Crestron CPC-2000A Touchpanel with Dual Joysticks

Contents

Touchpanel with Dual Joysticks: CPC-2000A 1

Description.................................................................................................................................1

Functional Description ................................................................................................1

Software ......................................................................................................................1

Physical Description....................................................................................................1

Leading Specifications...............................................................................................................3

Setup ..........................................................................................................................................4

Recommended Cleaning..............................................................................................4

Network Wiring........................................................................................................... 5

Hardware Hookup .......................................................................................................5

Identity Code ............................................................................................................... 6

Configuring the Touchpanel........................................................................................7

Programming ...........................................................................................................................10

Reserved Join Numbers............................................................................................. 10

Sample Program ........................................................................................................11

Problem Solving ......................................................................................................................11

Troubleshooting ........................................................................................................11

Further Inquiries........................................................................................................13

Software License Agreement...................................................................................................14

Return and Warranty Policies.................................................................................................. 16

Merchandise Returns / Repair Service ......................................................................16

CRESTRON Limited Warranty ................................................................................16

Operations Guide - DOC. 5801A Contents •i

Crestron CPC-2000A Touchpanel with Dual Joysticks

Touchpanel with Dual Joysticks:

CPC-2000A

Description

Functional Description

The CPC-2000A is a 5.7 inch (14.5 cm) passive matrix color LCD touchscreen

control panel with dual joystick control and adjustable speed knobs for the remote

control system (herein referred to as the control system). As part of the Crestron

ProCam family which includes pan/tilt heads, a camera control network is formed.

The network can accept up to 250 separate cameras - or other controlled devices - at

distances up to 5000 feet without expansion modules. This unique camera control

network also allows the option of additional or alternative controllers, such as

Crestron touchpanels, PC-based control software, and button panel consolettes.

When included in a camera control network with proper programming, the

CPC-2000A permits control of camera pan/tilt and lens zoom/focus with speed

adjustments. Presets that store the pan/tilt/zoom/focus positions are allowed.

Software

The CPC-2000A has one 256-color

alette. Therefore, all custom colors

are mapped to the nearest color in

that palette, such that colors from

the custom color dialog box may not

be exactly represented. If the precise

shade is not immediately achieved,

the solution is to experiment with a

slightly different color from the

custom color dialog box in VT

Pro-e.

VisionTools™ Pro-e (VT Pro-e), a Windows-based design software, permits the

creation of unlimited control screen variations incorporating two and three-

dimensional graphics and text. A set of pages which make up a project can be

designed for each CPC-2000A application. Each page contains objects such as

custom control graphics, two and three-dimensional buttons, sliders, and digital

readouts which allow the user to interface with the control system. The project is

uploaded to the touchpanel and programmed into the flash PROM. The touchpanel

uses the programmed project until another set is uploaded from the PC. The PC may

be disconnected from the rack or panel, except during reprogramming. VT Pro-e

also allows users the option to generate projects destined for web browsers rather

than for physical touchpanels. For additional software information, consult the VT

Pro-e help file.

Physical Description

The 5.7 inch (14.5 cm) touch sensitive viewing screen is located on the large angled

portion of the top face of the CPC-2000A. The touchscreen is identical to the

Operations Guide - DOC. 5801A Touchpanel with Dual Joysticks: CPC-2000A •1

Touchpanel with Dual Joysticks Crestron CPC-2000A

Crestron CT-1600 with respect to programming and configuration. The electronic

hardware is housed in a black metal enclosure with silk-screened labels, shown

below. Four speed adjustment knobs are located below the touchsceen area. Two

joysticks are located on the horizontally level area of the top face. A RJ-type

network connector is available from the back panel of the unit. There are four rubber

feet on the base of the unit for stability and to prevent slippage.

CPC-2000A Physical Views

TOP FACE

10.07 in

(25.59 cm)

SIDE VIEW

9.00 in

(22.86 cm)

BACK PANE

4.09 in

(10.40 cm)

Sensitivity Adjustment Knobs

Four sensitivity adjustment knobs, located beneath the touchscreen, are used to

regulate pan, tilt, focus, and zoom speeds. Turning the knobs clockwise maximizes

2 •Touchpanel with Dual Joysticks: CPC-2000A Operations Guide - DOC. 5801A

Crestron CPC-2000A Touchpanel with Dual Joysticks

the speed. Speed can be adjusted while using the joysticks. The knobs are panel

mounted single-turn potentiometers.

Joysticks

Two 2-axis, spring centering joysticks, located beneath the sensitivity adjustment

knobs, are used to control pan, tilt, focus, and zoom movement of a network

camera/lens assembly. Vertical movement of the right-most joystick (when viewing

the touchscreen) tilts the head. Horizontal movement of the right-most joystick pans

the head. Vertical movement of the left-most joystick zooms the lens. Horizontal

movement of the left-most joystick focuses the lens.

Network Connector

This 6-pin, 6-position RJ11 modular jack, located on the back panel of the

CPC-2000A, is used to receive power and to communicate with the control system.

Use the cable assembly (supplied) to connect the CPC-2000A to the CN-RJ11

(supplied) and, in turn, connect the CN-RJ11 to the control system per the latest

revision of the network interconnection diagram (Doc. 5411). If connecting the

CPC-2000A to a CNX-series control system, the CN-RJ11 is not required. Make

connections per the latest revision of the modular cable requirements (Doc. 5682).

Leading Specifications

The two tables, shown after this paragraph, provides a summary of leading

specifications for the CPC-2000A and joystick particulars. Dimensions and weight

are rounded to the nearest hundredth unit.

Leading Specifications of the CPC-2000A

SPECIFICATION DETAILS

Power Requirements 12 Watts, 24 VDC 0.5 Amp

Default Network ID 03 (touchpanel) & 30H (joystick)

SIMPL™ Windows® Version 1.22 or later*

CNX Operating System Version 5.01.09x or later

CNX Monitor Version 2.00 or later

CNMS, CNRACK, CNLCOMP Version 3.16.08 or later

Operating System

ST-CP Operating System Version 4.00.29 or later

ST-CP Monitor Version 1.29 or later

VisionTools™ Pro Version 1.2.1 or later*

Crestron Database Version 11.7.209 or later*

Memory 768 Kbytes flash memory for display

Dimensions Height: 4.09 in (10.40 cm)

Width: 9.00 in (22.86 cm)

Depth: 10.07 in (25.59 cm)

Weight (without CN-RJ11) 3.60 lb (1.63 Kg)

* The latest software versions can be obtained from the Downloads page (SIMPLWIN, TOUCHPNL,

and CRESDB Libraries) on the Crestron website (www.crestron.com). New users are required to

NOTE: In order to have CPC-2000A available from the Device Library when

programming in SIMPL Windows, use the latest version of SIMPL Windows

available from Crestron’s website or use an earlier version with library update file

smwlib58.exe and library update document smwlib58.txt or later. These update files

are available from the Downloads page (SIMPLWIN Library) of Crestron’s website.

Operations Guide - DOC. 5801A Touchpanel with Dual Joysticks: CPC-2000A •3

Touchpanel with Dual Joysticks Crestron CPC-2000A

Leading Specifications of the CPC-2000A (Continued)

SPECIFICATION DETAILS

View Screen Dimensions Height: 3.50 in (8.89 cm)

Width: 4.70 in (11.94 cm)

View Screen Resolution 320 x 240 pixels

View Screen Display Passive Matrix Color LCD

View Screen Illumination Edgelit Fluorescent

View Screen Touch Screen Resistive Membrane

Leading Specifications of the CPC-2000A Joysticks

SPECIFICATION DETAILS

Number of Axes 2-Axis

Mounting Bezel Rubber Boot Seal

Centering Spring Centering

As of the date of manufacture, the CPC-2000A has been tested and found to comply

with specifications for CE marking.

NOTE: This device complies with part 15 of the FCC rules. Operation is subject to

the following two conditions: (1) these devices may not cause harmful interference,

and (2) these devices must accept any interference received, including interference

that may cause undesired operation.

Setup

Recommended Cleaning

Keep the surface of the touchscreen free of dirt, dust, or other materials that could

degrade optical properties. Long term contact with abrasive materials can scratch the

surface which may detrimentally affect image quality.

For best cleaning results, use a clean, damp, non-abrasive cloth with any

commercially available non-ammonia glass cleaner. The surrounding plastic

enclosure may not provide a complete water-tight seal, therefore, apply cleaning

solution to the cloth rather than the surface of the touchscreen. Wipe touchscreen

clean and avoid ingress of moisture beneath panels.

4 •Touchpanel with Dual Joysticks: CPC-2000A Operations Guide - DOC. 5801A

Crestron CPC-2000A Touchpanel with Dual Joysticks

Network Wiring

NOTE: This section only applies to those applications using 4-wire Cresnet wiring.

When calculating the wire gauge for a particular network run, the length of the run

and the power factor of each network unit to be connected must be taken into

consideration. If network units are to be daisy-chained on the run, the power factor

of each network unit to be daisy-chained must be added together to determine the

power factor of the entire chain. If the network unit is a home-run from a Crestron

system power supply network port, the power factor of that network unit is the

power factor of the entire run. The length of the run in feet and the power factor of

the run should be used in the resistance equation, shown below, to calculate the

value on the right side of the equation.

Resistance Equation

R = Resistance (refer to table below)

L = Length of run (or chain) in feet

PF = Power factor of entire run (or chain)

R < L x PF

40,000

Where:

The required wire gauge should be chosen such that the resistance value is less than

the value calculated in the resistance equation. Refer to the table below.

Wire Gauge Values

RESISTANCE (R) WIRE GAUGE

416

618

10 20

15 22

13 Doubled CAT5

8.7 Tripled CAT5

NOTE: All Cresnet wiring must consist of two twisted-pairs. One twisted pair is the

+24V conductor and the GND conductor and the other twisted pair is the Y

conductor and the Z conductor.

NOTE: When daisy-chaining Cresnet units, strip the ends of the wires carefully to

avoid nicking the conductors. Twist together the ends of the wires that share a pin on

the network connector, and tin the twisted connection. Apply solder only to the ends

of the twisted wires. Avoid tinning too far up the wires or the end becomes brittle.

Insert the tinned connection into the Cresnet connector and tighten the retaining

screw. Repeat the procedure for the other three conductors.

Hardware Hookup

WARNING: To avoid shock hazard and possible damage to the unit, do not use

touchpanel in rain or expose it to unnecessary moisture.

NOTE: The CN-RJ11 is not necessary if the CPC-2000A is connected directly to a

CNX-series control system.

NOTE: Before making any connections, review the latest revisions of the network

interconnection drawing (Doc. 5411) and the network modular cable requirements

Operations Guide - DOC. 5801A Touchpanel with Dual Joysticks: CPC-2000A •5

Touchpanel with Dual Joysticks Crestron CPC-2000A

(Doc. 5682). Pinout notations are provided on these documents. The wiring

documents can be obtained from the Downloads page (CABLES and MANUALS

Libraries) of the Crestron website (www.crestron.com). Search for the

CRESNET.PDF and MODULAR.PDF files.

Refer to the hookup diagram below for proper connections of the

CPC-2000A to the control system. Other than making the power connection last,

complete the connection in any order.

Control System Hookup Connections for the CPC-2000A

BACK PANEL VIEW OF CPC-2000A

THIS CONNECTION IS ONLY REQUIRED

WHEN LOADING YOUR VT PRO-E

PROJECT TO THE CPC-2000A OR

WHEN SETTING THE NET ID OF

THE JOYSTICK.

UNITS IN THIS ILLUSTRATION

ARE NOT DRAWN TO SCALE.

CRESTRON

CN-RJ11

NOTE:

SERIAL

PORT

CONTROL

SYSTEM

NOTE:

Identity Code

Each device and user interface within the network requires a unique identity code

(NET ID). These codes are recognized by a two-digit hexadecimal number from 03

to FE. The NET ID of the unit must match an identity code specified in the SIMPL

Windows program.

The CPC-2000A possesses two distinct identity codes; one code is for the

touchpanel and the other is for the sensitivity adjustment knobs and joysticks which

are treated as a network device. The NET ID of the touchpanel component is set to

03. Refer to “Interface Menu” on page 9 for instructions on setting the touchpanel

component of the unit’s identity code. For the knob/joystick component, the NET ID

has been factory set to 30H, but may be changed from the PC via VT Pro-e or

SIMPL Windows.

The method for changing the unit’s NET ID is identical regardless of the software

chosen. Attach the CPC-2000A to the control system (verify that the software is

running) and complete the following steps to change the NET ID.

1. Disconnect all network devices from the control system, except for the

one CPC-2000A that needs to have its NET ID changed.

6 •Touchpanel with Dual Joysticks: CPC-2000A Operations Guide - DOC. 5801A

Table des matières

Autres manuels Crestron Écran tactile

Crestron

Crestron STX-1550C Manuel utilisateur

Crestron

Crestron TSS-770 Manuel utilisateur

Crestron

Crestron CT-1000 Manuel utilisateur

Crestron

Crestron Isys TPS-3100L Manuel utilisateur

Crestron

Crestron TST-902 Manuel utilisateur

Crestron

Crestron Lsys TPS 2000L Manuel utilisateur

Crestron

Crestron TPMC-9 Manuel utilisateur

Crestron

Crestron TSW-570 Manuel utilisateur

Crestron

Crestron QM-FTCC Comment utiliser

Crestron

Crestron Smart Touch C2N-IRGW Manuel utilisateur

Crestron

Crestron Isys i/O TPMC-15-CH Manuel utilisateur

Crestron

Crestron TPS-4500IMPC Manuel utilisateur

Crestron

Crestron Isys i/O TPMC-15-CH-L Manuel utilisateur

Crestron

Crestron TSW-560P Dessin dimensionnel

Crestron

Crestron TS-1542 Manuel du propriétaire

Crestron

Crestron STX-1550C Manuel utilisateur

Crestron

Crestron DualTouch DTT-18 Manuel utilisateur

Crestron

Crestron Isys TPMC-4SM Instructions d'utilisation d'origine

Crestron

Crestron TSW-732 Manuel du propriétaire

Crestron

Crestron Isys TPS-4500LV Manuel utilisateur

Crestron

Crestron TPS-4500IMC Manuel utilisateur

Crestron

Crestron DualTouch DTT-15V3 Manuel utilisateur

Crestron

Crestron QM-FTCC Comment utiliser

Crestron

Crestron Isys TPS-4500 Manuel utilisateur

Manuels Écran tactile populaires d'autres marques

FlowLine

FlowLine Data loop Manuel utilisateur

ALPEX

ALPEX AEx-8 P Series Manuel utilisateur

Ltech

Ltech E5S Manuel utilisateur

Harman

Harman AMX MODERO S MSD-701-L2 Manuel utilisateur

Acnodes

Acnodes PC 1150 Manuel utilisateur

AIS

AIS IP10IA99 series Manuel utilisateur

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manuel utilisateur

YASKAWA

YASKAWA TP 610C Manuel utilisateur

B&R

B&R Power Panel C Series Manuel utilisateur

Beijer Electronics

Beijer Electronics X2 control Manuel utilisateur

AXIOMTEK

AXIOMTEK GOT321W-521 Manuel utilisateur

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manuel utilisateur

Qomo

Qomo QIT1386 Manuel utilisateur

DFI

DFI KS104-CD Manuel utilisateur

AMX

AMX AXP-PPC Mode d’emploi

Sartorius

Sartorius X3 PR 5410 Manuel utilisateur

AMX

AMX Modero X Series Manuel utilisateur

Advantech

Advantech TPC-30 Series Manuel utilisateur
