D-Link DES-1008P Manuel utilisateur

D-Link

DES-1008P

8-Port 10/100Mbps

with 4 PoE Ports Switch

User Guide

FCC Warning

This equipment has been tested and found to comply with the

regulations for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in

accordance with this user guide, may cause harmful interference to

radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference, in which case the user will

be required to correct the interference at his/her own expense.

CE Mark Warning

This is a Class B product. In a domestic environment, this product

may cause radio interference, in which case the user may be required

to take adequate measures.

UL Warning

a) Elevated Operating Ambient Temperature- If installed in a closed

or multi-unit rack assembly, the operating ambient temperature of the

rack environment may be greater than room ambient. Therefore,

consideration should be given to installing the equipment in an

environment compatible with the manufacturer's maximum rated

ambient temperature (Tmra).

b) Reduced Air Flow- Installation of the equipment in a rack should

be such that the amount of air flow required for safe operation of the

equipment is not compromised.

c) Mechanical Loading- mounting of the equipment in the rack

should be such that a hazardous condition is not achieved due to

uneven mechanical loading.

d) Circuit Overloading- Consideration should be given to the

connection of the equipment to the supply circuit and the effect that

overloading of circuits might have on over current protection and

supply wiring. Appropriate consideration of equipment nameplate

ratings should be used when addressing this concern.

e) Reliable Earthing- Reliable earthing of rack-mounted equipment

should be maintained. Particular attention should be given to supply

connections other than direct connections to the branch circuit (e.g.,

use of power strips).

Ver. 1.00

TABLE OF CONTENTS

About This Guide................................................................................. 1

Purpose ............................................................................................ 1

Terms/Usage .................................................................................... 1

Introduction.......................................................................................... 2

Fast Ethernet Technology ................................................................ 2

Switching Technology ..................................................................... 3

Power over Ethernet (PoE) .............................................................. 4

Features............................................................................................ 4

Unpacking and Installation .................................................................. 5

Unpacking........................................................................................ 5

Installation ....................................................................................... 5

Connecting Network Cable.............................................................. 6

Identifying External Components ........................................................ 7

Front Panel....................................................................................... 7

Rear Panel........................................................................................ 7

Understanding LED Indicators .............................................................9

System LED......................................................................................9

POE status LEDs (Port 1 ~ Port 4)....................................................9

Ethernet port status LEDs (Ports 1~8) ........................................... 10

PoE Rule ........................................................................................ 10

Technical Specifications .................................................................... 12

ABOUT THIS GUIDE

Congratulations on your purchase of the D-Link DES-1008P, an 8-

Port 10/100Mbps Fast Ethernet Switch with 4-Port PoE. This Switch

integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network

capabilities in a highly flexible package. Port-1 to Port-4 on the switch

support Power over Ethernet (PoE), meaning it will automatically

detect the presence of an IEEE 802.3af-compliant powered device (PD)

and provide power through the port. The switch provides up to 15.4 W

per PoE port and can be used to power WLAN access points, IP

phones, video cameras, and other PD devices. The Switch will

automatically detect the network appliance’s requirements, and will

supply the required power to each appliance accordingly.

Purpose

This guide discusses how to install your 8-Port 10/100Mbps Fast

Ethernet Switch with 4-Port PoE.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to your

8-Port 10/100Mbps Fast Ethernet Switch with 4-Port PoE and

“switch” (first letter lower case) refers to other Ethernet switches.

INTRODUCTION

This chapter describes the features of the D-Link DES-1008P Fast

Ethernet PoE Switch and some background information about

Ethernet/Fast Ethernet, Switching and Power over Ethernet

technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of

desktop computing applications are fueling the need for high

performance networks. A number of high-speed LAN technologies

have been proposed to provide greater bandwidth and improve

client/server response times. Among them, 100BASE-TX (Fast

Ethernet) provides a non-disruptive, smooth evolution from the

current 10BASE-T technology.

100Mbps Fast Ethernet is a standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps Ethernet standard

with the ability to transmit and receive data at 100Mbps, while

maintaining the CSMA/CD Ethernet protocol. Since the 100Mbps

Fast Ethernet is compatible with all other 10Mbps Ethernet

environments, it provides a straightforward upgrade and takes

advantage of the existing investment in hardware, software, and

personnel training.

Switching Technology

Another approach to pushing beyond the limits of Ethernet technology

is the development of switching technology. A switch bridges

Ethernet packets at the MAC address level of the Ethernet protocol

transmitting among connected Ethernet or Fast Ethernet LAN

segments.

Switching is a cost-effective way of increasing the total network

capacity available to users on a local area network. A switch increases

capacity and decreases network loading by dividing a local area

network into different segments, which don’t compete with each other

for network transmission capacity.

The switch acts as a high-speed selective bridge between the

individual segments. The switch, without interfering with any other

segments, automatically forwards traffic that needs to go from one

segment to another. By doing this the total network capacity is

multiplied, while still maintaining the same network cabling and

adapter cards.

Switching LAN technology is a marked improvement over the

previous generation of network bridges, which were characterized by

higher latencies. Routers have also been used to segment local area

networks, but the cost of a router, the setup and maintenance required

make routers relatively impractical. Today switches are an ideal

solution to most kinds of local area network congestion problems.

Power over Ethernet (PoE)

Power over Ethernet (PoE) integrates power and data onto one single

cabling infrastructure, eliminating the need to have AC power

available at all locations.

Power and Data is integrated onto the same cable, supporting category

5/5e up to 100 Meters. PoE will provide power to PoE compatible

devices, such as IP telephones, wireless LAN access points and IP

security cameras.

PoE is already widely adopted in the market, saving up to 50% of

overall installation costs by eliminating the need to install separate

electrical wiring and power outlets.

Features

8 ×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports with

4-port PoE function (port-1 ~ port-4)

Compliant with 802.3af specification

Supports PoE power up to 15.4W for PoE port

Supports PoE power up to 56W for all PoE ports

Supports PoE IEEE802.3af compliant Powered Device (PD)

Each port supports auto MDI/MDIX, so there is no need to use

cross-over cables or an up-link port

Full/half duplex transfer mode for each port

Wire speed reception and transmission

Up to 1K unicast addresses entities per device, self-learning, and

table aging

96KBytes packet buffer

Supports IEEE 802.3x flow control for full-duplex mode ports

Supports Back-pressure flow control for half-duplex mode ports

UNPACKING AND INSTALLATION

This chapter provides unpacking and installation information for the

Switch.

Unpacking

Open the shipping cartons of the Switch and carefully unpack its

contents. The carton should contain the following items:

One DES-1008P

One AC power adapter

Four rubber feet

CD-ROM with Product Document

Quick Installation Guide.

If any item is found missing or damaged, please contact your local

reseller for replacement.

Installation

The setup of the Switch can be performed using the following steps:

The surface must support at least 1.5 Kg (3.5 lbs) for the Switch.

The power outlet should be within 1.82 meters (6 feet) of the

Switch.

Visually inspect the DC power jack and make sure that it is fully

secured to the power adapter.

Make sure that there is proper heat dissipation from and

adequate ventilation around the Switch. Do not place heavy

objects on the Switch.

Connecting Network Cable

The Switch support 8 10/100Mbps Ethernet ports and Port 1 ~ port 4

are PoE Enabled ports, these PoE port will automatically activate

when a compatible terminal is identified. The Switch will supply

power through the Ethernet port to the connected PoE powered device

(PD).

For legacy devices that are not compatible, the PoE port will not offer

power to this device. This feature allows users to freely and safely mix

legacy and Power over LAN compatible devices on their network.

The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and

it runs both in half and full duplex mode using two pair of Category 5

cable.

These RJ45 ports are Auto-MDI type port. The Switch can auto

negotiate to MDI-II or MDI-X type, so you can connect any RJ-45

cable regardless if it is a standard or crossover cable.

Autres manuels pour DES-1008P

Table des matières

Autres manuels D-Link Changer

D-Link

D-Link DES-2110 Manuel utilisateur

D-Link

D-Link DGS-1024D/E1 Manuel utilisateur

D-Link

D-Link DKVM-4U Manuel utilisateur

D-Link

D-Link DGS-3000 series Manuel utilisateur

D-Link

D-Link DGS-1024C Manuel utilisateur

D-Link

D-Link DES-1018P Manuel utilisateur

D-Link

D-Link DGS-1016T Manuel utilisateur

D-Link

D-Link 1016R - DES Switch Manuel utilisateur

D-Link

D-Link SmartPro DGS-1500-20 Manuel utilisateur

D-Link

D-Link DGS-1005D - Switch Manuel utilisateur

D-Link

D-Link DGS-3308TG Manuel utilisateur

D-Link

D-Link DGS-3630-52TC Manuel utilisateur

D-Link

D-Link DGS-3224TGR - Switch Manuel utilisateur

D-Link

D-Link DXS-3410 Series Manuel

D-Link

D-Link xStack DES-3552 Series Manuel utilisateur

D-Link

D-Link DGS-1005P/A1A Manuel utilisateur

D-Link

D-Link DGS-1100-08PD Manuel utilisateur

D-Link

D-Link mydlink DCH-G022 Manuel utilisateur

D-Link

D-Link DXS-3227P - xStack Switch - Stackable Manuel utilisateur

D-Link

D-Link DES-3852 - xStack Switch - Stackable Manuel utilisateur

D-Link

D-Link DGS-1210-10/FL Manuel utilisateur

D-Link

D-Link DGS-1016D - Switch Manuel utilisateur

D-Link

D-Link DUB-H4 - Hub - USB Manuel utilisateur

D-Link

D-Link xStack Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
