown in the illustrations. For

more detailed information about the router,

please refer to the User Manual.

Package Contents

This DIS-2650AP package includes the

following items:

• DIS-2650AP

• Quick Installation Guide

• DIN rail mounting kit

• 4 installation screws (3 x 7 mm)

• Bracket

If any of the above items are damaged or missing,

please contact your local D-Link reseller.

System Requirements

• Computers with Windows®, Macintosh®,

or Linux-based operating systems with an

installed Ethernet Adapter

Front Panel Features

4 5

6 7

DIS-2650AP

5G 2.4G ALARM POE PWR2 PWR1STATUS

SIGNAL

CONSOLE RESET

LAN2

LAN1/ POE

Figure 1: Front Panel

Feature

Description

Console

Console port which is used to

connect to the device using an

Port

RJ-45 to serial cable.

2 Reset Press and hold to perform a

Button factory reset.

LAN2

10/100/1000 Mbps Ethernet

LAN port.

4 LAN1/PoE PoE-capable Ethernet LAN port.

5 5G/2.4G A green LED indicates the

LEDDIS-2650AP is receiving power.

Alarm

A light indicates that the power

supply has failed.

PoE

Indicates whether a device is

receiving power on the PoE port.

PWR1/2

Indicates whether power sources

1 and 2 are connected.

Status

Indicates the device’s operational

status.

Signal

Indicates the strength of the

signal the device is receiving.

Table 1: Right Panel Feature Descriptions

ENGLISH

DIS-2650AP Quick Installation Guide 1

ENGLISH

Side Panel Features

1 2

Figure 2: Left Panel Interface Connectors

Connector

Description

1 Switch Ground This is used to connect

the device to ground.

This is used to connect the

2 Terminal Block device to external power sources

and an alarm relay.

Table 2: Side Panel Features

Hardware Installation

Before You Begin

Observe the following precautions to help

prevent shutdowns, equipment failures,

and personal injury:

• Install the DIS-2650AP in a cool and

dry place.

• Install the DIS-2650AP in a site free

from strong electromagnetic sources,

vibration, dust, excessive moisture,

and direct sunlight.

• Place antennas in an unobstructed area

with a clear signal. Avoid metal boxes,

brick walls, and other dense materials.

• Visually inspect the power connector

and make sure that it is fully secure.

• Do not stack any devices on top of

the DIS-2650AP.

Attach the External Antennas

The DIS-2650AP requires two external antennas to

function correctly. The included antennas are

interchangeable

1. Attach the two included antennas to

the RP-SMA connectors on the side

of the DIS-2650AP. Turn clockwise

to fasten the antennas.

2. Arrange the antennas so that they’re

pointing upwards and in a configuration

to receive optimal signals.

Mounting the Device on a Wall

The DIS-2650AP can be installed on a

solid surface by using the included wall

mounting plates attached to the back of

the device. Use the following instructions

to install the DIS-2650AP on a wall:

1. Align the cross-section of the mounting

plates with the openings on the back of

the device. Secure the plates with the

included mounting screws.

Figure 3: Attaching Mounting Plates

2. Remove the DIN rail mounting clip from

the back of the device (if present).

2 DIS-2650AP Quick Installation Guide

3. Place the mounting brackets

(attached to the device) on the

location where you want to mount it,

and use the brackets as a guide to

mark where to drill the screw holes.

4. Drill holes on the marks and insert

wall anchors appropriate for the

material of the wall.

5. Align the device with the wall anchors and

secure it to the wall using appropriate

screws for the wall anchors.

Installing the Device on a DIN Rail

The DIS-2650AP can be mounted on a standard

DIN rail using the included DIN mounting kit.

Use the following instructions to install the

DIS-2650AP on a rail:

1. Check that the DIN rail is installed properly

using at least two screws on each end.

2. Fasten the DIN mounting clip to the

rear panel of the device using the

included mounting screws.

Installing the Device into a Rack

The DIS-2650AP can be mounted on a

standard rack using the included mounting

plates. To install the device on a rack:

Attach the mounting brackets to the rear

panel of the device using the

provided installation screws.

Figure 5: Installing onto a Rack

2. Use the provided screws to attach the

two rear mounting plates to the rack.

Figure 4: Hooking onto the Rail

3. Position the DIS-2650AP against the

rail, then tilt it upwards and hook the

DIN rail clip on the back of the device

against the rail. Snap the device into

place to complete the installation.

Grounding the Device

To use the DIS-2650AP safely, it needs to

be grounded. Please complete these

steps before powering on the device.

1. Remove the grounding screw from

the top of the DIS-2650AP and place

the grounding cable lug ring on top

of the grounding screw opening.

2. Insert the grounding screw back into

the grounding screw opening and

use a screwdriver to tighten the

grounding screw, securing the

grounding cable to the DIS-2650AP.

3. Attach the terminal lug ring at the

other end of the grounding cable to

an appropriate grounding source.

DIS-2650AP Quick Installation Guide 3

Powering the Device

The DIS-2650AP can be powered with an 802.3at

PoE source or by using the built-in terminal

adapter. This allows dual power inputs using

wires from the power source(s) to be screwed

into the terminal connections.

Using the Terminal Connections

Before continuing, consult the diagram

below to decide which wires from the

power source need to connect to which

contacts on the terminal block. Note

that two power sources can be used;

one inserted into V1-/V1+ (labeled

PWR 1) and the other inserted into

V2-/V2+ (labeled PWR2).

Figure 6: Terminal Block Diagram

2. Use a lever to remove the terminal

block from the switch.

Figure 7: Removing the Terminal Block

3. Use a flat head screwdriver to unscrew the

terminal connections that you wish to use.

4. Insert the wires into the terminal

connectiosn and use the screwdriver to

tighten the screws to secure the wires.

Figure 8: Connecting a Power

Source to the Terminal Block

5. Re-insert the terminal block into the

socket on the device.

Connecting Devices

The Ethernet port can be connected to an

end device. Use a standard Category

5/5e/6 RJ-45 Ethernet cable to connect

the end device to the DIS-2650AP.

The port will auto-negotiate to the highest

possible port speed based on the

connected device.

Management Options

The DIS-2650AP can be managed by

using the Web User Interface (Web UI),

the Nuclias Connect app, or the console

port or Telnet management interfaces.

4 DIS-2650AP Quick Installation Guide

Nuclias Connect App Configuration

1. Download the free Nuclias Connect

app from the App Store or Google Play

by searching for Nuclias Connect or

by scanning the QR code below.

2. Open the Nuclias Connect app and

follow the onscreen instructions to

discover and set up your device.

Manual Configuration

Note: The management computer, DHCP server

and DIS-2650AP must be in the same subnet.

Use one of the following methods to

access the web user interface:

Connecting through Ethernet

1. Use an Ethernet cable to connect the

DIS-2650AP to the management

computer, or to the switch or router the

management computer is connected to.

2. Manage the access point from a

computer. Enter dis2650ap.local in

the address field of your browser.

3. Log in to the administration user

interface. The default information is:

Username: admin

Password: admin

Connecting Wirelessly

1. Connect the management computer to the

default SSID of the DIS-2650AP, “dlink.”

2. Manage the access point from a

computer. Enter dis2650ap.local in

the address field of your browser.

3. Log in to the administration user

interface. The default information is:

Username: admin

Password: admin

Additional Information

If you are encountering problems setting up

your network, please refer to the user manual.

Additional help is available online. To find

out more about D-Link products or marketing

information, please visit the D-Link support

website at http://dlink.com/support/.

Warranty Information

The D-Link Limited Lifetime Warranty

information is available at the following

website: http://warranty.dlink.com/.

ENGLISH

DIS-2650AP Quick Installation Guide 5

Appendix - Statements

ErP Power Usage

This device is an Energy Related Product (ErP) that automatically switches to a power-saving

Network Standby mode within 1 minute of no packets being transmitted. It can also be turned off

through a power switch to save energy when it is not needed.

Network Standby: 3.12 watts

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Non-modifications Statement:

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

Caution:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other

antenna or transmitter except in accordance with FCC multi-transmitter product procedures. For

product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other

channels is not possible.

Note

The country code selection is for non-USA models only and is not available to all USA models. Per FCC

regulations, all WiFi product marketed in the USA must be fixed to USA operational channels only.

Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

RF Frequency Requirements

This device is for indoor use only when using all channels in the 5.15 to 5.25 GHz frequency range.

High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz

bands. These radar stations can cause interference with and/or damage this device. This device

will not operate on channels which overlap the 5600-5650 MHz band.

It is restricted to indoor environments only.

IMPORTANT NOTICE:

Innovation, Science and Economic Development Canada (ISED) Statement:

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Innovation, Science and Economic Development Canada (ISED) Statement:

This device complies with ISED licence-exempt RSS standard(s). Operation is subject to the

following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d’ISED applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes :

(1) l’appareil ne doit pas produire de brouillage, et

(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si

le brouillage est susceptible d’en compromettre le fonctionnement.

(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential

for harmful interference to co-channel mobile satellite systems;

(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une

utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de

satellites mobiles utilisant les mêmes canaux;

Operations in the 5.25-5.35 GHz band are restricted to indoor usage only.

Les opérations dans la bande de 5.25-5.35 GHz sont limités à un usage intérieur seulement.

Radiation Exposure Statement

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance 20 cm

between the radiator and your body.

Déclaration d’exposition aux radiations

Cet équipement est conforme aux limites d’exposition aux rayonnements ISED établies pour un

environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm

de distance entre la source de rayonnement et votre corps.

Japan Voluntary Control Council for Interference Statement

この装置は、クラス B 情報技術装置です。この装置は、家庭環境で使用することを目的としていますが、こ

の装置がラジオやテレビジョン受信機に近接して使用されると、受信障害を引き起こすことがあります。

取扱説明書に従って正しい取り扱いをして下さい。

Japan Voluntary Control Council for Interference Statement

This is a Class B product based on the standard of the VCCI Council. If this is used near a

radio or television receiver in a domestic environment, it may cause radio interference.

Install and use the equipment according to the instruction manual.

電波法により 5GHz 帯は屋内使用に限ります。

Product and Warranty Information

To find out more about D-Link Nuclias product or marketing information, please visit the

website http://www.dlink.com or https://www.nuclias.com.

The D-Link Limited Lifetime Warranty information is

available at http://www.dlink.com/warranty

VCCI-B

低功率電波輻射性電機管理辦法

第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、

加大功率或變更原設計之特性及功能。

第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停

用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。

低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

==========================================================================

For UNII 產品(5GHz WLAN/WIFI)

==========================================================================

1. 使用此產品時應避免影響附近雷達系統之操作。

Autres manuels pour DIS-2650AP

Table des matières

Autres manuels D-Link Point d'accès sans fil

D-Link

D-Link DAP-1360U Manuel utilisateur

D-Link

D-Link DBT-900AP Manuel utilisateur

D-Link

D-Link AirPremier N DAP-3525 Manuel utilisateur

D-Link

D-Link DWL-1000AP Manuel utilisateur

D-Link

D-Link DAP-1150 Manuel utilisateur

D-Link

D-Link AirPremier DWL-2210AP Manuel utilisateur

D-Link

D-Link DAP-2620 Manuel utilisateur

D-Link

D-Link AirPremier DWL-7700AP Manuel utilisateur

D-Link

D-Link DAP-1260L Manuel utilisateur

D-Link

D-Link AirPlus Xtreme G DWL-2000AP Manuel utilisateur

D-Link

D-Link DAP-3520 - AirPremier N Dual Band Exterior PoE Access... Manuel utilisateur

D-Link

D-Link DAP-2230 Feuille d'instructions

D-Link

D-Link DAP-1360 Manuel utilisateur

D-Link

D-Link Nuclias Cloud DBA-X1230P Manuel utilisateur

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

D-Link

D-Link DAP-1350 Manuel

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

D-Link

D-Link DI-713 Manuel utilisateur

D-Link

D-Link AirPremier N DAP-2690 Manuel utilisateur

D-Link

D-Link DAP-2610 Manuel utilisateur

D-Link

D-Link DAP-1360 Manuel utilisateur

D-Link

D-Link Nuclias Connect DAP-2622 Manuel utilisateur

D-Link

D-Link DWL-8620AP Manuel utilisateur

D-Link

D-Link DWL-700AP - Air - Wireless Bridge Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur

EnGenius

EnGenius EAP350 Manuel utilisateur
