Cypress CPLUS-V4H1HP Manuel utilisateur
CPLUS-V4H1HP
6G UHD 4 to 1 HDMI Switcher with HDCP 2.2
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2016 by Cypress Technology.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 17/04/16 Preliminary Release
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Remote Control................................5
6.4 WebGUI.............................................6
6.5.1 WebGUI Control Page..................7
6.5.2 Power On/Off ................................7
6.5.3 Routing ...........................................8
6.5.4 Source Detect ...............................8
6.5.5 Status ..............................................8
6.5.6 EDID ................................................9
6.5.7 HDCP Control ................................9
6.5.8 HDMI Out Info ..............................10
6.5.9 NAMING .......................................10
6.6 Telnet Control .................................12
6.7 RS-232 Command ..........................13
6.8 IR Cable Pin Assignment................15
6.9 D-sub 9 Pin Denition .....................15
7. Connection Diagram .......................... 16
8. Specications ...................................... 17
9. Support Timing Table........................... 18
9.1 Support Timing Table .....................18
9.2 HDMI Cable Length .......................19
1
1. INTRODUCTION
The 6G UHD 4 to 1 HDMI switcher is the most advanced HDMI solution
for your true Ultra High-Denition signal distribution. It allows you to
manipulate four 6G HDMI input signals with switching into one 6G
HDMI displays. With supports 4K2K@60, 48-bit Deep Color, HDR (High
Dynamic Range) audio and other features dened by HDMI 2.0
specications. Multi control interfaces include RS-232, Telnet, WebGUI,
IR remote and on-panel control makes operation easily and intuitive.
2. APPLICATIONS
• Entertainment Room & Home Theater
• Show Room & Demo Room
• Lecture Room & Hall Presentation
• Show Room & Demo Room
• Public Commercial Display
3. PACKAGE CONTENTS
• 1 x HDMI switcher unit
• 1 x IR Extender with cable
• 1 x 5V / 2.6A DC power adaptor
• 1 x Remote control unit (model: CR-72)
• 1 x Operation Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as PS3/Blu-ray player and output UHD
TV/display.
2
5. FEATURES
• HDMI with 6G 4Kx2K supported, HDCP 2.2 and DVI compliant
• Supports 4 HDMI inputs and 1 HDMI output of 6G video
• Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30/50/60 &
4096x2160 @24/25/30/50/60Hz)
• Supports data rate up to 6Gbps and Deep Color up to 1080p 48-bit
• Supports pass-through of HD audio formats of PCM 2/5.1/7.1CH,
Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD,
Dolby Atmos and DTS-HD Master Audio
• Device could be controlled via Telnet, WebGUI, IR remote and RS-
232
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWERSYNC INPUT1 234
UHD 4 TO 1 SWITCHER
+
HDCP2.2
4321 5 6
1IR receiving window: The IR receiving window receives IR signal of
remote control unit supplied in the package.
2Power: Presses this button to power on the switcher once
connecting with power supply supplied in the package.
3Power indicator: This LED indicator illuminated in red once the
device is connected to power supply and this switcher goes to
standby mode. The network and RS-232 remain active in standby
mode. Press the power button again to power on switcher unit, the
LED indicator illuminated in green.
4SYNC: The SYNC LED indicator illuminated in green when
connecting with sink device.
5Input: Press input button to select preferred source to display. This
switcher unit allowing four sources connection.
6Input source LED indicator: These LED indicator is for distinguish
selected source. Four of input sources are able to be connected.
The correspondence LED indicator (1 ~ 4) illuminated in green
once selected.
4
6.2 Rear Panel
1234
HDMI IN HDMI OUT SERVICECONTROL RS-232IR IN DC 5V
54321 6 7
1HDMI In : Connects with HDMI input sources such as gaming
console, Blu-ray player via HDMI cable. The DVI source is
compatible.
2HDMI Out: Connects with display equips with HDMI input
connector.
3SERVICE: This service slot (USB2.0) is for rmware update in eld.
Please plug in USB thumb drive to update rmware.
4CONTROL: Connects to PC or Laptop with active internet service
for Telnet and WebGUI control with RJ-45 terminated cable.
5RS-232: Connects with D-Sub 9 pin cable with PC or laptop in order
to send RS232 commands to control switcher unit.
6IR IN: Connect the IR Receiver cable supplied in the package for
receiving IR signal for remote control purpose.
7DC 5V: Connects with power adaptor supplied in the package
and connect to AC wall outlet for supplying power to switcher
unit. The power LED indicator on front panel will illuminate once
connecting with AC power.
5
6.3 Remote Control
1POWER: Press this button to switch ON the
device or to set it to standby mode.
2INPUT: Press 1~4 to select input source.
CR-72
POWER
INPUT
34
12
1
2
6
6.4 WebGUI
Install the IP Discovery Tool:
(1) Please obtain the Device Discovery software from your authorized
dealer and save it in a directory where you can easily nd it.
Note: The unit’s default IP address is 192.168.1.50
(2) Connect the unit and your PC/Laptop to the same active network
and execute the Device Discovery software. Click on “Find Devices
on Networkd your PC/Laptop to the same active network and
execute the Device Discovery software. Click on “ntilatio.
(3) By clicking on one of the listed devices you will be presented with
the network details of that particular device. If you choose, you
can alter the static IP network settings for the device, or switch
the unit into DHCP mode to automatically obtain proper network
settings from a local DHCP server. To switch to DHCP mode, please
select DHCP from the IP mode drop-down, then click “Save”
followed by “Reboot”.
(4) Once you are satised with the network settings, you may use them
to connect via Telnet or WebGUI. The network information window
provides a convenient link to launch the WebGUI directly.
