Cooper Lighting FAIL-SAFE 1509 Manuel utilisateur

FAIL-SAFE®

TRANSIT

• Fiberglass housing is

reinforced polyester and

self extinguishing (ASTM-

D635-74) plastic; top has

ﬁve embossments (2' unit);

watertite hubs for 1/2"

conduit entry. Polyurethane

gasketing

• Ballasts are CBM/ETL Class

"P" suitable to minus 20°F.

• Three shielding choices:

DR–clear, low brightness

pattern acrylic with 15%

high impact additive;

DR-100–clear, low

brightness pattern acrylic

with 100% high impact

additive; LEX, low

brightness pattern, high

impact LEXAN

polycarbonate

• Four sturdy cam latches

(2’ unit), six (4’ unit), and

twelve (8’ unit) with

integral stainless steel

TORX®screws. Clamp

diffuser tightly for a

positive seal between

housing, gasketing and

diffuser.

DESCRIPTION

The Fail-Safe VRVT2 Series

ﬂuorescent luminaires

combine harsh environment

protection with the latest in

energy efﬁcient technology.

Their Vaportite design is U.L.

listed and C.S.A. certiﬁed for

wet locations. Other features

include continuous seal

gasketing, reinforced

ﬁberglass housing, steel

mounting brackets, and end

hub entry (standard) or top

hub entry (optional.)

VRVT2

2', 4', 8' LONG

1 OR 2 LAMP

VANDAL RESISTANT

LUMINAIRE

ABCD

VRVT2 5 7/8" 7" 6 5/8" 25 13/16"

2' (149mm) (178mm) (168mm) (656mm)

VRVT2 5 7/8" 7" 6 5/8" 49 13/16"

4' (149mm) (178mm) (168mm) (1265mm)

8VRVT2 5 7/8" 7" 6 5/8" 97 13/16"

8' (149mm) (178mm) (168mm) (2484mm)

MOUNTING

DIMENSIONS

Tandem

8T=8'

Length

Series

VRVT2

ORDERING INFORMATION

SAMPLE NUMBER: VRVT2-232DR-120V-EB81-WL-U

Number of

Lamps

1 or 2 Lamps

(Not included)

Wattage (Length)

20=20W (24")1

17=17W T8 (24")

BX40=40W Biax (24")

BX50=50W Biax (24")

40=40W (48")

32=32W T8 (48")

48=60W (48") SL

96=110W (96") HO

96T8=59W (96") SL)

Lens

DR=Internal Prismatic Lens/15% DR High

Impact Additive (Standard)

DR-100=100% High Impact Additive

LEX=High Impact Clear Polycarbonate LEXAN

Lens/Low Brightness Pattern

Voltage 2

120=120V

277=277V

347=347V

UNV=

Universal

Voltage

120-277V

LTS=Low

Trigger

Start (20

Watt)

HTS=High

Trigger

Start (20

Watt)

HO=High Output (800 MA)

Ballast Type 2

Standard Magnetic

Ballast

Leave Blank

LE3= Energy Saving

Ballast

LEOC8= Energy Saving

Ballast

(T-8 Lamp

Only)

EB _ _= Generic

Electronic

Ballast

No. of

Ballasts

1or 2

Lamp Size

2=T12

8=T8

5=T5

(For Speciﬁc Electronic

Ballast Specify Brand

and Catalog Number)

WL=Wet

Label

Options

GL=Internal Single

Element Fusing

GM=Dual Element

Fusing

EL4=Emergency

Lighting self-

contained.

EL8=Emergency

Lighting self-

contained.

RIF1=Radio

Interference

Suppressor

TH2=(2) Top

Watertite Hubs3

TEH2=(2) Top & (2)

End Watertite Hubs

(All Watertite3Hubs

Have 1/2" Conduit

Entry)

TILW=Tandem In-

Line Wiring Option

PI/CPI=Plug-In

Option

RLS=Rotor-Lock

Socket (T8 Lamps

Only)

DL=Damp Location

Labeled

WL=Wet Location

Labeled

DD=Deep Diffuser

(Available On 4'

Fixtures. Deep

Housing

Standard On 8'

Fixtures)

NOTE: For additional options, consult your Cooper Lighting Representative. Specifications and Dimensions subject to change

without notice.

1Standard Ballast (Non-LE3). 2Contact Pre Sales Technical Support. 3Optional VT2 1/2" stem bushing available. 4Ambient Thermal

Conditions: Operating Ambient Temperature Limitations Are Applicable. Contact Sales Engineering for Full“Operating Temperature

Range” of Specific Fixture. COOPER LIGHTING 1509
