Cisco WAP371 Mode d’emploi

Cisco Small Business

WAP371 Wireless-AC/N Dual Radio Access Point

with Single Point Setup

ADMINISTRATION

GUIDE

Cisco Small Business WAP371 Wireless Access Point Administration Guide 1

Contents

Chapter 1: Getting Started 5

Starting the Web-Based Configuration Utility 5

Using the Access Point Setup Wizard 6

Getting Started 9

Window Navigation 10

Chapter 2: Status and Statistics 13

System Summary 13

Network Interfaces 15

Traffic Statistics 16

WorkGroup Bridge Transmit/Receive 16

Associated Clients 17

TSPEC Client Associations 18

TSPEC Status and Statistics 20

TSPEC AP Statistics 22

Radio Statistics 22

Email Alert Status 24

Log 24

Chapter 3: Administration 25

System Settings 25

User Accounts 26

Time Settings 28

Log Settings 29

Email Alert 31

LED Display 34

HTTP/HTTPS Service 35

Management Access Control 37

Manage Firmware 37

Download/Backup Configuration File 39

Cisco Small Business WAP371 Wireless Access Point Administration Guide 2

Contents

Configuration Files Properties 41

Copy/Save Configuration 42

Reboot 42

Discovery—Bonjour 43

Packet Capture 44

Support Information 50

Chapter 4: LAN 52

Port Settings 52

VLAN and IPv4 Address Settings 53

IPv6 Addresses 54

IPv6 Tunnel 56

LLDP 57

Chapter 5: Wireless 60

Radio 60

Rogue AP Detection 68

Networks 71

Scheduler 82

Scheduler Association 85

Bandwidth Utilization 86

MAC Filtering 86

WDS Bridge 88

WorkGroup Bridge 91

Quality of Service 94

Chapter 6: System Security 99

RADIUS Server 99

802.1X Supplicant 101

Password Complexity 102

Cisco Small Business WAP371 Wireless Access Point Administration Guide 3

Contents

WPA-PSK Complexity 103

Chapter 7: Client Quality of Service 105

Client QoS Global Settings 105

ACL 105

Class Map 113

Policy Map 117

Client QoS Association 119

Client QoS Status 121

Chapter 8: Simple Network Management Protocol 123

General SNMP Settings 123

Groups 127

Users 129

Targets 130

Chapter 9: Captive Portal 132

Local Groups 132

Local Users 133

Instance Configuration 134

Instance Association 137

Web Portal Customization 138

Captive Portal Global Configuration 142

Authenticated Clients 143

Failed Authentication Clients 144

Chapter 10: Single Point Setup 145

Single Point Setup Overview 145

Access Points 149

Cisco Small Business WAP371 Wireless Access Point Administration Guide 4

Contents

Sessions 152

Channel Management 154

Wireless Neighborhood 157

Appendix A: Deauthentication Message Reason Codes 161

Deauthentication Reason Code Table 161

Appendix B: Where to Go From Here 163

Cisco Small Business WAP371 Wireless Access Point Administration Guide 2

Getting Started

This chapter provides an introduction to the Wireless Access Point (WAP) devices web-based

configuration utility, and includes these topics:

• Starting the Web-Based Configuration Utility

• Using the Access Point Setup Wizard

• Getting Started

• Window Navigation

Starting the Web-Based Configuration Utility

This section describes system requirements and how to navigate the web-based configuration

utility.

Supported Browsers

•Internet Explorer 7.0 or later

•Chrome 5.0 or later

•Firefox 3.0 or later

•Safari 3.0 or later

Browser Restrictions

•If you are using Internet Explorer 6, you cannot directly use an IPv6 address to access

the AP. You can, however, use the Domain Name System (DNS) server to create a

domain name that contains the IPv6 address, and then use that domain name in the

address bar in place of the IPv6 address.

•When using Internet Explorer 8, you can configure security settings from Internet

Explorer. Select Tools > Internet Options and then select the Security tab. Select

Local Intranet and select Sites. Select Advanced and then select Add. Add the

intranet address of the AP (http://<ip-address>) to the local intranet zone. The IP

Getting Started

Using the Access Point Setup Wizard

Cisco Small Business WAP371 Wireless Access Point Administration Guide 3

address can also be specified as the subnet IP address, so that all addresses in the

subnet are added to the local intranet zone.

•If you have multiple IPv6 interfaces on your management station, use the IPv6 global

address instead of the IPv6 local address to access the AP from your browser.

Logging Out

By default, the web-based AP configuration utility logs out after 10 minutes of inactivity. See

HTTP/HTTPS Service for instructions on changing the default timeout period.

To log out, click Logout in the top right corner of the web-based AP configuration utility.

Using the Access Point Setup Wizard

The first time that you log into the AP (or after it has been reset to the factory default settings),

the Access Point Setup Wizard appears to help you perform initial configurations. Follow

these steps to complete the wizard:

NOTE If you click Cancel to bypass the Wizard, the Change Password page appears. You can then

change the default password for logging in. For all other settings, the factory default

configurations apply.

You must log in again after changing your password.

STEP 1 Click Next on the Welcome page of the Wizard. The Configure Device - IP Address window

appears.

STEP 2 Click Dynamic IP Address (DHCP) if you want the WAP device to receive an IP address from

a DHCP server. Or select Static IP Address to configure IP Address manually. For a

description of these fields, see VLAN and IPv4 Address Settings.

STEP 3 Click Next. The Single Point Setup — Set a Cluster window appears. For a description of

Single Point Setup, see Single Point Setup.

STEP 4 To create a new Single Point Setup of WAP devices, select Create a New Cluster and specify a

New Cluster Name. When you configure your devices with the same cluster name and enable

Single Point Setup mode on other WAP devices, they automatically join the group.

Getting Started

Using the Access Point Setup Wizard

Cisco Small Business WAP371 Wireless Access Point Administration Guide 4

If you already have a cluster on your network, you can add this device to it by clicking Join an

Existing Cluster, and then entering the Existing Cluster Name.

If you do not want this device to participate in a Single Point Setup at this time, click Do not

Enable Single Point Setup.

(Optional) You can enter text in the AP Location field to note the physical location of the WAP

device.

STEP 5 Click Next. The Configure Device - Set System Date and Time window appears.

STEP 6 Select your time zone, and then set the system time manually or set up the WAP device to get

its time from an NTP server. For a description of these options, see Time Settings.

STEP 7 Click Next. The Enable Security - Set Password window appears.

STEP 8 Enter a New Password and enter it again in the Confirm Password text box. For more

information about passwords, see User Accounts.

NOTE You can uncheck the Password Complexity box if you wish to disable the

password security rules. However, we strongly recommend keeping the password

security rules enabled.

STEP 9 Click Next. The Enable Security - Name Your Wireless Network window appears for the

Radio 1 interface.

NOTE For this window and the following two windows (Wireless Security and VLAN

ID), you configure these settings for the Radio 1 interface first. Then the windows

repeat to enable you to configure these settings for Radio 2.

STEP 10 Enter a Network Name. This name serves as the SSID for the default wireless network.

STEP 11 Click Next. The Enable Security - Secure Your Wireless Network window appears.

STEP 12 Choose a security encryption type and enter a security key. For a description of these options,

see System Security.

STEP 13 Click Next. The Wizard displays the Enable Security- Assign the VLAN ID For Your Wireless

Network window.

STEP 14 Enter a VLAN ID for traffic received on the wireless network.

It is suggested that you assign a different VLAN ID from the default (1) to wireless traffic, in

order to segregate it from management traffic on VLAN 1.

STEP 15 Click Next.

STEP 16 For the WAP371 device, the Network Name, Wireless Security, and VLAN ID pages show to

enable configuring Radio 2. When finished with configuring Radio 2, click Next.

Getting Started

Using the Access Point Setup Wizard

Cisco Small Business WAP371 Wireless Access Point Administration Guide 5

The Wizard displays the Enable Captive Portal - Create Your Guest Network window.

STEP 17 Select whether or not to set up an authentication method for guests on your network, and click

Next.

If you click No, skip to STEP 25.

If you click Yes, the Wizard displays the Enable Captive Portal - Name Your Guest Network

window.

STEP 18 Specify a Guest Network Name for Radio 1. For the WAP371 device, select whether the guest

network uses Radio 1 or Radio 2.

STEP 19 Click Next. The Wizard displays the Enable Captive Portal - Secure Your Guest Network

window.

STEP 20 Choose a security encryption type for the guest network and enter a security key. For a

description of these options, see System Security.

STEP 21 Click Next. The Wizard displays the Enable Captive Portal - Assign the VLAN ID window.

STEP 22 Specify a VLAN ID for the guest network. The guest network VLAN ID should be different

from the management VLAN ID.

STEP 23 Click Next. The Wizard displays the Enable Captive Portal - Enable Redirect URL window.

STEP 24 Select Enable Redirect URL and specify a fully qualified domain name or IP address in the

Redirect URL field (including http://). If specified, guest network users are redirected to the

specified URL after authenticating.

STEP 25 Click Next. The Wizard displays the Summary - Confirm Your Settings window.

STEP 26 Review the settings that you configured. Click Back to reconfigure one or more settings. If

you click Cancel, all settings are returned to the previous or default values.

STEP 27 If they are correct, click Submit. Your WAP setup settings are saved and a confirmation

window appears.

STEP 28 Click Finish. The Login window appears to log in to the AP using the changed password.

Getting Started

Cisco Small Business WAP371 Wireless Access Point Administration Guide 6

Getting Started

To simplify device configuration through quick navigation, the Getting Started page provides

links for performing common tasks. The Getting Started page is the default window every time

you log into the web-based AP configuration utility.

Links on the Getting Started Page

Category Link Name (on the Page) Linked Page

Initial Setup Run Setup Wizard Using the Access Point

Setup Wizard

Configure Radio Settings Radio

Configure Wireless Network Settings Networks

Configure LAN Settings LAN

Configure Single Point Setup Single Point Setup

Device Status System Summary System Summary

Wireless Status Network Interfaces

Quick Access Change Account Password User Accounts

Upgrade Device Firmware Manage Firmware

Backup/Restore Configuration Download/Backup

Configuration File

Autres manuels pour WAP371

Table des matières

Autres manuels Cisco Point d'accès sans fil

Cisco

Cisco 1522AG - Aironet Lightweight Outdoor Mesh Access... Manuel utilisateur

Cisco

Cisco Aironet 1240AG Series Manuel utilisateur

Cisco

Cisco Catalyst Wireless 9163E Manuel utilisateur

Cisco

Cisco WAP300N Manuel utilisateur

Cisco

Cisco AIR-AP1232AG-A-K9 - Aironet 1230AG - Wireless Access... Manuel utilisateur

Cisco

Cisco Aironet 2802E Manuel utilisateur

Cisco

Cisco Small Business AP541N Mode d’emploi

Cisco

Cisco Small Business WAP551 Manuel utilisateur

Cisco

Cisco Meraki GR10 Manuel utilisateur

Cisco

Cisco Aironet 3502P Manuel utilisateur

Cisco

Cisco FM PONTE-50 Manuel

Cisco

Cisco Aironet 1815w Manuel utilisateur

Cisco

Cisco 1130AG - Aironet - Wireless Access Point Manuel

Cisco

Cisco Aironet 1140 Series Manuel utilisateur

Cisco

Cisco USC 3330 Manuel utilisateur

Cisco

Cisco Aironet 3800P Series Manuel utilisateur

Cisco

Cisco Meraki Go GR62 Manuel utilisateur

Cisco

Cisco AIR-CAP1552H-x-K9 Manuel utilisateur

Cisco

Cisco ISR Manuel utilisateur

Cisco

Cisco WAP300N Manuel utilisateur

Cisco

Cisco Meraki CW9162I-MR Manuel

Cisco

Cisco Aironet OfficeExtend AIR-OEAP602I-E-K9 Manuel utilisateur

Cisco

Cisco Mesh Access Points Guide de référence rapide

Cisco

Cisco Aironet 3600 Series Manuel utilisateur

Manuels Point d'accès sans fil populaires d'autres marques

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuel utilisateur

Ubiquiti

Ubiquiti NanoStation NSM2 Manuel utilisateur

Aruba

Aruba IAP-335 Manuel utilisateur

Advantek Networks

Advantek Networks AWN-AP-54MR Manuel utilisateur

IP-COM

IP-COM AP355 Manuel utilisateur

Buffalo

Buffalo AirStation WLA-L11G Manuel utilisateur

EnGenius

EnGenius EnStationACv2 Manuel utilisateur

D-Link

D-Link DAP-3662 Manuel utilisateur

xG Technology

xG Technology xMax CN1300 Manuel utilisateur

Widelink

Widelink ezWave WAP-1100 Series Manuel utilisateur

Edimax

Edimax CAP1200 Manuel utilisateur

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuel utilisateur

Aruba

Aruba AP-203R Manuel utilisateur

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuel utilisateur

CreatComm

CreatComm TB5F Manuel utilisateur

SineDigital

SineDigital MW-1500AP(H) Manuel utilisateur

TP-Link

TP-Link AP9650 V1 Manuel utilisateur

Draytek

Draytek VIGORAP 902 Manuel utilisateur
