StorageWorks by Compaq

NAS Executor E7000

Release Notes version 1.1

Part Number 261259-002

(Second Edition) April 2002

Product Version: Version 2.0

These release notes are for the StorageWorksTM NAS Executor E7000 by

Compaq running version 2.0 of the Compaq NAS software image and

provide important information not covered in other documentation.

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

Compaq, the Compaq logo, SANWorks, and StorageWorks are trademarks of

Compaq Information Technologies Group, L.P.

[Microsoft, MS-DOS, Windows, Windows NT, and Windows-Powered Operating

System are trademarks of Microsoft Corporation.]

All other product names mentioned herein may be trademarks of their respective

companies.

Compaq shall not be liable for technical or editorial errors or omissions contained

herein. The information in this document is provided “as is” without warranty of any

kind and is subject to change without notice. The warranties for Compaq products

are set forth in the express limited warranty statements accompanying such products.

Nothing herein should be construed as constituting an additional warranty.

StorageWorks by Comapq NAS Executor E7000 Release Notes

(Second Edition) April 2002

Part Number 261259-002

StorageWorks by Compaq NAS Exectutor E7000 Release Notes 3

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

Contents

Overview ...................................................................................................5

Software Updates................................................................................5

NFS Logging................................................................................5

NFS administrative shares support...............................................6

Volume Mount Points support .....................................................6

User name mapping Japanese characters .....................................7

NFS Share parameters cannot be changed after taking a group

offline ...........................................................................................7

Admin cannot list and map domain users and groups for SFU

mapping unless the SFU admin is logged into the domain ..........8

Password Synchronization will not work correctly on a Domain

Controller without an Admin UI ..................................................8

Disconnected Client Telnet Session can cause the SFU GUI to

hang ............................................................................................10

How to read SFU Help ...............................................................11

Storage, SAN, and Switching ...........................................................11

LUN Identification .....................................................................11

SAN Connection Process ...........................................................15

Hub and loop switch restrictions................................................17

Support For Enterprise Virtual Array.........................................18

Cluster Agent Activation............................................................18

Cluster Setup Tool ............................................................................19

Cluster Setup Tool screens lose focus........................................19

Cluster Setup Tool requires a Gateway......................................19

Quick Restore Process ......................................................................19

Quick Restore Removes all Data on the local disks...................19

SANworks Virtual Replicator...........................................................20

Disk Defragmenter does not work on SWVR volumes..............20

LVM Defaults to Dynamic Disk ................................................20

Network Disks............................................................................20

Contents

4 StorageWorks by Compaq NAS Exectutor E7000 Release Notes

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

Lifeguard and Snapshots............................................................20

Snapshots Naming......................................................................21

SWVR and TaskScheduler.........................................................21

Using Virtual Replicator with Other Windows Tools................22

Segment Size..............................................................................23

Allocation Unit Size...................................................................23

SWVR Driver and Windows Powered Operating System Issue 23

VR Namespace Recovery ..........................................................24

NAS Web User Interface..................................................................24

WebUI hangs when moving the cluster group...........................24

Loading page malfunction .........................................................25

Web UI default page may change..............................................25

Terminal Services returns a VBScript error...............................25

Moving an owned Cluster resource should report an error........26

Managing NTFS Mountpoints ...................................................26

CIFS incorrectly allows 'Change' selection................................27

Microsoft Powered OS .....................................................................28

Event Log Messages in the Event Log.......................................28

Things that will cause the cluster to fail.....................................29

StorageWorks by Compaq NAS Exectutor E7000 Release Notes 5

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

Overview

These release notes are for the StorageWorksTM NAS Executor

E7000 by Compaq running version 2.0 of the NAS software

image. This document provides important information that is not

covered in other documentation.

IMPORTANT: Read this entire document before installing and

configuring the StorageWorks NAS Executor E7000.

Software Updates

The software that ships with the StorageWorks NAS Executor

E7000 includes a special build of Microsoft Windows-Powered

Operating System. Any software updates must be qualified

against the Windows-Powered Operating System.

IMPORTANT: Install only Compaq-approved patches or service packs.

To view the list of approved patches please see the

StorageWorks NAS Website at:

http://www.compaq.com/storage/nas_index.html.

NFS Logging

The maintenance of the NFS log through the web interface to the

E7000 does not allow the deletion of the log. The NFS log

delete option is located in the WebUI under Maintenance, Logs,

NFS Log, and then clicking the Clear button. After clicking the

Clear button, a confirmation screen appears. After clicking OK

to confirm the deletion, the following error message will appear:

Release Notes

6 StorageWorks by Compaq NAS Exectutor E7000 Release Notes

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

"Error: There has been a sharing violation.

The source or destination file may be in use."

The administrator can delete the log after the Server for NFS

service is stopped.

Be aware that this will cause a service interruption to all users

trying to access NFS shares on the E7000.

1. Open the web user interface to the E7000.

2. Click Maintenance->Terminal Services and log in.

3. Right mouse click the My Computer icon and choose

Manage.

4. Open the Services portion of the management tree.

5. Select and stop the Server for NFS service.

You can now delete the log using the web interface as

instructed.

6. Start the Server for NFS service.

NFS administrative shares support

SFU does not work with administrative shares in the same

fashion as CIFS. By default, a volume drive such as C: is CIFS

shared as C$. This is an example of an administrative share and

is hidden from CIFS clients. If an NFS share is created and

named drive$, as in the example, the share will not be hidden

from NFS clients. This NFS share will act as a normal NFS

share.

Volume Mount Points support

Attempting to create an NFS share on a disk mounted on a

mount point will result in the error message:

“Cannot write IOCTL to NFS driver…”.

Release Notes

StorageWorks by Compaq NAS Exectutor E7000 Release Notes 7

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

StorageWorks NAS Executor E7000 supports many network-

sharing protocols, including the NFS protocol for UNIX and

Linux clients. Shares for which the NFS protocol will be

enabled must be created on Virtual Disks that are mounted on a

drive letter. Microsoft Windows-Powered OS supports

mounting virtual disks onto mount points or reparse points

created on another disk already mounted on a drive letter.

Mount points enable the administrator to mount many disk

devices under a single drive letter, creating the appearance and

behavior of a larger disk drive with a contiguous namespace.

However, the Microsoft Services for UNIX (SFU) NFS Server

does not yet support the functionality of mount points.

All virtual disks to be used for NFS sharing should be mounted

on a drive letter, not on a reparse or mount point. If no NFS

shares will be created on a particular virtual disk, that virtual

disk can be mounted on a mount point instead of a drive letter.

User name mapping Japanese characters

User name mapping for the network file system (NFS) server does not

support Windows or UNIX user names containing Japanese

characters.The name of NFS client groups that are used by the NFS

server cannot contain Japanese characters.

NFS Share parameters cannot be changed after

taking a group offline

NFS Share parameters cannot be changed after taking its group

offline. An error will appear when attempting to edit the NFS

parameters in this manner.

"Error: The Path entered does not exist."

Workaround:

NFS Share parameters can be modified if the NFS resource is

taken offline individually, rather than as a group.

Release Notes

8 StorageWorks by Compaq NAS Exectutor E7000 Release Notes

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

Take only the NFS share that you want to edit offline and then

change parameters.

1. Select Cluster Management from the WebUI.

2. Click Resources.

3. Click the radio button for the NFS resource being edited.

4. Click Take Offline.

5. Return to the Resources page and click the radio button for

the NFS resource being edited.

6. Click Parameters from the NFS resource properties page.

7. Edit the parameters and click OK.

8. Using Cluster Management in the WebUI, turn the NFS

resource to online.

Admin cannot list and map domain users and

groups for SFU mapping unless the SFU admin

is logged into the domain

The administator must log into the domain before mapping

domain users and groups. If the admin is not logged into the

domain, the domain user or group is not on the list of Windows

users or groups and cannot be mapped.

Password Synchronization will not work

correctly on a Domain Controller without an

Admin UI

The sfucustom.msi file located on the StorageWorks NAS E7000

at c:\SFU does not install an Admin UI for password

synchronization on a DC.

The Admin UI is used to set up:

•=Direction of password synchronization

Release Notes

StorageWorks by Compaq NAS Exectutor E7000 Release Notes 9

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

•=Encryption Key

•=Port Number

•=Password Sync retries

•=Unix systems to sync with

NOTE: NFS Authentication Tools and Password Synchronization can

be installed separately or together. The instructions follow.

To install Password Synchronization on the DC by itself (no

NFS Authentication Tools):

1. Allow the c:\WINNT\bin\SFU directory of the E7000 to be

shared.

net share SFU=C:\WINNT\bin\SFU

2. On the DC, connect to the share.

net use Z: \\NAS_machine_name\SFU

3. Change directories from the DC to the root of the connected

E7000 share.

cd /d Z:\

4. Run the install program on the DC.

OemSetup.msi ADDLOCAL=PasswdSync

SFUDIR=C:\SFU OEMINSTALL=TRUE SOURCELIST=Z:\

/l*v %temp%\sfusetup.log /q

5. Reboot the DC.

The DC must be rebooted manually after installing the password

synchronization piece to run correctly.

6. Run the Admin UI on the DC and setup password

synchronization.

7. Click Start->Programs->Windows Services for Unix-

>Services for Unix Administration.

Release Notes

10 StorageWorks by Compaq NAS Exectutor E7000 Release Notes

COMPAQ CONFIDENTIAL

Writer: Doug Warren File Name: 261259-002.doc

Codename: Eusebio Part Number: 261259-002 Last Saved On: 4/29/02 9:42 AM

To install NFS Authentication Tools on the DC by itself (no Password

Synchronization),Use the instructions outlined in the E7000

Administration Guide.

To install NFS Authentication Tools and Password

Synchronization on the DC:

1. Allow the c:\WINNT\bin\SFU directory of the E7000 to be

shared.

net share SFU=C:\WINNT\bin\SFU

2. On the DC, connect to the share.

net use Z: \\NAS_machine_name\SFU

3. Change directories from the DC to the root of the connected

E7000 share.

cd /d Z:\

4. Run the install programs on the DC in the following order.

a. OemSetup.msi ADDLOCAL=NFSServerAuth

SFUDIR=c:\SFU OEMINSTALL=TRUE

SOURCELIST=Z:\ /l*v %temp%\sfusetup.log /q

b. OemSetup.msi ADDLOCAL=PasswdSync

SFUDIR=c:\SFU OEMINSTALL=TRUE

SOURCELIST=Z:\ /l*v %temp%\sfusetup.log /q

5. Reboot the DC. The DC must be rebooted manually after

installing the password synchronization piece to run

correctly.

Disconnected Client Telnet Session can cause

the SFU GUI to hang

If a client Telnet session is forcibly disconnected from the E7000

while the SFU GUI is open, the SFU GUI can hang and become

unusable. To get around this, stop the SFU GUI on the E7000

using Task Manager and reopen the SFU GUI.

Autres manuels pour 230039-001 - StorageWorks NAS Executor E7000 Model 904...

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Compaq Stockage

Compaq

Compaq 179740-001 - ProLiant - 3000 Guide de référence rapide

Compaq

Compaq DLT Manuel utilisateur

Compaq

Compaq MSL5026 Manuel utilisateur

Compaq

Compaq ProLiant Storage System U1 Manuel utilisateur

Compaq

Compaq SSL2000 Series Manuel utilisateur

Compaq

Compaq 157770-001 - DAT Drive 20/40 Tape Mode d’emploi

Compaq

Compaq SDLT 110 Instructions d'utilisation

Compaq

Compaq SSL2000 Series Manuel utilisateur

Compaq

Compaq 157770-001 - DAT Drive 20/40 Tape Manuel utilisateur

Compaq

Compaq 219700-001 - ProLiant - 1500 Manuel utilisateur

Compaq

Compaq 312134-B21 - Intel Pentium II Xeon Processor... Manuel utilisateur

Compaq

Compaq QUICKSPECS 294162-B21 Instructions d'utilisation

Compaq

Compaq SW TL881 DLT Mini-Lib/1 Manuel utilisateur

Compaq

Compaq StorageWorks MSL5026DLX Manuel utilisateur

Compaq

Compaq TL891 - DLT Tape Library Manuel utilisateur

Compaq

Compaq StorageWorks TM RAID Array 3000 Pedestal Storage... Manuel d'installation

Compaq

Compaq SW TL881 DLT Mini-Lib/1 Manuel utilisateur

Compaq

Compaq AIT 35 LVD Manuel utilisateur

Compaq

Compaq StorageWorks ESL9000 Series Manuel utilisateur

Compaq

Compaq 157770-001 - DAT Drive 20/40 Tape Mode d’emploi

Compaq

Compaq StorageWorks 3000 - RAID Array Mode d’emploi

Compaq

Compaq StorageWorks 4000 - RAID Array Manuel utilisateur

Compaq

Compaq StorageWorks 4000 - RAID Array Guide de référence rapide

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
