Data Sheet

Cisco SR216 16-Port 10/100 Rack-Mountable Switch

Cisco Small Business Unmanaged Switches

High-Speed 10/100 Switching for Rack-Mount or Desktop Installations

Highlights

●Connect up to 16 devices - PCs, printers, wireless access points, servers - with

autosensing 10/100 ports

●Designed for small businesses that require speed, reliablity, and simple management

●Works right out of the box with no software to configure

●Suitable for both desktop and rack-mount installation

Figure 1. Cisco SR216 16-Port 10/100 Rack-Mountable Switch

Product Overview

With its advanced switching technology, the Cisco®SR216 16-Port 10/100 Rack-Mountable Switch

(Figure 1) will boost your network performance with much more than just full-duplex data transfer

and dedicated bandwidth. It features nonblocking, wire-speed switching that forwards packets as

fast as your network can deliver them. Also included are Address Learning and Aging to prevent

data transfer errors and Data Flow Control to help prevent packet collisions.

You have several installation options. The compact switch fits onto your desktop, or uses the wall-

mount slots to hang it somewhere out of the way. If your network equipment is in a rack, install it

using the included rack-mount brackets.

No matter how intensive your network demands, the Cisco SR216 switch has speed, flexibility, and

reliability that you can count on.

Features

●Ideal for integrating your 10BASE-T and 100BASE-TX network hardware

●Sixteen 10/100 ports provide dedicated bandwidth in half- or full-duplex mode

●Switched 10/100 ports run at up to 200 Mbps in full-duplex mode

●Each port supports automatic medium dependent interface (MDI) and MDI crossover (MDI-

X) cable detection

●Compatible with all major network operating systems

Data Sheet

●Advanced store-and-forward packet switching optimizes data transfers

●Auto partitioning protects PCs from downed network lines

Specifications

Table 1 gives the specifications and package contents for the Cisco SR216 16-Port 10/100 Rack-

Mountable Switch.

Table 1. Specifications for the Cisco SR216 16-Port 10/100 Rack-Mountable Switch

Specifications

Standards IEEE 802.3, IEEE 802.3u

Ports Sixteen 10/100 RJ-45

Cabling type Category 5 Ethernet or better

LED System, 1 through 16

Range 328 feet

Security features Security slot

Environmental

Dimensions

W x H x D 11 x 1.75 x 9.45 in.

(279 x 45 x 240 mm)

Unit weight 3.31 lb (1.5 kg)

Power Input 110V AC, internal 3.3V/3A

Certification FCC Class B, CE

Operating temperature 32º to 104ºF (0º to 40ºC)

Storage temperature -40º to 158ºF (-40º to 70ºC)

Operating humidity 20% to 95% noncondensing

Storage humidity 5% to 90% noncondensing

Package Contents

●Cisco SR216 16-Port 10/100 Rack-Mountable Switch

●AC power cord

●User guide

●Registration card

Product Warranty

Limited lifetime hardware warranty with return to factory replacement and 1-year limited warranty for fans and power supplies

Cisco Limited Lifetime Hardware Warranty LLW

Cisco Small Business products offer a limited lifetime hardware warranty with return to factory

replacement and a 1-year limited warranty for fans and power supplies. In addition, Cisco offers

software application updates for bug fixes and telephone technical support at no charge for the first

12 months following the date of purchase. To download software updates, go to:

http://www.cisco.com/go/smallbiz.

Product warranty terms and other information applicable to Cisco products are available at

http://www.cisco.com/go/warranty.

For More Information

For more information on Cisco Small Business products and solutions, visit:

http://www.cisco.com/smallbusiness.

Data Sheet

Printed in USA C78-500609-00 11/08
