D-Link DWL-3150 Manuel utilisateur

2D-Link DWL-3150 User Manual

Table of Contents

Product Overview ........................................................4

Package Contents....................................................4

Minimum System Requirements..............................4

Introduction..............................................................5

Features...................................................................7

Wireless Installation Considerations......................... 8

Three Operational Modes ...........................................9

Using the Conﬁguration Menu .................................10

Home > Basic Settings..............................................11

Wireless Bridge .....................................................11

No Security ......................................................12

Open System (64 Bits or 128 Bits) ..................13

Shared Key (64 Bits or 128 Bits)......................14

WPA & WPA2 Personal ....................................15

Wireless Workgroup Bridge ................................... 16

No Security ......................................................17

Open System (64 Bits or 128 Bits) ..................18

Shared Key (64 Bits or 128 Bits)......................19

Wireless WAN........................................................20

Wireless WAN > DHCP Client ...............................22

No Security ......................................................22

Open System (64 Bits or 128 Bits) ..................23

Shared Key (64 Bits or 128 Bits)......................24

WPA & WPA2 Personal ....................................25

WPA & WPA2 Enterprise..................................26

Wireless WAN > Static IP ...................................... 27

No Security ......................................................28

Open System (64 Bits or 128 Bits) ..................29

Shared Key (64 Bits or 128 Bits)......................30

WPA & WPA2 Personal ....................................31

WPA & WPA2 Enterprise..................................32

LAN........................................................................ 33

Home > Advanced Settings ...................................... 35

Performance .......................................................... 35

Virtual Server......................................................... 37

Port Forwarding .....................................................38

Application Rules...................................................39

Firewall .................................................................. 40

Advanced Network.................................................41

DDNS.....................................................................42

Schedule................................................................ 43

Filters.....................................................................44

Network Filter................................................... 44

Website Filter ...................................................45

Home > Status ...........................................................46

Device Information.................................................46

Wireless Information.............................................. 47

Table of Contents

3D-Link DWL-3150 User Manual

Table of Contents

Statistics ................................................................48

Log......................................................................... 49

View Log ..........................................................49

Log Settings.....................................................50

Tool .............................................................................51

Administrator Settings............................................51

Firmware Upgrade................................................. 52

Conﬁguration File Upload and Download ..............53

NTP Settings..........................................................54

Conﬁguration............................................................. 55

Save and Activate..................................................55

System........................................................................56

System Settings..................................................... 56

System Information................................................57

Wireless Basics ......................................................... 58

Networking Basics .................................................... 63

Check your IP Address .......................................... 63

Statically Assign an IP Address.............................64

Contacting Technical Support..................................65

Warranty .....................................................................66

Registration................................................................71

4D-Link DWL-3150 User Manual

Section 1 - Product Overview

• D-Link DWL-3150 802.11g Wireless Bridge

• Install Guide

• Manual, Install Guide, and warranty on CD

• Ethernet (CAT5-UTP/Straight-Through) Cable

• Power Adapter

If any of the above items are missing, please contact your reseller.

Minimum System Requirements

• Computers with Windows®, Macintosh, or Linux-based operating systems with an installed Ethernet

Adapter.

• Internet Explorer version 6.0 or Mozilla Firefox version 1.5 and above.

Product Overview

Package Contents

5D-Link DWL-3150 User Manual

Section 1 - Product Overview

Introduction

At up to ﬁfteen times the speed* of previous wireless devices you can work faster and more efﬁciently, increasing

productivity. With the DWL-3150, bandwidth-intensive applications like graphics or multimedia will beneﬁt signiﬁcantly

because large ﬁles are able to move across the network quickly.

Inclusion of all three standards (802.11b and 802.11g) means that the DWL-3150

is versatile enough to allow

connection to almost any 802.11 network or device.

The DWL-3150 is capable of operating in one of 3 different modes to meet your wireless networking needs.

The DWL-3150

can operate as a Wireless Bridge, a Wireless Workgroup Bridge

, or a Wireless WAN.

An ideal solution for quickly creating and extending a wireless local area network

(WLAN) in ofﬁces or other workplaces,

trade shows and special events, the DWL-3150

provides data transfers at up to 54Mbps* when used with other D-Link

Air Premier®or Air Premier AG® products (The 802.11g standard is backwards compatible with 802.11b devices).

WPA is offered in two ﬂavors: Enterprise (used for corporations), and Personal (used for home users).

WPA-Personal and WPA2-Personal is directed at home users who do not have the server based equipment required

for user authentication. The method of authentication is similar to WEP because you deﬁne a “Pre-Shared Key” on

the wireless router/AP. Once the pre-shared key is conﬁrmed and satisﬁed on both the client and access point, then

access is granted.The encryption method used is referred to as the Temporal Key Integrity Protocol (TKIP), which offers

per-packet dynamic hashing. It also includes an integrity checking feature which ensures that the packets were not

tampered with during wireless transmission. WPA2-Personal is far superior to WPA-Personal, because the encryption

of data is upgraded with the Advanced Encryption Standard (AES).

*Maximum wireless signal rate derived from IEEE Standard 802.11g speciﬁcations. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trafﬁc, building

materials and construction, and network overhead lower actual data throughput rate.

6D-Link DWL-3150 User Manual

Section 1 - Product Overview

WPA-Enterprise and WPA2-Enterprise is ideal for businesses that have existing security infrastructures in place.

Management and security implementation can now be centralized on a server participating on the network. Utilizing

802.1x with a RADIUS (Remote Authentication Dial-in User Service) server, a network administrator can deﬁne a list

of authorized users

who can access the wireless LAN. When attempting to access a wireless LAN with either WPA-

Enterprise or WPA2-Enterprise conﬁgured, the new client will be challenged with a username and password.

If the

new client is authorized by the administration, and enters the correct username and password, then access is granted.

In a scenario where an employee leaves the company, the network administrator can remove the employee from the

authorized list and not have to worry about the network being compromised by a former employee. WPA2-Enterprise

is far superior to WPA-Enterprise, because the encryption of data is upgraded with the Advanced Encryption Standard

(AES).

7D-Link DWL-3150 User Manual

Section 1 - Product Overview

• 3 Different Operation modes - Capable of operating in one of three different operation modes to meet your

wireless networking requirements: Wireless Bridge, Wireless Workgroup Bridge, or Wireless WAN.

• Faster wireless networking speeds up to 54Mbps*.

• Compatible with 802.11b and 802.11g Devices that is fully compatible with the IEEE 802.11b and 802.11g

standards, the DWL-3150 can connect with existing 802.11b- or 802.11g-compliant wireless network adapter

cards.

• Compatible with the 802.11b standard to provide a wireless data rate of up to 11Mbps - that means you can

migrate your system to the 802.11g standard on your own schedule without sacriﬁcing connectivity.

• Better security with WPA - The DWL-3150 can securely connect wireless clients on the network using WPA

(Wi-Fi Protected Access) providing a much higher level of security for your data and communications than has

previously been available.

• Utilizes OFDM technology (Orthogonal Frequency Division Multiplexing).

• Operates in the 2.437GHz frequency range for an 802.11b and 802.11g network.

• Web-based interface for managing and conﬁguring.

*Maximum wireless signal rate derived from IEEE Standard 802.11g speciﬁcations. Actual data throughput will vary. Network conditions and environmental factors, including volume of network

trafﬁc, building materials and construction, and network overhead lower actual data throughput rate.

Features

8D-Link DWL-3150 User Manual

Section 2 - Installation

Wireless Installation Considerations

The D-Link 802.11g Wireless Bridge lets you access your network using a wireless connection from virtually anywhere

within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location

of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary

depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to

maximizing wireless range is to follow these basic guidelines:

1. Keep the number of walls and ceilings between the D-Link adapter and other network devices to a

minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position

your devices so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a

45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet

(14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead

of at an angle) for better reception.

3. Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on

range. Try to position access points, wireless routers, and computers so that the signal passes through

drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water

(ﬁsh tanks), mirrors, ﬁle cabinets, brick, and concrete will degrade your wireless signal.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that

generate RF noise.

5. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and

home security systems), your wireless connection may degrade dramatically or drop completely. Make

sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits

a signal even if the phone in not in use.

9D-Link DWL-3150 User Manual

Section 3 - Conﬁguration

Three Operational Modes

Operation Mode

(Only supports one mode at a time) Function

Wireless Bridge This enables any device behind the DWL-3150 that connects to the wireless

LAN.

Wireless Workgroup Bridge Wirelessly connects multiple networks (using multiple DWL-3150s)

Wireless WAN The WISP (Wireless Internet Service Provider) subscriber can share the WISP

connection without the need of an extra router.

10D-Link DWL-3150 User Manual

Section 3 - Conﬁguration

To conﬁgure the DWL-3150, use a computer which is connected to the DWL-3150 with an Ethernet cable (see the

Network Layout diagram).

First, disable the Access the Internet using a proxy server function. To disable this function, go to Control Panel >

Internet Options > Connections > LAN Settings and uncheck the enable box.

Open a web browser such as Internet Explorer and Type the IP address and http

port of the DWL-3150 in the address ﬁeld (http://192.168.0.50) and press Enter.

Make sure that the IP addresses of the DWL-3150 and your computer are in the

same subnet.

After the connection is established, you will see the user identiﬁcation window as shown.

Note: If you have changed the default IP address assigned to the DWL-3150, make sure to enter the correct IP

address.

• Type admin in the User Name ﬁeld

• Leave the Password ﬁeld blank

• Click OK

Note: If you have changed the password, make sure to enter the correct password.

Using the Conﬁguration Menu

Autres manuels pour DWL-3150

Table des matières

Autres manuels D-Link Matériel réseau

D-Link

D-Link MYDLINK DNR-322L Manuel utilisateur

D-Link

D-Link ShareCenter Pro DNS-1550-04 Manuel utilisateur

D-Link

D-Link ShareCenter Pulse DNS-320 Manuel utilisateur

D-Link

D-Link DNS-323 - Network Storage Enclosure NAS... Manuel utilisateur

D-Link

D-Link xStack Storage DSN-4000 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-323 Manuel utilisateur

D-Link

D-Link DAP-3711 Manuel utilisateur

D-Link

D-Link DSL-6300V Manuel utilisateur

D-Link

D-Link DSM-G600 - MediaLounge Wireless G Network Storage Enclosure NAS... Manuel utilisateur

D-Link

D-Link DWA-F18 Manuel utilisateur

D-Link

D-Link ShareCenterTM + DNS-340L Manuel utilisateur

D-Link

D-Link ShareCenter Shadow DNS-325 Manuel utilisateur

D-Link

D-Link DNS-321 - Network Storage Enclosure Hard Drive... Manuel utilisateur

D-Link

D-Link DNS-722-4 Manuel utilisateur

D-Link

D-Link DKVM-2 Manuel de service

D-Link

D-Link mydlink DNR-312L Manuel utilisateur

D-Link

D-Link DNS-313 Manuel utilisateur

D-Link

D-Link DIR-505 Manuel utilisateur

D-Link

D-Link MYDLINK DNR-322L Manuel utilisateur

D-Link

D-Link ShareCenter Pulse DNS-320 Manuel utilisateur

D-Link

D-Link mydlink DNR-202L Manuel utilisateur

D-Link

D-Link MYDLINK DNR-322L Manuel utilisateur

D-Link

D-Link DNR-F4432-16P Manuel utilisateur

D-Link

D-Link DNR-2060-08P Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Lanner

Lanner NCA-1525 Manuel utilisateur

Cantek

Cantek NR310-4 Manuel utilisateur
