Commell SP-501 Manuel utilisateur

SP-501

User’s Manual

Edition 1.0

2008/7/3

SP-501 User’s Manual

1

Copyright

Copyright 2008 all rights reserved. This document is copyrighted and all rights are reserved.

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners.

Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT.

SP-501 User’s Manual

2

Packing List:

Hardware:

SP-501 PCI Capture Card x1

Cable kit:

CD Content:

Drivers & User’s Manual

BNC Cable x 2

2 x D-SUB 9 Cable x 1 D-SUB9 Cable x 1

Audio Cable x 1 (optional)

SP-501 User’s Manual

3

1.0<Product Specification>

General Specification

Form Factor PCI Card with 120-pin interface

Controller One dataGATE MV9200

Accessories 2 x D-sub 9 to 8 x BNC connector cable

1 x D-sub 9 to 2 channel audio cable

Features 16 channel video input for camera

Support NTSC/PAL video decoding 120 fps at NTSC/PAL

Support image capture resolutions up to

768 x 576 (PAL)

720 x 480 (NTSC)

Dimensions (L x W) 120mm x 97mm

Ordering Code

SP-501H 16 ch video and 2 ch audio input with SDK provided

SP-501HA 16 ch video and 2 ch audio input with Scode DVR program

Recording & monitor

Input Resolution Frame rate

D1 15 fps/per channel4 Channel CIF 30 fps/per channel

D1 7.5 fps/per channel8 Channel CIF 15 fps/per channel

D1 5 fps/per channel12 Channel CIF 10 fps/per channel

D1 3.75 fps/per channel16 Channel CIF 7.5 fps/per channel

SP-501 User’s Manual

4

1.1 <Component Placement>

CN_DIO

SP-501 User’s manual

5

1.2 <Mechanical Drawing>

‘

‘

‘

‘

‘

‘‘

‘

SP-501 User’s Manual

6

1.3 <Connector Reference>

Connector: CN_DIO

Type: 12-pin (6x2) header

Pin Description Pin Description

1 GND 2 GND

3 IO1 4 IO5

5 IO2 6 IO6

7 IO3 8 IO7

9 IO4 10 IO8

11 +5V 12 +3.3V

1

2

11

12

SP-501 User’s manual

7

1.4 <Driver Setting>

1. Please choose Device Manager

SP-501 User’s Manual

8

2. Then you can see other devices

SP-501 User’s manual

9

3. Please choose Multimedia Controller then press

Reinstall Driver
