D-Link DUB-1210 Manuel utilisateur

D-Link DUB-9240 Wireless USB Kit

DUB-1210 Wireless USB Adapter

DUB-2240 Wireless USB Hub

User Manual

2D-Link DUB-9240 User Manual

Table of Contents

Product Overview ........................................................3

Package Contents....................................................3

Getting Started ........................................................4

Software Installation...........................................4

Using the Control Center .......................................14

Link Info ........................................................... 14

Conﬁguration....................................................15

About ...............................................................16

Contacting Technical Support.................................. 17

Warranty .....................................................................18

Registration................................................................25

Table of Contents

3D-Link DUB-9240 User Manual

Section 1 - Product Overview

Product Overview

D-Link DUB-2240 Wireless USB 4-Port Hub

D-Link DUB-1210 USB Adapter

USB Cable

Power Adapter (5V; 3A)

Firmware, Drivers and Utilities CD

Quick Installation Guide

Package Contents

Note: Using a power supply with a different voltage than the one included with the DUB-2240 will cause damage and

void the warranty for this product.

If any of the above items are missing, please contact your reseller.

Your DUB-9240 should contain all the items listed below. Before you begin the installation of the device, please check

to make sure that the following items are included in your package.

4D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

Click Next.

Getting Started

Before connecting your wireless USB Adapter or 4-port Hub, insert the provided CD into your PC. The InstallSheild

Wizard will start automatically and detect what operating system you are running on the PC.

After the InstallSheild Wizard detects what operating

system is running on your PC, the Welcome screen

will appear.

Software Installation

5D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

The InstallSheild Wizard will begin the DUB-9240

software installation.

The wizard will prompt you to insert the DUB-1210

wireless USB dongle into an available USB slot.

Click OK.

6D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

Click Next to continue.

The wizard will prompt you to install the Device Firmware

Utility. Select “Install the software automatically”.

The Device Firmware Utility will take a few moments

to install.

7D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

After the Device Firmware Utility has installed, your

system should detect the DUB-1210 Wireless USB

Control Driver as new hardware.

The InstallSheild Wizard will prompt you to install

software for the DUB-1210 Wireless USB Control Driver.

Select “Install the software automatically”.

Click Next to continue.

8D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

Click Finish.

After the DUB-1210 Wireless USB Control Driver has

installed, your system should detect the DUB-1210

Wireless USB Host Wire Adapter as new hardware.

9D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

Click Next to continue.

The InstallSheild Wizard will prompt you to install

software for the DUB-1210 Wireless USB Host Wire

Adapter. Select “Install the software automatically”.

The wizard will prompt you to remove the DUB-1210

wireless USB dongle from the USB port.

Click OK.

10D-Link DUB-9240 User Manual

Section 3 - Conﬁguration

Click Finish.

The following prompt appears when the installation is

complete.

You will be prompted to power on the DUB-2240Wireless

USB Hub and connect it to an available USB port.

Click OK.
