Craftsman 919.722010 Manuel utilisateur

120V

INFLATOR

Model No.

919.722010

Owner’s Manual

• Safety Guidelines

• Assembly

• Operation

• Maintenance

• Troubleshooting

• Repair Parts

CAUTION: Read the Safety Guidelines

and All Instructions Carefully Before

Operating.

D29496 Rev. 0 9/05/03

2- ENG

D29496

TABLE OF CONTENTS

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

SPECIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

SAFETY GUIDELINES-DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . .3

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . .3-8

GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-13

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

REPAIR PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17-31

HOW TO ORDER REPAIR PARTS . . . . . . . . . . . . . . . . . . . . . .back cover

WARRANTY

FULL ONE YEAR WARRANTY ON INFLATORS

If this inflator fails due to a defect in material or workmanship within one year

from the date of purchase, RETURN IT TO THE NEAREST SEARS SERVICE

CENTER THROUGHOUT CANADA AND SEARS WILL REPAIR IT, FREE OF

CHARGE.

If this inflator is used for commercial or rental purposes, the warranty will

apply for ninety days (90) from the date of purchase.

This Craftsman inflator warranty gives you specific legal rights and you may

have other rights which vary from province to province.

Sears Canada, Inc., Toronto, Ont. M5B 2B8

3- ENG D29496

SPECIFICATION CHART

Model No. 919.722010

Bore 1.875

Stroke 1.25

Voltage/Hertz/Phase 120/60/1

Minimum Branch Circuit Requirement 15 amps

Fuse Type Time Delay

SCFM@ 30 psig 2.5

Maximum Pressure 125 PSI

SAFETY GUIDELINES - DEFINITIONS

Indicates an

imminently hazardous

situation which, if not avoided, will

result in death or serious injury.

Indicates a potentially

hazardous situation

which, if not avoided, could result in

death or serious injury.

Indicates a potentially

hazardous situation

which, if not avoided, may result in

minor or moderate injury.

Used without the

safety alert symbol

indicates a potentially hazardous

situation which, if not avoided, may

result in property damage.

This manual contains information that is important for you to know and understand. This information

relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you

recognize this information, we use the symbols below. Please read the manual and pay attention to

these sections.

IMPORTANT SAFETY INSTRUCTIONS

Some dust created by power sanding, sawing, grinding, drilling, and other

construction activities contains chemicals known (to the State of California) to

cause cancer, birth defects or other reproductive harm. Some example of these chemicals are:

Glead from lead-based paints

Gcrystalline silica from bricks and cement and other masonry products

Garsenic and chromium from chemically-treated lumber

Your risk from these exposures varies, depending on how often you do this type of work. To reduce

your exposure to these chemicals: work in a well ventilated area, and work with approved safety

equipment, always wear MSHA/NIOSH approved, properly fitting face mask or respirator when using

such tools.

When using air tools, basic safety precautions should always be followed to reduce the risk of

personal injury.

SAVE THESE INSTRUCTIONS

IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN

SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL

WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT.

4- ENG

D29496

IMPORTANT SAFETY INSTRUCTIONS

Save these instructions

Improper operation or maintenance of this product could result in serious injury and

property damage. Read and understand all warnings and operation instructions before

using this equipment.

HAZARD

WARNING: Risk of explosion or fire

How To Prevent It

What Could Happen

It is normal for electrical contacts

within the motor to spark.

If electrical sparks from inflator come

into contact with flammable vapors,

they may ignite, causing fire or

explosion.

Restricting any of the inflator ventilation

openings will cause serious overheating

and could cause fire.

Unattended operation of this product

could result in personal injury or

property damage. To reduce the risk of

fire, do not allow the inflator to operate

unattended.

Always operate the inflator in a well

ventilated area free of combustible

materials, gasoline, or solvent vapors.

Store flammable materials in a secure

location away from inflator.

Never place objects against or on top

of inflator. Operate inflator in an open

area at least 12 inches away from any

wall or obstruction that would restrict the

flow of fresh air to the ventilation

openings.

Operate inflator in a clean, dry well

ventilated area. Do not operate unit in

any confined area.

Always remain in attendance with the

product when it is operating.

Always disconnect electrical power by

moving on/off switch to the off position

and unplug the power cord.

5- ENG D29496

WARNING: Risk of Bursting

How To Prevent It

What Could Happen

WARNING: Risk from Flying Objects

The inflator air stream can cause soft

tissue damage to exposed skin and

can propel dirt, chips, loose particles,

and small objects at high speed,

resulting in property damage or personal

injury.

Always wear ANSI Z87.1 approved safety

glasses with side shields when using the

inflator.

Never direct compressed air toward any

part of the body or at other people or

animals.

Always turn the inflator off before

attempting maintenance, attaching tools,

or accessories.

HAZARD

Follow the equipment manufacturers

recommendation and never exceed the

maximum allowable pressure rating of

attachments or inflatable items.

ATTACHMENTS & ACCESSORIES:

Exceeding the pressure rating of air

operated accessories, tires, inflatable

balls, and other inflatables items can

cause them to explode or fly apart, and

could result in serious injury.

How To Prevent It

What Could Happen

Always remain in attendance when

inflating tires, inflatable balls, inflatable

toys, and other inflatable items. Be

prepared to stop inflator when item is fully

inflated, sometimes in a matter of

seconds.

Unattended tires, inflatable balls,

inflatable toys, and other inflatable

items can over inflate very quickly

sometimes in a matter of seconds and

result in personal injury or property

damage.

6- ENG

D29496

WARNING: Risk to Breathing

WARNING: Risk of Electrical Shock

HAZARD

Your inflator is powered by electricity.

Like any other electrically powered

device, if it is not used properly it may

cause electric shock.

Repairs attempted by unqualified

personnel can result in serious injury

or death by electrocution.

Electrical Grounding: Failure to provide

adequate grounding to this product

could result in serious injury or death

from electrocution.

See grounding instructions.

Never operate the inflator outdoors when

it is raining or in wet conditions.

Never operate inflator with protective

covers removed or damaged.

Any electrical wiring or repairs required

on this product should be performed by

authorized service center personnel in

accordance with national and local

electrical codes.

Make certain that the electrical circuit to

which the inflator is connected provides

proper electrical grounding, correct

voltage, and adequate fuse protection.

The compressed air directly from your

inflator is not safe for breathing. The air

stream may contain carbon monoxide,

toxic vapors, or solid particles from the

tank. Breathing these contaminants

can cause serious injury or death.

Air obtained directly from the inflator

should never be used to supply air for

human consumption. In order to use air

produced by this inflator for breathing,

suitable filters and in-line safety

equipment must be properly installed.

In-line filters and safety equipment used

in conjunction with the inflator must be

capable of treating air to all applicable

local and federal codes prior to human

consumption.

How To Prevent It

What Could Happen

How To Prevent It

What Could Happen

Always replace damaged or worn

electric cords before operating inflator.

When operating inflator outdoors use

GFCI outlet.

7- ENG D29496

WARNING: Risk of Burns

Touching exposed metal such as the

inflator head or outlet tubes, can result

in serious burns.

Never touch any exposed metal parts

on inflator during or immediately after

operation. Inflator will remain hot for

several minutes after operation.

Do not reach around protective shrouds

or attempt maintenance until unit has

been allowed to cool.

WARNING: Risk from Moving Parts

Never operate the inflator with guards

or covers which are damaged or

removed.

Moving parts such as the pulley, flywheel,

and belt can cause serious injury if they

come into contact with you, your clothing,

loose hair, or jewelery.

WARNING: Risk of Falling

An inflator can fall from a table,

workbench, or roof causing damage to

the inflator and could result in serious

injury or death to the operator.

Always operate inflator in a stable

secure position to prevent accidental

movement of the unit. Never operate

inflator on a roof or other elevated

position.

HAZARD

Any repairs required on this product

should be performed by authorized

service center personnel.

Attempting to operate inflator with

damaged or missing parts or attempting

to repair inflator with protective shrouds

removed can expose you to moving parts

and can result in serious injury.

How To Prevent It

What Could Happen

How To Prevent It

What Could Happen

How To Prevent It

What Could Happen

8- ENG

D29496

Review and understand all instructions

and warnings in this manual.

Become familiar with the operation and

controls of the inflator.

Keep operating area clear of all persons,

pets, and obstacles.

Keep children away from the inflator at all

times.

Do not operate the product when

fatigued or under the influence of

alcohol or drugs. Stay alert at all times.

Never defeat the safety features of this

product.

Equip area of operation with a fire

extinguisher.

Do not operate machine with missing,

broken, or unauthorized parts.

WARNING: Risk of Unsafe Operation

Unsafe operation of your inflator could

lead to serious injury or death to you

or others.

HAZARD

SAVE THESE INSTRUCTIONS

How To Prevent It

What Could Happen

GLOSSARY

ACCESSORIES

Become familiar with these terms

before operating the unit.

CFM: Cubic feet per minute.

SCFM: Standard cubic feet per

minute; a unit of measure of air

delivery.

PSIG: Pounds per square inch

gauge; a unit of measure of pressure.

Code Certification: Products that

bear one or more of the following

marks: UL, CUL, ETL, CETL, have

been evaluated by OSHA certified

independent safety laboratories and

meet the applicable Underwriters

Laboratories Standards for Safety.

Branch Circuit: Circuit carrying

electricity from electrical panel to

outlet.

Inflation Needle: Used to inflate

sport balls.

Extension Nozzle: Used to inflate

small inflatable items such as air rafts

and beach balls.

This unit is capable of powering the following Accessories. Accessories

included with your inflator:

High Flow Inflator/Deflator adapter

body with three nozzles and seal

ring: Used to inflate or deflate air

mattresses, small boats, inflatable

toys, and other inflatable items that

use a large volume of low-pressure air.

9- ENG D29496

1. The cord set and plug with this

unit contains a grounding pin.

This plug MUST be used with a

grounded outlet.

IMPORTANT: The outlet being used

must be installed and grounded in

accordance with all local codes and

ordinances.

2. Make sure the outlet being used

has the same configuration as

the grounded plug. DO NOT

USE AN ADAPTER. See

illustration.

3. Inspect the plug and cord before

each use. Do not use if there are

signs of damage.

4. If these grounding instructions

are not completely understood,

or if in doubt as to whether the

inflator is properly grounded,

have the installation checked by

a qualified electrician.

GROUNDING INSTRUCTIONS

Risk of Electrical

Shock. In the

event of a short circuit, grounding

reduces the risk of shock by

providing an escape wire for the

electric current. This inflator must

be properly grounded.

The inflator is equipped with a cord

having a grounding wire with an

appropriate grounding plug (see

following illustrations). The plug must

be used with an outlet that has been

installed and grounded in accordance

with all local codes and ordinances.

HOW TO SET UP YOUR

UNIT

Grounding Pin

Grounded

Outlets

Plug

INSTALLATION

Location of the inflator

Locate the inflator in a clean, dry and

well ventilated area. The inflator

pump and housing are designed to

allow for proper cooling. The

ventilation openings on the inflator

are necessary to maintain proper

operating temperature. Do not place

rags or other containers on or near

these openings.

Contents of Carton

1 - Inflator equipped with hose and

universal valve adapter

1 - Accessories Kit

1- Inflator Needle

1 - Extension Nozzle

1 - High Flow Inflator/Deflator

adapter body with three

nozzles and seal ring

ASSEMBLY

To Remove Inflator from Carton

1. Grasp handle and lift the inflator

out of the carton.

2. Remove all packaging from

inflator and discard.

10- ENG

D29496

Voltage and Circuit Protection

Refer to the specification chart for the

voltage and minimum branch circuit

requirements.

Certain inflators can be operated on a

15 amp circuit if the following

conditions are met.

1. Voltage supply through branch

circuit is 15 amps.

2. Circuit is not used to supply any

other electrical needs (lights,

appliances, etc.).

3. Extension cords comply with

specifications.

4. Circuit is equipped with a 15

amp circuit breaker or 15 amp

time delay fuse. NOTE: If inflator

is connected to a circuit

protected by fuses, use only time

delay fuses. Time delay fuses

should be marked “D” in Canada

and “T” in the US.

If any of the above conditions cannot

be met, or if operation of the inflator

repeatedly causes interruption of the

power, it may be necessary to

operate it from a 20 amp circuit. It is

not necessary to change the cord set.

Risk of Electrical

Shock. IMPROPER

GROUNDING CAN RESULT IN

ELECTRICAL SHOCK.

Do not modify the plug provided. If

it does not fit the available outlet, a

correct outlet should be installed

by a qualified electrician.

Repairs to the cord set or plug

MUST be made by a qualified

electrician.

Extension Cords

If an extension cord must be used, be

sure it is:

• a 3-wire extension cord that has

a 3-blade grounding plug, and a

3-slot receptacle that will accept

the plug on the product

• in good condition

• no longer than 50 feet

• 16 gauge (AWG) or larger. (Wire

size increases as gauge number

decreases. 14, 12, 10, and 8

AWG may also be used.

Table des matières

Langues :

Autres manuels Craftsman Compresseur d'air

Craftsman

Craftsman 919.157251 Manuel utilisateur

Craftsman

Craftsman 921.164780 Manuel utilisateur

Craftsman

Craftsman 919.167783 Manuel utilisateur

Craftsman

Craftsman AIR COMPRESSOR 919.724701 Manuel utilisateur

Craftsman

Craftsman 919.167600 Manuel utilisateur

Craftsman

Craftsman 919.156830 Manuel utilisateur

Craftsman

Craftsman 919.167360 Operators Manuel utilisateur

Craftsman

Craftsman 921.153640 Manuel utilisateur

Craftsman

Craftsman 919.727340 Manuel utilisateur

Craftsman

Craftsman 919.724590 Manuel utilisateur

Craftsman

Craftsman 921.16472 Manuel utilisateur

Craftsman

Craftsman 919.724131 Manuel utilisateur

Craftsman

Craftsman 921.166420 Manuel utilisateur

Craftsman

Craftsman 919.724572 Manuel utilisateur

Craftsman

Craftsman 921.16472 Manuel utilisateur

Craftsman

Craftsman 919.167341 Manuel utilisateur

Craftsman

Craftsman 919.167770 Manuel utilisateur

Craftsman

Craftsman 919.15402 Manuel utilisateur

Craftsman

Craftsman 919.724570 Manuel utilisateur

Craftsman

Craftsman 919.152921 Manuel utilisateur

Craftsman

Craftsman 919.153090 Manuel utilisateur

Craftsman

Craftsman 921.166430 Manuel utilisateur

Craftsman

Craftsman 919.153160 Manuel utilisateur

Craftsman

Craftsman 919.184160 Manuel utilisateur

Manuels Compresseur d'air populaires d'autres marques

Sparmax

Sparmax DC-25XR Manuel utilisateur

KAESER

KAESER M122 Manuel utilisateur

GMC

GMC GAC1500 Manuel utilisateur

Briggs & Stratton

Briggs & Stratton Air Compressor Manuel utilisateur

Fini

Fini F3GST2TK Manuel utilisateur

Industrial Air

Industrial Air CP1580325 Manuel de programmation

Campbell Hausfeld

Campbell Hausfeld RP3300 Guide de démarrage rapide

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuel utilisateur

Hitachi

Hitachi EC99S Manuel de l'opérateur

Parkside

Parkside PKO 270 A1 Manuel utilisateur

Sullair

Sullair 185 Manuel utilisateur

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuel utilisateur

Ferm

Ferm CRM1046 Manuel utilisateur

BE AC153 Manuel utilisateur

RIDGID

RIDGID OF25150A Manuel utilisateur

Johnson Controls

Johnson Controls QUANTUM LX Manuel

Sears

Sears Craftsman 919.167463 Manuel utilisateur

Ring Automotive

Ring Automotive RAC700 Manuel utilisateur
