Crestron TST-902 Manuel utilisateur

TST-902

8.7 in. Wireless Touch Screen

Product Manual

Crestron Electronics, Inc.

The original language version of this document is U.S. English.

All other languages are a translation of the original document.

Crestron product development software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a

limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating

system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement.

Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_

agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed online at www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, Cresnet, Crestron Toolbox, DigitalMedia, Instant-Waking, Rava, and Smart Graphics are

either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries.

Wi-Fi is either a trademark or a registered trademark of Wi-Fi Alliance in the United States and/or other countries.

Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities

claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of

others. Crestron is not responsible for errors in typography or photography.

Contents

Overview 1

Features 2

TST-902 Features 3

TST-902-BTP Features 7

TST-902-DS Features 8

TST-902-DSW Features 9

TST-902-DSW-BB Features 10

TST-902-DSW-BBI Features 11

TST-902-DSW-PMK Features 12

TST-902-DSW-WMKM Features 13

TST-902-DSW-WMKT Features 14

Specifications 15

TST-902 Specifications 16

Product Specifications 16

Dimension Drawings 19

TST-902-BTP Specifications 21

TST-902-DS Specifications 22

Product Specifications 22

Dimension Drawings 23

TST-902-DSW Specifications 24

Product Specifications 24

Dimension Drawings 26

TST-902-DSW-BB Specifications 28

Product Specifications 28

Dimension Drawings 28

TST-902-DSW-BBI Specifications 29

Product Specifications 29

Dimension Drawings 29

TST-902-DSW-PMK Specifications 30

Product Specifications 30

Dimension Drawings 30

TST-902-DSW-WMKM Specifications 31

Product Specifications 31

Dimension Drawings 32

TST-902-DSW-WMKT Specifications 33

Product Specifications 33

Dimension Drawings 34

Installation 35

TST-902 Installation 36

Product Manual — Doc. 7750C Contents • iii

In the Box 36

Install the Battery Pack 36

Place the TST-902 39

TST-902-BTP Installation 40

In the Box 40

Remove the Existing Battery Pack 40

Install the TST-902-BTP 42

Charge the TST-902-BTP 42

Store the TST-902-BTP 43

Recycle the TST-902-BTP 43

TST-902-DS Installation 44

In the Box 44

Install the TST-902-DS 44

TST-902-DSW Installation 46

In the Box 46

Install the Mounting Hardware 46

Install the TST-902-DSW 47

Dock the Touch Screen 50

Undock the Touch Screen 50

TST-902-DSW-BB Installation 53

In the Box 53

Install the Back Box 53

TST-902-DSW-BBI Installation 58

In the Box 58

Install the Back Box 58

TST-902-DSW-PMK Installation 60

In the Box 60

Install the Mounting Kit 60

TST-902-DSW-WMKM Installation 66

In the Box 66

Prepare for Installation 66

Install the Mounting Kit 67

TST-902-DSW-WMKT Installation 76

In the Box 76

Prepare for Installation 76

Install the Mounting Kit 77

Configuration 82

Initial Setup 83

Access the Setup Screens 83

Set Up an Extended Range RFConnection 83

Set Up a Wi-Fi Network Connection 85

Upgrade Firmware 89

Local Configuration 90

iv • Contents Product Manual — Doc. 7750C

RFSetup 91

Audio Setup 92

Display Setup 93

Standby Timeout 94

Wi-Fi Setup 96

Diagnostics 100

About 111

Perform a Factory Restore 112

Operation 113

Resources 114

Crestron Support and Training 114

Programmer and Developer Resources 114

Product Certificates 114

Related Documentation 114

Product Manual — Doc. 7750C Contents • v

Product Manual — Doc. 7750C TST-902 • 1

Overview

The Crestron® TST-902 wireless touch screen is an advanced wireless controller, engineered to

deliver ultimate performance, reliability, and customization for controlling a wide range of

technologies. Its thin, tablet-style design is easy to hold and moves effortlessly between portable

and stationary use. Its large-capacity, rechargeable battery affords several hours of operation

between charges. Dual-mode wireless performance with roaming capability assures dependable

connectivity throughout a commercial facility or home.

This section provides the following information:

lFeatures on page 2

2 • TST-902 Product Manual — Doc. 7750C

Features

Refer to the following sections for more information on the features provided by the TST-902

and its accessories.

lTST-902 Features on page 3

lTST-902-BTP Features on page 7

lTST-902-DS Features on page 8

lTST-902-DSW Features on page 9

lTST-902-DSW-BB Features on page 10

lTST-902-DSW-BBI Features on page 11

lTST-902-DSW-PMK Features on page 12

lTST-902-DSW-WMKM Features on page 13

lTST-902-DSW-WMKT Features on page 14

Product Manual — Doc. 7750C TST-902 • 3

TST-902 Features

The Crestron® TST-902 wireless touch screen is an advanced wireless controller, engineered to

deliver ultimate performance, reliability, and customization for controlling a wide range of

technologies. Its thin, tablet-style design is easy to hold and moves effortlessly between portable

and stationary use.1Its large-capacity, rechargeable battery affords several hours of operation

between charges. Dual-mode wireless performance with roaming capability assures dependable

connectivity throughout a commercial facility or home.

Featuring a high-contrast 8.7in. capacitive touch screen with Smart Graphics® technology, the

TST-902 allows completely customizable control over media presentation and teleconferencing

systems, lighting and shades, HVAC, home theater, and a host of other technologies. Additional

advanced features include voice commands for controlling touch screen functions, full-motion

streaming video from cameras and other sources, Rava® SIP intercom, and an internet

browser.2,3

Key features include:

lAdvanced wireless touch screen controller with thin tablet design

l8.7in. LEDbacklit color LCDdisplay

lCapacitive touch screen display

lSupports Smart Graphics® technology custom user projects

lBuilt-in speakers and microphone

lBuilt-in Rava® SIPintercom

4 • TST-902 Product Manual — Doc. 7750C

lVoice recognition capability

lH.264 or MJPEG streaming video display

lBuilt-in web browsing

lMultitouch support

lDual-mode RF wireless connectivity (Extended Range 2.4 GHz RF and Wi-Fi®

communications)

lRoaming support for extended wireless coverage

lInstant-Waking® technology

lLarge-capacity, user-replaceable Lithium Ion battery pack

lIncluded table dock charges battery while allowing for stationary use

lWall dock option sold separately

Smart Graphics Technology

Smart Graphics® technology enables programmers to integrate fluid gesture-driven controls,

animated feedback, rich metadata, embedded apps and widgets, and full-motion video into their

user interfaces. Smart Graphics provides dynamic features such as graphical buttons and sliders,

lists and toolbars, drag-and-drop objects, dashboard widgets, screensavers, and customizable

themes.1

Voice Recognition

With built-in voice recognition, spoken commands can be issued to the TST-902 to quickly turn

devices on or off, select and play a specific media source, change the channel, choose a lighting

scene, lower the window shades, lock the doors, arm the security system, or enter a password.

Simply say a command and Crestron does the rest.2,3

Streaming Video

Native support for H.264 and MJPEG formats allows the TST-902 to display live streaming video

from an IP camera, a streaming encoder (DM-TXRX-100-STR or similar), or a DigitalMedia™

switcher.3

Rava SIPIntercom

Rava SIP Intercom Technology enables hands-free VoIP communication with other Rava-enabled

touch screens and door stations. Rava works over a network connection, supporting 2-way

intercom and paging without requiring any special wiring. Built-in echo cancellation affords

half-duplex performance for clear, seamless voice communication using the integrated

microphone and speakers.2

Web Browser

Using its built-in web browser, the TST-902 provides access to online program guides and other

web-based services, and it can be used to control DVRs and other devices without having to pick

up a separate tablet or smartphone.3

Product Manual — Doc. 7750C TST-902 • 5

Multitouch Support

The capacitive touch screen display affords enhanced capabilities for browsing web pages using

multitouch control.

On-Screen Keyboard

Typing in passwords, URLs, and text searches is facilitated using the on-screen multilanguage

keyboard.

Audio Feedback

Customized audio files can be loaded to add another dimension to the touch screen graphics

using personalized sounds, button feedback, and voice prompts.

Dual-Mode Wireless Connectivity

The TST-902 delivers high-performing wireless connectivity by employing a combination of

Crestron Extended (ER) Range 2.4 GHz RF and Wi-Fi® wireless technologies.

NOTE:Every TST-902 installation requires a Crestron ERwireless gateway to provide

essential wireless capability to the touch screen. The TST-902 will not function over Wi-Fi

communications alone.

lExtended Range RF(Required):Primary functionality is supported via Crestron ER

(Extended Range) wireless communications, providing seamless touch screen control with

true feedback. A single ER gateway provides dependable wireless performance at a range

of up to 200ft (60m) indoors.4,5 Roaming capability allows for even greater coverage

using up to eight ER gateways.

lWi-Fi Communications (Optional): Advanced wireless capabilities such as streaming video,

voice recognition, web browsing, and dynamic graphics are supported only by using both

ER and Wi-Fi communications together (dual-mode). Crestron-enhanced Wi-Fi wireless

performance supports up to 50ft (15m) of omnidirectional coverage indoors.5For Wi-Fi

networks with multiple access points, the TST-902 can hand off communication from one

access point to another if the active connection is lost.6Support for 802.11 b, g, and n

protocols affords reliable, high-speed wireless performance in virtually any RF

environment.

Instant-Waking Technology

The TST-902 has been engineered with Instant-Waking® technology, where the touch screen

display wakes instantly after being touched. Commands are also sent immediately, so

spontaneous actions like muting audio, pausing video, or changing a channel can be executed

without any waiting.

Extended Battery Life

The TST-902 features a large-capacity, user-replaceable Lithium Ion battery pack that allows for

up to nine hours of continuous operation and several days of typical use between charges.

Intelligent power management and Lithium Ion battery technology work together to provide a

lightweight, compact battery with long battery life.

Autres manuels pour TST-902

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Crestron Écran tactile

Crestron

Crestron TS-770-GV Manuel utilisateur

Crestron

Crestron TPS-FPAR6000L Manuel utilisateur

Crestron

Crestron MT-500C Manuel utilisateur

Crestron

Crestron TSCW-730 Dessin dimensionnel

Crestron

Crestron Isys TPS-3100L Manuel utilisateur

Crestron

Crestron TSW-732 Manuel du propriétaire

Crestron

Crestron TPS-4500IMW Manuel utilisateur

Crestron

Crestron Isys TPMC-4SM Instructions d'utilisation d'origine

Crestron

Crestron DualTouch DTT-17 Manuel utilisateur

Crestron

Crestron QM-FTCC Comment utiliser

Crestron

Crestron TST-902 Dessin dimensionnel

Crestron

Crestron TSS-770 Manuel utilisateur

Crestron

Crestron TSW-560P Dessin dimensionnel

Crestron

Crestron Isys TPMC-4SM Comment utiliser

Crestron

Crestron IM-WCCV Comment utiliser

Crestron

Crestron TPS-1700 Manuel utilisateur

Crestron

Crestron TSW-560 Manuel utilisateur

Crestron

Crestron TPS-FPAR4000L Manuel utilisateur

Crestron

Crestron TPMC-V12 & TPMC-V15 Manuel utilisateur

Crestron

Crestron TPMC-4SMD-FD Instructions d'utilisation d'origine

Crestron

Crestron TSW-770R Series Manuel utilisateur

Crestron

Crestron Isys TPS-3000 Mode d’emploi

Crestron

Crestron Isys TPS-5000 Manuel utilisateur

Crestron

Crestron TSW-560 Manuel du propriétaire

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
