Clarke CPSB1 Mode d’emploi

OPERATION & MAINTENANCE

INSTRUCTIONS

LS0509

PORTABLE SANDBLASTER HOPPER KIT

MODEL NO: CPSB1

PART NO: 7640125

INTRODUCTION

Thank you for purchasing this Clarke Portable Sandblaster Hopper Kit.

Before you try to use this product, read this manual and follow the instructions

carefully. In doing so you will ensure your safety and the safety of others

around you. You can also look forward to a purchase that gives you long and

satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

PARTS AND SERVICING

For Parts & Servicing, please contact your nearest dealer, or

CLARKE International, on one of the following numbers.

PARTS & SERVICE TEL: 020 8988 7400

PARTS & SERVICE FAX: 020 8558 3622

or e-mail as follows:

PARTS: [email protected]

SERVICE: Service@clarkeinternational.com

GENERAL SAFETY RULES

1. Read this instruction manual before connecting the sandblaster to a compressor.

2. Safety glasses, hood, long-sleeve shirt, gloves and a respirator must be worn during

operation and clean up.

3. During operation, do not expose the hands or skin to the blasted material, keep

hands away from the nozzle.

4. Everyone in the blasting area must also wear personal protective equipment.

5. Check the condition of hoses and air lines before each use.

6. Make sure all connections are secure before use.

7. Abrasives used in this unit may be covered by COSHH Regulations.

8. ALWAYS make sure there is adequate ventilation. Do not spray in confined areas.

9. ALWAYS disconnect the gun from the air supply when the sandblaster is not in use.

10. ALWAYS clean the gun thoroughly after use. See ‘Maintenance’

11. ALWAYS turn off the compressor and expel all air from the air hose and gun before

disconnecting the sandblasting gun.

12. ALWAYS use appropriate air hoses and couplings and ensure that they are in good

condition. If any parts are worn or damaged, they should be replaced immediately.

13. ALWAYS hold the tool firmly and maintain good balance.

14. NEVER carry the gun by the hose. Keep hoses away from heat, oil and sharp edges.

15. NEVER use wet or even damp grit. Ensure the grit is completely dry,

16. In the case of injury seek expert medical advice immediately.

17. NEVER allow unauthorised persons or children use or play with the sandblaster.

18. Do not use the sandblaster around animals.

Warning: Compressed air can be dangerous. Ensure that you are

thoroughly familiar with all precautions relating to the use of

compressors and compressed air supplies.

Warning: Disconnect the sandblaster from the air supply before

performing any maintenance.

Warning: Do not point the sandblaster gun at anyone or objects other

than the intended work object.

PART IDENTIFICATION

Unpack your sandblaster, should there be any damage caused during transit

contact your Clarke dealer immediately.

Delivery Hose

Sandblasting Gun

Hopper Hook

Hook

Handle

Please dispose of any packaging responsibly. The cardboard packaging can

be recycled.

OPERATION

USING YOUR SANDBLASTER

The compressor used must be at least 3hp and capable of supplying a

minimum of 10 CFM of air

FIG 1

Connect an air hose (sold

separately) from your compressor,

to the hose fitting on the

sandblasting gun. Fig 1.

• Set the air pressure on your air

compressor to 100 -150 psi.

FIG 2

Make sure air hole located on the

base of the hopper is not

covered. Fig 2.

3. Pour the blasting medium into the

hopper.

4. Start compressor according to the

manufacturers instructions.

5. Check for leaks along all hoses

and fittings. if leaks are found, turn

off the compressor, disconnect

the hose and repair immediately.

6. Point the sandblasting gun in a safe direction away from people, pets or

anything around you that may be damaged by direct or indirect abrasive

spray.

7. Press and hold the sandblasting gun trigger until abrasive medium is flowing

through the nozzle.

TO STOP BLASTING

1. Release the trigger on the sandblasting gun.

SPECIFICATIONS

CPSB1

Sand Grade Type Up to 60 Grit (Clarke AOP60)

Abrasive Material Aluminium Oxide, Garnet Powder,

Glass Bead

Sand Capacity: (kg/lbs) 22.7/50

Operating Pressure: (psi) 100-150

Minimum Flow Rate Req: (cfm) 10

Compressor Size Hp: (Minimum) 3

Air Fitting: 1/4” NPS

Dimensions (Length x Width x Height) 490 mm x 430 mm x 895 mm

Weight 2 kg
