251251251

RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

EI700

EI700AT

EI700R

EI700RAT

EI700NB

EI700ATNB

EI700

EI700AT

EI700R

EI700RAT

EI700NB

EI700ATNB

EI700

EI700AT

EI700R

EI700RAT

EI700NB

EI700ATNB

EI700

EI700AT

EI700NB

EI700ATNB

EI700

EI700R

EI700AT

EI700RAT

EI700NB

EI700ATNB

ERT713L

High Gloss Appliance White

Trim with Black Bafﬂe

ERT713LTS

High Gloss Appliance White Trim

with Black Bafﬂe and Torsion

Spring Construction

ERT713L - Black Metal Baffle

• Provides deeper lamp regression for

BR lamps

• ERT713LTS - Torsion spring retention

• ET713L - Friction clip retention

• Lamps:

EI700

EI700R

EI700AT

EI700RAT ERT714

High Gloss Appliance White Trim

with Black Bafﬂe

ERT714WHT

High Gloss Appliance White Trim

with White Bafﬂe

ERT714 - Plastic Baffle

• Coil spring retention

• Lamps:

ERT704

High Gloss Appliance White Trim

with White Eyeball

ERT704PB

Polished Brass Trim with

Polished Brass Eyeball

ERT704

Eyeball

• Torsion springs pull trim tight to ceiling

• Lamps:

ERT711

High Gloss Appliance White Trim

and Eyeball with Black Bafﬂe

ERT711

Regressed Eyeball

• Lamps:

ERT705

High Gloss Appliance White Trim

ERT705 - Open

• Coil Spring retention

• Lamps:

ERT721

High Gloss Appliance White Trim

with Frosted Lens

ERT721 - Shower Light with

Frosted Glass Lens and

Reflector

• Torsion springs pull trim tight to ceiling

• Wet location listed for use in showers

• Lamps:

EI700AT EI700RAT EI700NB EI700ATNBEI700 EI700R

Height:

2-1/4” [57mm]

OD:

8” [203mm]

Aperture:

3 15/16” [100mm]

OD:

8” [203mm]

Height:

3” [76mm]

OD:

8” [203mm]

Aperture:

3-7/8” [98mm]

OD:

8” [203mm]

Height:

4-1/4” [108mm]

OD:

8” [203mm]

Height:

5-3/8” [136mm]

OD:

7-1/4”[184mm]

ERT713LTS ERT713L

75W BR40,

65W BR30,

75W PAR30L

50W PAR30, 65W

BR30, 75W PAR30L

65W BR30, 75W R30,

75W PAR30L

50W PAR30

65 W R30, 75W PAR30,

75W PAR30L

40W A19

65W BR30, 75W R30

trim trim

trim

256

RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

ET700

ET700R ERT708

High Gloss Appliance White Trim

ERT708

Large Aperture Open

• Coil Spring Retention

• Lamps:

ERT701

High Gloss Appliance White Trim

with Albalite Lens

ERT701

Albalite Lens Shower Light

• Wet Location listed for use in showers

• Torsion spring retention

• Lamps:

ET700

ET700R

ERT702

High Gloss Appliance White

Trim with Drop Opal Lens

ERT702

Drop Opal Plastic Lens Shower

Light

• Wet Location listed for use in showers

• Torsion spring retention

• Lamps:

ERT703

High Gloss Appliance White

Trim with Fresnel lens

ERT703

Fresnel Lens Shower Light

• Wet Location listed for use in showers

• Lamps:

ERT705

White Trim

ERT705 - Open

• Coil Spring retention

• Fixed socket position

• Lamps:

OD:

8” [203mm]

OD:

8” [203mm]

OD:

8” [203mm]

OD:

8” [203mm]

60W A19

ET700

ET700R 60W A19

ET700

ET700R 60W A19

ET700

65W BR30, 75W R30,

75W PAR30, 75W

PAR30L

120W BR40, 150W R40

Aperture:

5-3/16” [131mm]

OD:

8” [203mm]

trim

ET700 ET700RET700 ET700R

261261261

RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

EI700U EI700UAT

EI700U

EI700UAT

ERT701

High Gloss Appliance White Trim

with Albalite Lens

ERT701

Albalite Lens Shower Light

• Wet Location listed for use in showers

• Torsion Spring retention

• Lamps:

ERT702

High Gloss Appliance White Trim

with Drop Opal Lens

ERT702

Drop Opal Plastic lens Shower

Light

• Wet Location listed for use in showers

• Torsion spring retention

• Lamps:

ERT703

High Gloss Appliance White Trim

with Glass Fresnel Lens

ERT703

Fresnel Lens Shower Light

• Wet Location listed for use in showers

• Torsion spring retention

• Lamps:

ERT721

High Gloss Appliance White Trim

with Frosted Diffuser

ERT721

Shower Light with Frosted Glass

Lens and Reflector

• Wet Location listed for use in showers

• Torsion spring retention

• Lamps:

OD:

8” [203mm]

OD:

8” [203mm]

OD:

8” [203mm]

Height:

4-1/4” [108mm]

OD:

8” [203mm]

EI700U

EI700UAT

75W PAR30, 75W

PAR30L, 85W BR30,

100W R30

EI700U

EI700UAT 40W A19

EI700U

EI700UAT 40W A19

EI700U

EI700UAT 40W A19

60W A19

ERT705

High Gloss Appliance White Trim

ERT705 - Open

• Coil Spring retention

• Lamps: Aperture:

3-7/8” [98mm]

OD:

8” [203mm]

trim

ET700

ET700R

ERT708

High Gloss Appliance White Trim

ERT708

Large Aperture Open

• Coil Spring Retention

• Lamps:

100W R40 (Requires

H1999 Socket Extender)

Aperture:

5-3/16” [131mm]

OD:

8” [203mm]

trim

*When using an Air-Tite trim to meet California Title 24 air tight compliance, an additional gasket is required between the ﬁnished ceiling and the trim ﬂange ring. For California

Title 24 compliance use accessory trim gasket GA-ATRIM. Order separately in a 6 pack: GA-ATTRIM-6PK

264

RECESSED DOWNLIGHTING Incandescent

COOPER LIGHTING

ALL-PRO™

EI2700ATEI2700 EI2700R

EI2700

EI2700AT

EI2700R

50W PAR30

EI2700

EI2700AT

EI2700R

35W PAR30L

40W A19

EI2700

EI2700AT

EI2700R

35W PAR30L

40W A19

EI2700

EI2700AT

EI2700R

65W BR30, 75W R30,

75W PAR30L

65W BR30, 75W R30,

75W PAR30L

EI2700

EI2700AT

EI2700R

50W PAR30L, 60W

BR30, 75W PAR30

60W BR30

EI2700

EI2700AT

EI2700R

65W BR30, 75W PAR30,

75W PAR30L

ERT723

High Gloss Appliance White Trim

with Glass Fresnel Lens

ERT723 - Shower Light with Glass

Fresnel Lens and Reflector

• Torsion springs pull trim tight to ceiling

• Wet location listed for use in showers

• Socket supporting trim

• Lamps:

Height:

4-1/4” [108mm]

OD:

8” [203mm]

trim

*When using an Air-Tite trim to meet California Title 24 air tight compliance, an additional gasket is required between the ﬁnished ceiling and the trim ﬂange ring. For California

Title 24 compliance use accessory trim gasket GA-ATRIM. Order separately in a 6 pack: GA-ATTRIM-6PK

ERT716

High Gloss Appliance White

Trim with White Bafﬂe

ERT716 - Shallow Metal Baffle

• Socket Supporting trim

• Friction clip retention

• Lamps:

trim

Height:

4-1/4” [108mm]

OD:

8” [203mm]

ERT704

High Gloss Appliance White Trim

with White Eyeball

ERT704PB

Polished Brass Trim with

Polished Brass Eyeball

ERT704 - Eyeball

• Torsion springs pull trim tight to ceiling

• Lamps:

ERT711

High Gloss Appliance White Trim

and Eyeball with Black Bafﬂe

ERT711 - Regressed Eyeball

• Friction clip retention

• Lamps:

ERT705

High Gloss Appliance White

Trim

ERT705 - Open

• Coil Spring retention

• Socket supporting trim

• Lamps:

ERT721

High Gloss Appliance White Trim

with Frosted Lens

ERT721 - Shower Light, Frosted

Glass Lens and Reflector

• Torsion springs pull trim tight to ceiling

• Socket supporting trim

• Wet location listed for use in showers

• Lamps:

Aperture:

3 15/16” [100mm]

OD:

8” [203mm]

Height:

3” [76mm]

OD:

8” [203mm]

Aperture:

3-7/8” [98mm]

OD:

8” [203mm]

Height:

4-1/4” [108mm]

OD:

8” [203mm]

trim
