Cisco Catalyst IW9165D Manuel

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation

Guide

First Published: 2023-11-01

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Preface vii

PREFACE

About this Guide vii

Conventions vii

Related Documentation viii

Communications, Services, and Additional Information viii

Cisco Bug Search Tool viii

Documentation Feedback viii

About Cisco Catalyst IW9165D Heavy Duty Access Point 1

CHAPTER 1

Introduction to Cisco Catalyst IW9165D Heavy Duty Access Point 1

Cisco Catalyst IW9165D Heavy Duty Access Point Features 1

Connectors and Ports 2

4-Pin Micro-Fit Connector for DC Power 4

M12-RJ45 Adapter 5

M12-PWR Adapter 6

Power Sources 7

Power Adapters 7

Power Injectors 7

Ethernet (PoE) Ports 8

Antennas and Radios 8

Supported External Antennas 8

IW9165D (Internal Antenna) Radiation Patterns 10

Unpacking Your Access Point 13

CHAPTER 2

Package Contents 13

Unpacking the Access Point 13

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

iii

Cisco Orderable Accessories 13

Installation Overview 17

CHAPTER 3

Preinstallation Checks and Installation Guidelines 17

Mounting the Access Point 18

Wall Mounting the Access Point with the Fixed Mounting Kit 19

Pole Mounting the Access Point with the Tiltable Mounting Kit 22

Installing a Lightning Arrestor 24

Lightning Arrestor Installation Notes 25

Grounding the Access Point 26

Powering the Access Point 28

Power Feature Matrix 28

Connecting a Power Injector 28

Connecting to the DC Power Port Using Cable Gland 29

Connecting DC Power Port Using M12 Adapter 30

Connecting an Ethernet Cable to the Access Point 32

Connecting to the RJ-45 Port Using Cable Gland 32

Connecting to the RJ-45 Port Using M12 Adapter 34

Troubleshooting 37

CHAPTER 4

Checking the Access Point LEDs 37

Using the Reset Button 38

Safety Guidelines and Warnings 39

CHAPTER 5

Safety Instructions 39

FCC Safety Compliance Statement 40

Safety Precautions 40

Safety Precautions when Installing Antennas 41

Avoiding Damage to Radios in a Testing Environment 41

Performing Site Surveys 42

Declarations of Conformity and Regulatory Information 45

CHAPTER 6

Manufacturers Federal Communications Commission Declaration of Conformity Statement 45

Operation of Cisco Catalyst Access Points in México 46

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

Contents

VCCI Statement for Japan 46

Statement 191—Voluntary Control Council for Interference (VCCI) Class A Warning for Japan 46

ステートメント 191—日本向けVCCI クラス Aに関する警告 47

Guidelines for Operating Cisco Catalyst Access Points in Japan 47

Compliance Statement for Canada 48

Industry Canada 48

European Community, Switzerland, Norway, Iceland, and Liechtenstein 49

United Kingdom Compliance 49

Declaration of Conformity for RF Exposure 50

Generic Discussion on RF Exposure 50

This Device Meets International Guidelines for Exposure to Radio Waves 50

This Device Meets FCC Guidelines for Exposure to Radio Waves 51

This Device Meets the Industry Canada Guidelines for Exposure to Radio Waves 51

Cet appareil est conforme aux directives internationales en matière d'exposition aux fréquences

radioélectriques 52

Additional Information on RF Exposure 52

Declaration of Conformity Statements 52

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

Contents

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

Contents

Preface

This preface describes this guide and provides information about the conventions used in this guide, and

Related Documentation

CHAPTER 1

About Cisco Catalyst IW9165D Heavy Duty

Access Point

•Introduction to Cisco Catalyst IW9165D Heavy Duty Access Point, on page 1

•Cisco Catalyst IW9165D Heavy Duty Access Point Features, on page 1

•Connectors and Ports, on page 2

•Power Sources, on page 7

•Antennas and Radios, on page 8

Introduction to Cisco Catalyst IW9165D Heavy Duty Access Point

The Cisco Catalyst IW9165D Heavy Duty Access Point (hereafter referred to as IW9165D) is designed to

make wireless backhaul deployment simple. It comes with a built-in directional antenna that enables long-range,

high-throughput connectivity anywhere fiber is not an option, so you can create a fixed wireless infrastructure

(point-to-point, point-to-multipoint, and mesh) as well as backhaul traffic from mobile devices along wayside

or trackside deployments. The external antenna ports let you quickly extend your network to new places when

needed and choose the right antenna based on the use cases and deployment architectures. With heavy-duty

IP67 design, the IW9165D is certified to operate under wet, dusty, and extreme temperature conditions.

The IW9165D runs Cisco Ultra-Reliable Wireless Backhaul (Cisco URWB), which delivers high availability,

low latency, and zero packet loss with seamless handoffs. Cisco URWB is ideal for connecting moving assets

or extending your network where running fiber isn’t feasible or affordable.

A full listing of the AP's features and specifications is provided in the Cisco Catalyst IW9165 Series Data

Sheet.

Cisco Catalyst IW9165D Heavy Duty Access Point Features

The Cisco Catalyst IW9165D Heavy Duty Access Point has the following features:

• 1x 100M/1000M/2.5G Multigigabit Ethernet (RJ45)/M12 X-code autosensing PoE+ in (802.3af/at),

Cisco UPOE in

• 1x 100M/1000M/1G (RJ45)

• Dual-radio architecture

• 5-GHz 2x2 radio: 20, 40, and 80 MHz channels

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

• 5/6-GHz 2x2 radio: 20, 40, 80, and 160 MHz channels (6 GHz availability subject to country

approvals)

• External antenna—2 x N-type

• Integrated antenna—Built-in directional antennas

• Peak gain 15 dBi, internal antenna, dual polarization, azimuth beamwidth 30 deg, elevation

beamwidth 30 deg, frequency: 4900 to 5925 MHz

• BLE antenna gain: 5.5 dBi max, internal antenna, linear polarization, omnidirectional

• 1x TNC GNSS antenna port

• Management console port (RJ45)

• Dual power input—PoE-in 802.3af, 802.3at (PoE+), and 24-48VDC

• Dual mounting options—Pole and wall mount

• IP67, heavy-duty design

• Multicolor system LED

• Reset button

Connectors and Ports

The following figures show the available ports on the AP.

Figure 1: IW9165D Right-Side Connectors and Ports

Console port (RJ-45) and reset button2Ground connection point1

Cisco Catalyst IW9165D Heavy Duty Access Point Hardware Installation Guide

About Cisco Catalyst IW9165D Heavy Duty Access Point

Connectors and Ports
