USER GUIDE

BUSINESS SERIES

24-Port 10/100/1000

Gigabit Switch

Model: SR2024

24-Port 10/100/100 Gigabit Switch

About This User Guide

Icon Descriptions

While reading through the User Guide, you may encounter various icons

designed to call attention to a specific item. Below are descriptions of

these icons:

NOTE: This check mark indicates that there is a note of interest

and is something that you should pay special attention to

while using the product.

WARNING: This exclamation point indicates that there is a

caution or warning and it is something that could damage

your property or product.

WEB: This globe icon indicates a noteworthy website address

or e-mail address.

Online Resources

Website addresses in this document are listed without http:// in front of

the address because most current web browsers do not require it. If you

use an older web browser, you may have to add http:// in front of the

web address.

Resource Website

Linksys www.linksys.com

Linksys International www.linksys.com/international

Glossary www.linksys.com/glossary

Network Security www.linksys.com/security

ii 24-Port 10/100/100 Gigabit Switch

About This User Guide

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

and product names are trademarks or registered

trademarks of their respective holders.

iii

24-Port 10/100/100 Gigabit Switch

Table of Contents

Chapter 1: Introduction 1

The 10/100/1000 Gigabit Switch . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Chapter 2: Product Overview 3

Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Chapter 3: Installation 5

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Pre-Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . 6

Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Appendix A: Specifications 11

Appendix B: Warranty and Regulatory Information 13

Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Exclusions and Limitations. . . . . . . . . . . . . . . . . . . . . . . . . 13

Obtaining Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . 15

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Appendix C: Regulatory Information 17

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . 18

Avis d’ Industrie Canada . . . . . . . . . . . . . . . . . . . . . . . . . . 18

User Information for Consumer Products Covered by EU Directive

2002/96/EC on Waste Electric and Electronic Equipment (WEEE) 19

Appendix D: Contact Information 27

iv 24-Port 10/100/100 Gigabit Switch

Table of Contents

24-Port 10/100/100 Gigabit Switch

Chapter 1: Introduction

Chapter 1:

Introduction

The 10/100/1000 Gigabit Switch

The 24-Port 10/100/1000 Gigabit Switch provides non-blocking,

wirespeed switching for your 10, 100, and 1000 megabit network

clients. Drop this Switch in place of your current workgroup hub or

switch, and you can upgrade your high-requirement workstations to full

Gigabit speeds as necessary, while continuing to service other clients at

their current speeds. Or build your network from the ground up, with

appropriate link speeds for each user’s requirements.

Either way, it’s perfect for graphics, multimedia, and other applications

that have to move large files across the network quickly. And with the

24-Port 10/100/1000 Gigabit Switch, when you need to expand your

network even further, its two MiniGBIC ports let you add fiber-optic

capability easily and cost effectively.

With the 24-Port 10/100/1000 Gigabit Switch, you can connect your

existing 10/100 Ethernet network to a Gigabit server backbone without

any additional equipment. All ports have automatic MDI/MDI-X crossover

detection, so you don’t have to worry about the cable type. Each port

independently and automatically negotiates speed and duplex mode.

Address learning and aging is supported, as well as 802.3x flow control

with head-of-line blocking prevention to keep your high-speed clients

from bogging down in lower-speed traffic. Fast store-and-forward

switching prevents damaged packets from being passed on into the

network. World famous Linksys reliability and the limited lifetime

warranty give you peace of mind and the rackmount form factor

integrates smoothly into your network infrastructure. Let the Linksys 24-

Port 10/100/1000 Gigabit Switch kick your network into high gear.

224-Port 10/100/100 Gigabit Switch

Chapter 1: Introduction

Features

24 RJ-45 ports for 10BASE-T/100BASE-TX/1000BASE-TX connections

Supports half duplex and full duplex modes

Autonegotiation support on all ports

Auto MDI/MDI-X support on all ports for easy cable detection

Efficient MAC Address learning engine supports up to 32K MAC

Addresses

Provides store-and-forward forwarding scheme

Fits in standard 19-inch rack using included rack-mount kit

Two miniGBIC ports for easy expansion to other miniGBIC equipped

switches

•

Chapter 2: Product Overview

24-Port 10/100/100 Gigabit Switch

Chapter 2:

Product Overview

Front Panel

The LEDs and ports are located on the front panel of the Switch.

SR2024 24-Port 10/100/1000 Gigabit Switch

Link/Act

SYSTEM

Gigabit

miniGBIC2

miniGBIC1

Link/Act

Gigabit

(Shared with 24)(Shared with 12)

Front Panel

LEDs

System (Green) The System LED will light up when the

Switch is powered on.

Link/Act (Green) Each LED will light up when there is a

connection made through its corresponding port. It will flash

when there is activity on its corresponding port.

Gigabit (Amber) Each LED will light up when there is a Gigabit

connection made through its corresponding port. It will flash

when there is activity on its corresponding port.

Ports

1-24 The Switch is equipped with 24 auto-sensing RJ-45

ports. These RJ-45 ports support network speeds of either

10Mbps, 100Mbps, or 1000Mbps and can operate in half

and full-duplex modes. Auto-sensing technology enables

each port to automatically detect the speed of the device

connected to it and adjust its speed and duplex accordingly.

To connect a device to a port, you will need to use a network

cable. You will need to use Category 5 (or better) cables.

Chapter 2: Product Overview

424-Port 10/100/100 Gigabit Switch

MiniGBIC (1-2) The Switch is equipped with two miniGBIC

ports. These ports provide links to high-speed network

segments or individual workstations at speeds of up to

1000Mbps (Gigabit Ethernet). These ports are shared. If you

use the MiniGBIC1 port, then you cannot use port 12. If

you use the MiniGBIC2 port, then you cannot use port 24.

Back Panel

The power port is located on the back panel of the Switch.

Back Panel

(power) The power port is where you will connect the

included power cord.
