This document will guide you through the

basic installation process for your new

D-Link Network Video Recorder.

DNR-326

Quick Installation Guide

2-Bay Professional Network Video Recorder

Quick Installation Guide



Guía de Instalación Rápida

Guia de Instalação Rápida

快速安裝指南

Petunjuk Pemasangan Cepat

2 D-Link 2-Bay Professional Network Video Recorder

ENGLISH

About This Guide

This guide provides step by step instructions for

setting up your D-Link DNR-326 2-Bay Professional

Network Video Recorder. Please note that the

model you have purchased may appear slightly

different from those shown in the illustrations.

The DNR-326 2-Bay Professional NVR is a reliable

network camera surveillance recorder for home

and business. The DNR-326 provides a range of

display, storage, and management functions for

users to easily manage their surveillance system.

Unpacking the Product

Open the shipping carton and carefully unpack its

contents. Please consult the following packing list

to make sure that all the items are present and

undamaged. If any item is missing or damaged,

please contact your local D-Link reseller for a

replacement.

- DNR-326 2-Bay Professional NVR

- Power Cord

- Power Adapter

- Cable Holder

- Ethernet (CAT5 UTP) Cable

- Installation CD (CD-ROM containing the

NVR Search Utility and product documentation

in PDF format)

Item Feature Description

A USB Port This can be used to connect to a

UPS with a USB cable.

B HDD (Left) LED Lights up solid blue when the hard

drive is connected, blinks when

data is being transferred, and lights

up amber if the drive has failed.

C HDD (Right) LED Lights up solid blue when the hard

drive is connected, blinks when

data is being transferred, and lights

up amber if the drive has failed.

D Power LED Indicates the DNR-326 is powered

on.

E Power Button Press to power on the DNR-326.

Table 1. Front Panel Descriptions

Front Panel - DNR-326

Product Overview

Installation and Connection

Hard Drive Installation

1. Access the DNR-326's hard drive bays by

sliding the top cover back until it unlatches

from the device. Once the faceplate is

unlatched, pull it off the device's bays.

2. Align the drives with the grooves in the

enclosure, insert one or two 3.5" SATA hard



seated. If a drive has been inserted incorrectly,

the LED will not light up.

3. Re-attach the top cover to the device.

Figure 1. DNR-326 Front Panel

B C DE

D-Link 2-Bay Professional Network Video Recorder 3

ENGLISH

Ethernet Connection

Connect an Ethernet cable to the Ethernet port of

your DNR-326. This cable should connect your

DNR-326 to your local network via a router or



Connecting a UPS (Optional)

If you have a Universal Power Supply (UPS) that

you would like to use with the NVR, you may con-

nect it before powering the unit on.

1. Connect the USB cable from the UPS to the port

on the back of the NVR.

2. Connect the power cable to the UPS. (Ensure

that the UPS is plugged in and receiving power.)

Operation

Getting Started

1. Make sure the NVR is connected to a network

via a router or a switch, or directly connected

to a PC.

2. Insert the DNR-326 CD in the CD-ROM drive.

If the CD Autorun function does not automati-

cally start on your computer, go to Start > Run.

In the Run box, type D:\autorun.exe (where

D: represents the drive letter of your CD-ROM

drive) and click OK. When the autorun screen

appears, click NVR Search Utility.

3. Highlight an available NVR and click Configu-

ration to access the NVR's web UI. For more

detailed configuration instructions, please refer

to the user manual on the CD-ROM.

Power On

Connect the power adapter. Switch the NVR on

and ensure the power LED on the front of the unit

is lit.

Figure 2. DNR-326 NVR Search Utility

4 D-Link 2-Bay Professional Network Video Recorder

ENGLISH
