This chapter provides an overview of the features of the Catalyst 4500 series

supervisor engines and switching modules. The information is presented in the

following major sections:

•Catalyst 4000 Series Switches, page 1-1

•Catalyst 4500 Series Switches, page 1-2

•Supervisor Engines, page 1-2

•Ethernet and Fast Ethernet Switching Modules, page 1-12

•Gigabit Ethernet Switching Modules, page 1-29

•Other Switching Modules, page 1-42

•Switching Module LEDs, page 1-43

•Hot-Swapping Feature, page 1-45

Catalyst 4000 Series Switches

The Catalyst 4000 series switches consist of the Catalyst 4003 switch and the

Catalyst 4006 switch. The switches are designed for high-performance,

high-density wiring closet applications. A detailed overview of these switches is

in the Catalyst 4000 Series Installation Guide.

Chapter 1 Module Overview and Specifications

Catalyst 4500 Series Switches

1-2

Catalyst 4500 Series Module Installation Guide

78-13267-06

Catalyst 4500 Series Switches

The Catalyst 4500 series switches consist of the Catalyst 4503 switch, the

Catalyst 4506 switch, the Catalyst 4507R switch, and the Catalyst 4510R switch.

The switches are designed for high-performance, high-density wiring closet

applications. A detailed overview of these switches is in the Catalyst 4500 Series

Installation Guide.

Supervisor Engines

These sections describe the supervisor engines available for the Catalyst 4500

series switches:

•Supervisor Engine I (WS-X4012), which is used in the Catalyst 4003 switch

(Figure 1-1)

•Supervisor Engine II (WS-X4013, which is used in the Catalyst 4006, 4503,

and 4506 switches (Figure 1-2)

•Supervisor Engine II-Plus (WS-X4013+), which is used in the Catalyst 4006,

4503, 4506, and 4507R switches (Figure 1-3)

•Supervisor Engine II-Plus TS (WS-X4013+TS), which is used in Catalyst

4503 switches only (Figure 1-4)

•Supervisor Engine II-Plus 10GE (WS-X4013+10GE), which is used in

Catalyst 4503, 4506, and 4507R switches (Figure 1-5)

•Supervisor Engine III (WS-X4014), which is used in the Catalyst 4006, 4503,

and 4506 switches (Figure 1-6)

•Supervisor Engine IV (WS-X4515), which is used in the Catalyst 4006, 4503,

4506, and 4507R switches (Figure 1-7 )

•Supervisor Engine V (WS-X4516), which is used in the Catalyst 4006, 4503,

4506, 4507R, and 4510R switches (Figure 1-8)

•Supervisor Engine V-10GE (WS-X4516-10GE), which is used in the

Catalyst 4503, 4506, 4507R, and 4510R switches (Figure 1-9)

On the Catalyst 4006, 4503, and 4506 switches, you can install the Supervisor

Engine in slot 1 only. On the Catalyst 4507R or 4510R switch, you install the

primary supervisor engine in slot 1, and you can install an optional redundant

supervisor engine in slot 2.

1-3

Catalyst 4500 Series Module Installation Guide

78-13267-06

Chapter 1 Module Overview and Specifications

Supervisor Engines

The supervisor engines have the following features:

•Data path and control for all network interfaces

•Management functions:

–

Interface monitoring

–

Environmental status

–

SNMP and console/Telnet interface

•Hot-swapping

Note Packets are not forwarded while the module is removed. A system

reboot occurs when a supervisor engine is reinserted.

•The Supervisor Engine II-Plus TS provides 12 nonblocking

10/100/1000BASE-T (RJ-45) ports and 8 1000BASE-X (SFP) ports.

•The Supervisor Engine II-Plus 10GE and Supervisor Engine V-10GE provide

2 nonblocking 10GBASE uplink ports.

•The Supervisor Engine II-Plus 10GE and Supervisor Engine V-10GE provide

4 1000BASE-X (SFP) ports.

•The Supervisor Engine IV and V support the Catalyst 4500 series NetFlow

Services Card (WS-F4531). NetFlow is integral to the Supervisor Engine

V-10 GE.

To install a supervisor engine, follow the procedure in the “Installing the

Modules” section on page 3-2.

The supervisor engines used in Catalyst 4000 and Catalyst 4500 switches are

shown in Figure 1-1 to Figure 1-8.

Chapter 1 Module Overview and Specifications

Supervisor Engines

1-4

Catalyst 4500 Series Module Installation Guide

78-13267-06

Figure 1-1 Supervisor Engine I (WS-X4012)

Figure 1-2 Supervisor Engine II (WS-X4013)

16671

100%

Switch load

indicators

STATUS LED

Ethernet

management

port

Console

port

Reset

button

UPLINKU

PLINK

2UPLINKSENABLED

CONSOLE

RESET

10/100

BASE-TX

STATUS

1% 100%

28844

STATUS LED Reset button

Gigabit uplink

ports

Switch load

indicators

Console

port

Ethernet

management port

1-5

Catalyst 4500 Series Module Installation Guide

78-13267-06

Chapter 1 Module Overview and Specifications

Supervisor Engines

Figure 1-3 Supervisor Engine II-Plus (WS-X4013+)

Figure 1-4 Supervisor Engine II-Plus TS (WS-X4013+TS)

UPLINK1UPLINK 2

ACTIVE

LINEACTIVELINEACTIVE

RESET

UTILIZATION

STATUS

WS-X4515 SUPERVISORENGINE IV

1% 100%

CONSOLE

LINK

EJECT

FLASH

10/100

MGT

78480

STATUS LED Reset button

Gigabit uplink

ports

Switch load

indicators

Console port

(RJ-45)

Ethernet

management port

CompactFlash port

113860

STATUS LED

RESET button

Switch load

indicators

CONSOLE

port

Ethernet

management port

Compact Flash port

PoE status

LED

Chapter 1 Module Overview and Specifications

Supervisor Engines

1-6

Catalyst 4500 Series Module Installation Guide

78-13267-06

Figure 1-5 Supervisor Engine II-Plus 10GE (WS-X4013+10GE)

Figure 1-6 Supervisor Engine III (WS-X4014)

120474

STATUS LED

RESET

button

10 GE uplink

ports

Gigabit SFP

ports

Switch load

indicators

CONSOLE port

Ethernet

management port

Compact

Flash

port

78479

STATUS LED RESET button

Gigabit uplink ports

Switch load indicators

CONSOLE port

(RJ-45)

Management port

CompactFlash port

UPLINK1

LINKACTIVELINKACTIVE

UPLINK2

CONSOLE 10/100 MGT

EJECT

FLASH

UTILIZATION

STATUS

SUPERVISORIII ENGINE

WS-X4014

1%100%

RESET

1-7

Catalyst 4500 Series Module Installation Guide

78-13267-06

Chapter 1 Module Overview and Specifications

Supervisor Engines

Figure 1-7 Supervisor Engine IV (WS-X4515)

Figure 1-8 Supervisor Engine V (WS-X4516)

UPLINK1UPLINK 2

ACTIVE

LINEACTIVELINEACTIVE

RESET

UTILIZATION

STATUS

WS-X4515 SUPERVISORENGINE IV

1% 100%

CONSOLE

LINK

EJECT

FLASH

10/100

MGT

78480

STATUS LED Reset button

Gigabit uplink

ports

Switch load

indicators

Console port

(RJ-45)

Ethernet

management port

CompactFlash port

UPLINK1UPLINK2

ACTIVE

LINEACTIVELINEACTIVE

RESET

UTILIZATION

STATUS

WS-X4515 SUPERVISORENGINEIV

1% 100%

CONSOLE

LINK

EJECT

FLASH

10/100

MGT

78480

STATUS LED Reset button

Gigabit uplink

ports

Switch load

indicators

Console port

(RJ-45)

Ethernet

management port

CompactFlash port

Chapter 1 Module Overview and Specifications

Supervisor Engines

1-8

Catalyst 4500 Series Module Installation Guide

78-13267-06

Figure 1-9 Supervisor Engine V-10GE (WS-X4516-10GE)

Front-Panel Components

The following connectors, LEDs, and buttons are located on the front panel of the

supervisor engine:

•The STATUS LED, which indicates the operating state of the module

•Two Gigabit uplink ports (WS-X4013, WS-X4013+, WS-X4014, and

WS-X4515 supervisor engines only)

•Four SFP Gigabit uplinks ports and 2 10-Gigabit uplink ports on

WS-X4013+10GE and WS-X4016-10GE.

•Eight unmarked switch load indicator LEDs, which provide an approximation

of the current traffic across the backplane

•A console port (DB-25 for the WS-X4012; RJ-45 for the WS-X4013,

WS-X4013+, WS-X4013+ TS, WS-X4013+10GE, WS-X4014, WS-X4515,

WS-X4516, and WS-X4516-10GE supervisor engines)

•An Ethernet management port (RJ-45)

•A link status LED, which provides status for the management port

(10BASE-T on the WS-X4012 and 10/100BASE-T on the WS-X4013,

WS-X4013+, WS-X4013+ TS, WS-X4013+10GE, WS-X4014, WS-X4515,

WS-X4516, and WS-X4516-10GE supervisor engines)

120474

STATUS LED

RESET

button

10 GE uplink

ports

Gigabit SFP

ports

Switch load

indicators

CONSOLE port

Ethernet

management port

Compact

Flash

port

1-9

Catalyst 4500 Series Module Installation Guide

78-13267-06

Chapter 1 Module Overview and Specifications

Supervisor Engines

•The Reset button (recessed), which allows you to reset the system

•The CompactFlash port and eject button (WS-X4013+, WS-X4013+ TS,

WS-X4013+10GE, WS-4014, WS-X4515, WS-X4516, and

WS-X4516-10GE supervisor engines only) (refer to Using the Compact

Flash on the Catalyst 4000 Family Supervisor Engine III and IV.)

Table 1-1 describes the supervisor engine LEDs.

Table 1-1 Supervisor Engine LEDs

LED Color/State Description

STATUS Indicates the results of a series of self-tests.

Green All diagnostic tests passed.

Red A test failed.

Orange System boot or diagnostic test is in

progress.

Off Module is disabled.

UTILIZATION Green 1–100% If the switch is operational, this display

indicates the current traffic load over the

backplane (as an approximate percentage).

LINK Indicates the status of the 10/100BASE-T

Ethernet management port or uplink ports.

Green The link is operational.

Orange The link is disabled by user.

Flashing orange The power-on self-test indicates a faulty

port.

Off No signal is detected or there is a link

configuration failure.

ACTIVE Indicates whether the uplink port is active

or not.

Green The port is active.

Off The port is not active.

Chapter 1 Module Overview and Specifications

Supervisor Engines

1-10

Catalyst 4500 Series Module Installation Guide

78-13267-06

Ethernet Management Port

The WS-X4012 supervisor engine has a 10BASE-T Ethernet management port.

The WS-X4516-10GE and WS-X4013+10GE supervisor engine modules have a

10/100/1000BASE-T Ethernet management port.The other supervisor engine

modules have a 10/100BASE-T Ethernet management port. Supervisor engines

use an RJ-45 connector on the front panel with a link status LED. For the location

of the port, see Figure 1-1 (WS-X4012), Figure 1-2 (WS-X4013), Figure 1-3

(WS-X4013+), Figure 1-4 (WS-X4013+TS), Figure 1-5 (WS-X4013+10GE),

Figure 1-6 (WS-X4014), Figure 1-7 (WS-X4515), Figure 1-8 (WS-X4516), or

Figure 1-9 (WS-X4516-10GE).

TCP/IP-based management services available through inband access also are

provided through this port (Telnet and SNMP). This management port also

supports image download.

Note The 10BASE-T and 10/100BASE-T Ethernet management ports are for network

management only. These ports do not support network switching.

Console Port

The console port allows you to perform the following functions:

•Configure the switch from the CLI

•Monitor network statistics and errors

•Configure SNMP agent parameters

•Download software updates to the switch or distribute software images

residing in Flash memory to attached devices

The Catalyst 4003 console port is a DCE DB-25 receptacle, which supports a

DCE EIA/TIA-232 interface. The console port is an RJ-45 receptacle on the

Catalyst 4006, 4503, 4506, and 4507.

Note EIA/TIA-232 was known as recommended standard RS-232 before its acceptance

as a standard by the Electronic Industries Association (EIA) and

Telecommunications Industry Association (TIA).

Autres manuels pour Catalyst 4500 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Changer

Cisco

Cisco 4900M - Catalyst Switch Manuel utilisateur

Cisco

Cisco SG350X Series Instructions d'utilisation

Cisco

Cisco ME 6500 Manuel utilisateur

Cisco

Cisco WS-C2950T-48-SI Manuel

Cisco

Cisco SD208P Manuel utilisateur

Cisco

Cisco AJ732A - MDS 9134 Fabric Switch Mode d’emploi

Cisco

Cisco AMP8050 Manuel

Cisco

Cisco WLC 5700 Series Manuel d'installation

Cisco

Cisco AJ732A - MDS 9134 Fabric Switch Mode d’emploi

Cisco

Cisco Catalyst 2960 Series Manuel utilisateur

Cisco

Cisco WS-C6509 Manuel utilisateur

Cisco

Cisco SLM248P Manuel utilisateur

Cisco

Cisco NMH Series Manuel utilisateur

Cisco

Cisco WS-X6066-SLB-APC - Content Switching Module Guide de démarrage rapide

Cisco

Cisco WS-C4003 - Catalyst 4000 Chassis Switch Manuel utilisateur

Cisco

Cisco Nexus 6000 Manuel utilisateur

Cisco

Cisco Catalyst 4500 Series Manuel utilisateur

Cisco

Cisco NM-16ESW - EtherSwitch Switch Manuel utilisateur

Cisco

Cisco SPS208G Manuel utilisateur

Cisco

Cisco MDS 9396T Manuel

Cisco

Cisco 3750 - Catalyst EMI Switch Manuel

Cisco

Cisco 4503 - Catalyst Switch Instructions d'utilisation et d'installation

Cisco

Cisco Laserjet,Color Laserjet 3020 Instructions d'utilisation

Cisco

Cisco Catalyst 2960-L Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
