D-Link DUB-E130 Manuel utilisateur

Version 1.00 | 02/27/2018

User Manual

USB Type-C to Gigabit Ethernet Adapter

DUB-E130

iD-Link DUB-E130 User Manual

Manual Overview

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any

person or organization of such revisions or changes. Information in this document may become obsolete as our services and

websites develop and change. Please refer to your local D-Link website for the most current information.

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United

States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of

their respective companies.

Apple®, Apple logo®, Safari®, iPhone®, iPad®, iPod touch® and Macintosh® are trademarks of Apple Inc., registered in the U.S.

and other countries. App StoreSM is a service mark of Apple Inc.

Internet Explorer®, Windows® and the Windows logo are trademarks of the Microsoft group of companies.

from D-Link Corporation.

iiD-Link DUB-E130 User Manual

Table of Contents

Package Contents.................................................................................1

System Requirements......................................................................... 1

Introduction ........................................................................................... 2

Features ...................................................................................................3

Hardware Overview............................................................................. 4

Software Installation...........................................................................5

Windows 10/8.................................................................................5

Windows 7....................................................................................... 6

Windows Vista................................................................................ 7

Windows XP.................................................................................... 8

Mac OS X........................................................................................10

Table of Contents

Connecting the Adapter to a Network.......................................11

Completing the Installation............................................................12

Troubleshooting .................................................................................13

Technical Specications...................................................................15

Safety Statements...............................................................................16

1D-Link DUB-E130 User Manual

Section 1 - Product Overview

DUB-E130 USB Type-C to Gigabit Ethernet Adapter

CD-ROM with DUB-E130 Drivers and User Manual

Quick Installation Guide

Package Contents

System Requirements

Computer with the following:

• Microsoft Windows® 10/8/7/Vista®/XP or Mac OS X 10.6 or above

• Pentium 2.0 GHz or higher with a minimum of 32 MB RAM

• Available USB Type-C port

• CD-ROM drive

If any of the above items are missing or damaged, please contact your reseller.

2D-Link DUB-E130 User Manual

Section 1 - Product Overview

Introduction

Thank you for choosing the D-Link DUB-E130 USB Type-C to Gigabit Ethernet Adapter. The DUB-E130 is specically designed

to plug into an available Universal Serial Bus (USB) Type-C port on a computer running Microsoft Windows 10/8/7/Vista/XP,

Mac OS X 10.6 or above. Based on the USB 3.0 standard, the DUB-E130 extends the transfer speed of earlier USB Fast Ethernet

adapters to true 1 Gbps connectivity. Power to the DUB-E130 is provided directly by the USB port, eliminating the need for an

external power adapter. It also supports USB energy-saving suspend and resume functions to minimize power consumption,

which is especially useful for laptop/notebook users.

3D-Link DUB-E130 User Manual

Section 1 - Product Overview

Features

Designed for versatility and performance, the DUB-E130 USB Type-C to Gigabit Ethernet Adapter has the following features:

• USB Type-C 3.0 connector to RJ-45 connector

• True 1 Gbps network connectivity

• Compliance with the IEEE 802.3ab gigabit Ethernet and IEEE 802.3u Fast Ethernet standards

• Plug-and-Play installation (operating system dependent)

• Auto 10/100/1000 Mbps speed detection

• Auto-negotiation to the highest available speed

• Two LED indicators: Connection Speed, Link/ACT

• Driver support:

• Microsoft Windows 10

• Microsoft Windows 8

• Microsoft Windows 7

• Microsoft Windows Vista

• Microsoft Windows XP

• Macintosh OS X (10.6 or above)

4D-Link DUB-E130 User Manual

Section 1 - Product Overview

Hardware Overview

ID COMPONENT DESCRIPTION

1 Ethernet Port Plug an Ethernet cable from a switch or router into this port.

2USB Type-C Connector Plug this connector into a USB Type-C port on your computer.

5D-Link DUB-E130 User Manual

Section 2 - Installation

Software Installation

Insert the CD included with the DUB-E130 into your computer’s DVD or CD drive, then proceed to the appropriate installation

section on the following pages according to your operating system.

Note: If the user interface does not start up, please go to the Autorun folder on the CD-ROM and open Autorun.exe manually.

Windows 10 and 8

The Windows 10 and 8 operating systems support plug-and-play functionality. No software installation or conguration is

necessary. Simply plug the DUB-E130 into your computer’s USB Type-C port when ready.

6D-Link DUB-E130 User Manual

Section 2 - Installation

When the InstallShieldWizard is completed, plug the DUB-E130 into your PC

and the driver software installation will be completed automatically.

When theWindows 7 driver installation is complete, proceed to ”Connecting

the Adapter to a Network”on page 11.

After you have inserted the CD into the CD drive, the DUB-E130 user interface

menu screen will appear. Click on Install to begin the DUB-E130 driver

installation.The InstallShield Wizard will then pop up and run automatically.

Note: The DUB-E130 user interface may dier in appearance depending on

your region.

Windows 7

7D-Link DUB-E130 User Manual

Section 2 - Installation

Windows Vista

After you put the CD into the CD drive, the DUB-E130 user interface menu

screen will appear. Click on Install to begin the DUB-E130 driver installation.

The InstallShield Wizard will then pop up.

This driver is not WHQL signed. If you receive a warning message, you will

have to accept the unsigned driver installation in order to continue.Windows

Vista x64 user will need to disableWHQL checking in order to install the driver.

Note: The DUB-E130 user interface may dier in appearance for dierent

regions.

Plug the DUB-E130 into your computer and the driver software installation

will be completed automatically.

When theWindowsVista driver installation is complete, you can connect the

DUB-E130 to a USB Type-C port on your computer. Please then proceed to

”Connecting the Adapter to a Network”on page 11.
