D-Link AirPro DWL-6000AP Manuel utilisateur

DWL-6000APDWL-6000AP

DWL-6000AP

2.4 GHz / 5 GHz Multimode

Manan

anan

anuu

ualal

alal

BuildinBuildin

Building Ng N

g Ng N

g Networks fetworks f

etworks fetworks f

etworks for Por P

or Por P

or Peopleeople

eopleeople

eople

D-LinkD-Link

D-Link

AirAir

Air

PrPr

Proo

Wireless Access Point

TMTM

ConCon

Contenten

tenten

tentsts

tsts

Package Contents ................................................................................3

Introduction............................................................................................4

Wireless Basics ....................................................................................8

Getting Started .................................................................................... 11

Using the Configuration Menu..............................................................12

Networking Basics ..............................................................................24

Troubleshooting...................................................................................53

Technical Specifications ......................................................................59

Contacting Technical Support ..............................................................62

Warranty ..............................................................................................63

Registration ........................................................................................66

ConCon

Contenten

tenten

tents ots o

ts ots o

ts of Pf P

f Pf P

f Packack

ackack

ackagag

agag

age:e:

e:e:

•D-Link

Air

Pro

DWL-6000AP 2.4GHz/

5GHz Multimode Wireless Access Point

•Power Adapter – 5V DC, 2.5A

•Manual on CD

•Quick Installation Guide

•Ethernet Cable

Note: Using a power supply with a different voltage rating than the one included with

the DWL-6000AP will cause damage and void the warranty for this product.

If any of the above items are missing, please contact your reseller.

System Requirements For Configuration:System Requirements For Configuration:

System Requirements For Configuration:

•Computer with Windows, Macintosh, or Linux-based

operating system with an installed Ethernet adapter

•Internet Explorer or Netscape Navigator version 4.0 or

above, with JavaScript enabled

Packack

ackack

ackagag

agag

age Cone Con

e Cone Con

e Contenten

tenten

tentsts

tsts

InIn

Intrtr

trtr

trodod

odod

oduu

ucticti

cticti

ctionon

onon

The new D-Link

Air

Pro DWL-6000AP Multimode Wireless Access Point is a

multimode access point that simultaneously serves both 802.11a wireless

connectivity at up to 54 Mbps (108 Mbps in

Turbo mode

) and 802.11b wireless

connectivity at up to 11Mbps (22 Mbps with D-Link

Air

Plus products

In addition to identifying and communicating with other 802.11a and 802.11b

wireless devices, the D-Link

Air

Pro DWL-6000AP access point also builds a

bridge between wireless and wired network segments with its integrated 10/

100 Ethernet port. The multimode access point will automatically obtain an IP

address and forward additional IP addresses to multiple clients for a seamless

Ethernet network connection and shared Internet access.

Armed with powerful management and security capabilities, the D-Link

Air

Pro

DWL-6000AP has an intuitive and secure web-based interface that is powered

by an embedded web server. You can also manage your network with the AP

Manager which is available on the CD that is included in your package. Advanced

security is offered 802.1x support.

After completing the steps outlined in the

Quick Installation Guide

(included in

your package) not only will you have the ability to share information and

resources, but you will also be able to enjoy the freedom that wireless networking

delivers, at speeds capable of handling a video stream.

When used with other D-Link

Air

Pro products.

The DWL-6000AP is compatible with most popular operating systems, including

Macintosh, Linux and Windows, and can be easily integrated into a large network.

This Manual is designed to help you connect the Access Point with the D-Link

2.4GHz

Air

Plus or 5GHz

Air

Pro Wireless Adapters into an existing network.

Please

take a look at the Getting Started section in this manual to see an example of an

Infrastructure network using the DWL-6000AP.

ConnectionsConnections

Connections ResetReset

ResetReset

Reset

MDI RJ-45 EthMDI RJ-45 Eth

MDI RJ-45 Ethernern

ernern

ernet Pet P

et Pet P

et Portort

ortort

ort PP

Power Receptorower Receptor

ower Receptorower Receptor

ower Receptor

•Straight-ThroughStraight-Through

Straight-ThroughStraight-Through

Straight-Through cable is required when

connecting to a router or switch

•Cross-OverCross-Over

Cross-OverCross-Over

Cross-Over cable is required when connecting directly to an ethernet adapter on a

computer

•Supports Data Transfer Rates of up to 108 Mbps at 5GHz in Turbo mode

•Supports Data Transfer Rates of up to 22 Mbps at 2.4GHz with D-Link

Air

Plus

products

•Wireless Range of up to 900 feet*

•Fully 802.11a and 802.11b compatible

•Supports up to 256-bit WEP Encryption at 2.4GHz and up to 152-bit with

Enhanced Dynamic Keying at 5 GHz

•Less Interference with a total of Eleven Non-Overlapping Channels

•Utilizes Direct Sequence Spread Spectrum (DSSS) and Packet Binary

Convolutional Code (PBCC) at 2.4GHz

•Utilizes Orthogonal Frequency Division Multiplexing (OFDM) at 5GHz

Features & BenefitsFeatures & Benefits

Features & Benefits

*Architectural and environmental factors may adversely affect range.

•Supports 802.1x Authentication when used with EAP-MD5 or EAP-TLS

•Supports easy firmware upgrade

•AP Manager on the Installation CD

• Supports AP Discover and easy IP Configuration

• Bulk Firmware upgrade

• Bulk device setting (WEP key, ACL, MD5 Database and others)

•Supports D-View and Open View for Enterprise application

•Supports Telnet Configuration

•MAC layer ACL (Access Control List) allows 16 MAC entries

•Enable/Disable SSID Broadcast

•PSPF-(Public Switch Packet Filter) - segregates the wireless segment from

the LAN

•Supports TPC and DFS function for worldwide operations

•Internal Station Connection Option - segregates the 802.11a segment from

the 802.11b segment

•3 methods of network configuration: Web-based management, APManager

(available on the Installation CD that came with your purchase), and Telnet.

•3 Year Warranty (USA only)

LEDSLEDS

LEDS

LED stands for Light-Emitting Diode. The DWL-6000AP Wireless Access

Point has 5 Green LEDs as shown below:

D-Link

Air

Pro

wireless products are based on industry standards to provide easy-to-

use and compatible high-speed wireless connectivity within your home, business or

public access wireless networks. Strictly adhering to the IEEE standard, the D-Link

Air

Pro wireless family of products will allow you to securely access the data you

want, when and where you want it. You will be able to enjoy the freedom that wireless

networking delivers.

A wireless local area network (WLAN) is a cellular computer network that transmits

and receives data with radio signals instead of wires. Wireless LANs are used

increasingly in both home and office environments, and public areas such as airports,

coffee shops and universities. Innovative ways to utilize WLAN technology are helping

people to work and communicate

WirWir

Wireless Basieless Basi

eless Basieless Basi

eless Basicscs

cscs

Wireless BasicsWireless Basics

Wireless Basics

more efficiently. Increased mobility and the absence of cabling and other

fixed infrastructure have proven to be beneficial for many users.

Wireless users can use the same applications they use on a wired network.

Wireless adapter cards used on laptop and desktop systems support the

same protocols as Ethernet adapter cards.

Under many circumstances, it may be desirable for mobile network devices

to link to a conventional Ethernet LAN in order to use servers, printers or an

Internet connection supplied through the wired LAN. A Wireless Access Point

(AP) is a device used to provide this link.

People use wireless LAN technology for many different purposes:

MobilityMobility

Mobility - Productivity increases when people have access to data in any

location within the operating range of the WLAN. Management decisions

based on real-time information can significantly improve worker efficiency.

Low ImplemLow Implem

Low Implemenen

enen

entatitati

tatitati

tation Costson Costs

on Costson Costs

on Costs –WLANs (Wireless Local Area Networks) are

easy to set up, manage, change and relocate. Networks that frequently

change, both physically and logically, can benefit from WLANs ease of

implementation. WLANs can operate in locations where installation of wiring

may be impractical.

Installation Speed and SimplicityInstallation Speed and Simplicity

Installation Speed and Simplicity - Installing a wireless LAN system can

be fast and easy and can eliminate the need to pull cable through walls and

ceilings.

Network ExpansionNetwork Expansion

Network Expansion - Wireless technology allows the network to go where

wires cannot go.

ScalabilityScalability

Scalability – Wireless Local Area Networks (WLANs) can be configured in a

variety of topologies to meet the needs of specific applications and

installations. Configurations are easily changed and range from peer-to-peer

networks suitable for a small number of users to full infrastructure networks

of thousands of users that allow roaming over a broad area.

Wireless BasicsWireless Basics

Wireless Basics

The DWL-6000AP is compatible with the D-Link Air

Pro

802.11a family of

products, which include

♦5GHz Wireless Cardbus Adapters used with laptop computers

(D-Link DWL-A650)

♦5GHz Wireless PCI Adapters used with desktop computers

(D-Link DWL-A520)

The DWL-6000AP is also compatible with the D-Link

Air

Plus

802.11b Wireless

Family of LAN products, which include

♦Enhanced 2.4GHz Wireless Cardbus Adapters used with laptop

computers (D-Link DWL-650+)

♦Enhanced 2.4GHz Wireless PCI cards used with desktop computers

(D-Link DWL-520+)

StanStan

Standd

darar

arar

ards-Based Tds-Based T

ds-Based Tds-Based T

ds-Based Technechn

echnechn

echnologyology

ologyology

ology

The versatile DWL-6000AP Multimode Wireless Access Point integrates both

802.11a and 802.11b standards into a single unit.

The IEEE 802.11a standard designates that devices operate at an optimal

data rate of 54 Mbps (108Mbps in proprietary

Turbo

mode.) This means you

will be able to transfer large files quickly or even watch a movie in MPEG

format over your network without noticeable delays. This technology works

by transmitting high-speed digital data over a radio wave utilizing OFDM

(Orthogonal Frequency Division Multiplexing) technology. OFDM works by

splitting the radio signal into multiple smaller sub-signals that are then

transmitted simultaneously at different frequencies to the receiver. OFDM

reduces the amount of crosstalk (interference) in signal transmissions.

D-Link

AirPro

products will automatically sense the best possible connection

speed to ensure the greatest speed and range possible.

Based on the IEEE 802.11b standard, the DWL-6000AP is also interoperable

with existing compatible 2.4GHz wireless technology with data transfer

speeds of up to 22Mbps (with D-Link

Air

Plus Family of Wireless devices,) as

well as standard 802.11b technology (with D-Link

Air

Family of Wireless

devices), with speeds of up to 11Mbps.

Supports 802.1x Authentication to prevent breeches in security. In

conjunction with EAP software, 802.1x Authentication verifies client identity

through a Radius Server to prevent unknown clients from accessing the

network.

Wireless BasicsWireless Basics

Wireless Basics

Installation ConsiderationsInstallation Considerations

Installation Considerations

Designed to go up to 328 feet (100 meters) indoors, D-Link

Air

Pro DWL-

6000AP lets you access your network, using a wireless connection, from

virtually anywhere. Keep in mind, however, that the number, thickness and

location of walls, ceilings or other objects that the wireless signals must

pass through may limit the range. Typical ranges vary depending on the

types of materials and background RF (radio frequency) noise in your home

or business. The key to maximizing wireless range is to follow these basic

guidelines:

1. Keep the number of walls and ceilings between the DWL-6000AP and

your receiving device (e.g., the DWL-A650) to a minimum - each wall or

ceiling can reduce your D-Link

Air

Pro Wireless product’s range from 3-90

feet (1-30 meters.) Position your Access Points, Residential Gateways,

and computers so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between Access Points, Residential Gateways

(routers) and computers. A wall that is 1.5 feet thick (.5 meters), at a 45-

degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree

angle it looks over 42 feet (14 meters) thick! Try to make sure that the

Access Points and adapters are positioned so that the signal will travel

straight through a wall or ceiling for better reception.

3. Building Materials make a difference - a solid metal door or aluminum

studs may have a negative effect on range. Try to position Access Points,

and computers with wireless adapters so that the signal passes through

drywall or open doorways and not other materials.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical

devices or appliances that generate RF noise.

For the average home or office, signal range should not be an issue. If you

experience low or no signal strength in areas of your home or office that you

wish to access, consider positioning the Access Point in a location directly

between the computers with wireless adapters. Additional Access Points

can be connected to provide better coverage in rooms or offices where the

signal does not appear as strong as desired.

Autres manuels pour AirPro DWL-6000AP

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels D-Link Point d'accès sans fil

D-Link

D-Link DAP-2230 Manuel utilisateur

D-Link

D-Link Rangebooster N 650 Access Point DAP-1353 Manuel utilisateur

D-Link

D-Link D DWL-G700AP DWL-G700AP Manuel utilisateur

D-Link

D-Link DAP-2620 Manuel utilisateur

D-Link

D-Link Air Premier DAP-2695 Manuel utilisateur

D-Link

D-Link DWL-3200AP - AirPremier - Wireless Access... Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

D-Link

D-Link AirPro DWL-6000AP Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

D-Link

D-Link DWL-1000AP Manuel utilisateur

D-Link

D-Link DWS-4000 Series Manuel d'installation

D-Link

D-Link DWL-1000AP Manuel utilisateur

D-Link

D-Link AirPremier DWL-1700AP Manuel utilisateur

D-Link

D-Link DWL-7200AP - AirPremier AG - Wireless Access... Manuel utilisateur

D-Link

D-Link DWL-700AP - Air - Wireless Bridge Manuel utilisateur

D-Link

D-Link D DWL-8200AP DWL-8200AP Manuel utilisateur

D-Link

D-Link Rangebooster N 650 Access Point DAP-1353 Manuel utilisateur

D-Link

D-Link DWL-3610AP Manuel utilisateur

D-Link

D-Link DAP-3310 Manuel utilisateur

D-Link

D-Link DWL-8200AP - AirPremier Managed Dualband Access... Manuel utilisateur

D-Link

D-Link DWL-7230AP - xStack - Wireless Access Point Manuel utilisateur

D-Link

D-Link NUCLIAS CONNECT DAP-2680 Manuel utilisateur

D-Link

D-Link DWL-1000AP Manuel utilisateur

D-Link

D-Link DAP-2553 - Wireless N Dual Band Gigabit Access... Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Cisco

Cisco Aironet 1550 Series Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur

EnGenius

EnGenius EAP350 Manuel utilisateur
