Quick Installation Guide
DAP-400P
Wireless AC1300 MU-MIMO Dual Band PoE
Access Point / Router
DAP-400P Quick Installation Guide
BEFORE YOU BEGIN
Delivery Package
•Access point DAP-400P
•Wall mounting bracket with mounting kit
•“Quick Installation Guide” (brochure).
f any of the items are missing, please contact your reseller.
The “User Manual” and “Quick Installation Guide” documents are available
on D-Link website (see www.dlink.ru).
!Using a power supply with a different voltage rating than the one
included will cause damage and void the warranty for this product.
2
DAP-400P Quick Installation Guide
Default Settings
IP add ess of device 192.168.0.50
Use name (login) admin
Passwo d admin
Name of wi eless netwo k
(SSID)
2.4GHz DAP-400P
5GHz DAP-400P-5G
Netwo k key (PSK passwo d)
see WPS P N on the barcode
label on the bottom panel of
the device
3
DAP-400P Quick Installation Guide
System Requirements and Equipment
•A computer with any operating system that supports a web browser.
•A web browser to access the web-based interface of the access point:
◦Apple Safari 8 and later
◦Google Chrome 48 and later
◦Microsoft nternet Explorer 10 and later
◦Microsoft Edge 20.10240 and later
◦Mozilla Firefox 44 and later
◦Opera 35 and later.
•A N C (Ethernet or Wi-Fi adapter) to connect to the access point.
•An 802.11a, b, g, n, or ac Wi-Fi adapter to create a wireless network.
4
DAP-400P Quick Installation Guide
CONNECTING TO PC
PC with Ethernet Adapter
1. Сonnect an Ethernet cable between the LAN port of the access point and
the Ethernet port of your PC.
2. For a switch supporting PoE: connect an Ethernet cable between the
PoE-enabled switch and the WAN port of the access point.
3. For a switch not supporting PoE or router: connect an Ethernet cable
between the switch or router and any Ethernet port of the access point.
4. Connect the power adapter (not included in the delivery package) to the
power connector port on the back panel of the access point, then plug the
power adapter into an electrical outlet or power strip.
Now you need to configure an P address for the Ethernet adapter of your PC.
5
DAP-400P Quick Installation Guide
Configuring IP Address in S Windows 7
1. Click the Sta t button and proceed to the Cont ol Panel window.
2. Select the Netwo k and Sha ing Cente section. ( f the Control Panel
has the category view (the Catego y value is selected from the View by
drop-down list in the top right corner of the window), choose the View
netwo k status and tasks line under the Netwo k and Inte net
section.)
3. n the menu located on the left part of the window, select the Change
adapte settings line.
4. n the opened window, right-click the relevant Local A ea Connection
icon and select the P ope ties line in the menu displayed.
5. n the Local A ea Connection P ope ties window, on the
Netwo king tab, select the Inte net P otocol Ve sion 4 (TCP/IPv4)
line. Click the P ope ties button.
6
DAP-400P Quick Installation Guide
6. Select the Use the following IP add ess radio button and enter the
value 192.168.0.51 in the IP add ess field. The Subnet mask
field will be filled in automatically. Click the OK button.
7. Click the OK button in the connection properties window.
Now you can connect to the web-based interface of DAP-400P for configuring all
needed parameters. To gain access to an external network (to the nternet), you
also need to specify the default gateway and the addresses of DNS servers.
7
DAP-400P Quick Installation Guide
Configuring IP Address in S Windows 10
1. Click the Sta t button and proceed to the Settings window.
2. Select the Netwo k & Inte net section.
3. n the Change you netwo k settings section, select the Change
adapte options line.
4. n the opened window, right-click the relevant Local A ea Connection
icon and select the P ope ties line in the menu displayed.
5. n the Local A ea Connection P ope ties window, on the
Netwo king tab, select the Inte net P otocol Ve sion 4 (TCP/IPv4)
line. Click the P ope ties button.
8
DAP-400P Quick Installation Guide
6. Select the Use the following IP add ess radio button and enter the
value 192.168.0.51 in the IP add ess field. The Subnet mask
field will be filled in automatically. Click the OK button.
7. Click the Close button in the connection properties window.
Now you can connect to the web-based interface of DAP-400P for configuring
all needed parameters. To gain access to an external network (to the nternet),
you also need to specify the default gateway and the addresses of DNS servers.
9
DAP-400P Quick Installation Guide
PC with Wi-Fi Adapter
1. For a switch supporting PoE: connect an Ethernet cable between the
PoE-enabled switch and the WAN port of the access point.
2. For a switch not supporting PoE or router: connect an Ethernet cable
between the switch or router and any Ethernet port of the access point.
3. Connect the power adapter (not included in the delivery package) to the
power connector port on the back panel of the access point, then plug the
power adapter into an electrical outlet or power strip.
4. Make sure that the Wi-Fi adapter of your PC is on. As a rule, modern
notebooks with built-in wireless N Cs are equipped with a button or
switch that turns on/off the wireless adapter (refer to your PC
documents). f your PC is equipped with a pluggable wireless N C, install
the software provided with your Wi-Fi adapter.
Now you should configure your Wi-Fi adapter.
