Crestron GLS-EM-MCU Manuel utilisateur

Crestron GLS-EM-MCU

Crestron Green Light®Power Meter

Control Unit

Operations Guide

This document was prepared and written by the Technical Documentation department at:

The specific patents that cover Crestron products are listed at patents.crestron.com.

Crestron, the Crestron logo, Crestron Green Light, Crestron Toolbox and Fusion EM are either trademarks or registered trademarks of Crestron

Electronics, Inc. in the United States and/or other countries. UL and the UL logo are either trademarks or registered trademarks of Underwriters

Laboratories, Inc. in the United States and/or other countries. Windows is either a trademark or registered trademark of Microsoft Corporation in

the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to

either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.

Regulatory Compliance

This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.

As of the date of manufacture, the GLS-EM-MCU has been tested and found to comply with specifications

for CE marking and standards per EMC and Radiocommunications Compliance Labelling.

Federal Communications Commission (FCC) Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:

(1) This device may not cause harmful interference and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment and receiver

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

•Consult the dealer or an experienced radio/TV technician for help

Industry Canada (IC) Compliance Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Crestron GLS-EM-MCU Crestron Green Light®Power Meter Control Unit

Operations Guide – DOC. 7294B Contents

•

Contents

Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU 1

Introduction ............................................................................................................................... 1

Features and Functions ................................................................................................ 1

Applications................................................................................................................. 3

Specifications ..............................................................................................................4

Physical Description .................................................................................................... 5

Setup ........................................................................................................................................ 10

Identity Code ............................................................................................................. 10

Installation and Wiring .............................................................................................. 10

Hardware Hookup ..................................................................................................... 10

Programming Software ............................................................................................................ 11

Earliest Version Software Requirements for the PC ................................................. 11

Programming with SIMPL Windows ........................................................................ 11

Uploading and Upgrading........................................................................................................ 13

Establishing Communication..................................................................................... 13

Programs and Firmware ............................................................................................ 14

Program Checks ........................................................................................................ 14

Configuration........................................................................................................................... 15

Recording Interval ..................................................................................................... 15

Electrical Tab ............................................................................................................ 15

Pulse Metering Tab.................................................................................................... 15

Problem Solving ...................................................................................................................... 16

Troubleshooting......................................................................................................... 16

Reference Documents................................................................................................ 16

Further Inquiries ........................................................................................................ 16

Future Updates .......................................................................................................... 16

Return and Warranty Policies .................................................................................................. 18

Merchandise Returns / Repair Service ...................................................................... 18

Crestron Limited Warranty........................................................................................ 18

Crestron GLS-EM-MCU Crestron Green Light®Power Meter Control Unit

Operations Guide – DOC. 7294B Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU

•

Crestron Green Light®Power

Meter Control Unit: GLS-EM-MCU

Introduction

The GLS-EM-MCU is an Ethernet-based power metering control unit, designed to

log overall electricity usage in real time. It measures and tracks actual energy

consumption by attaching to the incoming electrical service and branch circuits. The

GLS-EM-MCU also works in unison with the GLS-EM-CTI and GLS-EM-CT to

provide more detailed data by tracking individual branch circuits in a home or office.

This data is then displayed on a touch screen, mobile device or computer for viewing

by users. Additionally, the GLS-EM-MCU system interfaces with Fusion EM™

Energy Management Software to provide reports with greater detail showing total

building consumption.

Features and Functions

Three-Phase Monitoring

The main control unit (MCU) monitors both voltage and current to provide complete

statistics of a building's electricity consumption. To achieve this, the MCU connects

to line voltage of each phase (up to three) and neutral. Current transformers

(GLS-EM-CTs) clamp around each of the incoming feed wires. These CTs then wire

into the MCU's inputs. With the voltage and current data, the MCU calculates power

usage.

Individual Branch Monitoring

In many cases, users may want to monitor consumption by area, or even device. The

main control unit, in conjunction with the current transformer interface, enables

metering of multiple branch circuits. GLS-EM-CT current transformers are placed

•Power metering across 3 phases (main legs)

•Reports data to control system and Fusion EM™

•Monitors and logs RMS voltage, current, and active power

•Monitors up to 84 individual branch circuits for more detailed data

•Installs next to electrical panel

•Operable with 100-347 Volt, 2- and 3-phase systems

•Non-volatile memory reliably stores internally logged data

Crestron Green Light®Power Meter Control Unit Crestron GLS-EM-MCU

•

Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU Operations Guide – DOC. 7294B

around the feed wire of each circuit, and then connected to the GLS-EM-CTI current

transformer interfaces. Up to four GLS-EM-CTI can connect to a single

GLS-EM-MCU for monitoring of up to 84 branch circuits.

Current Transformers

Current transformers are vital to metering power. Crestron®offers various split-core

models that work with 600, 400, and 200 Amp feeds; these devices clamp around

main feeds. Solid-core models exist for 50 and 20 Amp circuits; the wire must be

routed through the closed loop of the core.

Real-time and Logged Data

Inherent to the GLS-EM-MCU is the ability to provide both real-time and logged

power usage data. Real-time data can be used on touch screens or lobby displays to

show instantaneous usage. The energy usage screen within Fusion EM software

provides attractive charts and graphs that illustrate the facility's energy consumption.

Additionally, logged data can be shared with Fusion EM for more detailed reporting.

The GLS-EM-MCU stores the logged data in non-volatile memory to prevent data

loss.

Crestron GLS-EM-MCU Crestron Green Light®Power Meter Control Unit

Operations Guide – DOC. 7294B Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU

•

Applications

The following diagram shows a GLS-EM-MCU in a typical application.

GLS-EM-MCU in a Typical Application

Crestron Green Light®Power Meter Control Unit Crestron GLS-EM-MCU

•

Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU Operations Guide – DOC. 7294B

Specifications

Specifications for the GLS-EM-MCU are listed in the following table.

GLS-EM-MCU Specifications

SPECIFICATION DETAILS

Wired Communications

Ethernet

Branch Circuit Monitor Bus

10/100 Mbps; auto-switching; auto-

negotiating; auto-discovery; full/half duplex;

industry-standard TCP/IP stack; UDP/IP;

CIP; DHCP; IPv4; installer setup via

Crestron Toolbox™

Addressable data bus for connecting MCU

to CTI units; transfers value provided by CT

connected to CTI

Operating Voltage 100 to 347 Volts AC, 50/60Hz

Minimum 2-Series Control

System Update File1,2

Version 4.003.0007 or later

Enclosure Galvanized steel with powder coat finish

Environmental

Installation Location Indoor use only

Temperature 32º to 104º F (0º to 40º C)

Humidity 0% to 95% RH (non-condensing)

Heat Dissipation 10 BTU/Hr

Dimensions

Height 10 1/4 in (260 mm)

Width 10 3/16 in (260 mm)

Depth 3 7/16 in (88 mm)

Weight 64 oz (1.8 kg)

1. The latest software versions can be obtained from the Crestron Web site. Refer to the NOTE

following these footnotes.

2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product

Catalog for a complete list of 2-Series control systems.

NOTE: Crestron software and any files on the Web site are for authorized Crestron

dealers and Crestron Authorized Independent Programmers (CAIPs) only. New users

must register to obtain access to certain areas of the site (including the FTP site).

Crestron GLS-EM-MCU Crestron Green Light®Power Meter Control Unit

Operations Guide – DOC. 7294B Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU

•

Physical Description

This section provides information on the connections, controls and indicators

available on the GLS-EM-MCU.

GLS-EM-MCU Physical View

Crestron Green Light®Power Meter Control Unit Crestron GLS-EM-MCU

•

Crestron Green Light®Power Meter Control Unit: GLS-EM-MCU Operations Guide – DOC. 7294B

GLS-EM-MCU Overall Dimensions

7 in

(178 mm)

Both Ends

7 3/4 in

(196 mm)

Both Ends

3 3/4 in

(96 mm)

Both Ends

(8x) Ø 3/16 in

(Ø 6 mm) Wall

Mounting Holes for

#8 or #10 Screws

(Not Supplied)

2 in

(51 mm)

1 11/16 in

(43 mm)

2 11/16 in

(69 mm)

10 1/4 in

(260 mm)

10 3/16 in

(260 mm)

10 1/8 in

(257 mm)

1 1/4 in

(32 mm)

3/8 in

(10 mm)

(12x) Knockouts for

1/2 in (13 mm) Conduit

3 7/16 in

(88 mm)

3 3/16 in

(81 mm)

3/16 in

(5 mm)

2 1/16 in

(53 mm)

6 in

(153 mm)

Both Ends

7 1/2 in

(191 mm)

Both Ends

2 7/16 in

(62 mm) 1 11/16 in

(44 mm)

1 5/16 in

(34 mm)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Crestron Unité de contrôle

Crestron

Crestron FT2A-PWR-UK Series Manuel utilisateur

Crestron

Crestron BiAmp AudiaFlex Manuel utilisateur

Crestron

Crestron DIN-AO8 Instructions d'utilisation d'origine

Crestron

Crestron FlipTop FT2 Series Manuel utilisateur

Crestron

Crestron TS-1542-IMCW Manuel utilisateur

Crestron

Crestron FT2A-CHGR-USBA/C Manuel utilisateur

Crestron

Crestron C2N-VEQ4 Manuel utilisateur

Crestron

Crestron FT2A-PWR 1-C14 Series Manuel utilisateur

Crestron

Crestron FT2A-PWR-UN-1-C14 Manuel utilisateur

Crestron

Crestron CP3 Manuel utilisateur

Crestron

Crestron INET-IOEX-IRCOM Manuel utilisateur

Crestron

Crestron CLTI-2DIMU8 Manuel utilisateur

Crestron

Crestron GLS-SIM Mode d'emploi

Crestron

Crestron C2N-VEQ4 Manuel utilisateur

Crestron

Crestron APAD Manuel utilisateur

Crestron

Crestron FT2A-PWR-UK-1-C14 Manuel utilisateur

Crestron

Crestron CNTV Manuel utilisateur

Crestron

Crestron FlipTop FT2 Series Manuel utilisateur

Crestron

Crestron CWD6790R1 Manuel utilisateur

Crestron

Crestron CWD6609 Manuel utilisateur

Crestron

Crestron DMPS3-4K-250-C Dessin dimensionnel

Crestron

Crestron APAD Instructions d'utilisation

Crestron

Crestron CGEIB-IP Comment utiliser

Crestron

Crestron C2N-IO Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
