CyberData 10807 Manuel utilisateur

Quick Reference 930086D © 2008, CyberData Corporation, ALL RIGHTS RESERVED.

Quick Reference for the 4-Port

PoweredUSB 2.0 Hub with External

Power Supply

010807

Installation information

The USB Driver for this Hub is included in the Windows 2000 operating system. For correct initial

enumeration, plug an HID-compliant mouse into the lower USB portion of one port prior to

plugging the hub into the Host PC.

Windows XP Service Pack 2 includes the updated drivers for this Hub. You can download the

Operations Guide for the 4-Port PoweredUSB 2.0 Hub, which includes information on the Windows

XP setup, from the following Product Support page:

http://www.cyberdata.net/support/pusb/4portpusb.html

Product components list

●(1) CyberData 4-Port PoweredUSB 2.0 Hub

●(1) Accessory Kit:

• (1) Short USB 2.0 Hi-Speed host cable

• (1) Host USB cable strain relief clamp

• (1) Hub External Power supply

• (1) Quick Reference for the PoweredUSB 2.0 Hub with External Power Supply and Dell Integrator

Kit

Contact CyberData

●4 Port PoweredUSB 2.0 Hub Product Support URL:

http://www.cyberdata.net/support/pusb/4portpusb.html

●CyberData Sales URL for cables and connectors:

http://www.cyberdata.net/products/poweredusb/pusbcables.html

●Phone: (831) 373-2601, Technical Support Ext. 333 or [email protected]

●Corporate Web Site URL: www.cyberdata.net

●Fax: (831) 373-4193

●Address: 2555 Garden Road, Monterey, CA 93940

●Service, warranty, and Return Materials Authorizations (RMAs): (831) 373-2601 Ext. 136

© 2008, CyberData Corporation, ALL RIGHTS RESERVED. 930086D Quick Reference

Figure 1: USB Host "B" connector and cable strain relief

Figure 2: Component identification: external front and back views

+24V up to 2.5 Amp load

+24V up to

6.5 Amp load

USB Host Connector Type B

Strain

Relief

+12V PoweredUSB Ports +24V

PoweredUSB Port

Port power

(Pwr) and

Hub power

LEDs

Link and

Port1

Status

LEDs

Standard USB 2.0 Hi-Speed

Type A Ports
