Cisco NCS 1002 Mise à jour du firmware

System Setup and Software Installation Guide for Cisco NCS 1002

First Published: 2015-12-21

Last Modified: 2019-01-30

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS,

INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND,

EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.

THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH

THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY,

CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.

The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB's public domain version of

NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS" WITH ALL FAULTS.

CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.

IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT

LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS

HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display output, network

topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional

and coincidental.

All printed copies and duplicate soft copies of this document are considered uncontrolled. See the current online version for the latest version.

Cisco has more than 200 offices worldwide. Addresses and phone numbers are listed on the Cisco website at www.cisco.com/go/offices.

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com

go trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any

other company. (1721R)

CONTENTS

Cisco NCS 1002 Product Overview 1

CHAPTER 1

Command Modes 1

Bring-up Cisco NCS 1002 3

CHAPTER 2

Boot Sequence 3

Boot NCS 1002 4

Boot NCS 1002 Using USB Drive 4

Boot Using iPXE 7

Setup DHCP Server 7

Boot Using iPXE 8

Boot Using ZTP 9

Boot NCS 1002 Using Golden ISO 10

Verify Boot Operation 11

Access the System Admin Console 12

Configure Management Interface 12

Configure Telnet 14

Configure SSH 15

Perform Clock Synchronization with NTP Server 16

Perform Preliminary Checks 17

CHAPTER 3

Verify Status of Hardware Components 17

Verify Node Status 21

Verify Software Version 23

Verify Firmware Version 24

Verify Management Interface Status 27

Verify Alarms 29

System Setup and Software Installation Guide for Cisco NCS 1002

iii

Verify Environmental Parameters 30

Verify Inventory 33

Create User Profiles and Assign Privileges 37

CHAPTER 4

Create a User Profile 37

Create a User Group 39

Create Command Rules 40

Create Data Rules 43

Change Disaster-recovery Username and Password 45

Perform System Upgrade and Install Feature Packages 47

CHAPTER 5

Upgrade the System 48

Software Upgrade Matrix 48

Install Packages 48

Workflow for Install Process 49

Install Packages 49

(Optional) Install Prepared Packages 54

Uninstall Packages 56

Upgrading the Firmware Version of Power Modules 58

FPD Automatic Upgrade 60

System Setup and Software Installation Guide for Cisco NCS 1002

Contents

CHAPTER 1

Cisco NCS 1002 Product Overview

The Cisco Network Convergence System (NCS) 1002 is a 2 RU system that delivers fully programmable,

high-bandwidth capacity (up to 250 Gbps) wavelengths over distances exceeding 3000 km using existing

fiber. Powered by the industry-leading Cisco IOS XR operating system, Cisco NCS 1002 offers robust functions

such as third party application hosting, machine-to-machine interface, telemetry and flexible package delivery.

NCS 1002 delivers the following benefits:

• Supports up to 2 Tbps capacity

• Transports 100, 200, or 250Gbps per wavelength on the same platform through software provisioning

• Transports 10 GE, 40 GE, and 100 GE on the same platform through software provisioning

• Supports grid-less tuning for flex-grid dense wavelength-division multiplexing (DWDM)

• Supports different modulation formats (PM-QPSK or PM-16QAM)

• Supports 7% or 20% Soft Decision (SD) FEC for maximum optical performance

• Allows for automated installation, configuration and monitoring

• Supports machine-to-machine (M2M) APIs based on YANG models for ease of configuration

• Supports a telemetry agent for a pub-sub model of device monitoring

•Command Modes, on page 1

Command Modes

The Cisco NCS 1002 system runs on the Cisco IOS XR operating system. This table lists command modes.

DescriptionCommand Mode

Displays and monitors the operational state in XR mode.

Example:

RP/0/RP0/CPU0:ios#

XR execution mode

System Setup and Software Installation Guide for Cisco NCS 1002

DescriptionCommand Mode

Performs feature configurations.

Example:

RP/0/RP0/CPU0:ios# configure

RP/0/RP0/CPU0:ios(config)#

XR configuration mode

Displays and monitors the operational state in System Admin mode.

Example:

sysadmin-vm:0_RP0#

System Admin execution mode

System Setup and Software Installation Guide for Cisco NCS 1002

Cisco NCS 1002 Product Overview

Command Modes

CHAPTER 2

Bring-up Cisco NCS 1002

After installing the hardware, boot the Cisco NCS 1002 system. You can connect to the XR console port and

power on the system. NCS 1002 completes the boot process using the pre-installed operating system (OS)

image. If no image is available, NCS 1002 can be booted using the iPXE boot or an external bootable USB

drive.

After booting, create the root username and password, and then use it to log on to the XR console. From the

XR console, access the System Admin console to configure system administration settings.

•Boot Sequence, on page 3

•Boot NCS 1002, on page 4

•Boot NCS 1002 Using USB Drive, on page 4

•Boot Using iPXE, on page 7

•Boot Using ZTP, on page 9

•Boot NCS 1002 Using Golden ISO, on page 10

•Verify Boot Operation, on page 11

•Access the System Admin Console, on page 12

•Configure Management Interface, on page 12

•Configure Telnet, on page 14

•Configure SSH, on page 15

•Perform Clock Synchronization with NTP Server, on page 16

Boot Sequence

The boot sequence in NCS 1002 that you need to follow is:

1. Boot using SSD (hard disk)

2. Boot using USB drive

3. Boot using iPXE

If there is no bootable image in all three boot options, reboot the system.

System Setup and Software Installation Guide for Cisco NCS 1002

Boot NCS 1002

Use the console port to connect to NCS 1002. By default, the console port connects to the XR mode. If required,

subsequent connections can be established through the management port, after it is configured.

Procedure

Step 1 Connect a terminal to the console port of the RP.

Step 2 Start the terminal emulation program on your workstation.

The console settings are 115200 bps, 8 data bits, 2 stop bits and no parity.

Step 3 Power on the NCS 1002.

To turn on the power shelves, press the power switch up. As NCS 1002 boots up, the boot process details are

displayed at the console of the terminal emulation program.

Step 4 Press Enter.

The boot process is complete when the system prompts you to enter the root-system username. If the prompt

does not appear, wait for a while to give the NCS 1002 more time to complete the initial boot procedure; then

press Enter.

If the boot process fails, it may be because the pre-installed image on the NCS 1002 is corrupt. In

this case, the NCS 1002 can be booted using an external bootable USB drive.

Important

Boot NCS 1002 Using USB Drive

The bootable USB drive is used to re-image the NCS 1002 for the purpose of system upgrade or to boot the

NCS 1002 in case of boot failure. A bootable USB drive is created by copying a compressed boot file into a

USB drive. The USB drive becomes bootable after the contents of the compressed file are extracted.

This task can be completed using the Windows, Linux, or MAC operating systems available on your local

machine. The exact operation to be performed for each generic step outlined here depends on the operating

system in use.

Before you begin

• You need a USB drive with a storage capacity of at least 4 GB.

• NCS 1002 software image can be downloaded from this location.

• Copy the compressed boot file from the software download page at cisco.com to your local machine.

The file name for the compressed boot file is in the format ncs1k-usb-boot-<release_number>.zip. For

example, ncs1k-usb-boot-6.3.2.zip.

System Setup and Software Installation Guide for Cisco NCS 1002

Bring-up Cisco NCS 1002

Boot NCS 1002

Procedure

Step 1 Connect the USB drive to your local machine and format it with the FAT32 file system.

Step 2 Copy the compressed boot file to the USB drive.

Step 3 Verify that the copy operation is successful. To verify, compare the file size at source and destination. Also,

verify the MD5 checksum value.

Step 4 Extract the content of the compressed boot file by unzipping it in the USB drive. This makes the USB drive

a bootable drive.

The content of the zipped file ("EFI" and "boot" directories) must be extracted directly in the root

folder of the USB drive. If the unzipping application places the extracted files in a new folder, move

the "EFI" and "boot" directories to the root folder of the USB drive.

Note

Step 5 Insert the USB drive in one of the USB ports of NCS 1002.

Step 6 Reboot NCS 1002 using power cycle or console.

Step 7 Press Esc to enter BIOS.

Step 8 Select the Save & Exit tab of BIOS.

Step 9 Choose UEFI based USB device.

The system detects USB and boots the image from USB.

Admin Console:

GNU GRUB version 2.00

Press F2 to goto grub Menu..

Booting from USB..

Loading Kernel..

Validating End Entity Certificate...

Validating SubCA Certificate...

System Setup and Software Installation Guide for Cisco NCS 1002

Bring-up Cisco NCS 1002

Boot NCS 1002 Using USB Drive

Validating Root Certificate...

Loading initrd..

Validating End Entity Certificate...

Validating SubCA Certificate...

Validating Root Certificate...

CiscoSec: Image signature verification completed.

XR Console:

CiscoSec: Image signature verified.

[ 9.957281] i8042: No controller found

Starting udev

udevd[972]: failed to execute '/etc/udev/scripts/network.sh' '/etc/udev/scripts/network.sh':

No such file or directory

Populating dev cache

Running postinst /etc/rpm-postinsts/100-dnsmasq...

update-rc.d: /etc/init.d/run-postinsts exists during rc.d purge (continuing)

Removing any system startup links for run-postinsts ...

/etc/rcS.d/S99run-postinsts

Configuring network interfaces... done.

Step 10 Remove the USB drive. The NCS 1002 reboots automatically.

Setting maximal mount count to -1

Setting interval between checks to 0 seconds

Fri Dec 11 20:35:56 UTC 2015: Install EFI on /dev/mb_disk4

Fri Dec 11 20:35:57 UTC 2015: Install finished on mb_disk

Rebooting system after installation ...

[ 116.973666] reboot: Restarting system

BIOS Date: 11/29/2015 12:02:45 Ver: 0ACBZ1110

Press <DEL> or <ESC> to enter setup.

CiscoSec: Image signature verified.

GNU GRUB version 2.00

Press F2 to goto grub Menu..

Booting from Disk..

Loading Kernel..

Validating End Entity Certificate...

Validating SubCA Certificate...

Validating Root Certificate...

Loading initrd..

Validating End Entity Certificate...

Validating SubCA Certificate...

Validating Root Certificate...

CiscoSec: Image signature verification completed.

Initrd, addr=0xff69a000, size=0x955cb0

[ 1.745686] i8042: No controller found

System Setup and Software Installation Guide for Cisco NCS 1002

Bring-up Cisco NCS 1002

Boot NCS 1002 Using USB Drive

Autres manuels pour NCS 1002

Table des matières

Autres manuels Cisco Matériel réseau

Cisco

Cisco ONS 15600 Manuel utilisateur

Cisco

Cisco NCS 4016 Manuel utilisateur

Cisco

Cisco Meraki MX68 Manuel

Cisco

Cisco SCE 2000 4/8xFE Manuel de l'opérateur

Cisco

Cisco Firepower 4100 Series Manuel utilisateur

Cisco

Cisco S170 Web Manuel utilisateur

Cisco

Cisco 2600 Series Document technique

Cisco

Cisco Content Engine 510 Manuel utilisateur

Cisco

Cisco IDS 4210 - Intrusion Detection Sys 4210... Manuel utilisateur

Cisco

Cisco AIR-WLC2106-K9 - Wireless LAN Controller... Manuel utilisateur

Cisco

Cisco NCS 2000 series Manuel utilisateur

Cisco

Cisco Aironet 340 Series Manuel utilisateur

Cisco

Cisco Physical Access 1125 Appliance Manuel utilisateur

Cisco

Cisco ASR 9000 Series Manuel utilisateur

Cisco

Cisco IAD1101 Manuel utilisateur

Cisco

Cisco Nexus 93180LC-EX Manuel utilisateur

Cisco

Cisco 8540 - Catalyst Campus Switch Router Modular Expansion... Manuel utilisateur

Cisco

Cisco Catalyst 8300 Series Manuel

Cisco

Cisco ONS 15454 M12 Manuel utilisateur

Cisco

Cisco Octal-Port DMT ATU-C Line Card Manuel technique

Cisco

Cisco Fourth-Generation Versatile Interface Processor... Manuel de l'opérateur

Cisco

Cisco BR1400 Series Guide de référence rapide

Cisco

Cisco 2431 - IAD Router Manuel utilisateur

Cisco

Cisco ONS 15454 SDH E1-75 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
