Clarke Devil 355MD Mode d'emploi

MODEL No: Devil 355MD

Part No: 6925117

OPERATING & MAINTAINENCE

INSTRUCTIONS

1008

Multi-Directional Quartz

Halogen Infra Red Heater

Multi-Directional Quartz

Halogen Infra Red Heater

Thank you for purchasing this Clarke Infra Red Heater.

Before attempting to operate the unit please read this instruction leaflet and

carefully follow all directions given. By doing so you will ensure safe operation of the

unit and you can also look forward to it providing you with long and trouble free

service.

GUARANTEE

This CLARKE product is guaranteed against faults in manufacture for 12 months from

purchase date. Please keep your receipt as proof of purchase.

This guarantee is invalid if the product has been found to have been abused in any

way, or not used for the purpose for which it was intended, or to have been tam-

pered with in any way. The reason for return must be clearly stated.

This guarantee does not affect your statutory rights.

SPECIFICATIONS

Model ......................................................... Devil 355MD

Part No : ..................................................... 6925117

Wattage : .................................................. 3 KW

Amps : ........................................................ 13A

Dimensions (LWH) : ................................... 1000 x 490 x 480 mm

Net Weight : .............................................. 10 Kg

Weight (packed) : .................................... 12 Kg

Please note that the details and specifications are correct at the time of going to

print. CLARKE International reserve the right to change specifications at any time

without prior notice. Always consult the machines data plate

Do not dispose of this product with general household waste. It must be disposed

of according to the laws governing Waste Electrical and Electronic Equipment, at

a recognised disposal facility.

SAFETY PRECAUTIONS

• This heater is for indoor use only.

• ALWAYS disconnect from the mains supply before moving or performing

any maintenance tasks.

• DO NOT use this heater in a bathroom or shower room.

• DO NOT use this heater in the vicinity of a swimming pool.

• DO NOT use this heater in greenhouses or construction areas.

• DO NOT position the heater below an electrical outlet.

• NEVER position the heater near combustible materials such as curtains,

furniture etc. Allow at least 2 metres clearence.

• DO NOT position the heater close to an adjacent wall or ceiling, allow a

distance of at least 1 metre from the wall or ceiling.

• ONLY use the heater in an upright position.

• NEVER cover the heater, or block any of the vents.

• NEVER use the heater if either of the guards have been removed.

• DO NOT use if the IR Halogen Tubes are damaged or broken.

• NEVER touch the heater elements- even when cold.

• NEVER touch the heater for at least 15 minutes after it is switched off.

• INSPECT the mains cable regularly for signs of damage. DO NOT use the

heater if the mains cable is damaged.

• ALWAYS keep mains cable away from the source of heat.

• NEVER use the heater with a timer device as this could be a fire hazard

should the heater move for any reason whilst unattended.

ELECTRICAL CONNECTIONS

230 VOLT MODELS

Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an

approved 13 amp BS 1363 plug, or a suitably fused isolator switch.

WARNING! THIS APPLIANCE MUST BE EARTHED

IMPORTANT: The wires in the mains lead are coloured in accordance with the following

code:

Green & Yellow ................................ Earth

Blue .................................................... Neutral

Brown ................................................ Live

As the colours of the flexible lead of this appliance may not correspond with the coloured

markings identifying terminals in your plug, or your mains supply, proceed as follows:

• Connect GREEN & YELLOW coloured cord to plug terminal marked with a

letter “E” or Earth symbol “ ” or coloured GREEN or GREEN & YELLOW.

• Connect BROWN cord to terminal marked with a letter “L” or coloured RED.

• Connect BLUE cord to terminal marked with a letter “N” or coloured BLACK.

FUSE RATING

The fuse in the plug must be replaced with one of the same rating (13 amps) and this

replacement must be ASTA approved to BS1362.

CABLE EXTENSION

Always use an approved cable extension suitable for the power rating of this tool (see

specifications), the conductor size should also be at least the same size as that on the

machine, or larger. When using a cable reel, always unwind the cable completely.

WARNING!

IF YOU ARE IN ANY DOUBT ABOUT ELECTRICAL CONNECTIONS, CONSULT A

QUALIFIED ELECTRICIAN

NEVER ATTEMPT ELECTRICAL REPAIRS YOURSELF

SPARE PARTS

No. Description Part No.

1 Handle. DADEV355MD01

2 Guard. DADEV355MD02

3 IR Halogen Lamp. DADEV355MD03

4 Castor (with brake). DADEV355MD04

5 Castor (standard). DADEV355MD05

6 Securing Knob. DADEV355MD06

DEVIL355MD

OPERATION

Tools Required: 2 x 13mm spanners and 1 x

Pozidrive screwdriver (medium).

ASSEMBLY

To reduce the risk of transit damage, the

support legs (2), castors (4) and the halogen

lamps (2) are not fitted.

1. Attach the four castors to the support legs

using the bolts, washers and nuts supplied.

Fig 1.

2. Attach the legs to the main body using bolts

supplied. Fig 2

3. Fit the four handles as shown in Fig 2 using

the 8 screws supplied.

4. Insert the securing knobs into the rear of

each heating element.

Do not tighten them fully at this stage.

5. Connect the mains cable to a suitable

supply.

USING THE HEATER

1. Position the heater as required and lock the

wheels to prevent the heater from rolling.

2. Release the locking clips and use the

handles on each side of the heater to rotate

the heating element to the required position.

3. Tighten the securing knob on the back of the

heating element to lock in to place.

4. Use the on/off switch to turn on the required

heating element.

Handle

Bolts and Washers

Bolt and

Washer

Nut

Fig 2

Fig 1

Fig 3

On/Off Switch

(Top Element)

On/Off Switch

(Bottom Element)

PARTS & SERVICE

MAINTENANCE

Allow the heater to cool down for at least 15 minutes after switching off, before

performing any maintenance tasks.

REPLACING THE HEATING LAMPS

NEVER handle the heater lamps with bare hands, ALWAYS handle using either a soft

clean glove, or a piece of soft clean cloth wrapped around the lamp.

Before attempting to fit/replace heater lamps, ensure the heater is switched off and

isolated from the main electrical supply by removing the plug from the socket. Also

ensure the heater is in an upright position.

1. Loosen and remove the two pozidrive screws securing the chromed guard, remove

the guard and store removed parts safely.

2. To remove lamp, grasp lamp and gently but firmly push it towards one end of the

heater, the lamp holders are sprung loaded and will allow the lamp to move

sufficiently in order to clear the opposite holder.

3. Remove the lamp and dispose of according to local regulations.

4. Fit new halogen lamp in reverse order, repeat both procedures for second lamp.

5. Replace the guard using the screws removed earlier.

The heater is now ready for use again, and may be plugged in and switched on.

IMPORTANT

IF IN ANY DOUBT, ALWAYS CONSULT A QUALIFIED TECHNICIAN. DO NOT

CARRY OUT ANY REPAIRS YOURSELF.

CLEANING

• Disconnect from the mains supply, remove the guard and wipe the reflectors

with a clean dry cloth. DO NOT use abrasive cleaners. Take care NOT to touch

the tube with your fingers.

• Inspect the mains cable for damage. Heat damage will cause the cable to stiffen

and crack. If this is found, have the cable replaced (refer to your CLARKE dealer),

check cable routing and ensure it is well away from the heat source.

PARTS & SERVICE TEL: 020 8988 7400

or e-mail as follows:

PARTS: [email protected]

SERVICE: [email protected]
