D-Link DVG-5121SP Manuel utilisateur

D-Link DVG-5121SP

VoIP Telephone Adapter

User Manual

Building Networks for People

RECYCLABLE

2006/11/27

Ver. 1.00

Table of Content DVG-5121SP User’s Manual

D-LinkCorporation

1. Introduction

1-1. Product Overview..…..................................................................................................5

1-2. Product Features……………………………..……………….……………………………6

1-3. Hardware Description……………………………………………………………………...8

2. Before You Begin

2-1. Package Contents ...................................................................................................11

2-2. System Requirements …….………….………………………………………………….11

3. Installation and Applications

3-1. VoIP Telephone Adapter Assigned with a Public IP Address…………………………12

3-2. VoIP Telephone Adapter in a NAT Network………………………………………….....13

3-3. Telephone Interface Description…………………………………………..…………….14

3-4. Setting a VoIP Telephone Adapter with WEB Browser…………………………..……15

4. Basic Network Settings

4-1. WAN

4-1-1. Static IP………………………………………………………………………………….17

4-1-2. DHCP……………………………………………………………………………………18

4-1-3. PPPoE………………………………………………………………………..………… 20

4-1-4. PPtP………….…………………………………………………………………….…….24

4-1-5. L2TP……….…………………………………………………………………………….27

4-1-6. Big Pond………….……………………………………………………………………..29

4-2. LAN

LAN Setting…………………………………………………………………………….……….31

4-3. DHCP Server

4-3-1. DHCP Server Setting………..…………………………………………………………32

4-3-2. DHCP Static Map…………………………………………………………………….....33

5. Advance Network Settings

5-1. NAT…………………………….…………………………………………………………...34

5-2. Virtual Server Setting……….…………………………………………………………….35

5-3. Application Setting………………………………………………………………………..37

Table of Content DVG-5121SP User’s Manual

D-LinkCorporation

5-4. UPNP Setting……………………………………………………………………………...39

5-5. Route

Static Route………………………………………………………………………………….….40

5-6. Security

5-6-1. MAC filter………………………………………………………………………………..42

5-6-2. IP Filter…………………………………………………………………………………..43

5-6-3. URL Filter………………………………………………………………………………..44

5-6-4. Domain Filter……………………………………………………………………………45

5-6-5. Firewall…………………………………………………………………………………..46

5-6-6. Rule Summary……….………………………………………………………………….47

6. SIP Setting

6-1. Basic Setting………………………………………………………………………………48

6-2. Account Setting………………………………………………………….........................50

6-3. NAT Traversal……………………………………………………………………………..51

7. VOIP Setting

7-1. Voice Setting………………………………………………………………………………52

7-2. Call Service………………………………………………………………………………..54

7-3. Phone Setting……………………………………………………………………………..56

7-4. E.164 Setting……………………………………………………………………………...58

7-5. FAX Setting………………………………………………………………………………..59

7-6. General Dialing Setting……………………………………………………....................60

7-7. QOS/TOS Setting…………………………………………………………………………61

7-8. Phone Book………………………………………………………………………………..64

7-9. Call Screen……………………………………………………...…………………………65

8. Tools

8-1. Admin………………………………………………………………………………………66

8-2. Page Configure…………..……………………………………………………………….67

8-3. Date/Time………………………………………………………………………………….68

8-4. DDNS………………………………………………………………………………………70

8-5. System……………………………………………………………………………………..71

Table of Content DVG-5121SP User’s Manual

D-LinkCorporation

8-6. Firmware…………………………………………………………………………………...72

8-7. Device Setting……………………………………………………………………………..73

9. Status

9-1. Device Information………………………………………………………………………..74

9-2. Log………………………………………………………………………………………….75

9-3. Status……………………………………………………………………………………….76

9-4. CDR………………………………………………………………………………………...77

10. Telnet

Run Telnet……………………………………………………………………………………….78

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

1. Introduction

1-1. Product Overview

D-Link®, an industry leader in networking, introduces DVG-5121SP VoIP telephone adapter for

the home environment. The DVG-5121SP VoIP Telephone Adapter conver ts any existing analog

(cord or cordless) telephone into an IP Phone. Also by plugging in a FAX machine, the

DVG-5121SP will enable users to send and receive fax the same way as a traditional analog

telephone line.

The DVG-5121SP carries both voice and facsimile over the IP network. It supports SIP industry

standard call control protocol and is compatible with free registration services or VoIP service

providers’ systems. It also supports the most popular audio CODECs to ensure compatibility

and voice quality.

The DVG-5121SP provides two FXS port to connect to two analog telephone sets, PSTN lifeline

port to connect to the phone line, one Fast Ethernet (10/100) port to connect to the VoIP

telephone adapter and another LAN port which allow another computer to be connected by wire.

VoIP service providers can con gure service settings such as a server address, CODEC and

STUN settings via TFTP directly to the DVG-5121SP.

For security, all of the con guration settings are encrypted. Only the VoIP service

providers/resellers with the authenticated password and user name can access them.

The DVG-5121SP features both the VAD (Voice Activity Detection) and CNG (Comfort Noise

Generator) to reduce the band width consumption and to sustain voice quality.

The DVG-5121SPhas a built-in QoS setting to provide voice priority in IP networks and prevent dropped calls.

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

1-2. Product Features

WAN:

One RJ-45 10/100Mbps auto-MDI/MDIX Ethernet port

WAN type: Static IP, PPPoE, DHCP, PPtP, Big Pond, PPtP Client

VPN Pass Through

QoS: IP Precedence, DiffServ

NAT Traversal: Outbound Proxy, STUN, UPnP

SIP and RTP Priority Queuing

RTP Packet Summary: sent, received, loss packet count

NTP: 3 Time Servers, Time Zone support

DDNS: DynDns.ORG

MAC Address Clone

LAN:

One RJ-45 10/100Mbps auto-MDI/MDIX Ethernet port

Router or Bridge mode

NAT / PAT (RFC1631 / RFC3235):

Virtual Server, DMZ

DHCP Server (RFC 2131 / RFC2132)

Firewall: MAC Filter, IP Filter, Port Filter

VoIP:

Two FXS RJ-11 ports

One FXO RJ-11 PSTN life line port

Management:

LEDs: Power/Alarm, VoIP, WAN, LAN, Phone/Line

Web-based, TELNET

Password controlled administration

Remote firmware upgrade via TFTP or FTP

Inbuilt PING tool

Multi-function reset button: restore default

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

Voice

Pond Key

SIPv2 (RFC3261) compliance

SIP METHOD: ACK, BYE, CANCEL, INFO, INVITE, NOTIFY, OPTIONS,

PING, PRACK, REFER, REGISTER, SUBSCRIBE, UPDATE

SIP Extension: Session Timer, Proxy-Require,

P-Asserted (RFC3325), MWI (RFC3842)

Voice Compression: G.711 a/u-law , G.726, G.729A/B, G.723.1

CNG and VAD

Silence suppression & detection

168 Echo Cancellation

Adaptive jitter buffer

Programmable gain control

In-band DTMF

Out-of-band DTMF relay: RFC2833

*DTMF

Termination Impedance: 600/900& complex Impedance

Failover SIP Proxy server registrations

Failsafe Mechanism (FXS relay to PSTN):

Network failure

Service unavailable

Power loss

*T.30 FAX pass through, T.38 real time FAX relay

Caller ID: DTMF, FSK-Bellcore

*Hunting number support

*Telephone book

*E.164 numbering

Hot line

Call features:

Call Hold, Call Waiting, *Call Pickup

Call Forward - Unconditional, Busy, No Answer

*Call Transfer - Unattended, Attended

Speed Dialing, Repeat Dialing, Three Way Calling (Media Server required)

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

1-3. Diagnostic LEDs and External Interfaces

Front

Panel

WAN LED

When a connection is established, this LED is on. The LED will blink to indicate network

traffic is passing through the WAN port. If the LED does not light up when a cable is

connected, verify the cable connections and make sure the connected devices are

powered on.

LAN LED

When a connection is established, the LED will light up. The LED will blink to indicate

activity. If the LED does not light up when a cable is connected, verify the cable

connections and make sure the connected devices are powered on.

Power LED When this LED is on, DVG-5121SP is powered on.

Provision LED The Provision LED will flash during the device access to TR-069 provision ACS and off

after provision process finished

Phone LEDs

Phone 1

Phone 2

These LEDs display the VoIP status and Hook activity on the phone ports that are used

to connect to the analog telephones. If a phone connected to a phone port is off hook or

in use, this LED will light up. When a phone is ringing, the indicator will blink.

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

Rear

Panel SidePanel

WAN Port

This port connects to your broadband modem or

router through an Ethernet cable.

LAN Port

This port connect to an Ethernet enabled computer/

IP sharing device using Ethernet cabling.

Reset

This button is used to reset the unit to its factory

default settings.

Phone Ports

Each of ports connects to an analog phone via an

RJ-11 phone cable.

RJ11 PSTN Life

Line Phone Port

This port connects to the wall phone line via an

RJ-11 phone cable.

Power Socket This socket connects to the external power adapter.

Introduction DVG-5121SP User’s Manual

D-LinkCorporation

WARNING: To avoid any possible damage to your DVG-5121SP devices, do not connect the

Phone 2 port to a wall phone line. If any of these are done, your DVG-5121SP may be damaged.

Restore to factory default:

A Reset Button is provided on the rear panel of the DVG-5121SP VoIP Telephone Adapter. This Reset Button is

used to restore any settings that you have act in the DVG-5121SP to its factory default settings. Examples of

these settings are the IP address, user’s name and password.

To reset the DVG-5121SP to its default settings, do as follows:

(1) Turn OFF the power of the DVG-5121SP by unplugging the external power adapter.

(2) Use a tip of a pen, push the Reset Button continuously for about 6 seconds.

(3) Release the Reset Button to return the DVG-5121SP to its default settings
