Installation Instructions

Vault w/ visor C-Scroll w/ visor Roundel w/ visor

These installation instructions are valid with the above metrix styles

Mounting Plate Dimensions In [mm]

Lamping Size Chart

(lamps provided by others)

Warning

: Before starting any work ensure

that all sources of power are turned off. ll

work must meet local/national codes and be

performed by a certified electrician. Do not

mount fixtures vertically.

Large, INDOOR

YR (30 1/2")

(Yoke mount, Remote ballast)

Visor an Non-Visor

Sheet 2 of 2

ADY071446 Rev A (ECN070295)

325.9

12 "

23.2

29 "

346.9

"13 32

651.7

"25 32

114.3

"4 2

57.2

"2 4

1173.5

"6 32

14 15

16 "

379.3

Mounting dimensions are for 30 1/2"(774.7mm) large YR indoor only

FIXTURE SIZE

(inches/ m m )

WATTAGE # OF

LAMPS LAMP TYPE LAMP DESCRIPTION

LAMP

(not to scale)

1/2

/ 774.7 36 W 1 T5 Twin Tube

1/2

/ 774.7 40 W 1 T5 Twin Tube

1/2

/ 774.7 50 W 1 T5 Twin Tube

1/2

/ 774.7 55 W 1 T5

1/2

/ 774.7 36 W 2 T5 Twin Tube

1/2

/ 774.7 40 W 2 T5 Twin Tube

1/2

/ 774.7 50 W 2 T5 Twin Tube

1/2

/ 774.7 55 W 2 T5 Twin Tube

1/2

/ 774.7 250 W 2 ET18 Metal Halide

1/2

/ 774.7 400 W 2 ET18 Metal Halide

1/2

/ 774.7 900 W 1 T3 Halogen(Double Ended)

1/2

/ 774.7 1000 W 1 T3 Halogen(Double Ended)
