HDMI 4K UHD Enhancer
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 15/09/14 Preliminary Release
RDV2 09/12/14 Remove Power Supply
RDV3 13/03/15 Cable Distance
VS0 30/06/15 Updated Connection Diagram
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 HDMI Dongle ....................................3
7. Connection Diagram ............................ 4
8. Specications ........................................ 5
8.1 Technical Specications .................5
8.2 Supported Resolutions.....................6
9. Acronyms ............................................... 6
1
1. INTRODUCTION
The HDMI 4K UHD Enhancer is an advanced solution for extending
or cascading an HDMI signal. It is designed to amplify and equalize
the signal to provide high performance transfer of audio and video
through HDMI cable for distance up to 10 meters at 4K2K@60Hz
(YUV420) and can be cascaded up to 5 layers and is capable of
receiving and transmitting up to 3Gbps bandwidth rate with CDR
(Clock Data Recovery) to ensure no loss of data. This unit can be
powered by the HDMI output of suitability equipped source device
(eliminating the need for a power supply) or an HDMI Power Inserter
can be used.
2. APPLICATIONS
• Custom installation usage
• Cascade an HDMI signal
• Extend the operating distance of an HDMI system
3. PACKAGE CONTENTS
• 1×HDMI 4K UHD Enhancer
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
HDMI source device and HDMI equipped output display (TV/monitor)
with HDMI connection cables.
2
5. FEATURES
• HDMI, HDCP 2.2 and DVI 1.1 compliant
• Built-in TMDS equalization and CDR (Clock Data Recovery) for
extending operating distances over HDMI cables
• Supports resolutions up to 4K2K@50/60 (YUV420) and 21:9 aspect
ratio
• Supports HDMI input or o utput cable lengths up to 10 meters at
4K2K@50/60 (YUV420) resolution
• Supports cascading of the HDMI signal to up to 5 layers
• Requires the HDMI source device to output power to the unit over
HDMI cable
• Compact design
Note:
1. Testing was done with 24AWG HDMI cable, results may vary when
used with different source devices or different specication cable
and may affect overall cable distance and cascadable layers.
2. For HDMI source devices that do not support Power over Cable
(PoC) an HDMI Power Inserter unit can be used in-line between
the source device and the HDMI Enhancer unit.
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 HDMI Dongle
IN OUT
EQ • CDR
Ultra HD
1 2
1
HDMI IN
Connect the HDMI input to the HDMI output of an source device
such as a Blu-ray player or an HDMI Matrix/Splitter/Switcher. The
unit can be directly powered by compatible HDMI source devices
that provide power through the HDMI cable or can be powered
by an HDMI Power Inserter placed in-line between the source and
the unit.
2
HDMI OUT
Connect the HDMI output to the HDMI input of an HDMI equipped
display (TV/monitor) or an HDMI Transmitter.
Note: Multiple HDMI Enhancer units may be used (up to 5 layers) to
cascade the signal over longer distances. Additional HDMI Power
Inserter units will be required. It is recommended that an HDMI
Power Inserter unit is used between the rst and the second HDMI
Enhancer units being used and on the last/5th layer before the
connecton to TV or monitor/nal HDMI equipped display.
4
7. CONNECTION DIAGRAM
HDMI OUT
HDMI IN
HDMI OUT 1 HDMI OUT 2
HDMI OUT
HDMI IN
IN OUT
EQ • CDR
Ultra HD
IN OUT
EQ • CDR
Ultra HD
4K AV Receiver
HDMI Cable
HDMI Cable
(Up to 10m@4K2K)
HDMI Cable
(Up to 10m@4K2K)
HDMI Enhancer
HDMI Enhancer
(Optional)
HDMI Splitter
(Optional)
Power Inserter
(Optional)
Power Inserter
(Optional)
HDMI Cable
(Up to 10m@4K2K)
HDMI Cable
(Up to 10m@4K2K)
HDMI Cable
(Up to 2m)
HDMI Cable
(Up to 2m)
HDMI 4K Source
(DVD/Blu-ray Player)
4K Display
4K Display
5
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 340 MHz/10.2 Gbps
Input Port 1×HDMI
Output Port 1×HDMI
Resolution PC: VGA~WUXGA (RB)
HDTV: 480i~4K2K@24/25/30 & 4K2K@50/60
(YUV420)
Cable Distance 10 m@4K2K
15 m@1080p/8-bit or 12-bit
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Dimensions 65 mm (W)×24 mm (D)×9.5 mm (H)
Weight 14 g
Chassis Material Plastic
Color Black
Operating Temperature 0˚C~40˚C/32˚F~104˚F
Storage Temperature −20˚C~60˚C/−4˚F~140˚F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 0.75 W (Max)
