Creative WebCam Live Ultra Manuel utilisateur

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Nederlands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Dansk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Norsk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

Svenska . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Suomi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Polski. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

CLE_multi.book Page 1 Tuesday, November 16, 2004 4:51 PM

CLE_multi.book Page 2 Tuesday, November 16, 2004 4:51 PM

English

About Your Creative WebCam

Power LED Lights up when your webcam is connected to your computer's USB port.

Focus ring Adjusts the view focus. Point the lens toward your subject and then rotate this ring in

a clockwise or counterclockwise motion until the image is in focus.

Snapshot

button Press it to launch WebCam Center and capture images.

USB cable Connect it to your computer's USB port.

Hinged lever Use this to mount your camera on an LCD display panel.

Focus ring

Snapshot

button

USB cable

Hinged

lever

Figure 1

Front View Side View

Power LED

CLE_multi.book Page 3 Tuesday, November 16, 2004 4:51 PM

Getting Started

1Installing Your Webcam

You need to install device drivers and applications before using your webcam.

Do not connect your webcam to your computer before installing the drivers.

If you accidentally begin installation with your webcam connected and the Add New

Hardware Wizard or Found New Hardware Wizard dialog box appears, click the

Cancel button.

1. Insert the Installation CD into your CD-ROM drive. Your CD should start

automatically. If it does not, follow the steps below:

i. Start Windows Explorer.

ii. On the left pane, click the My Computer icon.

iii. Right-click the CD-ROM/DVD-ROM drive icon, and then click Autoplay.

2. Select the region you are in and then click the Next button.

3. Select a language and then click the Next button.

4. Click the options for installing drivers and applications, and then click the Install

button.

CLE_multi.book Page 4 Tuesday, November 16, 2004 4:51 PM

5. Place your webcam on top of your computer monitor or other flat surface. For LCD

flat panel monitors or notebook computers, use the integrated hinged lever to balance

the camera (see Figure 2).

6. When prompted, connect your webcam's USB cable to an available USB port on your

computer (see Figure 3). Windows®automatically detects the device.

Figure 2

Figure 3

USB port

CLE_multi.book Page 5 Tuesday, November 16, 2004 4:51 PM

7. To complete the installation, follow the appropriate steps below:

For Windows XP

When the Found New Hardware Wizard dialog box appears, select Install the software

automatically (Recommended), and then click the Next button.

For Windows 2000

When a Digital Signature Not Found dialog box appears, telling you that Creative WebCam

Live! Ultra has been detected, click the Ye s button.

For Windows Me and Windows 98 SE

i. If you are prompted to insert the Windows 98 SE or Windows Me CD, replace the Creative

WebCam Live! Ultra Installation CD with the appropriate CD.

ii. In the Insert Disk dialog box, click the OK button.

iii. Follow the instructions on the screen to complete the installation.

iv. Click the Finish button.

8. You may be asked, after the drivers have been successfully installed, if you want to

restart your computer. Select No until all the applications are installed.

9. Restart your computer after all the applications have been installed.

For users with USB 2.0-equipped computers only

Creative Installation automatically checks that the software components required

for optimal USB 2.0 performance are installed on your computer, and alerts you if

these components are missing. If you receive such a message, do one of the

following to ensure that your webcam always performs to its fullest potential over a

USB 2.0 connection:

• install the USB 2.0 driver provided by your hardware vendor

• download and install the latest Windows Service Pack for your operating system

• if you are using Windows XP SP1, install Windows XP Hotfix KB822603

The latest Windows Service Packs and Windows Hotfix KB822603 can be obtained

from the Microsoft Help and Support website or via Windows Update.

CLE_multi.book Page 6 Tuesday, November 16, 2004 4:51 PM

2Verifying the Installation

1. Right-click the My Computer icon on your desktop or in the Windows Start menu.

2. On the menu that appears, click Properties.

In Windows XP and Windows 2000 only:

In the System Properties dialog box, click the Hardware tab. Click the Device Manager

button.

In Windows Me and Windows 98 SE:

In the System Properties dialog box, click the Device Manager tab.

3. Click the plus (+) sign next to the Imaging Device icon. The entry "Creative

WebCam Live! Ultra" appears.

3Using Your Creative WebCam

Taking a Photo

1. Click Start → Programs → Creative → Creative WebCam → Creative

WebCam Center.

2. In the Creative WebCam Center window, click the Capture tab.

3. Click the Photo Resolution box and select the resolution that you want.

4. Click the Snap photo button to capture an image. Images are saved as files in the

default media folder.

To view the photos in the image viewer, double-click the image files in the Thumbnails/

Details pane.

CLE_multi.book Page 7 Tuesday, November 16, 2004 4:51 PM

Recording a Video

1. Click Start → Programs → Creative → Creative WebCam → Creative

WebCam Center.

2. In the Creative WebCam Center window, click the Capture tab.

3. Click the Video Resolution box and select the resolution that you want.

4. Click the Record button to start and stop video recording. Videos are saved as files in

the default media folder when you stop recording.

To view the videos in the video viewer, double-click the video files in the Thumbnails/

Details pane.

Enabling Face Tracking

With Face Tracking, your camera automatically zooms in on your face during video instant

messaging sessions, or when recording video.

You can enable Face Tracking in the Face Tracking Utility. You can launch the Face Tracking

Utility in the following ways:

• In WebCam Center, click Tools → Face Tracking Utility.

• Right-click the Creative Cam Detector icon in the System Tray and click the Face

Tracking Utility option.

• Click Start → Programs or All Programs → Creative → Creative WebCam

Center → Face Tracking Utility.

For more information, read the User’s Guide on the Installation CD.

Go to d:\manual\<language>\manual.chm (replace d:\ with the drive letter of your CD-ROM/

DVD-ROM drive, and <language> for the language the document is in)

CLE_multi.book Page 8 Tuesday, November 16, 2004 4:51 PM

More Information

Enjoy a host of benefits by registering your product during installation, or at

www.creative.com/register. Benefits include:

• Service and product support from Creative

• Exclusive updates on promotions and events.

Please note that your warranty rights are not dependent on product registration.

Customer Support Services and Warranty

You can find Customer Support Services, Warranty and other information in the Installation CD.

(replace d:\ with the drive letter of your CD-ROM/DVD-ROM drive, <region> with the region that you

are in, and <language> with the language that your document is in)

Customer Support

Services d:\support\<region>\<language>\support.chm

Warranty d:\warranty\<region>\<language>\warranty.chm

Please keep your Proof of Purchase for the duration of the warranty period.

User’s Guide d:\manual\<language>\manual.chm

Creative Knowledge Base

If you have a technical problem with this product, you may wish to consult our

self-help tool “Knowledge Base” for on-line troubleshooting and solutions

(www.europe.creative.com/support)

Technology Ltd. in the United States and/or other countries. Microsoft and Windows are registered trademarks of Microsoft

Corporation. All other products are trademarks or registered trademarks of their respective owners and are hereby

recognized as such. All specifications are subject to change without prior notice. Actual contents may differ slightly from

those pictured.

CLE_multi.book Page 9 Tuesday, November 16, 2004 4:51 PM

Français

A propos de votre Creative WebCam

Ecran

d'alimentation S'allume lorsque votre webcam est connectée au port USB de votre ordinateur.

Bague de mise

au point

Permet de régler la mise au point. Dirigez l’objectif vers votre sujet puis faites

tourner la bague vers la gauche ou vers la droite jusqu’à ce que l’image soit nette

(mise au point).

Bouton Vue Appuyez dessus pour lancer WebCam Center et capturer des images.

Câble USB Connectez-le au port USB de l'ordinateur.

Levier à

charnière Utilisez-le pour monter votre caméra sur un écran d’affichage LCD.

Bague de

mise au point

Bouton

Vue

Câble

USB Levier à

charnière

Figure 1

Vue de face Vue latérale

Ecran

d'alimentation
