D-Link VisualStream DSB-C110 Manuel utilisateur

D-Link VisualStreamTM

DSB-C110 PC Camera

Manual

(10/07/04)

Building Networks for People

Contents

Package Contents ------------------------------------------------------------------------------- 4

Introduction------------------------------------------------------------------------------------------------------------5

Getting To Know Your VisualStreamTM PC Camera---------------------------------------------------------5

Features And Benefits----------------------------------------------------------------------------------------------5

Installing ArcSoft®PhotoImpression and VideoImpression ----------------------- 6

How to Use Your D-Link VisualStreamTM Camera ------------------------------------- 8

Setting the Focus ---------------------------------------------------------------------------------------------------8

Preview-----------------------------------------------------------------------------------------------------------------8

Record and Playback-----------------------------------------------------------------------------------------------8

How to Install Microsoft NetMeeting ------------------------------------------------------ 9

Using Your PC Camera With Microsoft NetMeeting ------------------------------------------------------10

How to Install MSN Messenger------------------------------------------------------------ 10

Using Your PC Camera With Microsoft NetMeeting ------------------------------------------------------ 11

Getting Started With VideoImpression 1.6 -------------------------------------------- 11

Working with Albums ---------------------------------------------------------------------------------------------12

Working with the Storyboard------------------------------------------------------------------------------------ 14

Editing Images -----------------------------------------------------------------------------------------------------15

Editing a Video -----------------------------------------------------------------------------------------------------16

Editing Audio--------------------------------------------------------------------------------------------------------17

Printing an Image From a Video File ------------------------------------------------------------------------- 18

Saving a Movie-----------------------------------------------------------------------------------------------------18

Getting Started With PhotoImpression 3.0 -------------------------------------------- 19

Opening an Image From a Disk Drive------------------------------------------------------------------------ 21

Acquiring Images From a TWAIN Device ------------------------------------------------------------------- 21

Downloading Images From the Internet ---------------------------------------------------------------------21

Working with Albums ---------------------------------------------------------------------------------------------22

Editing Images -----------------------------------------------------------------------------------------------------22

Creative Project Templates ------------------------------------------------------------------------------------- 25

Saving Images ----------------------------------------------------------------------------------------------------- 26

Printing Images ---------------------------------------------------------------------------------------------------- 26

Getting Help--------------------------------------------------------------------------------------------------------- 27

Warranty Information ------------------------------------------------------------------------ 28

Registration ------------------------------------------------------------------------------------- 31

Contents of Package

D-Link VisualStreamTM DSB-C110 100K Pixel PC Camera

Manual on CD

Quick Installation Guide

If any of the above items are missing, please contact your reseller.

System Requirements

Computer with Windows Operating System and available USB port

Package Contents

Introduction

Thank you for purchasing the D-Link DSB-C110 VisualStreamTM PC Camera. The DSB-C110 is a

great addition to your home PC, enabling you to personalize your e-communications. Talk to your

family, friends, and colleagues face-to-face over the Internet, create videos, digital photo albums, and

more, all the software needed to start creating digital content and enabling video communication is

included. This manual will guide you through the features of your new PC Camera and provides step-

by-step instructions for getting you started with the bundled Arcsoft®software.

Manual

Focus Ring

Swivel Base

Features And Benefits

Indicator Light

True 352 X 288 Pixels Resolution

ArcSoft®Software Included

Video Chat and Conferencing Capability with Microsoft NetMeeting

Add Video Messages to Your Email

Create VideoAlbums and Video Presentations

Create Personalized Greeting Cards, Calendars, and More

Getting To Know Your VisualStreamTM PC Camera

Installing ArcSoft®PhotoImpression™ and

VideoImpression™

Click OK

Click Next

Click D-Link®CIF WebCam Driver

Click Install Software

Click Install ArcSoft®PhotoImpression™

Click Next

Click Finish

Click Next

ArcSoft®PhotoImpression is now ready to use. Please repeat these steps to install ArcSoft

VideoImpression software.

Click Next

Click Yes

Setting the Focus

1. Start VideoImpression.

2. Select “New. “

3. Select “Capture Video.” A live preview from the video camera will appear in the

window.

4. Turn the manual focus ring until the image becomes sharp.

Preview

1. Follow steps 1~3 in the “Setting the Focus” section of this manual to

enable a live preview.

2. To stop the preview, click on “Stop” ( ).

3. To resume the preview, click on “Preview” ( ).

How To Use Your D-Link VisualStreamTM Camera

Record and Playback

* Video Recording:

1. Follow steps 1~3 in the “Setting the Focus” section to enable a live preview.

2. To start video recording, click on “Record” ( ).

3. To stop video recording, click on “Stop” ( ) or ESC.

4. To save captured video, click on “Save” ( ).

* Playback:

1. In VideoImpression, select “New.”

2. Select the source for playback by clicking on “Add” or from the drop down menu.

The selected source appears in the album.

3. Double click the source to add it to the Edit Board.

4. To replay captured video, click on “Play.”

For Windows 98SE/Me/2000 Users

Click Start, point to Programs, point to Accessories, point to Internet Tools and then click

NetMeeting.

For Windows 2000 Users

Click Start, point to Programs, point to Accessories, point to Communications, and click

Netmeeting.

For Windows XP Users

Click Start, point to Run, type in conf in the dialog box and click OK.

Proceed with steps 1-4 for Microsoft NetMeeting Installation

1. Click Next, type the appropriate information in the First Name, Last Name, E-Mail

Address, Location, and Comments dialog boxes, and then click Next.NOTE: The

Location and Comments information is optional.

2. Click Next, click and select the Log into a directory server when NetMeeting starts

check box (this is optional), and then type the name of the directory server in the

Server Name dialog box. If you do not want your name to be visible in the directory,

click and select the Do not list my name in this directory check box.

3. Click Next, and then select the appropriate location for the shortcuts.

4. Click Next, follow the instructions in the Audio Tuning Wizard, and then click Finish.

How To Install Microsoft NetMeeting

After you run NetMeeting for the first time, you can modify the information you entered

about yourself or the directory server name that you want to connect to. To do so, click

Options on the Tools menu, click the General tab, and then enter the appropriate

information.Also, you can run the Audio Tuning Wizard again, and to do so, click Audio

Tuning Wizard on the Tools menu.

If you can’t install the NetMeeting from your PC directly, please log on to http://

www.microsoft.com/windows/netmeeting/to downloaad.

Using Your PC Camera With Microsoft NetMeeting

1. Plug the PC camera into your PC first.

2. Click the NetMeeting” to go to the main screen, and then click “Start

Video” button, then you can start working with NetMeeting.

If you need more information or instruction on how to use a specific feature

or tool, click the “Help” button in the upper right-hand comer of the screen.

How To Install MSN Messenger

For Windows 98SE/Me/2000 Users

Please log on to http://messenger.msn.com to download.

After the installation package is downloaded to your computer, follow the instructions to

install MSN Messenger.

After the installation is completed, click Start, point to Programs, and click Windows

Messenger.

For Windows XP Users

Click Start, point to Programs, and click Windows Messenger.

After you run Messenger for the first time, you can add friends to your list and send

instant messages.
