CITROEN C4 PICASSO Guide de l'utilisateur

OWNER'S HANDBOOK

On-line owner's handbook

Referring to the owner's handbook on-line also gives you ac-

cess to the latest information available, easily identiﬁed by the

bookmark, associated with this symbol:

If the "MyCitroën" function is not available on the CITROËN public web-

site for your country, you can ﬁnd your handbook at the following address:

http://service.citroen.com

Select:

You can ﬁnd your handbook on the CITROËN website, under

"MyCitroën".

This personal and customisable space allows you to establish direct

and special contact with CITROËN.

The Vehicle documentation link in the home page (no registration is

needed),

the language,

the vehicle, its body style,

the print edition of your handbook appropriate for the date of registration

of your vehicle.

You have access to your handbook on line, together with the latest

information, identiﬁed by the symbol:

Your vehicle is ﬁtted with only some of the

equipment described in this document,

depending on the trim level, version and the

speciﬁcations for the country in which it is

sold.

The ﬁtting of electrical equipment or

accessories which are not recommended

by CITROËN may result in a failure of your

vehicle's electronic system. Please note this

speciﬁc warning and contact a CITROËN

dealer to be shown the recommended

equipment and accessories.

CITROËN has a presence on every continent,

a complete product range,

bringing together technology and a permanent spirit of innovation,

for a modern and creative approach to mobility.

We thank you and congratulate you on your choice.

Happy motoring!

Key

safety warning

We draw your attention to the following...

contributes to the protection of the

environment

programming a function with the

conﬁguration menu

At the wheel of your new vehicle,

getting to know each system,

each control, each setting,

makes your trips, your journeys

more comfortable and more enjoyable.

additional information

refer to the page indicated

CONTENTS

Monochrome screen A 49

Monochrome screen C 51

Colour screen 55

Trip computer 57

2 - MULTIFUNCTION

SCREENS 49 60

Ventilation 61

Manual air conditioning 63

Dual-zone digital air conditioning 65

Front demist - defrost 69

Rear screen demist - defrost 69

Front seats 70

Rear seats 75

Mirrors 76

Steering wheel adjustment 78

3 - COMFORT 61 78

Remote control key 79

Alarm 88

Doors 90

Boot 91

Electric windows 92

Panoramic sunroof 94

Fuel tank 95

Misfuel prevention (Diesel) 97

4 - ACCESS 79 97

Lighting controls 98

Automatic illumination of headlamps

102

Welcome lighting 103

Headlamp adjustment 104

Directional lighting 105

Wiper controls 107

Automatic rain sensitive wipers 108

Courtesy lamps 110

Interior mood lighting 111

Boot lamp 111

5 - VISIBILITY 98 111

Interior ﬁttings 112

Centre consoles 115

Front armrest 116

Boot ﬁttings 121

Luggage cover

(enterprise version) 124

6 -

FITTINGS

112 124

Instrument panels 28

Rev counter 31

Warning and indicator lamps 32

Indicators 43

Time and units 46

Customisation 48

FAMILIARISATION 4 25

1 - MONITORING 28 48

Child seats 125

Deactivating the passenger's front

airbag 127

ISOFIX child seats 134

Child lock 138

7 - CHILD SAFETY 125 138

ECO-DRIVING 26 27

CONTENTS

Direction indicators 139

Hazard warning lamps 139

Horn 139

Braking assistance systems 140

Trajectory control systems (ESP) 141

Emergency or assistance call 142

Front seat belts 143

Airbags 146

8 - SAFETY 139 149

Electric parking brake 150

Manual parking brake 157

Manual gearbox 157

Electronic gearbox 158

Automatic gearbox 161

Hill start assist 164

Gear efﬁciency indicator 165

Tyre under-inﬂation detection 166

Stop & Start 168

Lane departure warning system 171

Blind spot sensors 172

Speed limiter 176

Cruise control 178

Parking space sensors 180

Parking sensors 182

9 - DRIVING 150 183

Bonnet 185

Running out of fuel (Diesel) 186

Petrol engines 187

Diesel engines 188

Checking levels 189

Checks 191

10 -

CHECKS

184 192

Temporary puncture repair kit 193

Changing a wheel 198

Snow chains 202

Changing a bulb 203

Changing a fuse 209

12 V battery 213

Energy economy mode 216

Changing a wiper blade 216

Fitting roof bars 217

Very cold climate screen 217

Towing the vehicle 218

Towing a trailer 220

Audio pre-equipment 221

Accessories 222

11 - PRACTICAL

INFORMATION 193 223

Petrol engines 224

Petrol weights 225

Diesel engines 226

Diesel weights 227

Dimensions 230

Identiﬁcation markings 231

12 - TECHNICAL

DATA 224 232

Emergency or assistance 233

eMyWay 235

Audio system 289

AUDIO and

TELEMATICS 233 322

ALPHABETICAL

INDEX 327 331

VISUAL SEARCH 323 326

EXTERIOR

Parking sensors

This system measures the size of a

free parking space between two ve-

hicles or obstacles.

180

Stop & Start system

This system puts the engine temporar-

ily on standby during stops in the traf-

ﬁc (trafﬁc lights, trafﬁc jams, etc...). The

engine restarts automatically as soon

as you want to move off. The Stop &

Start system allows reductions of fuel

consumption and exhaust emissions,

as well as noise levels when stationary.

168

Welcome lighting

This additional exterior and interior

lighting, controlled remotely, makes

your approach to the vehicle easier

when the light is poor.

103

Directional lighting

This lighting automatically provides

additional visibility when cornering.

105

Cornering lighting

At low speed, this lighting automati-

cally provides additional visibility

when cornering, at junctions, when

parking... making use of the corre-

sponding front foglamp.

106

FAMILIARISATION

EXTERIOR

Blind spot sensors

In certain conditions, this system de-

tects the presence of a vehicle in the

blind spot. It informs you by means of a

warning lamp in the corresponding door

mirror.

172

Under-inﬂation detection

This system continuously monitors the

pressures in the tyres and alerts you in

the event of under-inﬂation.

166

Panoramic sunroof

This roof provides incomparable visibility

and light in the passenger compartment.

94

Temporary puncture repair kit

This kit is a complete system, consisting

of a compressor and a sealant cartridge,

for the temporary repair of a tyre.

193

OPENING

2-button remote control 3-button remote control Welcome lighting

A. Unfolding / Folding the key

(ﬁrst press this button).

79, 81

A. Folding/unfolding the key

(ﬁrst press this button).

80, 81

When a sensor detects a low level of

light, the remote switching on of the

dipped beam headlamps, the side-

lamps and the side spotlamps makes

your approach to the vehicle easier.

Complete or selective unlock-

ing of the vehicle

(rapid ﬂashing of the direction

indicators).

Normal locking

(press once; ﬁxed lighting of

the direction indicators).

Complete or selective unlocking

of the vehicle

(rapid ﬂashing of the direction

indicators).

Opening the windows

(hold until the desired level is reached).

Selective unlocking of the boot.

Normal locking

(press once; ﬁxed lighting of

the direction indicators).

Closing the windows

(hold until the desired level is reached).

In the same way, the passenger compart-

ment lighting, such as the courtesy lamps

and the footwell lamps, comes on.

103

FAMILIARISATION

OPENING

Boot

2-button remote control

3-button remote control

Fuel tank Panoramic sunroof

1. Unlocking the vehicle.

2. Opening the boot.

79, 91

1. Selective unlocking of the boot.

2. Opening the boot.

80, 91

A. Opening the fuel ﬁller ﬂap.

Capacity of the fuel tank: approximately

60 litres.

1. Opening the blind (four positions

possible).

2. Closing the blind (initial position).

95

94

INTERIOR

Interior mood lighting

This dimmed lighting of the passenger

compartment improves visibility inside

the vehicle when the light is poor.

111

Electronic gearbox

This system offers driving combining

a fully automatic mode and a manual

mode.

158

Electric parking brake

It combines the functions of auto-

matic application on switching off the

engine and automatic release when

moving off.

Manual application and release re-

mains possible.

150

Audio and communication systems

These systems beneﬁt from the following

technologies: radio, CD player, USB player,

Bluetooth system, satellite navigation sys-

tem with colour screen, auxiliary sockets.

Radio

289

eMyWay satellite navigation system

235

Massage system

This system provides a lumbar

massage for a period of 60 minutes.

The massage is done in 6 cycles of

10 minutes duration each.

73
