Before You Begin

You must have at least the following:

zPentium III 500 MHz, Celeron, AMD Athlon processor, or higher

z64MB RAM (or minimum OS requirement whichever is higher)

zMicrosoft Windows XP/2000/ME/98SE

zMicrosoft DirectX 8.1b or higher

zUpdate Service Pack

z200MB free hard drive space

zCD-ROM drive

zUSB Port (USB specificaiton version 1.1)

z24Bit color display adapter

zWindows compatible sound card and speakers (full duplex sound card

recommended)

Check Your Package Contents

These are the items included with your purchase:

If any of the below items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice.

This product works with the

following operating system

software: Windows

XP/2000/ME/98SE

B-

320 U

B P

AMERA

DSB-C320

D-Link 330K Pixel USB

PC Camera

CD-ROM(containing Drivers, Application

Software, PDF Installation Guide, PDF

Manual, and Warranty)

USB 1.1 Cable

Run the Driver CD

before you install the

PC Camera.The Driver CD

contains an installation

program that simplifies

your installation process.

DSB-C320 Driver Installation

Please bring out the attached CD-ROM and follow the steps listed

below carefully to insure the installation of DSB-C320 will be

complete.

If the Autorun screen does not automatically start, click on Start >

Run, enter „D:\Autorun.exe” and click OK. „D” represents the letter

of your CD-ROM drive. Replace it if your CD-ROM drive is a different

letter.

Windows XP Users

Click Install DSB-C320

Driver

Insert the software CD into

CD-ROM. As you can see

the below picture,D-Link

DSB-C320 startup window

will be displayed.

Click Next

Windows XP Users (Continued)

Click Finish

Plug the USB cable into camera

and USB port on the PC directly.

When all setup

procedures are finished,

you MUST restart the

operating system manually

after you plugged the USB

cable into camera and USB

port as well as ran image

device sucessfully.

Please Click “Yes” to restart

the operating system.

Windows 2000 Users

Click Next

Click Finish

Click Yes

Windows 2000 Users (Continued)

Click Finish

Please Click “Yes” to restart

the operating system.

Plug the USB cable into camera

and USB port on the PC directly.

When all setup

procedures are finished,

you MUST restart the

operating system manually

after you plugged the USB

cable into camera and USB

port as well as ran image

device sucessfully.

Windows ME & 98 Users

The DSB-C320 driver installation will proceed automatically for Windows

ME & 98SE users.

Plug the USB cable into camera

and USB port on the PC directly.

Click Next

Click Finish

Windows ME & 98 Users(Continued)

Driver Installing is Completed!

To confirm the DSB-C320 is properly installed, click “START”

→”SETTINGS”→”CONTROL PANEL”. Double-click ”SYSTEM”. Select

the ”HARDWARE” tab and click the ”DEVICE MANAGER” button.

Confirm that „”D-Link DSB-C320” appears in the ”IMAGE DEVICES”

section.

Please Click “Yes” to restart

the operating system.

When all setup

procedures are finished,

you MUST restart the

operating system manually

after you plugged the USB

cable into camera and USB

port as well as ran image

device sucessfully.

Once properly installed, you are ready to start immediately capturing

images and a creating video with the DSB-C320.

Please refer to the DSB-C320 Manual on the CD included with this

product for information on how to install and use the VP-EYE 4.0

software.

Attention:

1.Make sure to install the driver and software BEFORE plugging the

camera into USB port.

2.We recommend plugging the cable connector to USB pot on PC directly

to avoid low voltage.

3.If a dialog box pops up and request to have the language setting file

replaced after plugging the camera into USB port, please simply click

“Yes” to continue.

4.Please download the latest update of “Service Pack” (from Start Æ

Windows Update) to keep the camera running smoothly.

5.If you have more than one image device in your system, please select

the “D-Link DSB-C320” as the PC Camera device. In this way, you can

use this camera to capture images.

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within Australia:

D-Link Technical Support over the Telephone:

1300-766-868

Monday to Friday 8:00am to 8:00pm EST

Saturday 9:00am to 1:00pm EST

D-Link Technical Support over the Internet:

http://www.dlink.com.au

email:[email protected]

Tech Support for customers within New Zealand:

D-Link Technical Support over the Telephone:

0800-900-900

Monday to Friday 8:30am to 8:30pm

Saturday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.nz

email:[email protected]
