Cisco CIVS-IPC-5010 Manuel utilisateur

CHAPTER

1-1

Cisco Video Surveillance 5010/5011 Indoor Fixed HD IP Dome Camera User Guide

OL-22669-02

Introduction

The 5010/5011 cameras are fixed network dome cameras with a built-in Web-based viewer for live

streaming to a standard Web browser (Microsoft Internet Explorer 8).

The cameras support standard H.264 and MJPEG compression formats and dual video streams that can

be configured for a variety of resolutions, frame rates, and bit rates.

Each camera also includes a 2.8 - 8mm Varifocal Megapixel lens, a ready-to-install indoor enclosure,

and a mechanical IR cut filter for increased low-light sensitivity. Additional lenses are available, and the

cameras accept a wide range of megapixel varifocal CS-mount lenses.

The cameras also include built-in Power over Ethernet (PoE), which supplies power to the camera

through the network. If PoE is not available, the camera is prewired for 24 VAC.

Models

Getting Started

Before installing your network camera, thoroughly familiarize yourself with the information in this

section of the manual.

Note • Do not use a network hub when configuring the network settings for the camera.

•To ensure secure access to the network camera, place the camera behind a firewall when it is

connected to a network.

CIVS-IPC-5010 Indoor fixed dome network camera, 2.1 megapixel, day/night, and a

2.8 ~ 8 mm varifocal megapixel lens. This camera has a clear dome.

CIVS-IPC-5011 Indoor fixed dome network camera, 2.1 megapixel, day/night, and a

2.8 ~ 8 mm varifocal megapixel lens. This camera has a smoked dome.

1-2

Cisco Video Surveillance 5010/5011 Indoor Fixed HD IP Dome Camera User Guide

OL-22669-02

Chapter 1 Introduction

Product Overview

Parts List

Remove all of the contents from the shipping box.

Product Overview

Figure 1-1 Camera Connections and Features (Side View)

Qty Description

1 Back box with camera module

1 Surface mount

1 Lower dome (includes trim ring and bubble)

1 Dome liner

1 4-pin connector

1 2-pin connector

1 Quick Start Guide

1Relay and Alarm Connections: One relay that can be used to control an external circuit, and

one alarm for physical input into the system.

2Accessory Port: For use with compatible accessories.

3RJ-45 Network Port: Connects the camera to the IP network. Also supplies power to the

camera through the network using PoE. If PoE is not available, the camera is prewired for 24

VAC .

424 VAC Power Connections: Supports 24 VAC as the power source if PoE is not used.

1 2 3 4

278770

1-3

Cisco Video Surveillance 5010/5011 Indoor Fixed HD IP Dome Camera User Guide

OL-22669-02

Chapter 1 Introduction

Product Overview

Figure 1-2 Camera Connections and Features (Top View)

1Reset Button: Reboots the camera or restores the camera’s factory default settings. This

button is recessed. Using a small tool, such as a paper clip, press and release the reset button

once to reboot the camera. Press and hold the reset button for 10 seconds to restore the camera

to the factory default settings.

2Micro SD Card Slot: Saves a snapshot image to a micro SD card based on alarm activity.

3Power LED: Glows solid green to indicate that the camera has power and flashes green during

the boot cycle. The LED can be disabled through the user interface. If this LED glows red

(solid or flashing), contact Cisco support for assistance.

4Lens Mount: Fits a standard CS-mount lens. Use a megapixel lens with the 5010/5011

cameras. A standard definition lens installed on a megapixel camera will limit the resolution

of the camera and create poor image quality.

5Auto Iris Lens Connector: Controls the auto iris lens. Insert the 4-pin connector from the DC

drive auto iris lens into this connector.

6NTSC/PAL Button: Toggles the service connector between NTSC and PAL formats. The

default setting is NTSC.

7Service Port: Outputs analog video. Use this port at the installation site to set up the field of

view and to focus the camera. When a service cable is connected to the camera, video to the

IP stream is disabled.

8Auto Back Focus Button: Sets the auto back focus mechanism. Press the button once to

center the auto back focus mechanism and to fully open the iris. Press and hold the button for

three seconds to start the auto back focus mechanism and focus the camera.

9Ethernet Activity/Link LED: Flashes green to indicate that data is being transmitted or

received by the camera. Glows solid amber to indicate that a live network connection is

established and then turns off after one minute of operation.

2 7

3 8 9

4 5 6

278771

1-4

Cisco Video Surveillance 5010/5011 Indoor Fixed HD IP Dome Camera User Guide

OL-22669-02

Chapter 1 Introduction

Product Overview

Product Label

The product label lists the model number, date code, serial number, and Media Access Control (MAC)

address. This information might be required for setup. The product label is located on the side of the

back box.
