HDBaseT™ 4×4 HDMI over CAT5e/6/7 Matrix with
2 Simultaneous HDMI Outputs
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person to walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 13/09/12 Preliminary Release
RDV2 19/03/13 IR Accessaries Numbers
RDV3 29/05/13 Add WebGUI function
RDV4 22/07/14 RS-232 & Telnet Command
VS1 11/01/16 Updated Format/Diagrams
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 2
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Front Panel ........................................3
6.2 Rear Panel.........................................4
6.3 Side Panel .........................................5
6.4 Remote Control................................5
6.5 IR Cable Pin Assignment..................6
6.6 RS-232 Protocols ...............................6
6.7 RS-232 and Telnet Commands .......7
6.8 RS-232 UART Control.........................9
6.9 Telnet Control .................................10
6.10 WebGUI Control ...........................12
7. Connection Diagram .......................... 14
8. Specications ...................................... 15
8.1 Technical Specications ...............15
8.2 CAT5e/6/7 Cable Specications..16
9. Acronyms ............................................. 16
1
1. INTRODUCTION
The HDBaseT™ Lite 4 by 4 HDMI Matrix over CAT5e/6/7 with two
additional simultaneous HDMI outputs supports the transmission of
video (resolutions up to 1080p Full HD and 1920×1200@60 Hz), multi-
channel digital audio and control via IR, RS-232 or WebGUI/Telnet IP
from four high denition sources to four HDBaseT outputs over a single
CAT5e/6/7 cable (up to 60m) for each output. Output A and C have
additional mirrored HDMI outputs.
It supports high resolution digital audio formats such as LPCM 7.1 CH,
Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio as well as
3D content that can be displayed when connecting a 3DTV and 3D
source.
2. APPLICATIONS
• HDMI system controls
• Video/TV wall display and control
• Security surveillance and control
• Commercial advertising, displaying and control
• Lecture room display and control
• Hyper market demonstration and control
• Residential HDMI systems
3. PACKAGE CONTENTS
• 4 by 4 HDMI Matrix over 4 CAT5e/6/7 with 2 HDMI Outputs
• HDMI over CAT5e/6/7 Receivers (Optional)
• IR Extender Cable
• IR Blaster Cable
• 24V /2.7 A DC Adaptor
• Remote Control
• Operation Manual
2
4. SYSTEM REQUIREMENTS
• HDMI equipped source devices, connect with HDMI cables or DVI
equipped source, connect with DVI to HDMI cables
• HDMI equipped displays (TVs or monitors) or HDMI equipped AV
receivers, connect with HDMI cables
• Industry standard CAT5e/6/7 cables
• HDBaseT™ Receivers (i.e. CH-514RXL)
• Network Router for IP control
5. FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Supports HDMI 3D features
• Supports resolutions VGA~WUXGA and 480i~1080p dependent upon
the output display’s EDID settings
• Supports distances up to 60 meters through CAT6/7 cables
• Supports 3D signal display dependent upon the output display's
EDID settings
• Supports simultaneous HDMI and CAT 5e/6/7 display on outputs A
and C
• Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters
at 12-bit resolution
• Supports bi-directional IR from input and output locations
• Supports RS-232, remote control, on-panel control and IP Control
(Telnet or WebGUI)
• 1U size design
• Supports external and internal EDID settings
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
Note: Do not connect the LAN port to CAT outputs of this device or to
CAT inputs or receiver. Doing so may demage the unit.
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
OUT
12
34IN
CMSI-424L
4X4 HDMI MATRIX
POWERLOCKMENU
AB
CD
61 2 3 4 5
1
LCM: Displays the setting information of each input and output
setting.
2
IR Window: IR Receiver window (accepts the remote control signal
of this device only).
3
POWER: Press this button to power the device on/off. The LED will
illuminate green when the power is on, red when it is in 'Standby'
mode.
4
LOCK: Press this button to lock all the buttons on the panel; press
again to unlock. The LED will illuminate when locked.
5
MENU: Press to access the menu system for EDID and IP settings,
e.g. press once to select EDID setting from STD (internal) 1 or TV
(external) 2 then press it again to conrm the selection. Press the
the 'MENU' button to conrm the input or output selection.
6
IN/OUT and 1~4/A~D: Press the OUT button and then the number
buttons to select the required output ports, and press IN button
and then a single number button to select the required input
source, nally press the MENU button to conrm the selection.
For example, if outputs A~B need to be set to input 1 and outputs
C~D need to be set to input 2, then the following sequence of
button presses need to be performed:
Press: OUTABIN1→MENU,
and then press: OUTCDIN2MENU.
Note: If the menu button is not pressed the selection will not be
changed.
4
6.2 Rear Panel
1
IR IN IR OUT
2
IR IN IR OUT
3
IR IN IR OUT
4
IR IN IR OUT
HDMI OUT CAT5e/6 OUT
A
CAT5e/6 OUT
B
HDMI OUT CAT5e/6 OUT
C
CAT5e/6 OUT
D
HDMI IN 1HDMI IN 2 HDMI IN 3HDMI IN 4 DC 24V
1
2
3
4
V+
GND
GND GND
V+
IR OUT
IR IN
ALL
SERVICE
RS232
IP
CONTROL
2 3
5
1110
1
4
86
7 9
1
RS-232: Connect to a PC or control system with D-Sub 9-pin cable
to control the unit with RS-232 commands.
2
IP CONTROL: Connect to an active network for Telnet/WebGUI
control (refer to Sections 6.8 and 6.9)
Warning: Please do not connect this port directly to the PC/Laptop
as the Telnet function will not work.
3
SERVICE: Manufacturer use only.
4
HDMI OUT and CAT5e/6/7 OUT A/C: Simultaneous HDMI and
HDBaseT CAT5e/6/7 output. The HDMI output can be connected
directly to a display or to a point-to-point transmitter/receiver set.
Connect the CAT5e/6/7 output to a compatible receiver unit to
extend the signal up to 60 m.
5
CAT5e/6/7 OUT B/D: Connect from these CAT outputs to the CAT
input port of the receiver units with a single CAT5e/6/7 cable for HDMI
Audio/Video and IR control signal transmission.
Warning: Please do not connect the CAT5e/6/7 output into the
receiver's LAN port.
6
HDMI IN 1~4: Connect to the HDMI input source devices such as a
DVD player or a Set-top Box with HDMI cable or DVI to HDMI cable.
7
IR IN 1~4: Connect the IR receivers to the IR ouputs. Ensure that
the remote being used is within the direct line-of-sight of the IR
receiver. It will transmit the IR signal to the selected IR OUT output
(from 1~4) and IR OUT ALL.
8
IR OUT 1~4: Connect the IR blasters to the IR outputs. Place the IR
blaster in direct line-of-sight of the equipment to be controlled. It
will transmit the signal as selected in the settings.
9
ALL IR OUT: Connect an IR blaster to this IR output. Place the IR
blaster in direct line-of-sight of the equipment to be controlled. It
will transmit all IR signals received from IR IN 1~4.
5
10
ALL IR IN: Connect an IR Receiver to this IR input. Ensure that
the remote being used is within the direct line-of-sight of the IR
receiver. It will transmit all IR signals received from IR IN 1-8 and IR
IN ALL to IR OUT 1-4 and IR ALL OUT.
11
DC 24V: Connect the 24 V DC power supply to the unit and plug the
adaptor into an AC outlet.
6.3 Side Panel
1
1
Fan Ventilator: These are fan ventilation areas, DO NOT block these
areas or cover them with any object. Ensure there is adequate
space around the unit for air to circulate.
6.4 Remote Control
1
POWER: Press this button to switch on the device or set it to standby
mode.
2
1~4 IN: Input ports selection 1~4.
3
A~D OUT: Output ports selection A~D.
Note: IR Matrix control from Zones only
require the user to select the desired
input.
1A
B
2
C
3
4D
CR-121
IN OUT
1
2
3
Table des matières
Autres manuels CYP Amplificateur
CYP
CYP PU-Q1H8C Manuel utilisateur
CYP
CYP VOPEX-HDMI-2-LC Manuel utilisateur
CYP
CYP QU-110S-4K22 Manuel d'installation
CYP
CYP QU-14S Manuel utilisateur
CYP
CYP AU-A50 Manuel utilisateur
CYP
CYP QU-18S Manuel utilisateur
CYP
CYP QU-18S Manuel utilisateur
CYP
CYP CHDMI14 Manuel utilisateur
CYP
CYP QU-12S-4K22 Manuel utilisateur
CYP
CYP AU-A220 Manuel utilisateur
CYP
CYP QU-12S Manuel utilisateur
CYP
CYP PRO-3GSDI44 Manuel utilisateur
CYP
CYP DCT-23 Manuel utilisateur
CYP
CYP QU-12S Manuel utilisateur
CYP
CYP AU-A300 Manuel utilisateur
CYP
CYP QU-18S Manuel utilisateur
CYP
CYP CMPRO-4H2H Manuel utilisateur
CYP
CYP CHDD-3 Manuel utilisateur
CYP
CYP CHDMI-18C Manuel utilisateur
CYP
CYP AU-D820S Manuel utilisateur
