Crestron TPS-4500IMC Manuel utilisateur

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-800-CRESTRON

Crestron TPS-4500IMC Interface Module

Contents

Interface Module: TPS-4500IMC 1

Description.................................................................................................................................1

Functional Description ................................................................................................1

Physical Description....................................................................................................1

I/O Ports ......................................................................................................................1

Leading Specifications...............................................................................................................3

Setup ..........................................................................................................................................4

Network Wiring...........................................................................................................4

Hardware Hookup .......................................................................................................5

Problem Solving ........................................................................................................................8

Troubleshooting........................................................................................................... 8

Further Inquiries .......................................................................................................... 8

Future Updates ............................................................................................................9

Return and Warranty Policies ..................................................................................................10

Merchandise Returns / Repair Service ...................................................................... 10

CRESTRON Limited Warranty.................................................................................10

Operations Guide - DOC. 5890 Contents •i

Crestron TPS-4500IMC Interface Module

Interface Module: TPS-4500IMC

Description

Functional Description

The TPS-4500IMC is designed specifically to serve as an interface

module for the Crestron TPS-4500 tilt touchpanel. The sleek design of

the touchpanel base left little room for all the connectors that define the

touchpanel's versatility. Furthermore, since the panel is not a stationary

user interface, it is impractical to have an excessive amount of cable

connections directly to the touchpanel. As a result, it was necessary to

connect the touchpanel to an interface module that could offer additional

space for interconnections.

Physical Description

The TPS-4500IMC, shown on the next page, is supplied with every

TPS-4500 tilt touchpanel. The module is housed in a black enclosure

with silk-screened top panel. A network connector and video input

connectors are located on one side of the unit. The opposite side offers a

network/video connection to the touchpanel. At the shorter sides of the

TPS-4500IMC, the enclosure extends to form feet at a right angle to the

side. There are three holes per foot for inserting screws to further

stabilize the unit to a mounting surface.

I/O Ports

There are five I/O ports available on the TPS-4500IMC. Refer to the

diagram on the next page and the following bulleted items for

descriptions of each port.

Operations Guide - DOC. 5890 Interface Module: TPS-4500IMC •1

Interface Module Crestron TPS-4500IMC

Physical Views of the TPS-4500IMC

TOPANEL

CRESTRON

0.250 in

(0.635 cm)

CAUTION:

Verify that jumpers and six-pin video connector are installed

at all times, except for differential input (balanced) video signal.

Refer to "Hardware Hookup" beginning on page 5 for details.

1.240 in

(3.150 cm)

NET

24 Y Z

0.750 in

(1.905 cm)

0.750 in

(1.905 cm)

0.235 in

(0.597 cm)

NET/

TPS -4500 IMC

VIDEO

COMP

4.820 in

(12.243 cm)

5.325 in

(13.526 cm)

COMP

YCS+_

S+

NTSC/PAL VIDEO

2.000 in

(5.080 cm)

• NTSC/PAL VIDEO – These three ports are made active with

the purchase and installation of the TPS-VID, composite and

S-video input for TV video card. Consult the latest revision of

the TPS-VID Operations & Installation Guide (Doc. 5869) for

details. Use either the two BNC connectors or the six-pin

connector when connecting to a video source.

CAUTION: Except for differential input (balanced) video signal,

the six-pin video connector with jumpers should be installed at all

times. Refer to "Hardware Hookup" beginning on page 5 for

details.

• NET – This four-pin connector is used to connect to other four-

wire devices in the Cresnet system. If making network

connections to Cresnet peripherals, refer to "Network Wiring"

on page 4 for details.

2 •Interface Module: TPS-4500IMC Operations Guide - DOC. 5890

Crestron TPS-4500IMC Interface Module

• NET/VIDEO – This 10-position RJ45 mates with the TPS-4500

touchpanel and has a dual purpose. Refer to the descriptions

and pinout table that follow this paragraph.

1. This port provides network connection to the touchpanel.

2. This port also makes available composite or S-video input for

TV video card (with the purchase and installation of the TPS-

VID). Consult the latest revision of the TPS-VID Operations &

Installation Guide (Doc. 5869) for details.

NET/VIDEO Pinouts

PIN # DESIGNATION DESCRIPTION

1 +24V Power (Network)

2 GND Ground (Network)

3 C+ Chrominance (Positive)

4 C- Chrominance (Negative)

5 Y Data (Network)

6 Z Data (Network)

7 Y+ Luminance (Positive)/Composite

8 Y- Luminance (Negative)/Composite

9 GND Ground (Network)

10 +24V Power (Network)

Leading Specifications

The table after this paragraph provides a summary of leading

specifications for the TPS-4500IMC. Dimensions and weight are rounded

to the nearest hundredth unit.

Leading Specifications for the TPS-4500IMC

SPECIFICATION DETAILS

Dimensions Height: 2.00 in (5.08 cm)

Width: 5.33 in (13.53 cm)

Depth: 1.24 in (3.15 cm)

Weight 0.51 lb (0.23 kg)

As of the date of manufacture, the TPS-4500IMC has been tested and

found to comply with specifications for CE marking.

Operations Guide - DOC. 5890 Interface Module: TPS-4500IMC •3

Interface Module Crestron TPS-4500IMC

Setup

Network Wiring

NOTE: When making wire connections, refer to the latest revision of

the Cresnet Network Interconnect Drawing (Doc. 5411). The document

can be obtained from the Downloads page (CABLES and MANUAL

Libraries) of the Crestron website (www. crestron.com). Search for the

CRESNET.PDF files.

When calculating the wire gauge for a particular network run, the length

of the run and the power factor of each network unit to be connected

must be taken into consideration. If network units are to be daisy-chained

on the run, the load factor of each network unit to be daisy-chained must

be added together to determine the load factor of the entire chain. The

length of the run in feet and the load factor of the run should be used in

the following resistance equation to calculate the value on the right side

of the equation.

Resistance Equation

R = Resistance (refer to table below).

L = Length of run (or chain) in feet.

LF = Load factor of entire run (or chain).

R < L x LF

40,000 Where:

The required wire gauge should be chosen such that the resistance value

is less than the value calculated in the resistance equation. Refer to the

table after this paragraph.

Wire Gauge Values

RESISTANCE (R) WIRE GAUGE

416

618

10 20

15 22

13 24 (Doubled-CAT 5)

NOTE: All network wiring must consist of two twisted-pairs. One

twisted pair is the +24V conductor and the GND conductor and the other

twisted pair is the Y conductor and the Z conductor.

4 •Interface Module: TPS-4500IMC Operations Guide - DOC. 5890

Crestron TPS-4500IMC Interface Module

NOTE: When daisy chaining network units, always twist the ends of the

incoming wire and outgoing wire which share a pin on the network

connector. After twisting the ends, tin the twisted connection with solder.

Apply solder only to the ends of the twisted wires. Avoid tinning too far

up or the tinned end becomes brittle and breaks. After tinning the twisted

ends, insert the tinned connection into the network connector and tighten

the retaining screw. Repeat the procedure for the other three network

conductors.

Hardware Hookup

The TPS-4500IMC serves as an interface between the touchpanel and the

Cresnet system. Refer to the illustration on the next page for proper

connections; apply power last. When making network connections to the

CNX Generation control system or Cresnet peripherals, refer to "Network

Wiring" on page 4 for details. It is not necessary to make connections to a

video source unless the TPS-VID has been installed into the touchpanel

and a video window object resides on a page within the uploaded

VisionTools™ Pro-e project.

Operations Guide - DOC. 5890 Interface Module: TPS-4500IMC •5

Interface Module Crestron TPS-4500IMC

Hardware Hookup for the TPS-4500IMC

TPS -4500 IMC

CRESTRON

TOPANEL

VIDEO

NET/

NET

ZY24

COMP

NTSC/PAL VIDEO

COMP

++S

CONNECT TO CNX

GENERATION

CONTROL SYSTEM

OR CRESNET

PERIPHERALS

CONNECT TO TPS-4500

* CONNECT

TO VIDEO

SOURCE

* Connect to a video source only if the TPS-VID expansion card is

installed in the touchpanel. The BNC connector and screw terminal mini

Phoenix connector is connected in parallel. Possible options are no

connection, balance video using twisted pair cable, or unbalanced video

using coax cable. Depending on the option, the two jumpers on the

NTSC/PAL VIDEO six-pin connector remain attached or are removed.

CAUTION: If there is no video, do not make a connection to this port,

but leave connector and jumpers attached to the NTSC/PAL VIDEO six-

pin connector on the TPS-4500IMC. Failure to do so may damage the

TPS-4500IMC.

Video balance is determined by external connections. Refer to the two

diagrams on the next page.

6 •Interface Module: TPS-4500IMC Operations Guide - DOC. 5890
