xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

CLI Reference

Manual

Product Model : DES-3200 Series

Layer 2 Managed Ethernet Switch

Release 1.21

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly forbidden.

Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft and Windows are

registered trademarks of Microsoft Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or

their products. D-Link Corporation disclaims any proprietary interest in trademarks and trade names other than its own.

April 2010 P/N 651ES3200025G

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

Table of Contents

INTRODUCTION.........................................................................................................................................................1

USING THE CONSOLE CLI........................................................................................................................................3

COMMAND SYNTAX ..................................................................................................................................................7

BASIC SWITCH COMMANDS..................................................................................................................................10

MODIFY BANNER AND PROMPT COMMANDS ....................................................................................................30

SWITCH PORT COMMANDS ...................................................................................................................................33

PORT SECURITY COMMANDS ...............................................................................................................................37

NETWORK MANAGEMENT (SNMP) COMMANDS................................................................................................43

SWITCH UTILITY COMMANDS..............................................................................................................................67

NETWORK MONITORING COMMANDS................................................................................................................82

MULTIPLE SPANNING TREE PROTOCOL (MSTP) COMMANDS........................................................................99

FORWARDING DATABASE COMMANDS ............................................................................................................115

PACKET STORM CONTROL COMMANDS...........................................................................................................123

QOS COMMANDS ...................................................................................................................................................127

PORT MIRRORING COMMANDS..........................................................................................................................142

VLAN COMMANDS.................................................................................................................................................145

LINK AGGREGATION COMMANDS.....................................................................................................................156

BASIC IP COMMANDS ...........................................................................................................................................162

IGMP SNOOPING COMMANDS.............................................................................................................................168

DHCP RELAY COMMANDS...................................................................................................................................180

802.1X COMMANDS ................................................................................................................................................188

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

ACCESS CONTROL LIST (ACL) COMMANDS .....................................................................................................210

TIME RANGE COMMANDS ...................................................................................................................................227

SAFEGUARD ENGINE COMMANDS .....................................................................................................................229

TRAFFIC SEGMENTATION COMMANDS............................................................................................................231

TIME AND SNTP COMMANDS ..............................................................................................................................233

ARP COMMANDS....................................................................................................................................................239

ROUTING TABLE COMMANDS.............................................................................................................................243

MAC NOTIFICATION COMMANDS......................................................................................................................250

ACCESS AUTHENTICATION CONTROL COMMANDS.......................................................................................255

SSH COMMANDS....................................................................................................................................................278

SSL COMMANDS.....................................................................................................................................................286

D-LINK SINGLE IP MANAGEMENT COMMANDS...............................................................................................293

SMTP COMMANDS.................................................................................................................................................305

CABLE DIAGNOSTICS COMMANDS ....................................................................................................................310

DHCP LOCAL RELAY COMMANDS .....................................................................................................................312

GRATUITOUS ARP COMMANDS ..........................................................................................................................314

VLAN TRUNKING COMMANDS............................................................................................................................319

Q-IN-Q COMMANDS...............................................................................................................................................323

ASYMMETRIC VLAN COMMANDS ......................................................................................................................331

MLD SNOOPING COMMANDS ..............................................................................................................................333

IGMP SNOOPING MULTICAST VLAN COMMANDS...........................................................................................340

LIMITED IP MULTICAST ADDRESS COMMANDS..............................................................................................347

LLDP COMMANDS .................................................................................................................................................354

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

DOS PREVENTION COMMANDS...........................................................................................................................377

IP-MAC-PORT BINDING COMMANDS .................................................................................................................383

LOOPBACK DETECTION COMMANDS................................................................................................................395

PROTOCOL VLAN COMMANDS...........................................................................................................................402

MAC-BASED VLAN COMMANDS..........................................................................................................................408

FLOW METER COMMANDS..................................................................................................................................411

MAC-BASED ACCESS CONTROL COMMANDS...................................................................................................414

ARP SPOOFING PREVENTION COMMANDS.......................................................................................................431

TECHNICAL SUPPORT COMMANDS ...................................................................................................................434

COMMAND HISTORY COMMANDS .....................................................................................................................438

CONNECTIVITY FAULT MANAGEMENT COMMANDS.....................................................................................442

ETHERNET OAM COMMANDS.............................................................................................................................469

BPDU ATTACK PROTECTION COMMANDS........................................................................................................485

PER-QUEUE BANDWIDTH CONTROL COMMANDS ..........................................................................................492

ERPS COMMANDS..................................................................................................................................................495

NETWORK LOAD BALANCING (NLB) COMMANDS...........................................................................................505

PPPOE CIRCUIT ID INSERTION COMMANDS ....................................................................................................511

DHCP SERVER SCREENING SETTINGS...............................................................................................................515

APPENDIX A -TECHNICAL SPECIFICATIONS....................................................................................................519

APPENDIX B - PASSWORD RECOVERY PROCEDURE.......................................................................................522

APPENDIX C - RADIUS ATTRIBUTES ASSIGNMENT .........................................................................................524

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

INTRODUCTION

The Switch can be managed through the Switch’s serial port, Telnet, or the Web-based management agent. The Command Line

Interface (CLI) can be used to configure and manage the Switch via the serial port or Telnet interfaces.

This manual provides a reference for all of the commands contained in the CLI. Configuration and management of the Switch via

the Web-based management agent is discussed in the Manual. Configuration and management of the Switch via the Web-based

management agent is discussed in the User’s Guide.

Accessing the Switch via the Serial Port

The Switch’s serial port’s default settings are as follows:

9600 baud

no parity

8 data bits

1 stop bit

A computer running a terminal emulation program capable of emulating a VT-100 terminal and a serial port configured as above

are then connected to the Switch’s serial port via an RS-232 DB-9 cable.

With the serial port properly connected to a management computer, the following screen should be visible. If this screen does not

appear, try pressing Ctrl+r to refresh the console screen.

DES-3200-28 Fast Ethernet Switch

Command Line Interface

Firmware: Build 1.10.B014

UserName:

PassWord:

Figure 1 - 1. Initial CLI screen

There is no initial username or password. Just press the Enter key twice to display the CLI input cursor DES-3200-28:4#. This is

the command line where all commands are input.

Setting the Switch’s IP Address

Each Switch must be assigned its own IP Address, which is used for communication with an SNMP network manager or other

TCP/IP application (for example BOOTP, TFTP). The Switch’s default IP address is 10.90.90.90. Users can change the default

Switch IP address to meet the specification of your networking address scheme.

The Switch is also assigned a unique MAC address by the factory. This MAC address cannot be changed, and can be found on the

initial boot console screen – shown below.

Boot Procedure V1.00.B002

--------------------------------------------------------------------------

Power On Self Test........................................100%

MAC Address : 00-21-91-98-60-77

H/W Version : A1

Please wait, loading V1.10.B014 Runtime image...............100%

Figure 1 - 2. Boot screen

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

The Switch’s MAC address can also be found in the Web management program on the Switch Information (Basic Settings)

window in the Configuration folder.

The IP address for the Switch must be set before it can be managed with the Web-based manager. The Switch IP address can be

automatically set using BOOTP or DHCP protocols, in which case the actual address assigned to the Switch must be known.

The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows:

Starting at the command line prompt, enter the command config ipif System ipaddress xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy. Where

the x’s represent the IP address to be assigned to the IP interface named System and the y’s represent the corresponding subnet

mask.

Alternatively, users can enter config ipif System ipaddress xxx.xxx.xxx.xxx/z. Where the x’s represent the IP address to be

assigned to the IP interface named System and the z represents the corresponding number of subnets in CIDR notation.

The IP interface named System on the Switch can be assigned an IP address and subnet mask which can then be used to connect a

management station to the Switch’s Telnet or Web-based management agent.

DES-3200-28:4#config ipif System ipaddress 10.73.21.11/255.0.0.0

Command: config ipif System ipaddress 10.73.21.11/8

Success.

DES-3200-28:4#

Figure 1 - 3. Assigning an IP Address

In the above example, the Switch was assigned an IP address of 10.73.21.11 with a subnet mask of 255.0.0.0. The system message

Success indicates that the command was executed successfully. The Switch can now be configured and managed via Telnet,

SNMP MIB browser and the CLI or via the Web-based management agent using the above IP address to connect to the Switch.

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

USING THE CONSOLE CLI

The Switch supports a console management interface that allows the user to connect to the Switch’s management agent via a serial

port and a terminal or a computer running a terminal emulation program. The console can also be used over the network using the

TCP/IP Telnet protocol. The console program can be used to configure the Switch to use an SNMP-based network management

application over the network.

This chapter describes how to use the console interface to access the Switch, change its settings, and monitor its operation.

Note: Switch configuration settings are saved to non-volatile RAM using the save command. The current

configuration will then be retained in the Switch’s NV-RAM, and reloaded when the Switch is rebooted. If

the Switch is rebooted without using the save command, the last configuration saved to NV-RAM will be

loaded.

Connecting to the Switch

The console interface is used by connecting the Switch to a VT100-compatible terminal or a computer running an ordinary

terminal emulator program (e.g., the HyperTerminal program included with the Windows operating system) using an RS-232C

serial cable. Your terminal parameters will need to be set to:

VT-100 compatible

9600 baud

8 data bits

No parity

One stop bit

No flow control

Users can also access the same functions over a Telnet interface. Once users have set an IP address for your Switch, users can use

a Telnet program (in VT-100 compatible terminal mode) to access and control the Switch. All of the screens are identical, whether

accessed from the console port or from a Telnet interface.

After the Switch reboots and users have logged in, the console looks like this:

DES-3200-28 Fast Ethernet Switch

Command Line Interface

Firmware: Build 1.10.B014

UserName:

PassWord:

Figure 2 - 1. Initial Console Screen after logging in

Commands are entered at the command prompt, DES-3200-28:4#.

There are a number of helpful features included in the CLI. Entering the ? command will display a list of all of the top-level

commands.

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

cable_diag ports

clear

clear address_binding dhcp_snoop binding_entry ports

clear arptable

clear counters

clear dos_prevention counters

clear fdb

clear igmp_snooping data_driven_group

clear log

clear mac_based_access_control auth_mac

clear port_security_entry port

config 802.1p default_priority

config 802.1p user_priority

config 802.1x auth_mode

config 802.1x auth_parameter ports

config 802.1x auth_protocol

config 802.1x capability ports

config 802.1x guest_vlan ports

config 802.1x init

config 802.1x reauth

CTRL+C ESC qQuit SPACE nNext Page ENTER Next Entry aAll

Figure 2 - 2. The ? Command

When users enter a command without its required parameters, the CLI will prompt users with Next possible completions:

message.

DES-3200-28:4#config account

Command: config account

Next possible completions:

DES-3200-28:4#

Figure 2 - 3. Example Command Parameter Help

In this case, the command config account was entered without the parameter <username>. The CLI will then prompt users to enter

the <username> with the message, Next possible completions:. Every command in the CLI has this feature, and complex

commands have several layers of parameter prompting.

In addition, after typing any given command plus one space, users can see all of the next possible sub-commands, in sequential

order, by repeatedly pressing the Tab key.

To re-enter the previous command at the command prompt, press the up arrow cursor key. The previous command will appear at

the command prompt.

xStack® DES-3200 Series Layer 2 Ethernet Managed Switch CLI Reference Manual

DES-3200-28:4#config account

Command: config account

Next possible completions:

DES-3200-28:4#config account

Command: config account

Next possible completions:

DES-3200-28:4#

Figure 2 - 4. Using the Up Arrow to Re-enter a Command

In the above example, the command config account was entered without the required parameter <username>, the CLI returned the

Next possible completions: <username> prompt. The up arrow cursor control key was pressed to re-enter the previous command

(config account) at the command prompt. Now the appropriate username can be entered and the config account command re-

executed.

All commands in the CLI function in this way. In addition, the syntax of the help prompts are the same as presented in this manual

angle brackets < > indicate a numerical value or character string, braces { } indicate optional parameters or a choice of

parameters, and brackets [ ] indicate required parameters.

If a command is entered that is unrecognized by the CLI, the top-level commands will be displayed under the Available

commands: prompt.

DES-3200-28:4#the

Available commands:

.. ? cable_diag clear

config create delete dir

disable download enable login

logout ping ping6 reboot

reconfig reset save show

smtp telnet traceroute upload

DES-3200-28:4#

Figure 2 - 5. The Next Available Commands Prompt

The top-level commands consist of commands such as show or config. Most of these commands require one or more parameters

to narrow the top-level command. This is equivalent to show what? or config what? Where the what? is the next parameter.

For example, if users enter the show command with no additional parameters, the CLI will then display all of the possible next

parameters.

Autres manuels pour xStack DES-3200 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels D-Link Routeur réseau

D-Link

D-Link DI-304 Manuel utilisateur

D-Link

D-Link SharePort DIR-825 Manuel utilisateur

D-Link

D-Link DSL-2770L Manuel utilisateur

D-Link

D-Link DSL-2540T Manuel

D-Link

D-Link Ethernet Broadband Router DIR-100 Manuel utilisateur

D-Link

D-Link DES-1316K Manuel utilisateur

D-Link

D-Link EAGLE PRO AI AX1500 M15 Manuel utilisateur

D-Link

D-Link DSL-500T Manuel utilisateur

D-Link

D-Link DES-5016 Manuel utilisateur

D-Link

D-Link DIR-882 Manuel utilisateur

D-Link

D-Link DIR-813 Manuel utilisateur

D-Link

D-Link DIR-636L Manuel utilisateur

D-Link

D-Link DIR-842 Manuel utilisateur

D-Link

D-Link DIR-850L Instructions d'utilisation et de sécurité

D-Link

D-Link DIR-842 Manuel utilisateur

D-Link

D-Link DSL-2520U Manuel utilisateur

D-Link

D-Link DIR-825/AC Manuel utilisateur

D-Link

D-Link DI-206 Manuel utilisateur

D-Link

D-Link Xtreme N DIR-825 Manuel utilisateur

D-Link

D-Link DSL-G225 Manuel utilisateur

D-Link

D-Link DI-824VUP+ 2.4GHz Wireless VPN Router and Print... Manuel utilisateur

D-Link

D-Link DGS-3700-12 Manuel

D-Link

D-Link AirPlus XtremeG Ethernet-to-Wireless Bridge... Manuel utilisateur

D-Link

D-Link DIR-605L Manuel

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité

D-Link xStack DES-3200 Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques
