Crystal Mountain Avalanche Manuel utilisateur

AVALANCHE

Bottled Water Dispenser User Manual

1. LED Indicator

LED lights indicate when cold and/or hot water are at the optimum temperature

2. Touch Guard® Hot Water Faucet

3. Cold Water Faucet

4. Drip Tray

Parts may not appear exactly as shown

RECEIVING

Inspect the cooler box immediately and carefully for any evidence of shipping or

handing damage before signing to receive goods. In case of shipping damage, claims

should be filed immediately with the carrier. Please note that the carrier will not

accept claims for any damage discovered after the signing for UNINSPECTED

GOODS. Ensure cooler stands upright for 24 hours before plugging it in.

OPERATION

1. Place the water cooler on a flat level surface in a cool shaded location near a

grounded wall outlet. Position water dispenser so that the back of the unit is a

minimum of 2 inches / 5cm away from the wall to ensure proper ventilation

(Figure 1).

2. Place the water bottle on top of the cooler appropriately (Figure 2). For open

reservoir models, the bottle cap needs to be removed.

Note: On H&C models, vent the hot tank by holding the red faucet open until

water flows out (Figure 3). (Heater switch may now be turned on)

3. Ensure that the available power supply matches the cooler’s voltage specifications

indicated on the nameplate label (located at the rear of unit).

Plug power supply cord into receptacle (Figure 4).

Please ensure that cooler is set up so as access to the power outlet and plug is

unobstructed.

Note: To provide additional protection from the risk of shock, this unit MUST be

connected to a ground fault circuit interrupter (GFCI) outlet at all times. Use of an

extension cord will void any warranties.

THANK YOU FOR BUYING A CRYSTAL MOUNTAIN WATER COOLER!

Avalanche

by Crystal Mountain

On Cold

Avalanche

by Crystal Mountain

On Cold

2 inches (5 cm)

Figure 1

Avalanche

by Crystal Mountain

On Cold

Figure 2 Figure 3 Figure 4

4. Do not draw water from the cooler for about 30 minutes to let the water cool or

heat. Optimum water temperatures will be reached after several hours of operation

(Figure 5 and Figure 6).

5. Ensure the following when cooler is to be serviced.

5.1. Turn off Hot Tank Switch (H&C models only) (Figure 7) and disconnect

power supply cord (Figure 8).

5.2. Remove the water bottle (Figure 9) and drawing water from the reservoir

and hot tank, remembering to cool and drain hot tank. Allow 1 hour for hot

water to cool down inside the hot tank before removing the drain plug

located on the bottom of the cooler to drain into a bucket.

CAUTION! ALWAYS DRAIN WATER COMPLETELY

BEFORE SHIPPING OR STORING THE COOLER.

CLEANING

Do Not Immerse the Unit in Water for Cleaning

Remove the lid and clean any dust or contaminants from the cooler by rinsing the

cold water reservoir and faucets with clean water prior to use. Use only mild

dishwashing liquid detergent for cleaning the exterior surfaces (Figure 10 and

Figure 11). DO NOT USE bleach or abrasive cleaners.

Figure 7 Figure 8 Figure 9

Avalanche

by Crystal Mountain

On Cold

Figure 5

Avalanche

by Crystal Mountain

On Cold

Figure 6

Figure 10 Figure 11

Avalanche

by Crystal Mountain

On Cold

Avalanche

by Crystal Mountain

On Cold

Crystal Guard

Figure 12

Locking Pin

Note: The product you have purchased may look different than the model shown in Figure 12.

In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance

must not be supplied through an external switching device such as a timer, connected to a

circuit that is regularly switched on and off by the utility.

The appliance is not to be used by children or persons with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instructions. Children being supervised not to play with the appliance.

Capacity of maximum of 18.9 litres of water bottle or lower shall be used for the water

dispenser, otherwise the dispenser will topple.

Drain hole at the bottom base of the dispenser to prevent water been consolidated at the base.

CAUTION:

ON/OFF switch

(Located at the back of the water

dispenser). To heat up the water in

the Hot Water Tank, switch to ON

position.

Water Outlet for Drainage

(Caution of Hot Water)

WARNING:

The warranty and Underwriters’ Laboratory and CE listings for the coolers are invalidated if

any alteration, modification, or use or misuse in combination with any other machine or

devices is deemed to be the source of any claim. The manufacturer accepts no liability

(including for bodily injury) resulting from any alteration, misuse, neglect, accidents, improper

installations or repairs.

The Red Faucet dispenses hot water during normal operation that may cause severe burns.

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

Children should be supervised to ensure that they do not play with the appliance.

If the supply cord is damaged, it must be replaced by a special cord or assembly available from

the manufacturer or its service agent.

This marking indicates that this product should not be disposed with other household

wastes throughout the EU. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, recycle it responsibly to promote the

sustainable reuse of sustainable resources. To return your used device, please use the

return and collection systems or contact the retailer where the product was

purchased. They can take this product for environmental safe recycling.

The customer acknowledges that water, like other liquids, can cause damage to surfaces. The

customer takes full responsibility for placing the cooler within a residence or business, and

acknowledges that failure to address drips, leaks or spillages is at the customer’s risk.

Environmental application temperature: 10~32°C.

The unit is rated IP10. (This unit is not protected against ingress of water)

For more information on this product, please visit www.crystalcoolers.com
