Cognex DataMan 200 Manuel utilisateur

COGNEX®

DataMan®200

Quick Reference Guide

ii DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide iii

Section Title xxxx • xxxxx • xxxxx • xxxxx • xxxxx Page 2

1Getting Started DataMan 200 Systems • DataMan 200 Image Formation

Options • DataMan 200 Accessories Page 4

DataMan Software Page 14

3Start the Setup Tool • Use the Setup Tool Menu Bar •

DataMan 200 Triggering • Trigger Modes • Training the

Reader

1Connections Page 22

4C-Mount Option • Installing a C-Mount Lens • Liquid

Lens • EtherNet/IP Support • I/O Cable • Acquisition

Triggering • High-Speed Output Lines • High-Speed

Output Wiring • Ethernet M12 to RJ45 Cable • RS-

232 Cable • DataMan 200 Specications • Multi-Port

Connections

1Compliance Information, Warnings

and Notices Page 38

5Compliance Notice • Warnings and Notices

Setting Up Your DataMan Reader Layout • Setting the Focus Position • Mounting

the Reader • Connecting the Reader • Reading Distances

• Install DataMan 200 Software • Troubleshooting an

Ethernet Connection • DataMan 200 Imager Specications

2Page 6

4 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 5

DataMan 200 Systems

DataMan 200 Image Formation Options

High-Speed

Part Moving

Applications

1DMax+™ —

Best-In-Class

1-D Reading

IDQuick™ —

High-Speed

2-D Reading

2DMax™ —

Difcult DPM

Reading

DataMan 200S*

(DMR-200S-xx)√ √

DataMan 200QL**

(DMR-200QL-xx) √ √

DataMan 200Q

(DMR-200Q-xx)√ √ √

DataMan 200X

(DMR-200X-xx)√ √ √ √

Description Build Option Field Upgradeable

Manual Focus Option

(DMR-200x-00)

User-settable focus

positions from 40 to

105mm. √N/A

Liquid Lens Option

(DMR-200x-01)

Software-controlled

adaptive autofocus. √Yes

C-Mount Option

(DMR-200x-02)

Allows use of

customer-supplied

C-mount lenses.

√No

DataMan 200 Accessories

CD-ROM

(Setup Tool and Drivers)

(206-6400-330)

Quick Reference

Guide

(590-7138)

Mounting bracket

(DM100-

UBRK-000)

Ethernet M12 to RJ45 cable

(CCB-84901-y00x-xx,

y straight/angled, xx

species length)

Liquid Lens Module

(DM200-LLM-000)

I/O cable

(CCB-M8IO-xx)

RS-232 cables

(CCB-M8X4-xx)

AC Power over

Ethernet (PoE)

Injector

(CPS-AC-POE1A-xx)

24V Power over

Ethernet (PoE) DIN-

RAIL Mount Adapter

(CPS-24V-POE1)

Red lens cover (ESD-

safe)

(DM100-RLC-000)

Clear lens cover (ESD-

safe)

(DM100-CLC-000)

Harsh Environment

Enclosure

(DM100-HENCL-00)

Pivot Mounting

Bracket

(DM100-PIVOTM-00)

*S: Maximum decode rate of 5 codes / sec

**QL: 1D / Stacked symbols only

6 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 7

Reader Layout

Pushbutton

• Push to read

• Push and hold 3

seconds to train

• Use Setup Tool to

program additional

button functions

Setting the Focus Position

DataMan can operate in one of three distance ranges. To set the focus

position:

Set focus position.

Tighten screws in order

shown. Maximum torque

for the cover screws is 9

N-cm (0.8 pound-inch).

Disconnect

DataMan from

power before

adjusting

focus

Illumination LEDs (2)

Laser apertures (2)

(aiming)

Mounting holes

(M3 X 5)

System

• Yellow: Power

• Green: Ethernet connected

• Blink: Communication

(RS232, Ethernet or both)

User

• Yellow: Untrained

• Green: Trained

• Blinking: Trigger

Status

• Green (pulse): Read

• Red (pulse): No read

• Red/Green (long pulse): Train

or Optimize Focus result

Remove screws

and lens cover.

Replace lens cover

and screws.

21.122.8

Ethernet RS-232 I/O

63.45

19.5

37.0

42.0

The size of the holes

in the standard lens

cover is M2x6. For

SHD, it is M2x18.

Maximum screw

head diameter is 4

mm.

15°

(40 mm)

COGNEX

mm 20

60 80 100 120

34 x 22 50 x 32 77 x 49

140 160 180

M3 x 5

8 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 9

Mounting the Reader

Mount the reader at

a slight angle (15°)

to reduce reections

and improve reader

performance.

Horizontal eld of view for the DataMan 200 at working distances of 40mm,

65mm and 105mm (with and without optional liquid lens):

Disconnect DataMan from power before removing or

changing cables.

Connecting the Reader

Ethernet

RS-232 PoE injector

Out

Using an RS-232 connection can be necessary to congure the reader

with parameters that allow it to communicate over your Ethernet

network.

M12 to RJ45

Supply power to the reader using a Power over Ethernet (PoE) injector.

Cognex recommends the following connection sequence:

1. Connect the PoE injector with the Ethernet installation (both sides of

the patch cable).

2. Connect the power cord (AC 230V/110V) to the PoE injector.

3. Connect the reader to the PoE injector.

(optional)

To disconnect the reader:

1. Disconnect the reader from the PoE injector.

2. Disconnect the power cord from the PoE injector.

3. Disconnect the PoE injector from the Ethernet installation.

6 mil

8 mil

10 mil

12 mil

20mm 40 60 80 100 120 140 160 180

105

10 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 11

Reading Distances

Supported range of reading distances for four code sizes (6, 8, 10, and 12 mil)

at each of the three focus positions (40mm, 65mm, and 105mm).

RS-232 connection

12 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 13

Install DataMan 200 Software

Troubleshooting an Ethernet Connection

1. Check the DataMan Release Notes for a full list of system requirements.

2. Insert CD-ROM and follow the on-screen prompts.

3. Connect the DataMan 200 to your PC.

4. Launch the Setup Tool and click Refresh.

The reader will appear under COM ports, Network devices, or both.

5. Select a COM port listing or Network devices listing and click Connect.

Ethernet connection

“DM200_” with last 6

characters of MAC address,

printed on back of the

reader

Based on your network conguration, the Setup Tool may not be able

to communicate with the reader and it will not appear in the list of

Network devices.

First check your Ethernet connection with the reader and click Refresh

in the Setup Tool. Next, scan the Enable DHCP code in the DM200

Conguration Codes document available from the Start menu. This

might allow the reader to acquire a suitable IP address from a DHCP

server on your subnet.

If the reader still does not appear, you can use either the Add Device or

Force Network Settings options in the Setup Tool.

If you know the IP address of the reader, use the Add Device option.

If you do not know the IP address, use the Force Network Settings

options. Either method should allow the DataMan 200 reader to appear

in the list of Network devices so that you can connect to it through the

Setup Tool and your Ethernet connection.

DataMan 200 Imager Specications

Specication DataMan 200 Imager

Image Sensor 1/3 inch CMOS

Image Sensor

Properties 4.51mm x 2.88mm (W x H), 6.0μm square pixels

Image Resolution

(Pixels) 752 x 480

14 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 15

Start the Setup Tool

Connect to Reader

Establish a connection to the reader

Results Display

View results

Light and Camera Settings

Choose a trigger type and other acquisition

parameters

System Settings

Congure input and output signals

Trigger button Latest image Context based help

Read history Train status Connection status

Connect the reader to the Setup Tool to

congure it with the type of symbologies

it will decode as well as other parameters,

such as the type of trigger it will use and the

format of the results it will generate.

Region of interest

In1 button

16 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 17

Use the Setup Tool Menu Bar

File Menu

Open Conguration Open a saved .cfg conguration le.

Save Conguration Create a .cfg conguration le of current runtime

parameters.

Print Conguration Code Generate a programming codes sheet representing your

reader’s conguration.

Restore Device Load a saved device conguration .cdc le, with run-

time parameters plus device-specic information for a

particular DataMan 200.

Backup Device Create a device conguration .cdc le for a specic

reader.

System Menu

Save Settings Save the current parameters to non-volatile

memory, which allows the reader to restore these

settings each time you reboot it.

Reset Conguration Reset all conguration parameters in RAM (volatile

memory) to the default settings.

Update Firmware Update the reader software.

Upload Feature Key Unlock additional features available in the reader

software if you have the right key.

VeriCode License Add VeriCode decoding by entering a license

string provided by Veritek. Ask your Cognex sales

representative for details.

The In1 button on the toolbar creates a virtual rising edge signal on Input 1. Use the In1

button to train a code, optimize brightness or set a match string without a physical input 1

channel.

Each reader can store its current set of runtime parameters to a conguration (.cfg) le,

which contains information such as the enabled symbologies and how any output data

should be formatted.

The same conguration le can be loaded onto multiple readers, as the le does not

contain identication information such as the IP address or device name of the reader

used to create it.

A reader can also generate a Cognex device conguration (.cdc) le, which stores the set

of runtime parameters plus any identication data, such as the name of the device, its IP

address, subnet mask, and so on. Cognex recommends generating a device conguration

le for each reader to allow you to restore a reader to its operating state with minimal

effort.

Use the File menu of the Setup Tool to manage .cfg and .cdc les:

Load Image Load an 8-bit uncompressed grey-scale .bmp or

.jpg image for analysis.

Save Image Save the latest acquired image with the .jpg or

.bmp le format.

Save Burst Images Save the latest batch of burst images.

Use the Edit menu for standard Cut, Copy and Paste operations.

Use the View menu to view reader information (serial number, rmware version,

and so on) and to enable and disable various elements of the Setup Tool, and the

Tasks menu to switch between various Setup Tool options.

Use the System menu to manage the current settings on the reader and to

upgrade the features it currently supports:

Use the Help menu to display Setup Tool version information.

18 DataMan 200 Quick Reference Guide DataMan 200 Quick Reference Guide 19

DataMan 200 Triggering Trigger Modes

Trigger the reader using any of the following methods:

• Press the trigger button on the reader.

• Send a pulse on the I/O cable:

Trigger + (blue), Trigger - (black)

• Send a trigger command over the RS-

232 connection or Ethernet connection.

• Click the Trigger button in the Setup

Tool:

• Press <CTRL>-T on the keyboard.

DataMan supports a variety of trigger modes:

• Single: Acquires a single image and attempts to decode any symbol

it contains, or more than one symbol in cases where multicode is

enabled. The reader relies on an external trigger source.

• Presentation: Repeatedly scans for a symbol and decodes it

whenever one is detected. The reader relies on an internal timing

mechanism to acquire images.

• Manual (default): Begins acquiring images when you press the

trigger button on the reader, and continues acquiring images until a

symbol is found and decoded or you release the button.

• Burst: Performs multiple image acquisitions based on an external

trigger and decodes any symbol appearing in a single image or

within a sequence of images, or multiple symbols in a single image

or within a sequence of images when multicode is enabled. You can

control the number of images within each burst and the interval

between image acquisitions.

• Self: Similar to Presentation mode in that the reader perpetually

scans for symbols and decodes them each time one is detected.

Unlike Presentation mode, however, Self mode supports multicode

results and a decode attempt occurs with every image.

• Continuous: Begins acquiring images based on a single external

trigger and continues to acquire images until a symbol is found

and decoded, or until multiple images containing as many codes

as specied in multicode mode are located, or until the trigger is

released.

Autres manuels pour DataMan 200

Table des matières

Autres manuels Cognex Lecteur de codes-barres

Cognex

Cognex DataMan 100 Manuel utilisateur

Cognex

Cognex DataMan 370 Series Manuel utilisateur

Cognex

Cognex DataMan 8700 Manuel utilisateur

Cognex

Cognex DataMan 475 Verifier Manuel utilisateur

Cognex

Cognex DataMan 300 Series Manuel utilisateur

Cognex

Cognex MX-1000 Manuel utilisateur

Cognex

Cognex DataMan 7550 Manuel utilisateur

Cognex

Cognex DataMan 8700 Manuel utilisateur

Cognex

Cognex DataMan 475 Manuel utilisateur

Cognex

Cognex DataMan 280 Series Manuel utilisateur

Cognex

Cognex DataMan 260 Series Manuel utilisateur

Cognex

Cognex DataMan 503 Manuel utilisateur

Cognex

Cognex DataMan 8050 Manuel utilisateur

Cognex

Cognex DM8072 ER Manuel utilisateur

Cognex

Cognex DataMan 470 Series Manuel utilisateur

Cognex

Cognex DataMan Mode d'emploi

Cognex

Cognex DataMan DT150 Manuel utilisateur

Cognex

Cognex MX-1000 Manuel utilisateur

Cognex

Cognex DataMan 503 Manuel utilisateur

Cognex

Cognex DataMan 8600 Series Manuel utilisateur

Cognex

Cognex DataMan 9500 Manuel utilisateur

Cognex

Cognex DataMan 50 Series Manuel utilisateur

Cognex

Cognex DataMan 60 Series Manuel utilisateur

Cognex

Cognex DataMan 8072 DL Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
