Cypress CLUX-22HC Manuel utilisateur

CLUX-22HC

HDMI/CAT6 to HDMI/

CAT6 Splitter Switcher

Operation Manual

CLUX-22HC

Disclaimers

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes

no commitment to update or to keep current the information

contained in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer ﬁle, in any form or by any means

- electronic, mechanical, magnetic, optical, chemical, manual,

or otherwise - without express written permission and consent from

Cypress Technology.

Version 1.0 December 2009

Trademark Acknowledgments

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

Safety Precautions

Please read all instructions before attempting to unpack or install or

operate this equipment, and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

 Always follow basic safety precautions to reduce the risk of

ﬁre, electrical shock and injury to persons.

 To prevent ﬁre or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

 Never spill liquid of any kind on or into this product.

 Never push an object of any kind into this product through

module openings or empty slots, as you may damage parts.

 Do not attach the power supply cabling to building surfaces.

 Do not allow anything to rest on the power cabling or allow it to

be abused by persons walking on it.

 To protect the equipment from overheating, do not block the

slots and openings in the module housing that provide

ventilation.

Revision History

Version No Date Summary of Change

V1 20091208 Preliminary Release

Table of Contents

1. Introduction…………………………………………………........……….

2. Applications……………………..…………………………................….

3. Package Contents…………………………......…………….............…

4. System Requirements……...…………………..….…………........…….

5. Features…………………………………………….......……........………

6. Specications..………………………………………...........………...….

7. Operation Controls and Functions………………...……........………

7.1 Front Panel ...............................................................................

7.2 Rear Panel……………......………………………….........…….…

8. RJ-45 Pin Denitions …….………………….......................…..…..…...

9. Connection and Installation.............................................................

10. Acronyms...........................................................................................

1. Introduction

The HDMI/CAT6 to HDMI/CAT6 Splitter Switcher is the most advanced

solution for HDMI and Video/DDC signal distribution. This CAT6 output port

can be easily connected to an HDMI receivers CAT6 input port to allow a

stable connection between an HDMI source and any compatible display.

Each product in this series is compatible to HDMI V1.3, which deﬁnes and

supports the transfer of Deep Color (10bit and 12bit) video and a new

lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master

Audio) digital audio signal, with a high bandwidth up to 225MHz (6.75Gbps).

Besides splitting and distributing, the Video/DDC CAT6 output also does signal

ampliﬁcation and equalization which provide high performance I/O of audio

and video.

2. Applications

 Home entertainment integration

 Multi-task project presentation

 Showroom Display

 Advertising display control

 System installation control

3. Package Contents

 1 x HDMI/CAT6 to HDMI/CAT6 Splitter Switcher

 5V DC power supply adaptor

 User Manual

4. System Requirements

 Input source equipment(s) with HDMI cable and or HDMI to CAT6 transmitter

 Output display(s) with HDMI cable and or CAT6 to HDMI receiver with

HDMI cable to display

5. Features

 HDMI 1.3, HDCP1.1 and DVI1.0 compliant.

 Deep color video up to 12bit, 1080p@(24/60)Hz.

 Simultaneously outputs one HDMI and one Video/DDC CAT6 source to

one HDMI and one Video/DDC CAT6 output.

 HDCP keysets allows each output to work independently when

connecting to an HDMI display.

 Capable of splitting HDMI/CAT6 sources to HDMI/CAT6 outputs without

any signal loss.

 Supports LPCM7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD

master audio transmission (32-192 kHz Fs sample rate).

 Supports a wide range of PC and HDTV resolutions from VGA to SXGA

and 480i to 1080p.

 Full HDCP Compliant.

 According to tests The Input/Output source can be up to 15/15 meters

away when the HDMI cable has a resolution of with 1080p/8bits. The

CAT6 cable test showed that with a resolution of 1080p/8bits, the Input/

Output source can be 45/45 meters away. The HDMI cable test showed

that with a resolution of 1080p/12bits, the Input/Output source can be

15/10 meters away. And ﬁnally the CAT6 cable test showed that with a

resolution of 1080p/12bits, the Input/Output source can be 20/20 meters

away

Bandwidth Frequency 2.25Gbps (single link)

Input Ports 1 x HDMI female port (Type A connector)

1 x CAT6 input Video/1 x CAT6 input DDC

Output Ports 1 x CAT6 output Video/1 x CAT6 output DDC

1 x HDMI female ports (Type A connector)

EDID STD / TV

HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D-TrueHD,

DTS-HD

HDMI Cable In 1080p 8-bit (15M), 12-bit (15M)

HDMI Cable Out 1080p 8-bit (15M), 12-bit (10M)

CAT6 Cable In 1080p 8-bit (45M), 12-bit (20M)

CAT6 Cable Out 1080p 8-bit (45M), 12-bit (20M)

HDMI Resolution 480i, ~ 1080p 50/60, 1080p 24, VGA ~ SXGA

IR Frequency 20 ~ 60KHz

ESD Protection Human body model: ±8kV (air-gap discharge)

±4kV (contact discharge)

Power Supply 5VDC/3.2A (US/EU standards, CE/FCC/UL certiﬁed)

Dimensions (mm) 215(W) x123(D) x 30(H)

Weight(g) 365

Chassis Material Metal

Silkscreen Color Silver

Power Consumption 4.1W

Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F

Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F

Relative Humidity 20~90% RH (non- condensing)

6. Specications

7. Operation Controls and Functions

The following sections describe the hardware components of the unit.

7.2 Front Panel

1 2 3 4 65

①HDMI/CAT6 input selection: Switch to select input sources from either

HDMI or CAT6.

②EDID Control Switcher: The default factory setting is TV, do not switch if the

display is compatible. Switch to STD to use built-in EDID.

[Note]:

1. When EDID is switched to TV, the unit will detect and record the ﬁrst HDMI’s

output EDID in the unit. If the ﬁrst detected HDMI output is DVI it will

continue to pass on to the next output until the ﬁrst HDMI output is found.

The detection priority is HDMI v1.3 > HDMI v1.2 > DVI.

2. When EDID is switched to STD the unit will use its own EDID which supports:

Video →1080p 8-bit (max)

Audio →PCM 2CH

3. When EDID is switched to STD with input selection on HDMI or CAT6 IN the

display TV or monitor, they will automatically switch to HDMI input 1. When

EDID is switched to TV regardless of the input selection the display TV or

monitor will switch to HDMI input mode 1. Therefore it is not suggested to

switch the EDID to STD.

4. The EDID selection will activate only when the unit is plugged in and power

is on.

③CEC output: Only when switched to HDMI, the HDMI’s output port CEC will

bypass the CEC and proceed directly to the HDMI and CAT6 input ports.

When switched to HDMI and CAT6, the HDMI and CAT6 output ports CEC

will bypass the CEC and go proceed directly to the HDMI.

④HDMI Input: Connect input port to the HDMI or DVI output port of your

source equipment such as DVD player or set-top-box.

⑤CAT6 IN: These slots are for connecting the Video/DDC input to the

Video/DDC output of the transmitter unit with CAT6 cables.

[Note]:

1. Cable tested with CAT-6E / 23AWG / was solid, so any cables with

different speciﬁcations might result in a different distance.

2. The cable distance was tested with a PS3 40G and 37" SamSung 12

bits LCD TV.

3. The ﬁgures provided in this manual are for reference use only, actual

results depend on your speciﬁc conﬁguration, i.e.: your source and

display and type of cabling used.

⑥DC 5V: This is the slot where you insert the 5V DC power supply for

electrical power before plugging the adaptor into an AC wall outlet.

7.1 Rear Panel

1 2

①CAT6 OUT: Connect the Video/DDC output to the Video/DDC input of

the receiver unit using CAT6 cables.

②HDMI OUT: Connect HDMI output port to the HDMI display.

③HDCP indicators: When the input source has HDCP protection the HDCP

LED will turn on.

④The LED light will turn when the HDMI or DVI source has been connected.

⑤HDMI/CAT6 input indicator: The LED light will turn on when the HDMI or

CAT6 source has been selected.

⑥Link OUT: The LED light will turn on when the display has been connected.
