LE-37N

3.5 inch Motherboard

User’s Manual

Edition 1.1

2019/08/15

LE-37N User’s Manual

-1-

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners.

Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT

LE-37N User’s Manual

-2-

Packing List:

Please check the package content before you starting using the board.

1 x LE-37N 3.5 inch Miniboard

1 x SATA CABLE

(OALSATA3-H10-L35 / 1040523)

1 xUSB2.0 cable

(OALUSBA-3 / 1040173) (Optional)

1 x Audio cable

(OALPJ-HDUNB / 1040123)

1 x PS/2 Keyboard & Mouse cable

(OALPS2/KM / 1040131) (Optional)

1 x Dual COM cable

(OALES-BKU2NB / 1040090)

1 x SATA Power Cable

(OALSATA15-2PJ / 1040613)

1 xDC Input Power Cable

(OALDC-B / 1040513)

1 x Cooler Fan

(OHSF-37N / 2181010035)

1 x Driver CD

(Including User’s Manual)

1 x COM Cable

(OALES-BKU1NB / 1040086) (Optional)

LE-37N User’s Manual
-3-
Index
Chapter 1 <Introduction>............................................................... 4
1.1 <Product Overview>............................................................4
1.2 <Product Specification> ......................................................5
1.3 <Block Diagram>.................................................................6
Chapter 2 <Hardware setup>......................................................... 7
2.1 <Connector Location and Reference> ................................7
2.1.1 <Internal connectors list> ..........................................8
2.1.2 <External connectors list>.........................................8
2.2 <Jumper Location and Reference> .....................................9
2.2.1 <Jumper list> ............................................................ 9
2.2.2 <Clear CMOS and Power on type selection>..........10
2.3 <Installing the Memory> .................................................... 11
2.4 <I/O interface> ..................................................................12
2.4.1 <Serial ATA interface>.............................................12
2.4.2 <Ethernet interface>................................................12
2.4.3 <Display interface> .................................................13
2.4.4 <Serial Port interface> ............................................15
2.4.5 <USB interface>......................................................17
2.4.6 <Audio interface>....................................................18
2.4.7 <Expansion slot>.....................................................19
2.4.8 <Front panel switch and indicator> .........................20
2.4.9 <GPIO ,SMBus and Other Interface>......................21
2.5 <Power supply> ................................................................24
2.5.1 <Power input>.........................................................24
2.5.2 <Power output>.......................................................24
Appendix A <Flash BIOS> ........................................................... 25
Appendix B <LCD Panel Type select> ........................................26
Appendix C <Programmable Watch Dog Timer>....................... 28
Appendix D <Hardware Monitor>................................................30
Appendix E <Programmable GPIO> ........................................... 31
Appendix F <RAID Setting>......................................................... 32
Appendix G <Setup ADP-3355,ADP-3460>................................. 33
Contact information .....................................................................33

LE-37N User’s Manual

-4-

Chapter 1 <Introduction>

1.1 <Product Overview>

LE-37N is a 3.5” Motherboard which supports 8th Generation Intel® Core™ U-Series

processors, integrated HD Graphics, DDR4 memory, Realtek High Definition Audio, Intel

Gigabit LAN, USB3.1 Gen2, SATA3 with AHCI function for a system.

New feature for Whiskey Lake

Whiskey Lake-U processors are based on the 14nm++ process node, and offer long-life

availability. They have a TDP of 15W, and integrate Gen 9.5 Intel Graphics GT2. It allows

triple independent display with 4K resolution.

All in One multimedia solution

The board provides high performance onboard graphics, and supports single bus or dual

bus LVDS signaling with color depths of 18 bits or 24 bits, DisplayPort, HDMI, and High

Definition Audio, to meet the very requirement of the multimedia application.

Flexible Expansion Interface

The board provides one MiniPCIe slot(support mSATA), and one M.2 2230 slot.

Whiskey Lake support Windows10 64bit RS5 and Linux

Intel recommend using Windows 10 64bit RS5. It may lose some drivers if you use other

Windows version.

LE-37N User’s Manual

-5-

1.2 <Product Specification>

System

Processor

Intel® Whiskey Lake Processor

FCBGA1528 package

Memory

2 x DDR4 SO-DIMM 2400 MHz up to 32GB,

Support Non-ECC, unbuffered memory

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Expansion

1 x MiniPCIe (support mSATA)

1 x M.2 (Key E) for Wi-Fi and Bluetooth 2230mm

Graphics

Chipset

Intel® Gen 9.5 integrated HD Graphics

Display Interface

1 x DisplayPort(optional), 1 x HDMI,1 x LVDS

LAN

Chip

1 x Intel® I210-AT Gigabit LAN

1 x Intel® I219-LM Gigabit PHY LAN (Support iAMT12.0)

I/O

Serial ATA

2 x SATA3

Audio

Realtek ALC262 HD Audio

Digital I/O

Programmable 8-bit GPIO with 12 pin-header

Internal I/O

2 x SATA3, 4 x USB2.0, 1 x RS232, 2x RS232/485/422

1 x LVDS, 1 x LCD inverter, 1 x GPIO, 1 x Audio, 1 x PS/2, 1 x SMBus

Rear I/O

1 x DisplayPort(optional), 1 x HDMI, 4 x USB3.1 Gen2, 2 x LAN

1 x RS232

Mechanical & Environmental

Power Requirement

DC input 9~35V

Size

146mm x 101mm (L x W)

Temperature

Operating within 0°C~60°C (32°F~140°F)

Storage within -20°C~80°C (-4°F~176°F)

Relative Humidity

10%~90%, non-condensing

LE-37N User’s Manual

-6-

1.3 <Block Diagram>

LVDS

PTN3460

HDMI

DDR4 2400 SO-DIMM

I219

I210

4 x USB3.1 Gen2

4 x USB2.0

SPI

1 x mini PCIe / mSATA

1 x M.2 (Key E)

2 x SATA

ALC262

2 x RS232

2 x RS232/RS422/RS485

1 x PS/2

GPIO

CPUFAN

SYSFAN

Super I/O

NCT6116D

Whiskey Lake

Processor

LE-37N User’s Manual

-7-

Chapter 2 <Hardware setup>

2.1 <Connector Location and Reference>

DDR4_A DDR4_B

USB2 I210-AT I219-LM USB1 DP COM1

HDMI

CN_PS2

JFRNT

CN_INV

DC_OUT

DC_IN

MINI_CARD

M.2 (E KEY)

CN_LVDS CN_SATA3-1 CPUFAN CN_USB2-2

CN_SATA3-2 SYSFAN CN_USB2-1

CN_DIO

CN_COM3/4

CN_COM2

CN_AUDIO

CN_BAT CN_SMBus

LE-37N User’s Manual

-8-

2.1.1 <Internal connectors list>

Connector

Function

SO-DIMM

260-pin DDR4 SO-DIMM slot

CN_SATA3-1/2

10-pin Serial ATA3 connector

CN_AUDIO

5 x 2-pin audio pin header

CN_DIO

6 x 2-pin General Purpose In/Out pin header

CN_LVDS

20 x 2-pin LVDS connector

CN_DP

11 x 1-pin DP to VGA module connector for optional

CN_INV

5-pin LCD inverter connector

CN_COM2

5 x 2-pin RS232 connector

CN_COM3/4

20-pin RS232/422/485 connector

CN_USB1/2

5 x 2-pin USB2.0 pin header

CN_PS2

5 x 2-pin PS/2 pin header

CN_SMBus

5-pin SMBus connector

CPUFAN

4-pin CPU fan connector

SYSFAN

4-pin System fan connector

JFRNT

5 x 2-pin front panel switch/indicator pin header

MINI_CARD

52-pin MiniPCIe card slot

75-pin M.2 Key E slot

DC_OUT

4-pin SATA Power connector

DC_IN

2-pin power input Terminal Block

2.1.2 <External connectors list>

Connector

Function

COM1

DB9 connector

HDMI-DP

DisplayPort and HDMI dual layer connector

USB1

2 x USB3.1 Gen2 connector

USB2

2 x USB3.1 Gen2 connector

LAN1

RJ45 connector

LAN2

RJ45 connector

LE-37N User’s Manual

-9-

2.2 <Jumper Location and Reference>

2.2.1 <Jumper list>

Jumper

Function

JAT

Power mode select

JRTC

CMOS Normal/Clear Setting

JVLCD

Panel Voltage Setting

JMSATA

MiniCard mSATA Setting

JP1/2

COM1 and CN_COM2 9-pin setting

JP2

JP1

JVLCD JAT JRTC

JMSATA
