D-Link ShareCenter DNS-343 Manuel utilisateur

Wireless G USB 2.0 Adapter

Wireless Internet Camera

with 3G Mobile Video

2D-Link DNS-343 Quick Install Guide

System Requirements / Package Contents

System Requirements

Package Contents

Note: Using a power supply with a different voltage than the one

included with the DNS-343 will cause damage and void the warranty

for this product.

If any of the above items are missing, please contact your reseller.

D-Link DNS-343 ShareCenter• ™4-Bay Network Storage

CD-ROM with Manual and Software•

Quick Installation Guide•

Power Adapter (19V / 7.89A)•

Power Cord•

CAT5 Ethernet Cable•

For best results, the following system requirements are

recommended:

Computer with: 1GHz processor/512 MB RAM/200 MB available•

space/CD-ROM drive

Internet Explorer version 6.0 or Mozilla Firefox 1.0 and above•

3.5” SATA Hard Drive(s) Windows• ®XP (with Service Pack 2)

or Vista®

3 D-Link DNS-343 Quick Install Guide

Hardware Overview

Front View

Next Button

OLED Screen

Power Button

COMPONENT DESCRIPTION

OLED Screen This screen displays detailed information about the following:

System Information

HD Status

Server Status

RAID Status

Power Button Use this button to switch the device on or off.

To switch on the device press the button once.

To switch off the device hold the button down for 5 seconds.

Next Button Use this button to display the System Information (system state),

HD Status (hard drive state), Server Status (server status state)

on the OLED, and RAID status.

Press the button once to alternate between the different Status

screens.

4D-Link DNS-343 Quick Install Guide

Hardware Overview

Rear View

COMPONENT DESCRIPTION

Drive Eject Levers Use the provided levers to eject the SATA hard drives.

Reset Button Press this button for over 5 seconds to reset the unit to factory

defaults.

Power Receptacle Connect the 19V / 7.89A power supply to the receptacle.

USB Connector 1x USB 2.0 (Type A) connector. USB Host port for Print Server or

USB UPS monitoring.

Gigabit Ethernet Port Use the Gigabit Ethernet Port to connect the DNS-343 to the local

network.

Cooling Fans The cooling fans are used to cool the hard drives and feature

speedcontrol.Whentheunitisrstpoweredon,thefansrotate

at a low speed and they will switch to a high speed when the

temperature rises above 49° C.

Cooling Fan

Ethernet Port

USB Connector

Cooling Fan

Drive Eject Levers

Reset Button

Power Receptacle

5 D-Link DNS-343 Quick Install Guide

Conﬁguration

Using the OLED

The DNS-343 ShareCenter™4-Bay Network Storage features an

OLED that enables the administrator to easily view information

about the DNS-343. The OLED display screen displays information

about the network connection status and the number of hard drives

installed and the bay ID’s they are installed in. The OLED has four

different screens:

System Information- This screen shows the following information:

The hostname of the DNS-343.•

The Firmware version.•

The IP address of the DNS-343.•

The operating temperature.•

Hard Drive Status- This screen shows the following information:

The percentage of space used on the hard drives.•

Server Status- This screen shows the following information:

Whether a printer is connected to the server.•

The status of the UPNP server.•

The status of the iTunes server.•

The status of the FTP Server.•

RAID Status- This screen shows the following information:

The RAID health status.•

The status of the rebuilding progress.•

Click the Next button once to alternate between the different Status

screens.

6D-Link DNS-343 Quick Install Guide

Hardware Installation

1. Access the drive bays by sliding

the faceplate up until it unlatches

from the device.

2. Once the faceplate is unlatched,

pull it off of the device, exposing

the drive bays.

3. Insert a 3.5” SATA hard drive

into each available drive bay.

Make sure to align the drive

connectors to the endpoints in

the DNS-343. Gently push the

drive in until it connects.

7 D-Link DNS-343 Quick Install Guide

Hardware Installation

4. Attach the faceplate to the front of

the device.

5. Connect an Ethernet cable into the

available Ethernet port. This cable

should connect the DNS-343 to

your local network or directly to a

computerforconguration.

6. Finally, connect the supplied power

adapter to the power receptacle on

the back of the device.

8D-Link DNS-343 Quick Install Guide

Easy Search Utility

When rst powered on, during the initial boot sequence, the

DNS-343 will wait to be assigned an IP address via DHCP. If it does

not receive a DHCP assigned IP address, by default it will boot up

with a self-assigned IP address of 192.168.0.32.

The Easy Search Utility provided on the DNS-343 CD-ROM makes

it simple to nd any DNS-343 devices on your network, and it is

recommended to use the Easy Search Utility when accessing and

conguringtheDNS-343forthersttime.EachDNS-343willhave

a unique name of dlink-xxxxxx where ‘xxxxxx’ is the last six digits of

its MAC address.

9 D-Link DNS-343 Quick Install Guide

Conﬁguration

WhenloggingintotheDNS-343forthersttime,youwillbeasked

tochooseadrivecongurationandformatthedrives.Therearefour

available options, Standard, JBOD, RAID 0, RAID 1, and RAID 5.

Getting Started

From the DNS-343 CD, select Easy

Search Utility.

Highlight an available DNS-343 and

click to access the web-based utility.

At the login screen, type admin for the

usernameandleavethepasswordeld

blank. Click Conguration.

Selectatypeofharddriveconguration,

and click Next.

10D-Link DNS-343 Quick Install Guide

Conﬁguration

After the DNS-343 restarts, type admin for

theusernameandleavethepasswordeld

blank. Click Conguration.

The Web UI will appear. Your DNS-343 setup is now complete.

A warning message will appear, stating that

all data will be erased when the drives are

formatted. Click OK to continue.
