Before You Begin

DES-1024D

10/100M Fast Ethernet Switch

This Quick Installation Guide gives step-by-step instructions for setting up the D-Link

DES-1024D 10/100M Fast Ethernet Switch. The model you have purchased may

appear slightly different from those shown in the illustrations. For more detailed

information about the switch, its components, making network connections and

technical specifications, please refer to the User’s Guide included you’re your switch.

Check Your Package Contents

These are the items included with your DES-1024D purchase:

•DES-1024D 10/100M Fast Ethernet Switch

• User Manual

• Quick Installation Guide

•Power Cord

•Rack-mount Bracket

Using a powe

supply with a

different voltage rating

will damage and void

the warranty for this

product.

If any of the above items are missing, please contact your reseller.

respective holders. Software and specifications subject to change without notice.

This Manual: http://www.manuallib.com/file/2426647

Setup The DES-1024D 10/100M Fast

Ethernet Switch

The setup of the Switch can be performed using the following steps:

A. The surface must support at least 5 kg.

B. The power outlet should be within 1.82 meters (6 feet) of the device.

C. Visually inspect the power cord and see that it is secured fully to the AC

power connector.

D. Make sure that there is proper heat dissipation from and adequate

ventilation around the Switch. Do not place heavy objects on the

Switch.

Desktop or Shelf Installation

When installing the Switch on a desktop or shelf, the rubber feet included

with the device must be first attached.Attach these cushioning feet on the

bottom at each corner of the device. Allow enough ventilation space between

the device and the objects around it.

Fast Ethernet Switch installed on a Desktop or Shelf

This Manual: http://www.manuallib.com/file/2426647

Rack Installation

The Switch can be mounted in an EIAstandard size, 19-inch rack, which

can be placed in a wiring closet with other equipment. To install, attach the

mounting brackets on the switch’s front panel (one on each side) and secure

them with the screws provided.

Attaching the mounting brackets to the Switch

Then, use the screws provided with the equipment rack to mount the

Switch in the rack.

Installing the Switch in an equipment rack

Connecting Network Cable

The Fast Ethernet Switch supports 24 10/100Mbps Fast Ethernet ports. These

ports runs both half duplex and full duplex while it’s running in 10Mbps or

100Mbps.

These ports are Auto-MDI type port, these ports can auto transform to MDI-II or

MDI-X type, so you can just make an easy connection that without worrying if

you are using a standard or crossover cable.

This Manual: http://www.manuallib.com/file/2426647

Power

The Switch can be used with AC power sources 100 - 240 VAC, 50 - 60

Hz. The Switch’s power supply will adjust to the local power source

automatically and may be turned on without having any or all LAN segment

cables connected.

LED Indicators

The LED indicators of the Switch include Power, Link/Act and 100Mbps.

The following shows the LED indicators for the Switch along with an

explanation of each indicator.

The Switch LED indicators

POWER This indicator lights green when the Switch is receiving power,

otherwise, it is off.

Link/Act. These LED indicators are lighted up when there is a secure

connection (or link) to any ports. The LED indicators blink whenever

there is reception or transmission (i.e. Activity--Act) of data occurring at a

port.

100Mbps. These LED indicators are lighted up when there is a secure

connection (or link) to 100Mbps Fast Ethernet device at any of the ports.

This Manual: http://www.manuallib.com/file/2426647

Technical Support

You can find software updates and user documentation on the D-Link websites.

D-Link provides free technical support for customers within Canada,

the United Kingdom, and Ireland.

Customers can contact D-Link technical support through our websites,

or by phone.

For Customers within

The United Kingdom & Ireland:

D-Link UK & Ireland Technical Support over the Telephone:

08456 12 0003 (United Kingdom)

+44 8456 12 0003 (Ireland)

Lines Open

8.00am-10.00pm Mon-Fri

10.00am-7.00pm Sat & Sun

D-Link UK & Ireland Technical Support over the Internet:

http://www.dlink.co.uk

ftp://ftp.dlink.co.uk

For Customers within Canada:

D-Link Canada Technical Support over the Telephone:

1-800-361-5265 (Canada)

Mon. to Fri. 7:30AM to 9:00PM EST

D-Link Canada Technical Support over the Internet:

http://support.dlink.ca

email: [email protected]

This Manual: http://www.manuallib.com/file/2426647
