Cray T3E Manuel utilisateur

HMM-168-A.1 Cray Research/Silicon Graphics Proprietary 1

AC Repair and Adjustment Procedures

HMM-168-A.1

CRAY T3E™ Air-cooled Systems

Last Modiﬁed: January 1998

Record of Revision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety and ESD Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Field-replaceable Units (FRUs), On-site Spares, and Tools . . . . . . . . . . . . . . . 5

Cabinet Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Doors and Panels

FRP 1: Opening and Removing the Cabinet Doors . . . . . . . . . . . . . . . . . . . . . . 13

FRP 2: Removing the Cabinet Side Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Module Power Supplies, Modules, Daughter Cards, and Rails

FRP 3: Power Supply Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

FRP 4: Auxiliary Clock Power Supply Replacement . . . . . . . . . . . . . . . . . . . . 29

FRP 5: Module Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

FRP 6: Daughter Card Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

FRP 7: Power Supply Rail Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

FRP 8: Top Module Rail Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

FRP 9: Bottom Module Rail Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Cables

FRP 10: Logic Cable Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

FRP 11: GigaRing Cable Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

FRP 12: Clock Wire Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

FRP 13: Boundary Scan Cable/Wire Replacement . . . . . . . . . . . . . . . . . . . . . . 87

FRP 14: Module-to-WACS Cable Replacement . . . . . . . . . . . . . . . . . . . . . . . . 99

Warning and Control System (WACS) and Switches

FRP 15: WACS Microprocessor (EPROM) Replacement . . . . . . . . . . . . . . . . . 109

FRP 16: WACS Scanner Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 113

FRP 17: WACS Display Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

FRP 18: WACS Panel Switch (SW6, SW7, SW8) Replacement . . . . . . . . . . . . 120

FRP 19: Blower Controller Bypass Switch (SW3) Replacement . . . . . . . . . . . 122

AC Repair and Adjustment Procedures

2 CrayResearch/SiliconGraphicsProprietary HMM-168-A.1

FRP 20: Cabinet Power Switch (SW2) Replacement . . . . . . . . . . . . . . . . . . . . 124

FRP 21: Clock Switch Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

FRP 22: Module Thermistor Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

FRP 23: Inlet Air Thermistor Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

FRP 24: Exhaust Air Thermistor Replacement . . . . . . . . . . . . . . . . . . . . . . . . . 136

FRP 25: Thermostat Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Fuses and Circuit Breakers

FRP 26: WACS Scanner Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

FRP 27: Power Supply Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

FRP 28: Blower Control Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

FRP 29: Main Disconnect Circuit Breaker (CB1) Replacement . . . . . . . . . . . . 152

FRP 30: WACS Panel Circuit Breaker (CB8, CB9, or CB10) Replacement . . . 156

FRP 31: Power Supply Circuit Breaker (CB2 through CB7) Replacement . . . 160

Power Box Components

FRP 32: Voltage Selector Switch (SW1) Replacement . . . . . . . . . . . . . . . . . . . 164

FRP 33: Time-delay Relay Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168

FRP 34: Line Filter (FL1) Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

FRP 35: Contactor (CT1) Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

FRP 36: Resistor (R1) Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176

Cooling Components

FRP 37: Air Filter Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179

FRP 38: Blower Assembly Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

FRP 39: Blower Controller (SCR1) Replacement . . . . . . . . . . . . . . . . . . . . . . . 187

FRP 40: Transformer (T1) Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

FRP 41: Run Capacitor (C1) Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Preventive Maintenance and Adjustment Procedures . . . . . . . . . . . . . . . . . . . . 197

Cleaning the Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Cleaning the EMI Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Adjusting the Module Power Supply Output Voltage . . . . . . . . . . . . . . . . . 197

AC Repair and Adjustment Procedures Record of Revision

HMM-168-A.1 Cray Research/Silicon Graphics Proprietary 3

Record of Revision

September 1996

Original printing.

January 1998

Revision A. Added information on module pin protectors. Added steps for

packing a module in a shipping container to the module replacement procedure.

Made minor technical corrections elsewhere.

March 1998

Revision A.1. Updated the power supply removal procedure with information

about the appropriate tools to use in order to avoid stripping hex bolts.

Introduction AC Repair and Adjustment Procedures

4 CrayResearch/SiliconGraphicsProprietary HMM-168-A.1

Introduction

This document guides you in removing and replacing the field replaceable units

(FRUs) of the CRAY T3E air-cooled (AC) cabinet. This document includes a

list of FRUs, on-site spares, and tools for the CRAY T3E AC cabinet. It also

includes procedures for parts that need periodic maintenance.

This document does not contain power-on and power-off procedures. Refer to

the AC Power, Control, and Electromechanical Troubleshooting document,

Cray Research publication HMM-169-0, for power-on and power-off

procedures.

NOTE: Service personnel who are not Cray Research employees should

perform only procedures that are speciﬁed in their maintenance

agreements.

The following general instructions apply to all procedures in this document:

•Review the entire procedure before you perform any steps.

•Remember that the tools list for a given procedure does not include the

hex wrench required to open cabinet doors or the tools required to

complete additional tasks that are documented under a different

procedure.

•Label, or otherwise record the locations of, every wire or cable that you

disconnect during a procedure.

•Inspect all replacement parts for evidence of physical damage when you

receive them.

Safety and ESD Precautions

ObservesafetyandESDprecautionsduringallreplacementprocesses.Required

apparel includes an ESD smock, ESD wrist strap, and ESD shoes or shoe straps.

For further information on safety and ESD, read the Safety and ESD Guidelines,

Cray Research publication HGM-016-A.

Most CRAY T3E AC repair procedures require that you unplug the cabinet and

install, lock, and tag the plug with an electrical plug lockout device

(P/N 15255100).

AC Repair and Adjustment Procedures Field-replaceable Units (FRUs), On-site Spares, and Tools

HMM-168-A.1 Cray Research/Silicon Graphics Proprietary 5

Field-replaceable Units (FRUs), On-site Spares, and Tools

Table 1 lists the field-replaceable units (FRUs) for the CRAY T3E air-cooled

(AC) cabinet at the time of publication.

Table 1. Mainframe FRUs

Part Number Description Cabinet

Quantity Return for

Repair

Power Supplies

13264101 Power Supply, 3.3V with Thermal Pad 1/Module Yes

57170001 Cordset, IEC320 20A 250V W/Ferrite 1/Module No

57252400 Rail Assy, Power Supply Bottom 1/Supply Yes

57252500 Rail Assy, Power Supply Top 1/Supply Yes

15258000 Power Supply, Dual Output (auxiliary clock supply) 1/Clock Yes

Modules and Daughter Boards

Variable

(refer to

FN 2290)

Module Assy, Air-Cooled PEM Variable Yes

Variable

(refer to

FN 2290)

Module Assy, Clock Variable Yes

15107601 Daughter Board Assy, 1/2 pop 16Meg 70 NS (32MB) Variable Yes

15158500 Daughter Board Assy, 1/2 pop 16Meg 60 NS (32MB) Variable Yes

15104601 Daughter Board Assy, Single Hi 16Meg 70 NS (64MB) Variable Yes

15158100 Daughter Board Assy, Single Hi 16Meg 60 NS (64MB) Variable Yes

15104001 Daughter Board Assy, 2Hi Stack 16Meg 70 NS (128MB) Variable Yes

15158300 Daughter Board Assy, 2Hi Stack 16Meg 60 NS (128MB) Variable Yes

15148500 Daughter Board Assy, 1/2 pop 64Meg 60 NS (128MB) Variable Yes

15148700 Daughter Board Assy, Single Hi 64Meg 60 NS (256MB) Variable Yes

15108200 Daughter Board Assy, 2Hi Stack 64Meg 60 NS (512MB) Variable Yes

15108400 Daughter Board Assy, 4Hi Stack 64Meg 60 NS (1GB) Variable Yes

57163500 Handle, Module 1/Module No

57251800 Rail Assy, Clock Module-Top 1/Clock Yes

57251900 Rail Assy, Clock Module-Bottom 1/Clock Yes

57255300 Rail Assy, PEM Top 1/Module Yes

57255000 Rail Assy, PEM Bottom 1/Module Yes

Cables and Wires

15112904 Cable Assy, Ribbon (X dimension) 4/Module No

15112905 Cable Assy, Ribbon (Z dimension) 8/Module No

15112906 Cable Assy, Ribbon (Y dimension) 4/Module No

Field-replaceable Units (FRUs), On-site Spares, and Tools AC Repair and Adjustment Procedures

6 CrayResearch/SiliconGraphicsProprietary HMM-168-A.1

Cables and Wires (continued)

15200500 Cable Assy, GigaRing to Bulkhead 4/Module No

15214200 Cable Assy, PEM to WACS 1/Module No

15214300 Cable Assy, PEM to Scan 1/Module No

15223701 Wire Assy, Clock (system clock) 2/Module No

15223802 Cable Assy, Scan Jumper 120-in. 1 No

15224008 Wire Assy, 34 AWG 100 Ohm 120-in. (GigaRing Clock) 1/Module No

15224009 Wire Assy, 34 AWG 100 Ohm 144-in. 1 No

15237601 Cable Assy, 2 POS Skt to Pigtail (boundary scan) 2 No

15237701 Wire Assy, 4 POS Pin to Pigtail (boundary scan) 1/Module No

15237801 Cable Assy, 2 POS Pin to Pigtail (boundary scan) 2 No

15244601 Wire Assy, Clock Shielded w/ Drain (master clock) 1/Module No

57244600 Cable Assy, AUI 12 Foot 1 No

57251100 Couple, In-line 8 wire RJ45 5 No

57263800 Cable Assy, clock to WACS T3E-AC 1 No

WACS Components

15135901 IC, Micro T3E Air WACS 1 Yes

15130000 Thermistor Assy, Module Temperature 4 No

31445000 Module Assy, Disk IOSF Display 1 Yes

31504104 Module Assy, IOSF/T3E Air WACS (scanner) 2 Yes

57199600 Thermistor Assy, Air Flow 4 No

57199700 Thermostat, 65 Degree C 2 No

Switches

57185700 Switch, 600V 40A 5 Stage (Voltage Selector) 1 No

57186400 Switch, PB Gold Contacts (Restart) 1 No

57186500 Switch, Rocker Green LED (Remote Enable) 1 No

57186700 Switch, Rocker Green LED (PS Margin) 1 No

57199100 Switch, Rocker (Cabinet Power / Emergency) 1 No

57199101 Switch, Rocker Silver Contacts (Blower Bypass) 1 No

57253600 PC Board Assy, T3E Switch (Clock Switches) 1 No

Fuses

01134006 Fuse, 250V 1/2 Amp (0.5-A WACS scanner fuse) 2 No

01158809 Fuse, Ceramic 250V 15 Amp (power supply fuse) 2/PS No

57084701 Fuse, 250V 2/10 Amp (0.2-A blower control fuse) 2 No

Table 1. Mainframe FRUs (continued)

Part Number Description Cabinet

Quantity Return for

Repair

AC Repair and Adjustment Procedures Field-replaceable Units (FRUs), On-site Spares, and Tools

HMM-168-A.1 Cray Research/Silicon Graphics Proprietary 7

Circuit Breakers

57168600 Circuit Breaker Assy, 40A 480V (CB1) 1 No

57176100 Circuit Breaker, 20 Amp 480V (power supply) 6 No

57176101 Circuit Breaker, 10 Amp (blower) 1 No

57176102 Circuit Breaker, 3 Amp (WACS and auxiliary) 2 No

Power Box Components

55091902 Relay, Time Delay 1 No

57168800 Filter, Power 45 Amp 1 No

57186100 Contactor, 4 Pole 65 Amp 600V 1 No

57185400 Resistor, 50W 330 Ohm 1 No

57185700 Switch, 600V 40A 5 Stage (Voltage Selector) 1 No

57186100 Contactor, 4 Pole 65 Amp 600V 1 No

57170001 Cordset, IEC320 20A 480V 1 No

Blower, Blower Speed Control Components, and Air Filter

57067701 Controller, Power SCR 20A W/ XFMER (transformer) 1 No

57081901 Capacitor, Run 20MFD 1 No

57178900 Blower Assy, 18 Inch 1 Yes

57188100 Filter, Air Intake 1 No

Table 1. Mainframe FRUs (continued)

Part Number Description Cabinet

Quantity Return for

Repair

Field-replaceable Units (FRUs), On-site Spares, and Tools AC Repair and Adjustment Procedures

8 CrayResearch/SiliconGraphicsProprietary HMM-168-A.1

Table 2 lists on-site spares for the CRAY T3E AC cabinet.

Table 2. On-site Spares (57247700)

Part Number Description

01134006 Fuse, Glass 1/2 Amp (WACS scanner)

01158809 Fuse, Ceramic 250V 15 Amp (power supply)

01158900 Fuse, Glass 250V 1/16A

01158907 Fuse, Glass 250V 1A

01577002 Screw, Cap SCH BTNHD 6-32

01675100 Nut, Retainer 10-32

01775900 Lock, Pin Connector

12755600 Spacer, Connector

13033501 Screw, SCH Conn Mtg

13158903 Screw, Mach PNH PHH M3 8MM

13159002 Screw, Mach PNH PHH M4 6MM

13159003 Screw, Mach PNH PHH M4 8MM

13159004 Screw, Mach PNH PHH M4 10MM

13160602 Washer, Plain M3

13160603 Washer, Plain M4

13161502 Washer, Lock M3

13161503 Washer, Lock M4

13249901 IC, Micro PWR Subrack

13264101 Power Supply, T3E FRU

15130000 Thermistor Assembly, Module Temperature

15135901 IC, Micro T3E Air WACS

15215600 Spring, Rail

15223701 Wire Assy, Clock

15224008 Wire Assy, 34 AWG 100 Ohm 120”

15224009 Wire Assy, 34 AWG 144”

15237701 Wire Assy, 4 POS Pin to Pigtail

57084701 Fuse, 250V 2/10 Amp

(0.2-A blower control fuse)

57174200 Plug, Module Rail

57176200 Plug, Module Rail

57188100 Filter, Air

57199600 Thermistor Assembly, Air Flow

57199700 Thermostat, 65 Degree C

57253000 Screw, Mach PNH PHH Wshr M4 8MM

57264700 Filter Assy, Power Supply

AC Repair and Adjustment Procedures Field-replaceable Units (FRUs), On-site Spares, and Tools

HMM-168-A.1 Cray Research/Silicon Graphics Proprietary 9

Formore information on AC spares,refer to the CRAYT3E Spares Support Plan

athttp://www.csd.sgi.com/spo/T3E/t3espare.htm,whichcontainslistsofcountry

spares, parts bank spares, and central Logistics spares.

Table 3 lists the CRAY T3E AC tool kit at the time of publication.

Table 3. Tool Kit (57247800)

Part Number Description

01140800 Kit, Solderless Terminal

01263600 Multimeter, Digital

01523100 Cutter, Diagonal

01523700 Pliers, 6”

01524502 Wrench, Adjustable 12”

01524800 Wrench Set, Combination

01524900 Screwdriver Set, Phillips

01524901 Screwdriver Set, Flat Blade

01525001 Wrench Set, 1/4” Drive

01525400 Screwdriver Set, Torque

01529400 Holder, Hemostat Curved

01529401 Holder, Hemostat Straight

01529903 Battery, D Cell

01531200 Mirror, Inspection TLSCP

01531700 Tweezers, Micro

01532400 Magnet, Parts Pick-up

01563600 Screwdriver, PH Hard Tip

01596700 Probe Kit

12277700 Cable Assy, Test Lead Ohming

12804700 Connector, DB25 Loopback

12889800 Cam Tool, Shuttle Conn Actuator

13170700 Wire Stripper, Variable

13267200 Socket Set, Metric Hex Bit 2mm-6mm

13267300 Socket Set, Metric 1/4-in. Drive 4mm-12mm

13267400 Wrench Set, Metric 7 pc. 7mm-15mm

15252100 Pencil, Mechanical. 3mm

15252200 Dental Pick, Curved

15252400 Balldriver Set, Metric Hex 1.5-10mm

15255000 Extractor, PLCC 20-84 Pin

15255100 Lockout Device, Electric Plug

15255200 Tool Case, 7 1/2” Deep

Field-replaceable Units (FRUs), On-site Spares, and Tools AC Repair and Adjustment Procedures

10 CrayResearch/SiliconGraphicsProprietary HMM-168-A.1

NOTE: You can modify CRAY Y-MP carts for use with both CRAY Y-MP

and CRAY T3E modules by installing two rails, P/N 13267700.

15255800 Flashlight

15256900 Flashlight, NightHawk Microlight

35717400 Wrench Set, Balldriver Hex .050-5/32

51908400 Pliers, Needle Nose

90334800 Tape, Cleaner HD 4MM

ME107389 Tool Assy, Daughter Board Removal

Table 3. Tool Kit (57247800)

Part Number Description

Autres manuels pour T3E

Table des matières

Autres manuels Cray Ordinateur de bureau

Cray

Cray XD1 Manuel utilisateur

Cray

Cray CX1 Guide de configuration

Cray

Cray XC30-LC Manuel

Cray

Cray X-MP Manuel utilisateur

Cray

Cray CX1000 Mode d'emploi

Cray

Cray XD1 Guide de démarrage rapide

Cray

Cray CRAY-1 Guide rapide de l'utilisateur

Cray

Cray X-MP Series Manuel utilisateur

Cray

Cray CX1 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
